BF337SS Frost free
fridge/freezer
s
USER MANUAL FOR YOUR BAUMATIC
BF337SS 337 Litre frost free stainless
steel combi fridge/freezer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
DD 30/01/07
2
Contents
Environmental note 4
Important safety information 5 – 6
Specifications of your fridge freezer 7
Dimensions of the appliance 7
Energy efficiency class 7
Cubic capacities 7
Specifications of your appliance 7
Description of the appliance 8
Description of the product features 9
Using your Baumatic fridge freezer 10
Before switching on 10
During first use 10
Control panel 11
Turning on the appliance and setting the thermostat 12
Selecting superfreeze mode 13
Selecting holiday mode 13
Arranging and storing food in the fridge section 14
The freezer compartment 15
Freezing fresh food 15
Tips on freezing 16
Making ice cubes 16
Important user information 17
Cleaning and maintenance 17-18
Defrosting the
Replacing the light bulb 19
Installation 20
Electrical connection 20
Positioning 21
Reversing the doors 22-24
Troubleshooting 25
Baumatic Ltd. conditions of guarantee 26
Contact details 27
freezer compartment 18-19
3
Environmental note
Note
: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
o The packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
o Please discard all packaging material with due regard for the
environment.
4
Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Baumatic Technical
Department.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.
Use of the appliance
o Your appliance is only designed to be used in the
home. It is suitable for storing food that needs to
be chilled and refrigerated. If it is used for any
other purpose or it is not used correctly, then
Baumatic Ltd. will accept no liability for any
damage that is caused.
o Altering the specification of the appliance must not be attempted
for reasons of safety.
Before using your appliance
o Check the appliance for any signs of transport damage. If you
notice any damage, then you should not connect your appliance
to your mains supply and should contact your retailer.
Refrigerant
o Your appliance contains R134a refrigerant, which is a natural gas
that does not contain CFCs that can damage the environment.
o Care should be taken during the transportation and installation
of the appliance to make sure that the refrigeration pipework
does not get damaged.
o Do not place any objects on top of the appliance, as
this may damage the table top.
5
Child safety
o Packaging material should be kept away from
children.
o Children should not be allowed to touch the
controls or play with the appliance.
General safety
o Do not pull on the power supply cable to remove the plug from
your mains supply socket.
o Do not pull out or insert the plug with wet hands.
o Do not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
o Before cleaning the appliance or performing
maintenance work, ensure that the appliance has been
disconnected from your mains supply.
o Never allow the back coils of the appliance to come into contact
with the wall surface.
o Always ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
o Never block the ventilation openings of the appliance, either on
the inside or its exterior.
o It is vital to keep your appliance well ventilated,
so that there is proper air flow between the
bottom of the unit and the plinth/kick plate
which it is sitting on.
o Do not place electrical devices inside of the appliance, such as
mixers or ice cream makers.
Service
You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Baumatic Service Department.
6
Specifications of your fridge freezer
Congratulations on purchasing a Baumatic fridge freezer
Dimensions of your appliance
o Height: 1869 mm
o Width: 600 mm
o Depth: 634 mm
Energy efficiency class
Energy class: A
Cubic capacities
o Gross capacity (fridge): 223 litres
o Gross capacity (freezer): 114 litres
o Net capacity (fridge): 208 litres
o Net capacity (freezer): 97 litres
Specifications of the appliance
o Frost free fridge and freezer
o Electronic control operation
o Fast freeze switch
o Mark resistant coating
o 3 Safety glass shelves
o 2 Salad crispers
o Butter compartment
o Bottle rack
o 3 General racks
o 3 Freezer drawers
o Reversible doors
IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.
In order to find out the climatic rating of your appliance, you should
check the rating plate. The rating plate is located on the front left edge
of the inside of the fridge section. You will need to open the door of
your appliance to be able to find it. The rating plate will indicate the
ambient temperature range that your appliance will function correctly
within.
7
Description of the appliance
1) Shelves 13) Refrigerator light
2) Salad crisper 14) Airflow duct vent
3) Salad drawers
4) Rating plate
5) Ice cube tray
6) Freezer drawers
7) Adjustable foot
8) Large bottle shelf
9) Small bottle shelf
10) Egg holder
11) Dairy compartment
12) Control panel
8
Description of the product features
1) Shelves
o The shelves may be placed in any of the guide slots within the
interior of the appliance. They are protected from sliding out.
o To remove a shelf: Take off all of the items that are stored on
the shelf that you want to remove. Then lift the front of the shelf
and carefully pull it out of the grooves.
2) Salad drawer and cover
o The salad drawers can be found in the bottom of your
refrigerator and there is a cover that goes over them.
o The cover helps to prevent fruit and vegetables from drying out
prematurely.
3) Upper door shelves
o The door liner holds various shelves, which are suitable for
storing eggs, cheese, butter and yogurt. As well as smaller
packages, tubes, cans etc.
4) Bottle shelf
o The lower shelf should be used for storing reasonably sized
bottles.
o IMPORTANT: NONE OF THE SHELVES THAT SIT IN THE
DOOR SHOULD BE OVERLOADED, AS THIS WILL
DRASTICALLY REDUCE THEIR WORKING LIFE.
5) Freezer compartment
o A freezer section, with a net capacity of 97 litres.
9
