THE NEW PROFI LINE
REDEFINING MOBILITY
SPORTS & SAFETY
Page 2
BAUER KOMPRESSOREN BAUER PROFI LINE | 2
REDEFINING PROFESSIONAL EXCELLENCE
THE FLEXIBLE ALL-ROUND TALENTS FOR PROFESSIONAL
APPLICATIONS – NOW EVEN BETTER
NEW DESIGN FOR OPTIMUM COOLING
We challenged our engineers to raise the state-of-the-art quality of our mobile pro compressors to a new level.
And they succeeded – perfectly.
Their secret? An all-new design for the front housing. The iconic lines now conceal a completely new cooling
air flow design, which boosts cooling by a remarkable 25 per cent and thus cuts the output temperature of the
compressor block by 10 per cent. The advantage for divers is more air in the cylinder without repressurizing!
The new design dramatically expands the range of high-temperature applications where the compressor systems can be used.
QUIET, SMOOTH CONDENSATE DRAINING
The new B-DRAIN automatic condensate drain system ensures that any oil/water condensate is extracted at
minimum loss of pressure and low noise. This prolongs the service life of pressurized parts and saves energy.
› Smooth, controlled condensate extraction. The condensate flow from the B-DRAIN condensate value into the
hoses to the condensate reservoir is virtually unpressurized.
› No need for a depressurization vessel upstream from the condensate reservoir.
› Approx. 4 %
operation.
› Compact footprint. The condensate valve is screwed directly onto the interstage / final separator.
1
higher supply volume in comparison of new to old automatic condensate drain in continuous
A PERFECT FIT
No need to ask whether the new PROFI LINE will fit your location – the dimensions are unchanged!
In addition, we’ve optimized our proven-quality valves in line with operating needs. During the development phase,
tailored FMEA analyses were used to optimize the product life cycle.
We also supply our new toolkit along with every compressor. It is specifically designed for use with our COMPACT
and PROFI LINE systems and contains all the main tools you need for simple maintenance tasks such as changing
filter cartridges or oil.
1 Level may vary depending on compress or block and size of filter system in use.
Page 3
BAUER KOMPRESSOREN BAUER PROFI LINE | 3
MARINER 250-B
with optional trolley
TECHNICAL DATA
Model
number
CAPITANO 140 -B 140 5 350 5,000 P 21 3 1,300
CAPITANO 140 -E 14 0 5 350 5,000 P 21 3 1,300
MARINER 200-B 200 7 350 5,000 P 21 3 1,250 4-stroke petrol 5.9 115 130 x 62 x 63
MARINER 200-E 200 7 350 5,000 P 21 3 1,250
MARINER 250-B 250 9 350 5,000 P 31 3 1,450 4-stroke petrol 6.6 120 130 x 62 x 64
MARINER 250-E 250 9 350 5,000 P 31 3 1,450
MARINER 320-B 320 11.5 350 5,000 P 31 4 1,450 4-stroke petrol 8.8 138 130 x 65 x 70
MARINER 320-E 320 11 . 5 350 5,000 P 31 4 1,450
1 Measured by cylinder filling (10 l) from 0–200 bar, ± 5 %
2 Power plug: 16 A
Charging
rate ¹
l/min cfm bar psig rpm Motor kW kg cm
Max. operating
pressure
Purification
system
No.
stages
Speed
approx.
Motor / motor output
Petrol engine
4-stroke
Three-phase
400 V, 50 Hz ²
3-phase current,
400 V, 50 Hz ²
3-phase current,
400 V, 50 Hz ²
3-phase current,
400 V, 50 Hz ²
Net weight
approx.
4.0 95 115 x 59 x 55
3.0 102 115 x 59 x 55
4.0 11 5 130 x 60 x 63
5.5 135 130 x 60 x 64
7. 5 154 130 x 65 x 70
Dimens.
L x W x H
420 BAR
Model
number
MARINER
200/420- E
MARINER
25 0/420 -E
MARINER 320-B 320 11. 5 420 6,000 P 41/42 0 4 1,450 4-stroke petrol 8.8 138 130 x 65 x 81
MARINER 320-E 320 11. 5 420 6,000 P 41/420 4 1,450
1 Measured by cylinder filling (10 l) from 0–200 bar, ± 5 %
2 Power plug: 16 A
Charging
rate ¹
l/min cfm bar psig rpm Motor kW kg cm
200 7 420 6,000 P 41/42 0 3 1.250
250 9 420 6,000 P 41/42 0 3 1.450
Max. operating
pressure
Purification
system
No.
stages
Speed
approx.
Motor / motor output
3-phase current,
400 V, 50 Hz ²
3-phase current,
400 V, 50 Hz ²
3-phase current,
400 V, 50 Hz ²
Net weight
approx.
5,5 185 130 x 65 x 81
5,5 185 130 x 65 x 81
7. 5 15 4 130 x 65 x 81
Dimens.
L x W x H
Page 4
INTERESTED IN OUR
PRODUCTS?
CONTACT US – WE ARE HAPPY TO PROVIDE
INFORMATION AND ASSISTANCE.
BAUER KOMPRESSOREN GmbH
Stäblistr. 8
81477 Munich, Germany
Tel. +49 (0) 89 78049-0
Fax +49 (0) 89 78049-167
info@bauer-kompressoren.de
bauer-kompressoren.de
PROFI LINE EN
N44742
05.2022
Subject to technical change without notice
