Basic
Will it Work for My Project?
#1 Remove one endcap and the front panel of
your existing baseboard heater.
#2 Measure between the floor and the top of the
heater.
• Objective: 7.5” or greater
• If less than 7.5” use the Baseboarders Wall Brackets (WB001) for
mounting.
#3 Measure from the bottom of the heating
element to the top of the heater.
• Objective: Between 5” and 6.75”
• If less than 5” use the Baseboarders Wall Brackets (WB001) for
mounting.
• If the distance is greater than 6.75”, the Baseboarders Premium
TALL (BB003) panel should be used.
#4 Measure from the outside face of the fi nned
tube heating element to the back plate.
• Objective: Less than 3.25”
• If larger 4” x 4” or 4” x 6” commercial style element is in place, a
wood molding will solve the depth issue.
If your measurements fi t within all these
objectives then Baseboarders Basic, Premium
Elliptus
Premium
or Elliptus can be used for your application.
Basic
Premium
Will it Work for My Project?
#1 Remove one endcap and the front panel of
your existing baseboard heater.
#2 Measure between the floor and the top of the
heater.
• Objective: 7.5” or greater
• If less than 7.5” use the Baseboarders Wall Brackets (WB001) for
mounting.
#3 Measure from the bottom of the heating
element to the top of the heater.
• Objective: Between 5” and 6.75”
• If less than 5” use the Baseboarders Wall Brackets (WB001) for
mounting.
• If the distance is greater than 6.75”, the Baseboarders Premium
TALL (BB003) panel should be used.
#4 Measure from the outside face of the fi nned
tube heating element to the back plate.
• Objective: Less than 3.25”
• If larger 4” x 4” or 4” x 6” commercial style element is in place, a
wood molding will solve the depth issue.
If your measurements fi t within all these
objectives then Baseboarders Basic, Premium
Elliptus
Premium
or Elliptus can be used for your application.
Basic
Premium TALL
Will it Work for My Project?
#1 Remove one endcap and the front panel of
your existing baseboard heater.
#2 Measure from the bottom of the heating
element to the top of the heater.
• Objective: Distance greater than 6.75”
#3 Measure from the outside face of the fi nned
tube heating element to the back plate.
• Objective: Less than 3.25”
• If larger 4” x 4” or 4” x 6” commercial style element is in place, a
wood molding will solve the depth issue.
If your measurements fi t within all these
objectives then Baseboarders Premium TALL
should be used for your application.
Premium TALL
Elliptus
Will it Work for My Project?
#1 Remove one endcap and the front panel of
your existing baseboard heater.
#2 Measure between the floor and the top of the
heater.
• Objective: 7.5” or greater
• If less than 7.5” use the Baseboarders Wall Brackets (WB001) for
mounting.
#3 Measure from the bottom of the heating
element to the top of the heater.
• Objective: Between 5” and 6.75”
• If less than 5” use the Baseboarders Wall Brackets (WB001) for
mounting.
• If the distance is greater than 6.75”, the Baseboarders Premium
TALL (BB003) panel should be used.
#4 Measure from the outside face of the fi nned
tube heating element to the back plate.
• Objective: Less than 3.25”
• If larger 4” x 4” or 4” x 6” commercial style element is in place, a
wood molding will solve the depth issue.
If your measurements fi t within all these
objectives then Baseboarders Basic, Premium
Elliptus
Premium
or Elliptus can be used for your application.
Basic
Basic
Panel Measurements
Premium
Panel Measurements
Premium TALL
Panel Measurements
Elliptus
Panel Measurements
Basic
Easy Slip-On Installation
Installation is an easy DIY project, requiring no tools or hired help.
1
2
3
4
Remove existing baseboard heater endcaps and front cover panel
Snap your new Baseboarders endcaps onto your Baseboarders panel
Position the Baseboarders assembly onto the original back plate & push down firmly into place
That’s it – You’re done!
Premium
Easy Slip-On Installation
Installation is an easy DIY project, requiring no tools or hired help.
1
2
3
4
Remove existing baseboard heater endcaps and front cover panel
Snap your new Baseboarders endcaps onto your Baseboarders panel
Position the Baseboarders assembly onto the original back plate & push down firmly into place
That’s it – You’re done!
Premium TALL
Easy Slip-On Installation
Installation is an easy DIY project, requiring no tools or hired help.
1
2
3
4
Remove existing baseboard heater endcaps and front cover panel
Snap your new Baseboarders endcaps onto your Baseboarders panel
Position the Baseboarders assembly onto the original back plate & push down firmly into place
That’s it – You’re done!
Elliptus
Easy Slip-On Installation
Installation is an easy DIY project, requiring no tools or hired help.
1
2
3
4
Remove existing baseboard heater endcaps and front cover panel
Snap your new Baseboarders endcaps onto your Baseboarders panel
Position the Baseboarders assembly onto the original back plate & push down firmly into place
That’s it – You’re done!
Basic
Available Accessories
Baseboarders Basic Closed Endcap - Right Side
EC004-RT-WHT
Baseboarders Basic Closed Endcap - Left Side
EC004-LF-WHT
Baseboarders Basic Inside 90 Degree Corner
IC004-WHT
Baseboarders Basic Coupler
CP004-WHT
Overlaps two panels that are butted up together to create a
longer panel.
Baseboarders Wall Bracket (screw included)
WB001-WHT
Used when the original baseboard heater back plate has
been removed, when the original back plate is less than
7.25” in height, or in new construction environments.
Premium
Available Accessories
Baseboarders Premium Zero Clearance
Endcap - ZC001-WHT
Baseboarders Premium Closed Endcap
Right Side - EC001-RT-WHT
Baseboarders Premium Inside 90
Degree Corner - IC001-WHT
Baseboarders Premium Open Endcap
Left Side - EC002-LF-WHT
Baseboarders Premium Inside 135
Degree Corner - IB001-WHT
Baseboarders Premium Open Endcap
Right Side - EC002-RT-WHT
Baseboarders Premium Closed Endcap
Left Side - EC001-LF-WHT
Baseboarders Premium Outside 90
Degree Corner - OC001-WHT
Baseboarders Premium Outside 135
Degree Corner - OB001-WHT
Baseboarders Premium Coupler
CP001-WHT
Overlaps two panels that are butted up
together to create a longer panel.
Baseboarders Wall Bracket (screw
included) - WB001-WHT
Used when the original baseboard heater
back plate has been removed, when the
original back plate is less than 7.25” in
height, or in new construction environments.
Premium TALL
Available Accessories
Baseboarders Premium TALL Zero
Clearance Endcap - ZC003-WHT
Baseboarders Premium TALL Outside
90 Degree Corner - OC003-WHT
Baseboarders Premium TALL Inside 90
Degree Corner - IC003-WHT
Baseboarders Premium TALL Closed
Endcap Right Side - EC007-RT-WHT
Baseboarders Premium TALL Inside
135 Degree Corner - IB003-WHT
Baseboarders Premium TALL Closed
Endcap Left Side - EC007-LF-WHT
Baseboarders Premium TALL Outside
135 Degree Corner - OB003-WHT
Baseboarders Premium TALL Open
Endcap Left Side - EC008-LF-WHT
Baseboarders Premium TALL Open
Endcap Right Side - EC008-RT-WHT
Baseboarders Premium TALL Coupler
CP003-WHT
Overlaps two panels that are butted up
together to create a longer panel.
Baseboarders Wall Bracket
(screw included) - WB001-WHT
Used when the original baseboard heater
back plate has been removed, when the
original back plate is less than 7.25” in
height, or in new construction environments.
Elliptus
Available Accessories
Baseboarders Elliptus Zero Clearance
Endcap - ZC005-WHT
Baseboarders Elliptus Open Endcap
Left Side - EC006-LF-WHT
Baseboarders Elliptus Closed Endcap
Left Side - EC005-LF-WHT
Baseboarders Elliptus Inside 90 Degree
Corner - IC005-WHT
Baseboarders Elliptus Closed Endcap
Right Side - EC005-RT-WHT
Baseboarders Elliptus Coupler
CP005-WHT
Baseboarders Elliptus Open Endcap
Right Side - EC006-RT-WHT
Baseboarders Wall Bracket
(screw included) - WB001-WHT
Overlaps two panels that are butted up
together to create a longer panel.
Used when the original baseboard heater
back plate has been removed, when the
original back plate is less than 7.25” in
height, or in new construction environments.
Basic
About Basic Panels
2 Year Warranty
The Basic product line was created to maximize value. It contains the most common
panel lengths and is offered with standard accessories.
✓
✓
3’, 4’, 5’ & 6’ standard panel lengths
Primary Accessories: Closed Endcaps, Inside Corners & Couplers
Premium
About Premium Panels
Lifetime Warranty
The Premium line offers the most flexibility and will solve most installation
challenges. This line provides every common length and accessory you may need.
✓
✓
✓
2’, 3’, 4’, 5’, 6’ & 7’ standard panel lengths
Primary Accessories: Closed Endcaps, Inside Corners & Couplers
Additional Accessories: Open Endcaps, Zero Clearance Endcaps, Inside Corners and Outside Corners (90° & 135°)
Premium TALL
About Premium TALL Panels
Lifetime Warranty
The Premium TALL product line is identical to the Premium Series in all aspects except
all components are 2” taller. This line provides every common length and accessory
you may need.
✓
✓
✓
2’, 3’, 4’, 5’, 6’ & 7’ standard panel lengths
Primary Accessories: Closed Endcaps, Inside Corners & Couplers
Additional Accessories: Open Endcaps, Zero Clearance Endcaps, Inside Corners and Outside Corners (90° & 135°)
Elliptus
About Elliptus Panels
Lifetime Warranty
The Elliptus is the first baseboard radiator cover to use the gentle curve of an ellipse
to add elegance to baseboard heaters.
✓
✓
✓
2’, 3’, 4’, 5’, 6’ & 7’ standard panel lengths
Primary Accessories: Closed Endcaps, Inside Corners & Couplers
Additional Accessories:Open Endcaps & Zero Clearance Endcaps
