Basbau BB204 User Manual [it]

3.5 '' LCD Wireless

Video Baby Monitor

ENGLISH

User's Manual

Manuel de l'utilisateur

Manual del Usuario

Bedienungsanleitung

Manuale d'uso

FRANÇAIS

ESPAÑOL

DEUTSCH

ITALIANO

Figures and Quick Guide / Figures et Guide d'utilisation rapide / Figuras y guía rápida / Abbildungen und Schnellanleitung / Figure e Guida rapida

Product Layout / Description du produit / Esquema del producto

/ Produktübersicht / Struttura del prodotto

Camera / Caméra / Cámara / Kamera / Telecamera

3 4

Fig. 1

Monitor / Moniteur

Fig. 2

12 13 14 15 16

8 9

17 18

5 6

Setup / Installation / Configuración / Einrichtung / Installazione

Camera Setup / Installation de la caméra / Configuración de la cámara

/ Kameraeinrichtung / Installazione della telecamera

1.1

Power Supply - Using AC Power Alimentation - Avec alimentation secteur Fuente de alimentación - Utilizar la alimentación de CA Stromversorgung – über Netzstrom Alimentazione - Uso dell'alimentazione CA

Fig. 3

1.2

Fine Tuning / Réglages précis / Enfoque / Feineinstellung / Regolazione

Fig. 4

Monitor Setup / Installation du moniteur / Configuración del monitor

/ Monitoreinrichtung / Installazione del monitor

2.1

Power Supply / Alimentation / Fuente de alimentación / Stromversorgung / Alimentazione

Loading the Battery / Installation de la batterie / Insertar las pilas / Akku einlegen / Inserimento delle batterie

Fig. 5

Using AC Power / Utilisation de l'alimentation secteur / Uso de la alimentación de CA / Netzstrom verwenden / Uso dell'alimentazione CA

Fig. 6

Out o f Range

iii

2.2

Volume Setting / Réglage du volume / Configuración del volumen / Lautstärkeeinstellung / Impostazione del volume

Fig. 7

2.3

Brightness Setting / Réglage de la luminosité / Configuración del brillo / Helligkeitseinstellung / Impostazione della luminosità

Fig. 8

2.4

Zoom in Function / Fonction de zoom / Función de zoom de ampliación / Vergrößern-Funktion / Funzione ingrandimento

Fig. 9

2.5

VOX (Voice-Operated Transmission) Function Fonction TCV (Transmission de Commande Vocale) Función VOX (transmisión de activación por voz) VOX-Funktion (geräuschaktivierte Übertragung) Funzione VOX (trasmissione attivata a voce)

Fig. 10

2.6

Music Function / Fonction de musique / Función de música

/ Musikfunktion / Funzione musica

Fig. 11

2.7

Talkback Function / Fonction de réponse

/ Función de intercomunicador / Gegensprechfunktion

/ Funzione interfono

Fig. 12

Menu Options / Options du menu / Opciones del menú

/ Menüoptionen / Opzioni del menu

Fig. 13

3.1

Camera Selection / Sélection de la caméra / Selección de la cámara / Kameraauswahl / Selezione telecamera

Fig. 14

3.2

Feed Timer Setting / Paramètre du minuteur d'alimentation / Configuración del temporizador para las comidas / Fütterungstimer-Einstellung / Impostazione timer alimentazione

Fig. 15

3.3

Temperature Setting / Réglage de la température

/ Configuración de la temperatura / Temperatureinstellung / Impostazione temperatura

Fig. 16

3.4

Camera Setting / Paramètre caméra / Configuración de la cámara / Kameraeinstellung / Impostazione videocamera

Fig. 17

3.5

VOX Sensitivity / Sensibilité VOX / Sensibilidad de VOX / VOX-Empfindlichkeit / Sensibilità VOX

Fig. 18

vii

Status Information / Informations de statut

/ Información de estado / Statusinformationen / Informazioni di stato

2 3 4 5 6 8 91 7

Fig. 19

viii

Package Contents

One Camera One Monitor Two Power Adapters Battery for Monitor ( 3.7V 1100mAh Li-ion )

Two Cable Clips One Screw and One Wall Anchor

Velcro System User's Manual

Product Layout

Camera (Fig. 1)

1. Light sensor

2. Microphone

3. Lens

4. Infrared LEDs

5. Speaker

6. Power adapter plug

7. Power/Pairing button

8. Antenna

9. Temperature sensor

10. Power indicator LED

ENGLISH

Monitor (Fig. 2)

1. LCD screen

2. Brightness down button

3. Volume up button

4. Zoom/OK button

5. Brightness up button

6. Volume down button

7. Speaker

8. Microphone

9. Power indicator LED

10. VOX indicator LED

11. Volume indicator LEDs

12. Power/VOX button

13. Music button

14. VOX button

15. Talkback button

16. Menu button

17. Battery compartment

18. Holder

19. Power adapter plug

Setup

1.1

1.2

1.3

1.4

Camera Setup

Power Supply - Using AC Power

1. Plug one end of the provided power adapter into a wall outlet and the other end into the back of the camera. See Fig. 3.

Note : Use the adapter labeled OUTPUT: 6V DC with the camera.

2. Press the POWER button and keep it around 3 seconds to turn on the camera. The LED on the camera will light up (green light). See Fig. 3.

Note : Press the POWER button and keep it around 3 seconds to turn off

the camera.

Fine Tuning

Place the camera in a convenient location, point the lens toward the observation area and adjust the angle by rotating the lens head. See Fig. 4.

Night Vision

The camera has eight high-intensity LEDs for picking up clear images in the dark. When the light sensor detects low ambient light levels, the LEDs will be automatically activated.

Room Temperature Measurement

Temperature sensor can measure room temperature on camera side and the room temperature indicator will be displayed on the screen of the monitor unit.

2.1

Monitor Setup

Power Supply

The monitor uses 3.7V 1100mAh (Li-ion) battery or the household AC power current.

Loading the Battery

1. Open the battery compartment cover on the rear of the monitor. See Fig. 5.

2. Insert the battery with the metal facing the battery compartment. See Fig. 5.

3. Close the battery compartment cover, and make sure it is locked securely.

4. Press the POWER button and keep it around 3 seconds to turn the

monitor on. See Fig. 5.

Note 1: When power is sufficient, the "Power/Charging" LED will light up (green light); When battery is low, the red LED light will start blinking. Note 2: Press the POWER button and keep it around 3 seconds to turn off the monitor.

Using AC Power

1. Plug one end of the provided power adapter into a wall outlet and the other end into the monitor. See Fig. 6.

Note : Use the adapter labeled OUTPUT: 6V DC with the monitor.

2. Press the POWER button and keep it around 3 seconds to turn the monitor on. See Fig. 6.

Note 1: When charging starts or power on the monitor, "Power/Charging" LED will light up (green light). Note 2: "Out of Range" will be displayed on the LCD screen if the monitor exceeds the range (unlink). Note 3: Press the POWER button and keep it around 3 seconds to turn off the monitor.

2.2

2.3

2.4

2.5

2.6

Volume Setting

Press the volume selection button & to adjust volume level, and then press the Zoom/OK button to confirm the setting. See Fig. 7.

Brightness Setting

Press the brightness selection button & to adjust brightness level, and then press the Zoom/OK button to confirm the setting. See Fig. 8.

Zoom in Function

Press the Zoom/OK button on monitor once for a 2X zoom of image and press again to change back to normal view. See Fig. 9.

VOX ( Voice-Operated Transmission) Function

1. Press the VOX button on the monitor unit. This will turn off the screen but VOX LED will remain ON (green). See Fig. 10.

2. When the sound from the camera reaches the setting level (See Fig. 18), the screen will turn ON automatically. It will turn OFF again after 30 seconds. If the sound from the camera still reaches the setting level during the 30 seconds, it will extend 30 seconds to turn OFF the screen from the last voice event.

Music Function

You can play the music with the camera (three pieces of music) .

1. Press the music button , the camera will play music. See Fig. 11.

2. Press the music button again, the camera will play the next song.

2.7

Talkback Function

Press the talkback button to speak through the camera unit, and the icon will then be displayed on the screen. See Fig. 12.

Menu Options

1. Press the menu button on the monitor unit to display the main menu on the screen. See Fig. 13.

2. Use the brightness down and brightness up buttons to navigate through the menu.

3. Press the Zoom/OK button to confirm a setting.

4. The main menu contains 5 submenus.

3.1

3.2

3.3

3.4

Camera Selection ( Camera Select )

In this submenu you can switch between multiple cameras if the cameras have been paired. See Fig. 14.

Feed Timer Setting ( Feed Timer )

In this submenu you can set up feed timer to remind you the timing. See Fig. 15.

Temperature Setting ( Temp. Setting )

1. In this submenu you can choose the temperature unit between degrees Celsius or degrees Fahrenheit. See Fig. 16.

2. You can set the temperature range of the temperature alert. If you select "Alert On" to enable the temperature alert and the temperature is outside

the range, a warning sound will be emitted from the monitor unit. See Fig. 16.

Camera Setting ( Camera Setting )

The system comes with a camera unit that has already been paired with the monitor unit. The "Cam Setting" function gives each baby unit a separate channel on the monitor unit. This is necessary for configuring additional camera units.

1. If you want to add a new camera, please choose which number of cameras you want to add, and then select add camera icon and press the button

to confirm your selection (See Fig. 17). The screen will show "Press the pairing button on the Baby unit" , and then

please also press and hold the power button less than 1 second on the camera side at the same time.

2. If you want to delete a paired camera, please choose which number of cameras you want to delete, and then select delete camera icon to delete the camera (See Fig. 17).

3.5

VOX Sensitivity ( VOX Sensitivity )

This submenu lets you choose the VOX (voice activation) sensitivity level. When the level set to high, the screen will turn on by lower sounds.

See Fig. 18.

Status Information

The status bar will be displayed on the top of the screen. See Fig. 19.

1. Signal strength indicator

2. Camera number indicator

3. Temperature alert on/off indicator

4. Room temperature indicator

5. Zoom in indicator

6. Music indicator

7. Feed timer

8. Talkback indicator

9. Battery status/Charging indicator

Troubleshooting

You don't getting any signal at all

 Make sure the camera and the monitor are turned on.  Make sure the power plugs are pushed all the way in.

If the signal is poor, or there is interference

 If there is a microwave oven in use in the path between the camera and monitor, remove the microwave oven or turn it off.

 Make sure the camera and the monitor are within range of each other (range of approximately 950 feet; 300 meters in a clear line of sight).

 If the power LED is on but only voice signal input is detected, the monitor can be in voice-activated mode. Press the VOX button to turn on the screen.

Care and Maintenance

 Keep all parts and accessories out of children's reach.

 Fingerprints or dirt on the lens surface can adversely affect camera

performances. Avoid touching the lens surface with your fingers.

 Should the lens become dirty, use a blower to blow off dirt and dust, or a

soft, dry cloth to wipe off the lens.

 Keep the camera dry. Precipitation, humidity, and other liquids contain

minerals will corrode electronic circuits.

 Do not use or store in dusty, dirty areas.  Do not store in hot areas. High temperatures can shorten the life of

electronic devices and warp or melt certain plastics.

 Do not store in very cold areas. When the system warms up (to its normal

temperature), moisture can form inside the case, which may damage electronic circuit boards.

 Do not attempt to open the case. Non-expert handling of the device may

damage the system.

 Avoid dropping or strong shocks.  Operate this product using only with the power supply included or provided

as an accessory.

 Do not overload electrical outlets or extension cords this can result in fire

or electric shocks.
