Page 1
BDI460SS
46 cm High
compact dishwasher
Page 2
USER MANUAL FOR YOUR BAUMATIC
BDI460SS 46 cm High
compact dishwasher
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 16/04/10
2
Page 3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 - 9
Product and aperture dimensions 8
Product specifications 8 - 9
Energy efficiency details 9
Electrical details 9
Description of the appliance 9 - 10
Control panel 10
Using your dishwasher 11 - 19
Before first use 11
Filling with dishwasher salt 11 - 12
Setting the water softener level 12 - 13
Filling with rinse aid 13 - 14
Setting the rinse aid level 14 - 15
Filling with dishwasher detergent 15 - 16
Loading the basket 16 - 17
The cutlery basket 17
Loading dishes and cutlery 18 - 19
Program table 20 - 26
Setting a wash program 21 - 22
Changing a wash program 22 - 23
At the end of a wash cycle 23
Additional rinse option 24
“3 in 1” key 24
Setting a delay start 25
Rinse aid and salt indicator neons 26
Cleaning and maintenance 26 – 32
Removing the basket 26 - 27
The filter system 28
Cleaning the filters 29 – 30
The drip tray 30 - 31
Cleaning the spray arm 31
Cleaning the control panel 31
Cleaning the door 32
Cleaning the door gasket 32
Not using the appliance for a prolonged period? 32
Reconnecting the appliance after a period of disuse 32
Error code failure system 33 - 34
General troubleshooting 35 - 36
Installation 37 – 42
Installing the dishwasher into a kitchen cabinet 38 – 39
Connecting to the mains water supply 39
Water outlet 40 - 41
Power supply 41 - 42
Before first use 42
Contact details 43
3
Page 4
Environmental note
o The packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
o Please discard all packaging material with due regard for the
environment.
4
Page 5
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Safety
o Repairs to your appliance must only be carried out by a
Baumatic engineer or one of its authorised service agents. Any
attempt by an inexperienced person to repair the appliance,
could result in injury or damage to your dishwasher.
o If you notice that the mains cable is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
o The appliance should be turned off and isolated from the mains
supply, before either cleaning or maintenance work is attempted.
o The mains cable must not be used to pull the plug out of the
electrical socket.
o The machine should not be sprayed with water.
o The external surface of the appliance may become hot whilst
your dishwasher is in use.
o It is possible for small animals to chew either mains cables or
water hoses, which could cause an electric shock hazard.
Installation
o The installation instructions contained within this user manual
should be followed.
o It is obligatory for the completed installation to comply with all
relevant building regulations and local water authority
requirements.
o Before the first use of the appliance, you should follow the
steps listed in the “Before first use” section of this
manual.
5
Page 6
o Care should be taken not to trap the power supply cable
underneath the appliance whilst installing it.
o No attempt should be made to alter or modify the specifications
of this appliance.
In daily use
o This appliance is only designed to wash normal domestic
washloads. If you use your dishwasher in any other way or it is
incorrectly used, then Baumatic accepts no liability for any
damage that might be caused and any guarantee will be void.
o It is recommended that the appliance is unplugged and the
water supply is turned off after the machine is used.
o The detergents, rinse aid and salt that you place in this appliance
should be suitable for automatic dishwashers. With regards to
dosage levels, the detergent manufacturer’s recommendations
should be followed.
o Sharp knives or ones with long blades are a potential safety
hazard when placed in an upright position in the cutlery basket.
We would recommend that these items are placed horizontally in
the main basket.
o You should not wash any items that have come into contact
with corrosive, acidic or alkaline chemicals, paint, petrol, iron or
steel debris.
o You should not open the door whilst the appliance is set on a
wash program. Depending on which stage that the wash
program is at, hot water could escape the machine.
o You should not leave the door of the appliance open, unless
you are loading or unloading the dishwasher.
o You should not stand or sit on the door when it is open.
6
Page 7
Child Safety
o Your dishwasher should only be used by adults. You should not
allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
o It could be possible for a child or pet to gain access to the
dishwasher if the door is left open. Therefore please check the
inside of the appliance before setting it on a wash cycle.
o Any packaging that is removed from the machine should be kept
away from children.
o All detergents should be kept out of children’s reach in a safe
place.
o Some water will remain inside the dishwasher when it has
completed a wash cycle. This water is not suitable for drinking
and may contain residues from the detergents that are used in
the appliance.
Declaration of conformity
This appliance complies with the following European Directives:
-73/23 dated 19/02/1973 Low Voltage Directive and subsequent
modifications.
-89/336 dated 03/05/1989 Electromagnetic Compatibility Directive and
subsequent modifications.
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate of your dishwasher is
located on the right hand side of the drop down door.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….
7
Page 8
Specifications
Product and aperture dimensions
Product dimensions Aperture dimensions
Height: 457 mm Height: 450 mm
Width: 598 mm Height: 460 mm
Depth: 568 mm (built under)
Width: 560 mm
Depth: 560 mm
Product specifications
o 6 Place settings
o 5 functions: Normal
Intensive
Economy
Rapid
Powerful
o 4 Wash temperatures: 40°C, 50°C, 65°C, 70°C
o 2 Rinse temperatures: 68°C, 70°C
8
Page 9
o Electronic aqua stop
o Delay start
o LED display
o Residual drying
o Concealed heating element
o Mark resistant coating
o Self-cleaning stainless steel micro-filter
o Anti-leak device
o Anti-flood device
o Low water consumption (8 litres)
o Noise level (49 dB)
Energy efficiency details
Energy efficiency class: A
Washing performance class: A
Drying performance class: A
Electrical details
Rated voltage: 230 Vac 50 Hz
Maximum rated input: 1.58 kW
Supply connection: 13 A (double pole switched fused outlet
with 3 mm contact gap)
Description of the appliance
Interior of the appliance
9
Page 10
Control panel
A) ON/OFF key
B) Program selection key
C) Delay start key
C1) Delay start icon
D) Additional rinse key
D1) Additional rinse icon
E) “3 in 1” key
E1) “3 in 1” icon
F) Start program key
G & H) Digits
I) Warning icon
J) Salt required icon
K) Rinse aid required icon
L) Wash program icons
M) Wash temperature icons
N) Door locked icon
10
Page 11
Using your dishwasher
Before first use
o Install the appliance as per the installation instructions contained
within this booklet.
o Fill the water softener with 1 litre of tap water and then fill with
specialist dishwasher salt. After this you should set the water
softener level.
o Fill the rinse aid dispenser and then set the rinse aid dosage.
Filling with dishwasher salt
IMPORTANT: You should only use salt that is specially
designed for use in a dishwasher. If any other type of salt is
used in the appliance (in particular table salt), it will damage
the water softener.
o Ideally you should fill the water softener with salt, just before
you are about to run a wash program. This will help to clear any
salt that may have overflowed from the water softener during
the salt filling process.
o Open the door of the dishwasher and then unhook the basket
from the door. The basket should be empty when you remove it.
o Turn the water softener cap
anticlockwise and remove it.
o Pour 1 litre of water into the water
softener.
IMPORTANT: It is only necessary to do this when you fill
the container with salt for the first time.
o Ensure that the supplied funnel is
positioned correctly.
11
Page 12
o Pour salt into the water softener, you
should add approximately 1 kg of salt
into the water softener.
o It is perfectly normal for a small amount of water to come out of
the water softener, whilst you are filling it with salt. This does
not mean that the water softener is filled with the correct
amount of salt.
o Refit and fully tighten the water softener cap.
o To remove any excess salt that may have spilled out of the
water softener, we would recommend that the rapid wash
program is completed afterwards.
o When the salt required neon (J) lights on the control panel, then
you should follow the “filling with dishwasher salt” procedure
again.
o IMPORTANT: You do not need to pour 1 litre of water into
the container when you subsequently fill the water
softener with salt.
Setting the water softener level
It is possible to regulate the amount of salt that the water softener will
release during a wash cycle. The water softener should be set to a
level that is appropriate for the hardness of your water (please refer to
the table below).
Display °dH °fH °Clarke
0 0 – 6 0 – 10 0 – 7 0 – 1
1 6 – 14 11 – 25 8 – 18 1.1 – 2.5
2 15 – 22 26 – 40 19 – 28 2.6 – 4
3 23 – 28 41 – 50 29 – 35 4.1 – 5.0
4 > 28 > 50 > 35 >5.0
o The dishwasher will leave the factory with the water softener on
setting 2.
mmol/l
12
Page 13
You should adjust the amount of salt that is released by the machine
taking into account the water hardness of your geographical area, to
do this you should:-
o Close the door of the dishwasher, you will hear a mechanical
click when the door of the dishwasher is shut properly.
o Press the ON/OFF key (A) to switch the machine on, the LED
display will light up and show “P0”. Immediately press and hold
the program selection key (B) until the LED display is showing a
flashing “h0”.
o To alter the water hardness setting, use the additional rinse key
(D) to cycle through numbers 0 – 4.
o When the LED display shows the water softener setting that you
require, press the program selection button to confirm your
choice. The LED display will show “P0” to indicate that the
dishwasher is ready to program.
o If you live in a soft water area and as a result select setting “0”
for the water softener, there is no need to fill the water softener
with dishwasher salt. The salt required icon (J) will remain lit.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets then it
may still be necessary to fill the water softener. You should refer
to the instructions given by the dishwasher salt manufacturer. If
they suggest using 3 in 1 tablets and separate dishwasher salt,
we would recommend that water softener setting 1 is selected.
Filling with rinse aid
The rinse aid is released during the final rinse and it helps
to prevent water from forming droplets on your dishes.
These droplets will lead to spots and streaks being left on
items after the wash program has completed.
o Your dishwasher is designed to utilise liquid rinse aid.
o The rinse aid container is located on the inside of the dishwasher
door.
o To access the rinse aid
dispenser, you should turn and
remove the cap to reveal the
spout.
13
Page 14
o Slowly pour in liquid
rinse aid, the rinse aid
dispenser will hold
approximately 100ml
of rinse aid.
o You should continue to fill with rinse aid until the dispenser is
full. Be careful not to overfill the dispenser, as this could cause
oversudsing when a wash program is selected. Wipe away any
rinse aid excess or spillages with a damp cloth.
o Replace the cap and turn it until it locks into position.
o When the rinse aid required neon (K) lights on the control panel,
then you should follow the “filling with rinse aid” procedure
again.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets then it
may still be necessary to fill the rinse aid dispenser. You should
refer to the instructions given by the rinse aid manufacturer.
Setting the rinse aid level
The amount of rinse aid that the dishwasher requires also depends on
the hardness of your water. You should experiment with the rinse aid
setting, until you find a level that gives the best results.
o The dishwasher will leave the factory with the water softener on
setting “A1”.
o The rinse aid level can only be set whilst the LED display is
showing “P0”.
o Close the door of the dishwasher, you will hear a mechanical
click when the door of the dishwasher is shut properly.
o Press the ON/OFF key (A) to switch the machine on, the LED
display will light up and show “P0”. Immediately press and hold
the delay start key (C) until the LED display is showing “A1”.
o To alter the rinse aid setting, use the additional rinse key (D) to
cycle through A0 – A2.
14
Page 15
o When the LED display shows the rinse aid setting that you
require, press the program selection button to confirm your
choice. The LED display will show “P0” to indicate that the
dishwasher is ready to program.
o If you get water spots and poor drying performance, then the
rinse aid level should be increased to a higher level.
o You should continue to increase the rinse aid level until you get
no water spots.
o If you get cloudiness or streaking on your dishes, the rinse aid
level is set too high and it is causing foaming during the wash
cycle. The rinse aid level should be decreased to a lower level.
Filling with dishwasher detergent
The detergent dispenser must be refilled at the start of each wash
cycle.
o Your dishwasher is designed to use detergent tablets, you
should place one per wash cycle in the cutlery basket (in the
position shown in the above picture).
o If you are not placing the cutlery basket inside the dishwasher
on a particular wash cycle, then it is possible to place the
detergent tablet in one of the corners of the drip tray (see
above picture).
15
Page 16
o If you are using powder detergent, this should also be placed in
one of the corners of the drip tray. You should refer to the
manufacturer’s instructions when it comes to the amount of
power detergent to use per wash cycle.
o IMPORTANT: We do not recommend that you use liquid
detergent in this appliance.
o IMPORTANT: If you are using “3 in 1” detergent tablets and
not also using separate dishwasher salt and rinse aid, then the
salt required icon (J) and rinse aid required icon (K) will remain
lit.
o IMPORTANT: If you are using “3 in 1” detergent tablets and
not also using separate dishwasher salt and rinse aid, after
selecting your wash program you must press the “3 in 1” key
(E). The “3 in 1” icon (E1) will light on the LED display.
Loading the basket
The basket is designed to wash plates (up to 26 cm in diameter),
bowls, glasses, cups, pots, pans, lids, salad bowls etc. Examples of
appropriate ways to load the basket are shown in the pictures below.
o Loading without saucepans
o Loading without plates
16
Page 17
o Loading with a mixture of
plates and saucepans
o Saucepans and serving bowls must always be placed with their
bases upwards.
o Deep saucepans should be slanted, to allow water to run off.
IMPORTANT: Care should be taken to make sure that the spray
arm can move freely when items have been loaded into the
basket.
The cutlery basket
Cutlery should be placed inside of the cutlery basket. The cutlery
basket should then be placed in the appropriate position in the lower
basket.
1. Teaspoons
2. Dessert spoons
3. Soup spoons
4. Forks
5. Knives
6. Ladle
7. Serving fork
IMPORTANT: Do not allow items of cutlery to fall through
the bottom of the cutlery basket, as this may cause
damage to the spray arm and/or the cutlery. If the bottom
of the basket begins to deteriorate and allows items to fall
through, you should replace the cutlery basket.
17
Page 18
Loading dishes and cutlery
Household cloths, sponges or any other object that
may absorb water SHOULD NOT be washed in a
dishwasher.
o Remove leftovers and soften the remnants of burnt food in pans,
prior to loading dishes in the appliance.
o Once the dishwasher has been loaded, check that the spray arm
can move freely. If the spray arm comes into contact with any
item, then you should rearrange the wash load.
o Cups, glasses, pans etc should all be loaded with their bases
upwards, so that water does not collect inside of them.
o Cutlery and dishes should not cover each other; otherwise you
may get poor wash results.
o Do not allow glasses to touch inside the dishwasher, otherwise
damage may occur.
o Small objects can be placed inside of the cutlery basket.
o Sharp knives or ones with long blades are a potential safety
hazard when placed in an upright position in the cutlery basket.
We would recommend that these items are placed horizontally in
the main basket.
18
Page 19
The following items are NOT suitable for washing
inside a dishwasher:-
o Cutlery with a handle of mother-of-pearl, wood, horn or china.
o Plastic items that are not resistant to heat.
o Cutlery that consists of glued parts that are not resistant to heat.
o Cutlery items or crockery that are bonded.
o Copper or pewter items.
o Lead crystal glass.
o Wooden platters.
o Synthetic fibre items.
The following items are not always suitable for
washing inside a dishwasher:-
o Stoneware should only be washed if the manufacturer of the
item has marked it as dishwasher safe.
o Plastic items (such as lunchboxes) should only be washed if the
manufacturer has marked it as dishwasher safe.
o Glazed crockery may fade with repeated washing inside of a
dishwasher.
o Items made of silverware or aluminium can discolour when
washed inside a dishwasher.
o Any food residue should be removed from silver items
immediately, as this can also result in discolouration.
o Certain types of glass may become dull or cloudy after a large
number of washes.
19
Page 20
Program table
Wash program LED display information shown
P1
(50°C Economy)
P2
(70°C Intensive)
P3
(65°C Normal)*
P4
(40°C Rapid)
P5
(70° Powerful)
* Normal is the testing program for EN 50242.
Program
details
Description
Detergent
Rinse aid
Rinse plus
Delay start
“3 in 1”
option
Type of
dishes
Types of
soiling
P1 P2 P3 P4 P5
50°C
wash
68°C
rinse
Drying
70°C wash
Intermediate
rinse (x 2)
70°C rinse
Drying
65°C wash
Intermediate
rinse
70°C rinse
Drying
40°C wash
Intermediate
rinse
70°C rinse
Drying
YES YES YES YES YES
YES YES YES YES YES
YES YES YES YES YES
YES YES YES YES YES
YES YES YES YES YES
Mixed
dishes
Normal
soiling
Mixed
resistance
dishes
Heavy
soiling (not
for delicate
items)
Mixed
delicate
dishes
Heavy soiling
(not for
delicate
items)
Mixed
resistance
dishes
Light soiling Heavy soiling
70°C wash
Intermediate
rinse
70°C rinse
Drying
Mixed
resistance
dishes
or using a
dishwasher
cleaner
20
Page 21
Opening and closing the door
o Pull the dishwasher handle to open the door, continue to pull
forward until the drawer comes out of the appliance.
o IMPORTANT: The door should only be opened when the door
locked icon (N) is not lit. If the door is opened mid cycle, then
water may spill out of the machine, which may cause damage to
property and/or injury to person.
o To close the door, use the handle to slide the drawer back into
place.
o IMPORTANT: DO NOT close the door of
the dishwasher without using the handle.
Otherwise there is a risk of trapping your
fingers.
o Slide the drawer back fully into position and then press in the
centre of the LED display, until you hear a mechanical click. This
is when the door of the dishwasher is shut properly.
Setting a wash program
Make sure that the “Before first use” section has been
followed.
IMPORTANT: The drip tray MUST be in position before
loading the basket and setting the appliance on a wash
program. See the “cleaning and maintenance” section
for more information.
o Pull out the basket and then load it in accordance with the
loading instructions.
o Push the basket fully back into position.
o Place one detergent tablet into the relevant location in the
cutlery basket.
o Close the door firmly, so that you hear the door lock click shut.
o Press the ON/OFF key (A) to switch the machine on, the LED
display will light up and show “P0”.
21
Page 22
o Check whether the salt required icon (J) or rinse aid required
icon (K) are lit. If they are and you usually utilise separate salt
and rinse aid, then before continuing with the wash program you
should fill the dishwasher with salt and/or rinse aid.
o Press the program selection key (B) until the program that you
require appears on the LED display.
o Select any program option that you want to use (e.g. delay start,
additional rinse etc).
o IMPORTANT: If you are using “3 in 1” detergent tablets and not
also using separate dishwasher salt and rinse aid, after selecting
your wash program you must press the “3 in 1” key (E). The “3
in 1” icon (E1) will light on the LED display.
o Start the wash cycle by pressing the start program key (F), after
a few seconds, you will hear the appliance begin to fill with water
and the wash program will have started.
o The door locked icon (P) will light and the LED display will show
the time remaining until the end of the wash cycle.
Changing the wash program
o Whilst the program number still flashes on the LED display, the
wash program has not been confirmed and it is possible to alter
the wash program using the program selection key (B).
o Once the wash cycle is in progress, we do not recommend that
you attempt to change the wash program.
o However if you do wish to do this, you should press and hold
down the program selection key for 3 seconds to cancel the
wash cycle in progress. The LED display will show “00” and you
will hear the appliance pump out the water in the appliance.
o An audible signal will sound when the appliance has finished
pumping out.
o Press the ON/OFF key (A) to switch the appliance off. You can
then set a new wash program, by following the “setting a wash
program” section of this manual.
o IMPORTANT: Depending on what stage of the wash cycle has
been reached, it may be necessary to place a new detergent
tablet/detergent powder into the appliance for the new wash
cycle.
22
Page 23
At the end of a wash cycle
o When the wash cycle has completed, the LCD display will show
“0” and an audible signal will sound. The “0” will disappear from
the LCD display after 10 minutes but the audible signal will
repeat every 10 minutes, until the dishwasher is switched off.
o IMPORTANT: The door should only be opened when the door
locked icon (N) is not lit. The door locked icon will remain on for
approximately 2 minutes after the wash cycle has completed.
o When the door locked icon has gone out, use the ON/OFF key
(A) to switch the dishwasher off.
o IMPORTANT: You should leave the appliance for 15 minutes
BEFORE opening the door. This will allow the steam generated
from the final rinse(s) to dry the dishes.
o Carefully open the door of the appliance (as described on page
21) and leave it ajar for a few minutes, to allow any remaining
steam to disperse.
o WARNING: Hot steam may escape when the door is first
opened, so care should be taken.
o Unload the dishwasher; you should take care in case any of the
items are still warm.
o IMPORTANT: If you leave the door of the dishwasher shut and
do not unload the dishwasher for a prolonged period of time,
then you may get water droplets reforming on the washload.
23
Page 24
Additional rinse option
If you are washing dishes that are very heavily soiled, then it is
possible to program the dishwasher so that it gives an additional rinse
during the wash program.
o After you have selected a wash cycle (as described on pages 21
– 22), press the additional rinse key (D) to select the additional
rinse option.
o The additional rinse icon (D1) will light on the LED display.
o If you press the additional rinse key in error, then it is possible
to switch this option off by pressing the additional rinse key
again, the additional rinse icon will go out.
o IMPORTANT: Once the wash cycle has started, it is not
possible to switch off the additional rinse option.
“3 in 1” key
o IMPORTANT: If you are using 3 in 1 dishwasher tablets then it
may still be necessary to fill the water softener. You should refer
to the instructions given by the dishwasher salt manufacturer. If
they suggest using 3 in 1 tablets and separate dishwasher salt,
we would recommend that water softener setting 1 is selected.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets then it
may still be necessary to fill the rinse aid dispenser. You should
refer to the instructions given by the rinse aid manufacturer.
o IMPORTANT: If you are using “3 in 1” detergent tablets and not
also using separate dishwasher salt and rinse aid, after selecting
your wash program you must press the “3 in 1” key (E). The “3
in 1” icon (E1) will light on the LED display.
If your wash results are poor, then we would recommend
that you use a dishwasher detergent that doesn’t have
rinse aid and salt included in the tablet. The water softener
and rinse aid levels should then be adjusted appropriately
for the hardness of the water in your area.
24
Page 25
Setting a delay start
It is possible to delay the start of the wash program for a maximum of
9 hours.
o After you have selected a wash cycle (as described on pages 21
– 22), press the delay start key (C). The LED display will show
“d1”, indicating that the start of the wash cycle has been delayed
by 1 hour.
o Continue to press the delay start key, until the delay start
interval that you require appears on the LED display. “d9” is the
maximum delay start time interval that you can program (9
hours).
o Approximately 4 seconds after you release the delay start key,
the delay start icon (C1) will appear on the LED display and the
delay start time interval is confirmed.
o To commence the delay start countdown, press the start
program key (F).
o After the delay time has elapsed, you will hear the appliance
begin to fill with water and the wash program will start.
o When a delay start countdown is set, if you press and hold the
delay start key, the machine will immediately start the wash
cycle that you set previously.
o To cancel the delay start and the wash program that you set,
press and hold the program selection key (B) until “P0” appears
on the LED display. You can then either switch the machine off,
or set a completely new wash program.
25
Page 26
Rinse aid and salt indicator neons
o The rinse aid and salt indicator
neons on the control panel will let
you know when the appliance
needs rinse aid or salt adding to it.
o The neon indicates that you need to add rinse aid to the
appliance. You should follow the procedure outlined on pages 13
- 14.
o The neon indicates that you need to add dishwasher salt to
the appliance. You should follow the procedure outlined on pages
11 - 12.
Cleaning and maintenance
IMPORTANT: The appliance should be disconnected
from your mains supply before commencing any
cleaning process.
Removing the basket
o Fully open the door of the dishwasher.
o Grasp the basket with both
hands and then lift it upwards
to detach it from the front
part of the door.
o Push it towards the inside of the machine and with the basket
still slightly raised remove it from inside of the dishwasher.
o IMPORTANT: When removing the basket, make sure that the
upper part of the basket does hit against the inside of the
cabinet or hook onto the door seal.
26
Page 27
o When placing the basket back inside of the dishwasher, insert
the basket wheels into the basket wheel guides.
o Slide the basket fully into the
dishwasher and then refasten
the basket to the support on
the inside of the door (as
shown in the picture opposite).
o Check that the spray arm can
turn fully before setting the
dishwasher on a wash cycle.
27
Page 28
The filter system
Your appliance is fitted with three levels of filtering; these are located
in the base of the dishwasher for ease of access.
1) Main filter
2) Coarse filter
3) Fine filter
Main filter- Food and soil particles are trapped by this filter and
pulverised by a special jet on the lower spray arm.
This debris is then washed down the drain.
Coarse filter- Larger items such as pieces of bone or glass, which
could clog the drain, are trapped in this filter.
Fine filter- This filter holds soil and food residue in the sump
area and prevents it from being redeposited on the
dishes during a wash cycle.
IMPORTANT: Whilst the filtering system is efficient, your
dishwasher is not a waste disposal unit. All items being
washed inside of the dishwasher should have food scraps
removed from them before being loaded into the appliance.
28
Page 29
Cleaning the filters
For best performance and results, the entire filter assembly should be
thoroughly cleaned regularly (ideally after each wash cycle).
o Remove the basket from the appliance.
o Identify the coarse filter, which is
located in the middle of the main filter.
o Turn the coarse filter anti-clockwise
and then lift it upwards. Rinse out this
section under a tap to remove any food
debris that remains in it.
o Pull out the main filter and rinse this
under the tap to remove any food
debris that is trapped in it.
o Pull out the fine filter and rinse this
under the tap to remove any food
debris that is trapped in it.
o Place the fine filter back in its original position.
o Place the main and coarse filter back into their original positions
in the base of the dishwasher. You must turn the coarse filter
clockwise to lock it back into position.
29
Page 30
IMPORTANT: THE DISHWASHER SHOULD NEVER BE
SET ON A WASH CYCLE WITHOUT THE FILTERS BEING
INSIDE OF THE APPLIANCE.
The drip tray
The drip tray is positioned under the basket and it is designed to catch
dirt and food residue that may drop from items when they are placed
in the dishwasher. It is hooked directly onto the door for reasons of
safety and will slide out when the door is opened.
o To remove the drip tray for cleaning, you should firstly remove
the basket from the appliance (as described on pages 26 - 27).
o Grip the sides of the drip tray and raise it slightly, so that it
unclips from the drip tray catch fastener. Then push the drip
tray back inside of the appliance.
o You should slide the upper plate of the drip tray over the lower
plate of the drip tray. Grip the sides of the drip tray and then
remove it from the inside of the dishwasher.
o Clean both plates of the drip tray using hot soapy water and a
damp cloth, then rinse thoroughly and dry.
30
Page 31
o Slide the drip tray back into the dishwasher, with the upper and
lower plates closed together. Making sure that the wheels locate
into their guides at the side of the dishwasher tank.
o Once the wheels have reached their rear limit, you should gently
slide forward the upper plate only and clip this onto the drip tray
catch fastener.
o Refit the basket.
IMPORTANT: The drip tray MUST be in position before loading
the basket and setting the appliance on a wash program. The
dishwasher MUST NOT BE USED without the drip tray being in
position.
Cleaning the spray arm
The spray arm should be cleaned regularly, to prevent hard water
deposits from clogging the spray arm jets and bearings.
o IMPORTANT: Remove the basket before attempting to clean the
spray arm.
o Check that the nozzles of the spray arm are not obstructed by
food residue.
Cleaning the control panel
IMPORTANT: Do not use any abrasive cleaner or household polish on
either the control panel or operating parts.
o Wipe over the control panel using a brand new damp cloth with
warm water.
31
Page 32
Cleaning the door
o To clean the edge around the outside of the door, you should use
a soft, damp cloth only.
o To prevent water from penetrating the door lock or electrical
components, DO NOT use a spray cleaner of any kind.
o DO NOT use any abrasive cleaner or scouring pads on the inner
or outer surfaces, as they may cause damage to them.
Cleaning the door gasket
o Use a damp sponge to clean the door gasket from time to time.
This will prevent the build up of food residues which could cause
unpleasant odours.
Not using the appliance for prolonged periods?
If the dishwasher is not going to be used for a prolonged period of
time, then we would recommend that you do the following:-
o Fill the rinse aid dispenser.
o Run one or two cycles with the dishwasher empty.
o Disconnect the electrical and water connections.
o Leave the door ajar slightly to prevent an unpleasant odour
from developing.
o Clean all of the filters and dry the inside of the machine
thoroughly.
Reconnecting the appliance after a period of disuse
If the appliance has not been used for a prolonged period of time, then
before using the appliance again, we would recommend that you do
the following:-
o Check that no sludge or rust has built up in the pipes. If this has
happened, let water run through the tap for a few minutes.
o Reconnect the inlet hose and outlet hose, making sure that the
water tap is open.
o Reconnect the appliance to your mains supply.
32
Page 33
Error code failure system
If your appliance senses that it is not operating correctly, then an error
code may appear on the LED display and/or the warning icon (I) may
light.
The following error codes can possibly be remedied by the customer
and the steps outlined below should be followed.
BEFORE COMPLETING ANY MAINTAINEANCE ON THE
APPLIANCE, IT SHOULD BE DISCONNECTED FROM YOUR MAINS
POWER SUPPLY.
E0
o Insufficient amount of water in the dishwasher.
9 Check that the water tap is fully open.
9 Check that the filter in the inlet hose is not clogged.
9 Check that the inlet hose is not kinked or crushed.
E1
o No water.
9 Check that the water tap is fully open.
9 Check that the filter in the inlet hose is not clogged.
9 Check that the inlet hose is not kinked or crushed.
E2
o The dishwasher does not drain.
9 Check that the drain hose is not kinked or crushed.
9 Check that the drain hose is not blocked.
9 Check that the filter system inside the dishwasher is not blocked.
EA
o The machine was not able to fill with water.
9 Check that the drain hose is not kinked or crushed.
9 Check that the drain hose is not blocked.
9 Check that the filter system inside the dishwasher is not blocked.
9 Insufficient water pressure.
Ec
o Insufficient amount of water in the dishwasher
9 Check that no bowls have overturned inside the dishwasher.
Ed
o The door is not locked correctly
9 Check that the door is closed
9 Open and close the door.
33
Page 34
After taking the necessary action to clear the fault code, you should
switch the machine off using the ON/OFF key (A). Wait for a few
seconds before switching the machine back on again.
IMPORTANT: If any other fault code appears on the LED
display or the same fault code reoccurs, you should not
attempt to clear it yourself and contact the Baumatic
Customer Care Department.
IMPORTANT: If your appliance appears not to be
operating correctly, then you should disconnect it
from your mains supply and then contact
Baumatic Customer Care on telephone number
(0118) 933 6911.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE
YOURSELF.
Please note that if an engineer is asked to attend whilst the product is
under guarantee and finds that the problem is not the result of an
appliance fault, then you may be liable for the cost of the call out
charge.
The appliance must be accessible for the engineer to perform
any necessary repair. If your appliance is installed in such a
way that an engineer is concerned that damage will be caused
to the appliance or your kitchen, then he will not complete a
repair.
This includes situations where appliances have been tiled in,
sealed in with sealant, have wooden obstructions placed in
front of the appliance, like plinths. Or any installation other
than the one specified by Baumatic Ltd. has been completed.
Please refer to the conditions of guarantee that appear on the
warranty card that you receive with the appliance.
IMPORTANT: Baumatic Ltd. operates a policy of continuous
improvement and reserves the right to adjust and modify its
products without prior notification.
34
Page 35
General troubleshooting
Start up problems
The appliance does
not start
The socket does not work.
The appliance is not properly connected.
The dishwasher is not properly closed.
The water tap is closed.
There is no water supply to the property.
Insufficient water system pressure.
Inlet hose is kinked or crushed.
Filter for outlet hose or solenoid valve is blocked.
All necessary operations to start the dishwasher have
not been performed.
Fuse in the plug has blown or there is a problem with
the mains supply.
Dishwasher LED display is showing an error code.
Problems during wash cycle
Routine formation of
suds
The appliance shuts
down during the
wash cycle.
A whining sound can
be heard during the
wash cycle.
Noise during cycle. The spray arm is striking dishes.
Beating sound of the
inlet valve whilst
filling with water.
Spray arm is
struggling to rotate.
Water is left in the
appliance at the end
of the wash cycle.
The door is difficult
to close.
Loading error, there is wash detergent in the rinse aid
dispenser.
Rinse aid liquid spread over the inner door liner. After
filling with rinse aid, remove any excess rinse aid with a
damp cloth.
Power cut
No water in appliance.
A whining sound coming from the pump is not
significant. There may be too much detergent or a
detergent without phosphates. If the problem persists,
then contact the Customer Care Department.
Dishes have not been properly arranged in the basket.
Generated by water distribution, it has no effect on the
mechanical operation of the appliance. This type of noise
is unavoidable.
The spray arm is blocked by some food residue and
should be cleaned.
The drain hose is kinked or blocked.
The drain pump has jammed.
The filters in the base of the appliance are dirty and/or
filled with residue.
The appliance is not fitted correctly into the aperture.
Dishes are coming into contact with the door gasket.
35
Page 36
Poor wash results
Residue remains on
dishes.
Some plastic items are
faded.
Traces of a white coating
on dishes and glasses
which is difficult to
remove.
The dishes are not dried. The dishes were removed from the appliance before
Glasses have a greyish
looked.
Stubborn traces of tea,
coffee or lipstick.
The lids of some items
are stained.
Damaged dishes and
glasses.
Traces of rust on the
dishes.
The dishes were not properly arranged or there are
too many of them.
Some of the dishes are touching one another.
The spray arm cannot turn because of a large plate
or saucepan being placed in the dishwasher.
Insufficient detergent is being used.
The detergent is old or has hardened.
The detergent being used is not appropriate.
The wash program selected is not suitable.
The spray arm is blocked by some food residue and
should be cleaned.
The filters in the base of the appliance are dirty
and/or filled with residue.
The filters in the base are not positioned correctly.
The drain pump has jammed.
The water softener lid is not fully tightened.
The end of the drain hose is immersed in water.
Insufficient detergent (use detergent without
chlorine).
Insufficient detergent.
Incorrect amount of rinse aid.
Inappropriate salt was used.
The water softener lid is not fully tightened.
No salt has been added to the water softener, or
the water softener level has not been appropriately
adjusted.
The dishes are not suitable for being washed in a
dishwasher.
they had sufficient time to dry.
The dishes were left inside of the appliance for too
long after the wash cycle had finished.
No rinse aid has been added to the appliance or the
rinse aid level has not been appropriately adjusted.
The glasses are not suitable for washing in a
dishwasher.
Insufficient detergent.
The wash cycle temperature was too low.
The detergent is old or has hardened, or is of poor
quality.
The covers are not made of a stainless
material.
Type and manufacturing methods of the glasses
and dishes are not suitable for a dishwasher.
The chemical composition of the detergent is
unsuitable.
The temperature of the water and/or the duration
of the wash program are not appropriate.
Do not leave dishes and glasses in the dishwasher
for an extended period.
Dishes are not made completely of stainless steel.
The water softener level has been set too high.
The water softener lid is not fully tightened.
Salt has been left in the base of the dishwasher
after filling the water softener. If salt spills into the
base of the dishwasher, then use the rapid wash to
remove the salt.
36
Page 37
Installation
Installation of this appliance must be carried out by a
suitably qualified person, in accordance with the
current version of the following.
o UK Regulations and Safety Standards or their European Norm
Replacements.
o Building Regulations (issued by the Department of the
Environment).
o Building Standards (issued by the Scottish Development
Department).
o IEE Wiring Regulations.
o Electricity At Work Regulations.
Before connecting the appliance, make sure that the supply voltage
marked on the rating plate corresponds with your mains supply
voltage.
WARNING: THIS APPLIANCE MUST BE EARTHED.
WE RECOMMEND THAT TWO PEOPLE COMPLETE THE
INSTALLATION OF THIS APPLIANCE, PARTICULARLY
WHEN LIFTING THE OVEN INTO THE HOUSING UNIT.
IMPORTANT: THIS INSTALLATION MUST BE COMPLETED BY A
SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION
THE INSTALLATION GIVEN IN THIS INSTRUCTION MANUAL.
YOU SHOULD DISPOSE OF ALL PACKAGING IN AN
ENVIRONMENTALLY FRIENDLY MANNER.
37
Page 38
Installing the dishwasher into a kitchen cabinet
o Ensure that the aperture that you will be fitting the dishwasher
into is of the size given in the diagram above.
o Ensure that the rear panel of the furniture housing unit has been
removed and that the ventilation cut out shown is adhered to.
o You must ensure that there is a hole to feed the electrical cable
through. There must also be holes left to connect the appliance
to your mains water supply and to your drain outlet. These steps
must be done before commencing the rest of the installation
process.
o IMPORTANT: The stop valve for your water supply MUST be
easily accessible during an emergency.
o Before proceeding with the rest of the installation, you must
connect the inlet hose (page 39) and the outlet hose (page 40)
to the rear of the appliance.
o Lift the dishwasher towards the aperture and then feed the
electrical cable, inlet hose and outlet hose through the holes in
the housing unit that you made previously.
38
Page 39
o Open the door of the dishwasher and then fix it to the housing
unit, using the four screws provided. These should be screwed
through the dishwasher cabinet and into the housing unit. These
screws must be fully tightened.
Connecting to the mains water supply
IMPORTANT: Do not connect the appliance to your mains
water supply using an old or an existing water inlet hose.
The inlet hose supplied with the dishwasher is the ONLY one
that should be us
DO NOT CONNECT THE WATER INLET HOSE TO A HOT
WATER TAP.
ed.
o The inlet hose will be located inside the cabinet of the
dishwasher.
o Connect the inlet hose to the inlet valve on the rear of the
product. Please refer to the photographs above to see the
correct position that the inlet hose should be in when connected.
o Connect the water inlet hose to a threaded water tap that has a
3/4” thread.
o Fully tighten the inlet hose to the water tap and the dishwasher.
IMPORTANT: The inlet hose
is fitted with an aqua stop.
This MUST be fitted in the
upright position, as shown
in the above diagram.
Otherwise the appliance
will not operate correctly.
Minimum water pressure- 50KPa (0.5 bar)
Maximum water pressure- 1MPa (10 bar)
39
Page 40
Water outlet
9 Connect the drain hose to the rear of the appliance.
9 Place the end of the drain hose on your drain pipe. Push it a
short way down into your drain pipe. The drain hose should be in
the shape shown in the above line drawing.
9 IMPORTANT: Do not place the drain hose higher than 800 mm.
9 IMPORTANT: Do not insert the drain hose too deeply into the
water pipe, as this may cause siphoning.
9 Secure the drain hose, so that it cannot move whilst the
dishwasher is in use.
9 A drain hose hook is supplied and should be attached in one of
the two ways shown in the diagram below.
9 If you are placing the drain hose into a sink, then you should
make sure it is secured to the sink or use a cord to fix it in
position.
40
Page 41
9 NEVER EXTEND THE DRAINAGE HOSE FROM ITS ORIGINAL
LENGTH.
Power supply
9 IMPORTANT: The electrical socket must still be accessible
once the appliance is installed.
9 Consult the rating plate, located on the right hand of the inner
surface of the door BEFORE making the electrical connections.
Ensure that the voltage reaching the plug is the same as that on
the rating plate.
9 DO NOT REMOVE THE RATING PLATE AS THE
INFORMATION ON IT IS IMPORTANT.
9 The moulded plug that is supplied with the appliance must
be placed into an earthed and insulated socket.
9 If you are not going to use the plug that is fitted to the power
cable, then the dishwasher should be wired into a 13 A double
pole switched fused spur outlet, having 3 mm contact separation
and placed in an easily accessible position adjacent to the
appliance. The spur outlet must still be accessible even when
your dishwasher is located in its housing.
9 Broken or damaged power leads must only be replaced by a
suitably qualified person. A power lead of a similar type must be
used in replacement.
9 Power lead type – H 0 V V – F 3G 1,5.
41
Page 42
9 IMPORTANT: We do not recommend that this appliance is
connected to an extension lead.
Before first use
You should check the following before using the appliance for the first
time:-
o That the dishwasher is level and fixed in position.
o That the water tap is fully open.
o That there are no leaks at either end of the drain or inlet hoses.
o That the inlet and drain hoses are fully tightened.
o That the inlet and drain hoses are not kinked.
o That the power is switched on.
o That the water softener has been filled with 1 litre of water and
filled with dishwasher salt.
o That the rinse aid dispenser has been filled.
42
Page 43
United Kingdom
Baumatic Ltd.,
Baumatic Buildings,
6 Bennet Road,
Reading, Berkshire
RG2 0QX
United Kingdom
Sales Telephone
(0118) 933 6900
Sales Fax
(0118) 931 0035
Customer Care Telephone
(0118) 933 6911
Customer Care Fax
(0118) 986 9124
Spares Telephone
(01235) 437244
Advice Line Telephone
(0118) 933 6933
E-mail:
sales@baumatic.co.uk
customercare@baumatic.co.uk
spares@baumatic.co.uk
technical@baumatic.co.uk
Website:
www.baumatic.co.uk
Republic of Ireland
Service Telephone
1-890 812 724
Spares Telephone
091 756 771
Czech Republic
Baumatic CR spol s.r.o.
Průmyslová zóna Sever 696
460 11 Liberec 11
Czech Republic
+420 483 577 200
www.baumatic.cz
Slovakia
Baumatic Slovakia, s.r.o.
Galvániho 7/D
Slovakia
+421 255 640 618
Germany
Baumatic Gmbh
Lilienthalstrasse 1
320 52 Herford
Deutschland
+49 5221 694 99-0
www.baumatic.de
Italy
Baumatic Italia S.R.L.
Via Galvani N.3
35011 Campodarsego (PD)
+3904 9920 2297
www.baumatic.it
Holland
Baumatic Benelux B.V.
Grindzuigerstraat 22
1333 MS ALMERE
Nederland
+3136 549 1555
www.baumatic.nl
43
Page 44
4444
Loading...
