Bartscher Multi-Blender operation manual

V1/

0315

150151

GB/UK

ENGLISH
Translation
of the original instruction manual

Table of contents

1.Safety ........................................................................................................................ 18

1.1 Safety instructions ................................................................................................ 18

1.2 Key to symbols ..................................................................................................... 19

1.3 Hazard sources .................................................................................................... 20

1.4 Proper use ............................................................................................................ 22

2. General information ................................................................................................ 23

2.1 Liability and Warrantees ....................................................................................... 23

2.2 Copyright protection ............................................................................................. 23

2.3 Declaration of conformity ...................................................................................... 23

3. Transport, packaging and storage......................................................................... 24

3.1 Delivery check ...................................................................................................... 24

3.2 Packaging ............................................................................................................. 24

3.3 Storage ................................................................................................................. 24

4. Technical data ......................................................................................................... 25

4.1 Overview of parts ................................................................................................. 25

4.2 Technical specification ......................................................................................... 26

5. Installation and operation ....................................................................................... 27

5.1 Installation ............................................................................................................ 27

5.2 Operation .............................................................................................................. 28

6. Cleaning ................................................................................................................... 30

7. Possible Malfunctions ............................................................................................ 31

8. Waste disposal ........................................................................................................ 32

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]

- 17 -

Read this instruction manual before using and
keep them available at all times!

This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.

Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.

In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.

The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.

1.Safety

This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.

All persons using the device must follow the recommendations and instructions
in this instruction manual.

1.1 Safety instructions

• Please keep these instructions and give them to future owners of the device.

• Do not use the device in case it does not function properly, has been damaged or

dropped.

• The unit is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the unit.

• Children should be observed to ensure that they are not playing with the unit.

• Only a qualified technician and using original spare parts and accessories should

carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.

• Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.

- 18 -

• To prevent hazards and to ensure optimum efficiency, no modifications or alterations
to the device that are not explicitly approved by the manufacturer may be undertaken.

• Never allow the power cable to come into contact with heat sources or sharp edges.
The power cable should not hang over the side of the working surface. Ensure that no
one can step on or trip over the cable.

• The power cable must not be folded, bent or tangled, and must always remain fully
unrolled.

• Never place the device or other objects on the power cable.

• Do not lay the cable over carpets or heat insulations. Do not cover the cable.

Keep away the cable from operating range and do not dunk it into water.

• Inspect the power cable regularly for damage. Never use the device if the cable is
damaged. If the power cable is damaged, have an authorised service center or
qualified electrician replace it.

• The device is not adapted for use with an external timer or remote control.

• Never leave the device unattended when in use.

• Do not move or tilt the device when in operation.

• Only use the device indoors.

1.2 Key to symbols

In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to
avoid any risk of accident, personal injury or material damage.

WARNING!

This symbol highlights hazards which could lead to injury.

 To avoid them please follow the instructions very carefully and proceed with

particular attention in these cases.

WARNING!

This symbol highlights dangerous situations which could lead to injury or death.

 To avoid them please follow the instructions very carefully and proceed with

particular attention in these cases.

- 19 -

CAUTION!

This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.

 To avoid them please follow the instructions very carefully and proceed with

particular attention in these cases.

NOTE!

This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.

1.3 Hazard sources

DANGER!

Electric shock hazard!

To avoid the hazard results please follow the safety instructions below.
 Do not use the device in case of incorrect operation, damages or dropping on the

floor. When the cable is damaged it should be replaced by the service company or
qualified electrician in order to avoid the hazards.

 The supply cable must be disconnected from the socket only by pulling the plug.
 Never carry or lift the device by the supply cable.
 In any case do not open the device housing. In case of electrical or mechanical

modifications the electric shock hazard will occur.

 Never immerse the plug in water or other liquids.
 Do not use any acid agents and make sure no water ingresses the device.
 Never operate the device with moist hands or standing on wet floor.
 Remove the plug from its socket:

- when the device is not used,

- in case of anomalies during operation,

- before cleaning.

- 20 -

DANGER!

Suffocation hazard!

 Prevent access of children to the package materials like plastic bags and

foamed polystyrene elements.

WARNING!

Injury hazard!

To avoid the hazard results please follow the safety instructions below.
 Never place your hands, spoons, or other kitchen utensils in the blending tumbler

during the device operation. They may be caught by the knives leading to
lacerations, fractures, or other injuries.

 The device must be always activated after closing the lid.
 The knife in the tumbler is very sharp, so it is required to maintain caution during

emptying, washing, or inspecting the knife.

 When there are hot ingredients in the blending tumbler, it should be grabbed by the

handle, using the protective gloves when required.

CAUTION!

In order to avoid any damages of the device follow the instructions below.

 In order to avoid the damages of the motor block, blending tumbler, and the knife

system do not move or shake the device during its operation.

 When the device is supposed to stop the operation before 1 minute, deactivate it

with use of ON/OFF button, remove the tumbler from the motor block, release the
protective clamps, and remove the lid. Use the rubber spatula to carefully move the
tumbler content towards the knife. Refit the tumbler to the motor block, close the lid,
and restart the blending process.

 Never wash the device or its elements in the dishwasher.
 Inspect the blending tumbler and knife every day. Never use the damaged or

cracked tumbler.

 Inspect knife for wear and damages of the cutting blades. Never use the damaged

knife. In case of damages contact the vendor and replace the tumbler with the knife
system.
