Baumatic BR11.2A User Manual
BR11.2A
Built-under Fridge with Icebox
User Manual for your
BR11.2A
BUILT-UNDER FRIDGE
WITH ICEBOX
NOTE
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference.
: This User Instruction Manual contains important
DD 19/12/2006
CONTENTS
YOUR APPLIANCE’S SPECIFICATIONS …….…….3
SAFETY INFORMATION / ENVIRONMENTAL NOTE .. 4
USING YOUR FRIDGE……………….……………..………5-12
YOUR BR11.2A FRIDGE …………………….………………….5
BEFORE USING YOUR FRIDGE…………….……………….…6
USING YOUR FRIDGE…………………………………….…7-10
CLEANING AND MAINTENANCE……….………………11-12
DEFROSTING ………………………………..……………………13
TIPS FOR SAVING ENERGY …………………………………14
INSTALLING YOUR FRIDGE……………………………...….15
FITTING THE DÉCOR DOOR ………………………………...18
LEVELLING YOUR FRIDGE TO YOUR FLOOR ………..…19
HOW TO REVERSE THE DOOR SWING ……………………20
HOW TO REVERSE THE SWING OF YOUR
ICE
BOX
DOOR ……………………………………………………………….21
TROUBLESHOOTING ………………………………….……22
CONDITIONS OF GUARANTEE……………………….………23
CONTACT DETAILS……………………………………………..24
Specifications of your BR11.2A Built-under fridge with Icebox
Congratulations on purchasing a Baumatic
BR11.2A Built-under Fridge with icebox!
Your Fridge has:
 Gross capacity: 130 litres
 Net capacity (fridge/ freezer): 105/21 litres
 Energy efficiency class: A
 Star rating: ****
 Adjustable Thermostat
 Automatic Fridge Defrost
 Ice box
 2 Safety glass shelves
 Egg rack
 Salad crisper
 Reversible door
 Adjustable feet
Dimensions mm (H x W x D)
818-898 x 596 x 545
To fully enjoy using your appliance long into the future,
please firstly familiarise yourself with the specifications,
safety advice and operational instructions included in this
manual.
NOTE
When you install your Fridge, it is important to bear in mind its
climatic rating.
:
In order to find out the climatic rating of your appliance, check
the data rating tag inside your refrigerator. It indicates the
ambient temperature range within which your appliance will
function.
3
Important Safety Information: Please Read this before installing & using.
ELECTRICAL SAFETY
•
NOTE - This appliance must be grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance of
electrical current. You will be able to tell if it is because a non-grounded appliance will give off
an electrical discharge. Manufacturer declines all responsibility for any damage due to nongrounding of appliance.
• DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR AN AUTHORISED AGENT OF
BAUMATIC SHOULD CARRY OUT REPAIRS ON THIS UNIT.
• DO NOT USE IF THE SUPPLY CORD IS DAMAGED. NEVER TAKE RISKS WITH FIRE!
ENSURE YOU CONNECT THIS APPLIANCE TO A SUPPLY RATED AT 220-240V (or 200-230V) and 50HZ.
NOTE: the supporting structure is constructed in panels of treated sheet steel, electrostatically
enamelled to resist ill-treatment and to give long-lasting beauty and shine.
: Do not attempt to alter the specifications of
this appliance. Doing so could damage the
machine, cause injury & invalidate your
warranty. DO NOT USE ADAPTERS/SHUNTS.
: Do not allow children to play with, near or
inside this appliance.
: Never allow the back coils of the Appliance to
come into contact with any wall surface.
ALWAYS ENSURE THAT THE SPACE INTO
WHICH YOU ARE PLACING YOUR APPLIANCE IS
FREE OF STORED ITEMS SUCH AS PAPERS OR
OTHER FLAMMABLE MATERIALS.
: NEVER block the VENTILATION OPENINGS OF THE
: Do not pull on the power supply cable to
free the plug from the wall!
: Do not attempt to use your appliance
outdoors or any place where it is likely to
come into contact with the elements.
: Do not pull out or insert the plug with wet
hands.
: Before any cleaning or maintenance work,
ensure that the appliance has been
disconnected from the power supply.
PLEASE OBSERVE ALL INSTALLATION ADVICE IN THIS MANUAL FOR
SAFE USAGE OF YOUR APPLIANCE.
Note: Before discarding an old refrigerator/freezer, switch off and disconnect it
from the power supply. Cut off and render any plug useless. Ensure that the door
cannot jam (removing it is best), regardless of whether or not it can be pushed open
from inside. AN OLD FRIDGE/FREEZER CAN BE A DEADLY PLAYTHING FOR CHILDREN!
APPLIANCE EITHER INSIDE OR ON ITS EXTERIOR.
IT IS VITAL TO KEEP YOUR APPLIANCE WELL
VENTILATED SO THAT THERE IS PROPER AIR FLOW
BETWEEN THE BOTTOM OF THE UNIT AND THE
PLINTH / KICK PLATE ON WHICH IT IS SITTING.
: WARNING – DO NOT DAMAGE THE REFRIGERANT
CIRCUIT. AT THE END OF THE FUNCTIONAL LIFE
OF THE EQUIPMENT (WHICH USES COOLING GAS
R600o [ISOBUTANE]) AND INFLAMMABLE GAS
INSIDE THE INSULATING FOAM, IT MUST BE
PLACED IN SAFETY BEFORE SENDING IT FOR
PROPER WASTE DISPOSAL.
CONFORMITY TO W.E.E.E. DIRECTIVE
4
Using your Baumatic BR11.2A Built-under Fridge:
Your BR11.2A Built-under
Fridge with Icebox:
KEY
A
1 SHELF: The shelves may be
placed in any of the guide slots
within the interior of the
appliance. They are protected
from sliding out.
To remove a shelf
front of the shelf and carefully
pull it out of the grooves.
Quickly perishable food should be
stored at the back (the coldest
part of your refrigerator).
2 DEFROST WATER OUTLET
The interior of the fridge is cooled
with the cooling plate at the rear
wall. Beneath this, there is a
channel and an outlet for
defrosted water. It is important
5
, simply lift the
that this channel is never clogged.
Use a plastic straw to clear away
any dirt.
3 CRISPER TRAY & SERVING TRAY
The crisper tray at the bottom of
your refrigerator is covered by the
serving tray. This cover protects
fruit and vegetables stored within
from drying out.
Note that the door liner holds various
shelves containing holders for storing
eggs, cheese, butter and yoghourt, as
well as smaller packages, tubes, cans,
etc. The lower door shelf is used for
storing bottles.
B
ICE BOX
NOTE: BEFORE Using your BR11.2A FRIDGE:
UPON DELIVERY:
When your Fridge has been delivered, you will need to
wait approximately
12 hours
before turning it on. The fluid
of the compressor installed in the appliance will need
time to settle. PLEASE DO NOT PLUG IN ANY EARLIER
THAN THIS!
NOTE:
THERE CAN BE AN ODOUR WHEN
YOU FIRST SWITCH ON THE
APPLIANCE. IT WILL VANISH
WHEN THE UNIT STARTS
COOLING.
We recommend that you
have the Fridge delivered
near to where you plan to
install it so that this fluid
can settle.
SITUATING YOUR FRIDGE
CAUTION
AND FOLLOW THE INSTALLATION ADVICE SHOWN ON PAGE 16.
: DO NOT PLACE THE APPLIANCE NEAR HEAT SOURCES
FOR FULL INSTALLATION ADVICE, PLEASE SEE PAGE 16
MAKE A NOTE OF THE LOCATION FOR YOUR NEW FRIDGE. MAKE SURE THAT
IT WILL FIT PROPERLY SO THAT:
1) The doors can open freely and completely.
2) You can access your food conveniently.
3) There is sufficient space at the back for the cooling coils to
give off heat safely & that they do not touch the plug (see SAFETY
SECTION).
NOTE: You can reverse the swing of the door to customise the unit to
your location. Please see page 19 for details.
6
USING your Baumatic BR11.2A FRIDGE
YOU SWITCH ON YOUR APPLIANCE
by
PLUGGING IT IN &
SETTING THE
THERMOSTAT
inside the Fridge at
the upper righthand side:
Your Fridge’s thermostat automatically regulates the inside
temperature of the compartments. By rotating the thermostat knob
from a low to a higher number position, colder temperatures can be
obtained.
Refrigerator Thermostat setting
Note: Turning the knob setting towards 7 will make all
the compartments of your fridge colder. Because the
interior temperature may dip below 0
°C, you should not
leave your fridge on this setting for long periods.
Settings 3-5: Use these mid-settings for longer storage
of food in the fridge = mid-coldness. Settings below this
will give a milder coldness to the interior of the fridge.
0: This setting will make the fridge STOP (the cool
system is deactivated), although the light will still
function.
REMINDER:
On the maximum setting, your
fridge will work harder to maintain this low
temperature. So, after you reach this
temperature, you should turn the knob to a
milder setting (depending on long or shortterm storage intentions).
7
USING your Baumatic BR11.2A FRIDGE
Reminder: Allow the unit time to settle after
delivery. If your plug and power socket are now
behind the fridge and you still need to move the
unit into place, be especially careful. Remember
to leave a safe distance between the back of the
fridge and the wall or rear of the unit cabinet.
o You switch your fridge OFF by turning the
thermostat knob to position ‘0’.
NOTE: When you first switch on the appliance,
allow 24 hours for it to cool down to the desired
temperature. During this time, DO NOT open the
door often or place a lot of food inside the unit.
WARNING! If the appliance is switched off
then switched back on again after a short
period, the compressor will start up again
after approximately half-an-hour. This is
part of the normal operation of the appliance.
8
