BaudTec TW263HR4 Quick Installation Manual

Powerline Wireless

ADSL2+ Router

Powerline WLAN ADSL2+ Router

System Requirements

1. Pentium 200MHZ processor or above

2. Windows 98SE, Windows Me, Windows 2000, Windows XP and
Windows Vista.

3. 64MB RAM or above.

4. 25MB free disk space

Package Contents

For Annex-B Powerline WLAN ADSL2+ Router

1. Powerline WLAN ADSL2+ Router

2. CD-ROM (Software & Manual)

3. Quick Installation Guide

4. Telephone Cable (RJ-11)

5. Ethernet Cable (RJ-45)

6. Power cord

7. Annex-B ATF057 Splitter (Optional, with an extra RJ-11
Telephone cable)

Installation & Setup

Follow each STEP carefully and only go to the next step
once you have complete the previous STEP.

STEP 1

Connection of Powerline WLAN ADSL2+ Router

If you have an

ISDN telephone line connect to the Powerline

WLAN ADSL2+ Router as shown below:

If you have a PSTN telephone line connect to the Powerline

WLAN ADSL2+ Router as shown below:

1. Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port
to any of the 4 Powerline WLAN ADSL2+ Router's LAN Ports.

2. Connect the supplied RJ11 telephone cable from your home's telephone
jack to the “LINE” port of the supplied splitter. Connect another RJ11

LED Meaning

Your Powerline WLAN ADSL2+ Router has indicator lights on the front side.
Please see below for an explanation of the function of each indicator light.

● PWR : Power indicator

● @ACT : ADSL Active indicator

● @LINK : ADSL Link indicator

● 10/100Mbps 1~4 : Ethernet active indicator

●

: Wireless active indicator

●

: Powerline active indicator

Rear panel connection

ADSL:

to connect the ADSL / ADSL2+ line input

LAN 1~4: to connect the Ethernet cable
Reset:

Reset button, to return the factory default settings if

STEP 2

Configuration Procedures

Before starting the Powerline WLAN ADSL2+ Router configuration, please
kindly configure the PC computer as below, to have automatic IP address /
DNS Server.

For Windows 98SE/ME/2000/XP

1. Click on "Start” -> “Control Panel” (in Classic View).In the Control

Panel, double click on "Network Connections" to continue.

3. Double click on "Internet Protocol (TCP/IP)".

4. Check "Obtain an IP address automatically" and “Obtain DNS

server address automatically” then click on "OK" to continue.

For Windows Vista-32/64

1. Click on "Start” -> “Control Panel” (in Classic View) -> “Network and

Sharing Center”. In the Manage network connections, double click on

"Manage network connections " to continue.

2. Single right click on “Local Area connection", then click "Properties".

4. Double click on "Internet Protocol Version 4(TCP/IPv4)"

5. Check " Obtain an IP address automatically " and “Obtain DNS server

address automatically” then click on " OK " to continue.

STEP 3

Powerline WLAN ADSL2+ Router Configuration

1. Please insert the supplied CD into your CD-ROM drive.

2. The CD should auto-start, displaying the window shown in 3. below. If

your CD does not start automatically go to Windows Explorer, Select
your CD drive and double click “setup.exe”

3. Please click “Ethernet connection” button to continue.

5. When the “information” screen pop-up, please click “OK” button,

to configure the WLAN setting, or click “EXIT” button to exit program.

6. Please enter the SSID and wireless channel if you want to change

(the default setting SSID=RT2561_6, Channel=6). Choose the
Authentication type if necessary, as Disable / WEP-64bits /

7. Please click on “Save configuration” button. When the procedure is

completed, the program will exit.

STEP 4

Connect Wirelessly

For easy installation it is saved to keep the settings. You can later change the
wireless settings via the wireless configuration menu. (see user manual on the
CD – Chapter 10 and other)

1. Double click on the wireless icon on your computer and search for the
wireless network that you enter SSID name.

2. Click on the wireless network that you enter SSID name to connect

3. Enter the network key that belongs to your authentication type and key.
You can later change this network key via the wireless configuration
menu. (see user manual on the CD – Chapter 10 and other)

4. Click on “Connect” or “Apply”

STEP 5

Installation of Powerline Utility

The Configuration Utility for Windows OS enables the users to identify
HomePlug devices on the Powerline network, measures data rate
performance, ensures privacy and performs diagnostics by setting user
defined secure Powerline networks.
Users are requested to verify that no other Encryption Management Utilities
are installed prior to the installation of this utility. Other utilities should be
uninstalled before installing this utility.
Note : The Utility Software doesn’t support Windows Vista-32 / 64 OS, but
Powerline features are running properly in Windows Vista-32 / 64 OS.

1. Please insert the supplied CD into your CD-ROM drive again.

2. The CD should auto-start, displaying the window shown in 3. below. If

your CD does not start automatically go to Windows Explorer, Select
your CD drive and double click “setup”

3. Please select “Powerline Utility”.

4. If you click the “Powerline Utility” button, the screen will appear as
shown in below. Click the “Next” button to continue.

5. Click the “Next” button

6. Click the “Next” button

7. Please click the “Install” button to continue.

8. Click the “OK” button

9. Click the “Finish” button

10. In order to start the utility, double-click the utility icon on screen.

11. You can see your device working well via the Utility. The top panel of the

screen shot shows a Turbo device connected locally to your computer.
The bottom panel shows four devices connected remotely to the
computer running the utility, which includes HomePlug 1.0 and Turbo
devices.
