Name:
Serving trolley TSA300V
Art. No.:
300055
Material:
plastic, aluminium
Number of shelves:
3
Shelf dimensions (W x D), in mm:
785 x 485
Clearance between shelves, in mm:
295
Max. load-bearing capacity per shelf, in
kg:
40
Max. total load-bearing capacity, in kg:
120
Number of swivel casters:
4
Locking swivel casters:
2
Diameter of swivel casters, in mm:
100
Number of caster dampers:
4
Material of caster dampers:
plastic
Dimensions (W x D x H), in mm:
1000 x 495 x 920
Weight, in kg:
15,4
Technical Data
We reserve the right to implement technical modifications.
300055 3 / 10
EN
Version / Characteristics
• Colour: black
• Delivery form: self-assembly set, simple assembly
• Purpose:
– transportation
– serving
– cleaning
• Version: shelves
• Housing: 3-sided
• Rim: at 3 sides
• With handles
<Endergebnis>
Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Cleaning and transporting dishes.
– Serving dishes.
4 / 10 300055
EN
Cleaning container set TSA300V
for serving trolley TSA300V
Waste container:
W 343 x D 230 x H 440 mm
Cutlery container:
W 333 x D 230 x H 173 mm
Weight: 2.0 kg
Art. No. 300061
Fig. 1
Accessories (not included in the delivery)
300055 5 / 10
EN
No.
Name
Number
1
Handle
2x
2
Top shelf
1x
3
Handle bolt
4x
4
Rear wall (large)
2x
5
Side wall (small)
4x
6
Spacer
8x
7
Centre shelf
1x
8
Bottom shelf
1x
9
Swivel casters
4x
10
Cover (optional for 1-handle assembly)
2x
Scope of Delivery / Part Name
1. Unpack the serving trolley and remove the packing material pursuant to
environmental regulations.
2. Check completeness of delivery according to the list below and Fig. 2:
6 / 10 300055
EN
Fig. 2
300055 7 / 10
EN
4. First, place the back wall (4), inserting it into
the slots provided in the spacers (6).
5. In the same way, fit the side walls (5) on the
right and left sides into the spacers (6)
(Fig. 3).
6. Make sure that all the walls engage well in
the slots.
Fig. 3
Assembly
1. Under each shelf, check the marking for the bottom, centre or top shelves.
2. Start assembly with the bottom shelf (8, Fig. 2).
3. Place 4 spacers (6) in the corners of the bottom shelf.
NOTE!
Use a rubber mallet to hammer each spacer down until there are no gaps
between the spacers and the corner fixings of the bottom shelf.
7. Next, place the centre shelf (7) over the spacers (6).
8. Place 4 further spacers (6) in the corners of the centre shelf (7). Use a rubber
mallet to fix the spacers correctly.
9. Repeat steps 4 and 5 to fix the back and side walls.
10. Before fitting the top shelf (2) to the serving trolley, fix both handles (1) onto it.
11. Secure the handles in the lower holes of the top shelf with the screws (3)
provided.
12. Now, using a rubber mallet, fix the top shelf (2) with the handles (1) fitted onto
the spacers (6).
13. If only one handle will be used instead of two, note the notch in the upper part —
see Fig. 1.
A – optional covers (10) for the serving trolley with one handle.
B – with handle screw when using covers.
8 / 10 300055
EN
14. Lay the serving trolley on its side.
15. Use a rubber mallet to fix the swivel casters (9)
to the bottom shelf (8) of the serving trolley.
16. Place the serving trolley on the swivel casters.
Fig. 4
Fig. 5
Loading the Serving Trolley
1. The serving trolley with 3 shelves can be used for serving, cleaning and
transporting.
2. Place dishes, cutlery etc. on the shelves of the serving trolley as required.
Rims on the shelves prevent the transported items from slipping.
Thanks to the three-sided housing, the trolley hides transported items, such as dirty
dishes, from view.
300055 9 / 10
EN
ATTENTION!
For cleaning, do not use any scouring agents containing solvents nor
corrosive cleaning agents. They may damage the surface.
Cleaning
1. Clean the serving trolley regularly with warm water and a soft, damp cloth. Use
a mild cleaning agent when required.
2. Dry the serving trolley with a soft cloth.
10 / 10 300055
