Bartscher Paper towel dispenser ILZF10 Operating instructions

ILZF10

850006

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany

Phone: [phone]
Fax: [phone]
Service hotline: [phone]
www.bartscher.com

Version: 2.0
Date of preparation: 2023-07-28

Original instruction manual

EN

EN

Name:

Paper towel dispenser ILZF10

Article number:

850006

Material:

chrome nickel steel, brushed

Dimensions (W x D x H), in mm:

285 x 100 x 370

Weight in kg:

1,9

Technical Specifications

We reserve the right to implement technical modifications!

Version / Characteristics

• Version: wall-mounting

• Refillable

• Filling level check: viewing slot

• Loaded via the front flap

• Suitable for standard folded paper towels

• Paper towels folded the following way:
– Interfold folding
– Layer folding
– Zig-zag folding

• Lockable

• The set includes: attachment material (four-point attachment)

• The set does not include: filling

850006 3 / 6

EN

1. Lock

2. Front flap

3. Filling check viewing slot

4. Dispensing opening

2. Open the front flap of the paper towel dispenser
with the key included.

3. Use the fixing plate as a pattern and mark on the
wall and at the required height 4 spots for holes.

4. Bore 4 holes in the wall and put the supplied
pegs inside.

5. Use the included bolts to screw the paper towel
dispenser to the wall.

B

List of Components of the Appliance

Assembly

1. Unpack the paper towel dispenser and remove the entire packaging material.

4 / 6 850006

EN

NOTE!

When filling, pat attention to the direction of folding towels. Place them
in a way shown below.

Layer folding

Zig-zag folding

Interfold folding

Suitable paper towels

850006 5 / 6

EN

1. Open the front flap.

2. Fill the dispenser with suitable paper towels.

3. Close the front flap.

4. Use the key open the paper towel dispenser.

5. Take paper towels from the bottom dispensing
opening according to your needs.

The viewing slot in the front flap makes it possible
to check filling level.

ATTENTION!

Never use aggressive nor coarse cleaning agents which may scratch
the surface.

Filling/dispensing paper towels

Cleaning

1. Use a soft, damp cloth to wipe the inside and the outside surface of the paper
towel dispenser.

2. Finally, dry the cleaned surfaces with a soft cloth.

6 / 6 850006
