Bedienungsanleitung
Instruction manual
Mode d’emploi
V2/0311
860.000
Wandascher, schwarz
Seite 3 bis 4
Wall-mounted ashtray, black
from page 5 to 6
Cendrier mural, noir
de page 7 à page 8
D/A/CH
GB/UK
F/B/CH
- 1 -
Holes in
GB/UK
PRODUCT DESCRIPTION:
---------------------------------------------------------------------------
Description: ●
Article Number: ●
Style: ● sheet steel casing, painted black
Dimensions: ● W 160 x D 90 x H 200 mm
Weight: ● 1.1 kg
Accessories: ● 4 crosshead screws 3.9 x 25 mm,
4 raw plugs 6 mm
---------------------------------------------------------------------------
MOUNTING INSTRUCTIONS:
Wall-mounted ashtray, black
860.000
the wall
Raw plugs
• Open the wall ashtray and take out the ash compartments.
• Drill 4 holes in the required position with a 6mm stone drill.
• Place the 4 raw plugs in the holes.
• Affix the wall ashtray using the screws provided.
• Position the ash compartment inside the wall ashtray.
• Lock the wall ashtray back into position.
Screws
- 5 -
