Overall Dimensions:
Length: 112”
Width: 51”
Height: 74”
Wheel Base: 82”
Chassis Clearance: 9”
Weight:
1.5 to 3 tons
Transmission:
Type: Hydrostatic
Drive: Chain
Control: Shuttle lever
Braking:
Drive Brake: Hydrostatic
Parking Brake: Mechanical
Water System:
Tank Capacity: 70 gallons
Type: Pressurized
Manufactured By:
Shannon Chastain Enterprises, Inc. reserves the right to change specifications without notice in an effort to improve product quality.
Steering:
Hydraulic power steering
Tire Size:
7.5-15 6Ply
Engine:
Tier 4 Final
24.8 hp D1105 Kubota
Water cooled diesel engine
Travel Speed:
0-6mph Variable
Safety Features:
ISO Certified folding ROPS
w/Seatbelt
97 Decibel Back Up Alarm
Neutral Safety Start Position
Options:
Safety Beacon
Work Lights
Horn
Aluminum Shade Canopy
Features..
7 Wheel design creates greater compaction
Centered operator on small job sites
Excellent maneuverability on small job sites
Ideal for parking lots and driveway work
Simplistic design and construction allows for
longer machine life and easier repair
All wheels oscillate independently allowing
100% surface contact at all times
Seams and steel drum roller marks are blended
away by machines pneumatic tires creating a
more professional looking finished job
Consistent compaction across work surface
helps eliminate potholes from occurring and
causing costly warranty repairs.
