Product code: BT6107DORB
BATHSELECT RIVERA LIGHT OIL RUBBED BRONZE
LED SHOWER SET INSTALLATION INSTRUCTIONS
PRIOR TO INSTALLATION
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
POSSIBLE TOOLS REQUIRED*
Plumbers Tape
Tape Measure
Level
Adjustable Wrench
Hex Wrench
Thread Sealant
Drill
Pencil or Marker
1
Screwdriver
*not included
bathselect.com
Customer Service: 800-500-9895
Page 2
Wall Mount Shower Installations Instructions
Step 1: Step 2:
Step 3: Step 4:
Step 5: Step 6:
2
bathselect.com
Customer Service: 800-500-9895
Page 3
Step 7:
1. Apply plumber's tape to the threads on both ends of the shower arm and slide on the
decorative escutcheon.
2. Insert the new arm into the fitting in the Wall and twist to tighten. Finish tightening
with your adjustable wrench. Wrap a dry cloth around the shower arm to protect the finish
while tightening with adjustable wrench.
3. Thread the new shower head onto the arm and hand-tighten. Hold the shower arm in
place with groove joint pliers and finish tightening the shower head with your adjustable
wrench. Wrap both in a dry cloth to protect the finish.
4. Before securing the decorative escutcheon, turn on the water supply to make sure that
all connections are tight and there is no leaking. If no leaks are detected, continue with the
installation. If leakage does occur, use your adjustable wrench to tighten the connections
as necessary.
5. Apply a bead if silicone sealant to the back of the escutcheon and press firmly into place
against the installation surface. Wipe away any excess sealant with your damp cloth.
3
Customer Service: 800-500-9895
bathselect.com
Page 4
Hand-Held Shower Installations Instructions
Step 1 Step 2
Step 3
Hand Shower Outlet Installation
• Complete the outlet pipework ensuring it ends in an appropriate 15mm x 1/2" BSP female thread elbow.
Note: This fitting is not supplied as variations in installations require the selection of a suitable solder or
compression fitting.
• Install the 'Wall Outlet', thread long male 1/2" BSP into the appropriate female fitting using PTFE tape to
give a watertight joint.
Note: The thread can be cut to size if required. Make sure that all debris is removed from the connector
and the section that has been cut is dressed correctly, before installation.
The minimum required water pressure is 0.05 MPa (0.5 bar).
Flow rate 2.5 GPM (9.5 LPM).
4
Customer Service: 800-500-9895
bathselect.com
Page 5
Mixer Installations Instructions
Step 2Step 1
Hot Cold
Step 3 Step 4
Step 5
Shower
Hand
Shower
Mixer
Hot Water
Inlet
5
Customer Service: 800-500-9895
Cold Water
Inlet
bathselect.com
Page 6
Acid
General Information
All products manufactured and supplied by BathSelect are safe and comply to legislative
requirements. Providing they are installed correctly and receive regular maintenance in
accordance with these instructions your user experience will not be affected
Care & Cleaning
1. The product can be cleaned with warm water, a mild soap and a clean soft cloth.
2. Clean progressively and gently.
3. It is not required to use any abrasive cleaning pads, wire wool or cloths to clean the
product.
4. Avoid a vigorous cleaning action, as this could contribute to denaturing and dulling
5. Abrasive or strong cleaning products containing ammonia, bleaches, alcohol, dyes,
acids (hydrochloric, formic, phosphorus, chlorine or acetic) will be not be affected.
6. If using a spray cleaner, apply the cleaning agent onto a soft cloth, never directly
spray onto the product as the cleaner may enter gaps and openings and cause
damage. Do not allow the cleaner to remain on the product for a period of time. After
cleaning, rinse thoroughly with clean water.
6
Customer Service: 800-500-9895
bathselect.com
