Baumatic BDWI660 User Manual
BDWI660 60 cm Fully
integrated full height
dishwasher
USER MANUAL FOR YOUR BAUMATIC
BDWI660 60 cm Fully
integrated full height dishwasher
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 24/01/13
2
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 – 11
Product and aperture dimensions 8
Product specifications 8 – 9
Electrical details 9
Baumatic consumables 9
Description of the appliance 10
Control panel 11
Using your dishwasher 11 - 26
Before first use 11
Filling with dishwasher salt 11 – 12
Setting the water softener level 13
Filling with rinse aid 14
Setting the rinse aid level 15
Filling with dishwasher detergent 15 – 16
Concentrated detergent 16 – 17
Detergent tablets 17
Loading the upper basket 17
Adjusting the upper basket 18
Folding back the cup shelves 18
Loading the lower basket 19
Folding spikes of lower basket 20
The cutlery basket 20
Loading dishes and cutlery 21 - 22
Program table 22 - 23
Setting a wash program 23 – 24
Changing a wash program 24
Adding more dishes 24 - 25
At the end of a wash program 25
Delay start function 25 – 26
Alternative wash function 26
Saving energy using your dishwasher 27
Cleaning and maintenance 28 - 31
The filter system 28
Cleaning the filters 29
Cleaning the spray arms 30
Cleaning the control panel 30
Cleaning the door 31
Error code failure system 31 – 32
General troubleshooting 33 – 35
Installation 36 - 45
Aperture requirements 36 – 37
Installation stages 37
Preparing and connecting the furniture door 37 – 38
Adjusting the tension of the door spring 39
Connecting to the mains water supply 40
Connecting to the water outlet 40 - 41
Connecting to the power supply 41
Applying the condensation strip 42
Positioning the dishwasher 42 - 43
Levelling the appliance 43
Securing the dishwasher 44
Before first use 45
Baumatic consumables 46
Technical data 47
Contact details 48
3
ENVIRONMENTAL NOTE
Note
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
: Before discarding an old appliance, switch off and
o The packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
o Please discard all packaging material with due regard for the
environment.
4
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost inmportance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Safety
o Repairs to your appliance must only be carried out by a
Baumatic engineer or one of its authorised service agents. Any
attempt by an inexperienced person to repair the appliance,
could result in injury or damage to your dishwasher.
o If you notice that the mains cable is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
o The appliance should be turned off and isolated from the mains
supply, before either cleaning or maintenance work is attempted.
o The mains cable must not be used to pull the plug out of the
electrical socket.
o The machine should not be sprayed with water.
o The external surface of the appliance may become hot whilst
your dishwasher is in use.
o It is possible for small animals to chew either mains cables or
water hoses, which could cause an electric shock hazard.
Installation
o The installation instructions contained within this user manual
should be followed.
o It is obligatory for the completed installation to comply with all
relevant building regulations and local water authority
requirements.
o Before the first use of the appliance, you should follow the
steps listed in the “Before first use” section on page 11
and page 44 of this manual.
5
o Care should be taken not to trap the power supply cable
underneath the appliance whilst installing it.
o No attempt should be made to alter or modify the specifications
of this appliance.
In daily use
o This appliance is only designed to wash normal domestic
washloads. If you use your dishwasher in any other way or it is
incorrectly used, then Baumatic accepts no liability for any
damage that might be caused and any guarantee will be void.
o It is recommended that the appliance is unplugged and the
water supply is turned off after the machine is used.
o The detergents, rinse aid and salt that you place in this appliance
should be suitable for automatic dishwashers. With regards to
dosage levels, the detergent manufacturer’s recommendations
should be followed.
o Sharp knives or ones with long blades are a potential safety
hazard when placed in an upright position in the cutlery basket.
We would recommend that these items are placed horizontally in
the upper basket.
o You should not wash any items that have come into contact
with corrosive, acidic or alkaline chemicals, paint, petrol, iron or
steel debris.
o You should not open the door whilst the appliance is set on a
wash program. Depending on which stage that the wash
program is at, hot water could escape the machine.
o You should not leave the door of the appliance open, unless
you are loading or unloading the dishwasher.
o You should not stand or sit on the door when it is open.
Child Safety
o Your dishwasher should only be used by adults. You should not
allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
o It could be possible for a child or pet to gain access to the
dishwasher if the door is left open. Therefore please check the
inside of the appliance before setting it on a wash cycle.
6
o Any packaging that is removed from the machine should be kept
away from children.
o All detergents should be kept out of children’s reach in a safe
place.
o Some water will remain inside the dishwasher when it has
completed a wash cycle. This water is not suitable for drinking
and may contain residues from the detergents that are used in
the appliance.
Declaration of conformity
This appliance complues with the following European Directives:
- 73/23 dated 19/02/1973 Low Voltage Directive and subsequent
modifications.
- 89/336 dated 03/05/1989 Electromagnetic Compatibility
Directive and subsequent modifications.
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate of your dishwasher is
located on the right hand side of the drop down door.
Model Number …………………………………….
Serial Number …………………………………….
Date of Purchase …………………………………….
7
Specifications
Product dimensions
Height: 815 – 865 mm
Width: 598 mm
Depth: 550 mm
Aperture dimensions
Height: 820 – 870 mm
Width: 600 mm
Depth: 580 mm (MIN)
Product specifications
o 14 Place settings
o 6 programs: Normal
Intensive
Economy
Glass
Rapid
1 hour
o 5 temperatures: 40°C, 50°C, 55°C, 60°C, 65°C
o LED display
o Water consumption (Economy program): 11l/cycle
o Noise level: 49 dB
8
o Electronic aqua stop
o Delay start function
o Residual drying
o Alternative wash function
o Concealed heating element
o Self-cleaning stainless steel micro-filter
o Anti-leak device
o Anti-flood device
o Height adjustable upper basket
o Collapsible plate racks
o Adjustable feet
Energy efficiency details
Energy efficiency class: A++
Washing performance class: A
Drying performance class: A
Power consumption
Off mode: 0.45 W
Left on mode: 0.55 W
Electrical details
Rated voltage: 230 Vac 50 Hz
Supply connection: 13 A (double pole switched fused outlet
with 3 mm contact gap)
9
Description of the appliance
1) Top spray arm
2) Cutlery basket
3) Upper basket
4) Inner pipe
5) Lower basket
6) Salt container
7) Detergent dispenser
8) Cup shelf
9) Lower spray arm
10) Filter assembly
11) Inlet pipe connector
12) Drain pipe
13) Adjuster
10
Control panel
1) LED display
2) Alternative wash button
3) Delay start button
4) Program button
5) ON/OFF button
Using your dishwasher
Before first use
o Install the appliance as per the installation instructions contained
within this booklet.
o Fill the water softener with 1 litre of tap water and then fill with
specialist dishwasher salt. After this you should set the water
softener level.
o Fill the rinse aid dispenser and then set the rinse aid dosage.
Filling with dishwasher salt
IMPORTANT: You should only use salt that is specially
designed for use in a dishwasher. If any other type of
salt is used in the appliance (in particular table salt),
it will damage the water softener.
o Ideally you should fill the water softener with salt, just before
you are about to run a wash program. This will help to clear any
salt that may have overflowed from the water softener during
the salt filling process.
o Open the door of the dishwasher and then remove the lower
basket. The basket should be empty when you remove it.
o Turn the water softener cap anticlockwise and remove it.
o Pour 1 litre of water into the water softener.
11
IMPORTANT: It is only necessary to do this when you fill
the container with salt for the first time.
o Pour salt into the water softener, using the funnel that is
supplied with the appliance. You should add approximately 1.5
kg of salt into the water softener.
o It is perfectly normal for a small amount of water to come out of
the water softener, whilst you are filling it with salt. This does
not mean that the water softener is filled with the correct
amount of salt.
o Refit and fully tighten the water softener cap.
o The salt required warning light will go out
shortly after you have filled the water softener
with salt. When the salt indicator lights on the
control panel, then you should follow the filling
with dishwasher salt procedure again.
o IMPORTANT: You do not need to pour 1 litre of water into
the container when you subsequently fill the water
softener with salt.
12
Setting the water softener level
It is possible to regulate the amount of salt that the water softener will
release during a wash cycle. The water softener should be set to a
level that is appropriate for the hardness of your water (please refer to
the table below).
WATER HARDNESS
° dH ° fH ° Clarke Mmol/L
0-5 0-9 0-6 0-0.94 H1 0 /
6-11 10-20 7-14 1.0-2.0 H2 20 60
12-17 21-30 15-21 2.1-3.0 H3 30 50
18-22 31-40 22-28 3.1-4.0 H4 40 40
23-34 41-60 29-42 4.1-6.0 H5 50 30
35-55 61-98 43-69 6.1-9.8 H6 60 20
Selector
Salt
consumption
(gram/cycle)
Usage
(cycles/1
kg)
To alter the amount of salt that is released by the water softener, you
should:-
o Open the door and switch on the appliance using the
ON/OFF button (5).
o Press and hold the program button (4) for about 5
seconds to enter the water softener setting mode. The
salt and rinse aid indicators may light in the setting
mode.
o Repeatedly press the program button (4) to select the
appropriate option according to the hardness of your water. The
LED display will show your choice as shown in the above table.
o When you have made your selection, press the ON/OFF button
(5) to exit the setting mode.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets and live
in a medium or hard water area, then you should still fill the
water softener with salt. The water softener level should be set
accordingly.
13
Filling with rinse aid
The rinse aid is released during the final rinse and it helps
to prevent water from forming droplets on your dishes.
These droplets will lead to spots and streaks being left on
items after the wash program has completed.
o Your dishwasher is designed to utilise liquid rinse aid.
o The rinse aid dispenser is located inside the drop down door,
next to the detergent dispenser.
o To access the rinse aid dispenser, you should turn the cap
anticlockwise and it will pop out of the hole. Then slowly pour in
liquid rinse aid, the rinse aid dispenser will hold approximately
110 ml of rinse aid.
o Be careful not to overfill the dispenser, as this could cause
oversudsing when a wash program is selected. Wipe away any
rinse aid excess or spillages with a damp cloth.
o Replace the cap and turn it clockwise until it locks into position.
o You should refill the rinse aid dispenser when the
rinse aid indicator lights on the control panel.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets then
you should still fill the rinse aid dispenser.
14
Setting the rinse aid level
The amount of rinse aid that the dishwasher requires also depends on
the hardness of your water. You should experiment with the rinse aid
setting, until you find a level that gives the best results.
o On the first wash cycle, we would recommend that the rinse aid
level is set to number 4.
o If you get water spots and poor drying performance, then you
should turn the arrow anticlockwise and increase the setting to
the next number.
o You should continue to adjust the rinse aid level upwards until
you get no water spots.
o If you get cloudiness or streaking on your dishes, the rinse aid
level is set too high and it is causing foaming during the wash
cycle. Turn the arrow clockwise and lower the setting to the next
number.
Filling with dishwasher detergent
o The detergent dispenser must be refilled at the start of each
wash cycle.
o Your dishwasher uses less detergent and rinse aid than a
conventional dishwasher.
o In general, only one tablespoon of detergent is needed for a
normal wash load. More heavily soiled items may need more
detergent.
o Always add the detergent just before starting the wash program,
otherwise the detergent could get damp and not dissolve
properly.
15
o Open the lid that closes over the detergent dispenser by pushing
the release button. The lid will spring open. Place the detergent
inside of the dispenser.
o The section marked A in the diagram is for the main wash cycle
detergent. Only one detergent tablet should be placed in the
dispenser at any one time. If you are using detergent powder or
liquid, you should follow the detergent manufacturer’s
recommendations.
o The section marked B in the diagram can have separate
detergent placed in it for any wash cycle that has a pre-wash
element to it, however this is optional. This must be a liquid or
powder detergent, not another detergent tablet.
o Shut the detergent dispenser lid and press it until it locks into
place.
o At the beginning of a wash cycle the clip will open and the
tablet/powder/liquid will enter the dishwasher.
Concentrated detergent
o The use of the NORMAL program with concentrated detergents
reduces pollution and is good for your dishes.
16
Loading...
