Original
-
Gebrauchs
anleitung
MFG 7341 / 1582011
MFGO 7040 / 1582051
MFGO 7060 / 1582101
MFG 7360 / 1582201
V3/1020
GB/UK
ENGLISH
Table of contents
1. Safety ...................................................................................................................... 36
1.1 Key to symbols ................................................................................................... 36
1.2 Safety instructions .............................................................................................. 37
1.3 Intended use ...................................................................................................... 42
2. General information .............................................................................................. 43
2.1 Liability and Warrantees .................................................................................... 43
2.2 Copyright protection ........................................................................................... 43
2.3 Declaration of conformity ................................................................................... 43
3. Transport, packaging and storage ....................................................................... 44
3.1 Delivery check .................................................................................................... 44
3.2 Packaging .......................................................................................................... 44
3.3 Storage .............................................................................................................. 44
4. Overview of parts / Technical data ....................................................................... 45
5. Installation and operation ..................................................................................... 55
5.1 Installation instructions ....................................................................................... 55
5.1.1 Installation ................................................................................................. 55
5.1.2 Electric connection .................................................................................... 57
5.1.3 Gas connection.......................................................................................... 58
5.2 Tips for the user ................................................................................................. 62
5.2.1 First start-up .............................................................................................. 62
5.2.2 Operation elements ................................................................................... 62
5.2.3 Gas cooking surface .................................................................................. 63
5.2.4 Electric oven .............................................................................................. 64
6. Cleaning and maintenance ................................................................................... 66
7. Waste disposal ...................................................................................................... 68
Bartscher GmbH phone: +49 5258 971-0
Franz-Kleine-Str. 28 fax: +49 5258 971-120
33154 Salzkotten Service-Hotline: +49 5258 971-197
Germany www.bartscher.com
- 35 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
Please keep these instructions and give them to future owners of the device.
1. Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.
- 36 -
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.2 Safety instructions
•
The device is not intended for use by individuals (including
children) with physical or mental disabilities, insufficient
experience, and/or insufficient knowledge unless such persons
are under the care of a person responsible for their safety or
have received instructions regarding appropriate use of the
device.
•
Children should be observed to ensure that they are not playing
with or starting the device.
•
Never leave the device unattended when in use.
•
Only use the device indoors.
•
The device must be operated in correct and safe technical
condition only. In case of operational problems disconnect the
device from the power supply and contact the service company.
•
Prevent access of children to the package materials like plastic
bags and foamed polystyrene elements. Suffocation hazard!
- 37 -
Only a qualified technician and using original spare parts and
•
accessories should carry out repairs and maintenance of the
device. Do not attempt to repair the device yourself.
•
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous
for the user or lead to damages of the device or personal injury,
and further, the warranty expires.
•
To prevent hazards and to ensure optimum efficiency, no
modifications or alterations to the device that are not explicitly
approved by the manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the safety instructions
below.
•
Never allow the power cable to come into contact with heat
sources or sharp edges. The power cable should not hang over
the side of the working surface. Ensure that no one can step on
or trip over the cable.
•
The power cable must not be folded, bent or tangled, and must
always remain fully unrolled. Never place the device or other
objects on the power cable.
•
Do not cover the cable. Keep away the cable from operating
range and do not dunk it into water.
•
Inspect the power cable regularly for damage. Never use the
device if the cable is damaged. If the power cable is damaged,
have an authorised service center or qualified electrician
replace it.
- 38 -
The supply cable must be disconnected from the socket
•
only by pulling the plug.
•
Never carry or lift the device by the supply cable. Use the side
handles only.
•
In any case do not open the device housing. In case of
electrical or mechanical modifications the electric shock
hazard will occur.
•
Do not clean the device with water jets or pressure washer.
Water may penetrate the housing, damage the electric
elements, and cause electric shock.
•
Do not use any acid agents and make sure no water ingresses
the device.
•
Never operate the device with moist hands or standing on wet
floor.
•
Disconnect the device from the power supply:
- when the device is not used,
- in case of anomalies during operation,
- before cleaning.
WARNING gas supply hazards!
To avoid the hazard results please follow the safety instructions
below.
•
Never use the device in case of malfunction or damage and in
case of suspicion of malfunction or damage! In such a case,
set all gas control knobs to “OFF“ and close the main gas
valve! Contact technical service immediately.
- 39 -
In case of a smell of gas immediately close all gas control
•
knobs (set to “OFF“ position) and close the main gas valve.
Do not use open flame! Do not smoke cigarettes!
Do not activate any electrical switches!
Do not use any electrical devices!
Do not make any phone calls from this building – irrespec-
tive of the fact whether it is a fixed or mobile phone!
Ventilate the rooms properly: open all doors and windows
wide!
Immediately notify the gas supplier by calling him from the
outside of a given building!
•
Regularly control the tightness of the device. Never use open
flame for this purpose, but only soapsuds (leak detection agent).
•
During the operation of the device, children can neither come
close to the device nor play in its vicinity.
HOT SURFACE! Burn hazard!
To avoid the hazard results please follow the safety instructions
below.
•
During the device operation, the housing, gas burners, grates
and electric oven become very hot. During the operation only
touch the designated handles and switches.
•
After switching off the device, its surface remains hot for a long
time, therefore before cleaning the device wait until the device
fully cools down.
- 40 -
WARNING! Risk of fire or explosion!
To avoid the hazard please follow the safety instructions below:
•
Never use the device near flammable materials (e.g. petrol,
spirits, alcohol). High temperature may cause their evaporation
and as a result of contact with sources of ignition there may
occur a deflagration resulting in personal injury or property
damage.
•
Do not use the device near flammable objects, e.g. curtains or
wall cabinets.
•
Overheated fat and oil ignites very fast! Therefore, never leave
the device unattended during the preparation of meals with fats
or oils (e.g. fries)!
•
Never clean the device with use of flammable liquids. Vapours
may cause fire or explosion.
•
In case of fire, before taking relevant firefighting measures,
disconnect the device from the power supply and close the main
gas valve. When the fire has been extinguished ensure sufficient
fresh air inflow.
WARNING! Never use water for fire extinguishing when the
device is connected to the power supply. Electric shock hazard!
- 41 -
1.3 Intended use
CAUTION!
The device has been designed and built for commercial use and should be
operated only by qualified personnel in kitchen facilities.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The gas oven is intended only for preparing appropriate food products.
Do not use the device for heating of rooms.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.
- 42 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
- violation of advice concerning operation and cleaning;
- use other than designed;
- alterations made by user;
- use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.
- 43 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
If you liked to dispose the packing, consider the regulations applicable
in your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
- do not store outdoors,
- keep it dry and dust-free,
- do not expose it to aggressive media,
- do not expose it to direct sunlight,
- avoid mechanical shocks and vibration,
- in case of longer storage (> 3 months) make sure you check the state
of the packaging and the parts regularly, if required refresh or renew.
- 44 -
A 3,5 kW
4. Overview of parts / Technical data
MFG 7341 / 1582011
B A
A B
⑨
⑩
⑧
B 6,0 kW
①
④
②
③
⑦
Cast iron grate
①
Burners (4)
②
Operation elements
③
Shelves guides
④
Oven door
⑤
⑤
Oven door handle
⑥
Height-adjustable feet
⑦
Grate – shelf
⑧
Housing
⑨
Steam extractor
⑩
⑥
- 45 -
Name
Gas oven MFG 7341
with electric oven 2/1 GN
Art. no.:
Material: Stainless steel
Realization:
1582011
Operating mode: Gas / electric
Gas oven
Hobs:
- Number of hobs: 4
- Distribution of hobs: 2 x 3.5 kW, 2 x 6 kW
Gas type:
- Natural gas H
- Propane nozzles are enclosed
Ignition type: manual ignition
Pilot flame
Gas burner with ignition guard
Cast iron grille
Height-adjustable feet
Height-adjustable: 910 - 955 mm
Electric oven
Designed for 2/1 GN
3 guide levels
Top/bottom heat
Steam extractor
Oven temperature
adjustment range:
Gas power: 19.0 kW
100 °C – 300 °C
Electric power supply: 3.6 kW / 400 V 50/60 Hz 2 NAC
Dimensions device: W 800 x D 700 x H 910 mm
Dimensions electric oven: W 650 x D 580 x H 260 mm
Weight: 108.4 kg
Equipment:
We reserve the right to make technical changes!
- 46 -
1 grate, W 650 x D 530 mm
B 6,0 kW
MFGO 7060 / 1582101
B A B
A 3,5 kW
A B A
②
①
③
④
Cast iron grate
①
Gas burners (6)
②
Operation elements
③
Open sub-counter
④
Height-adjustable feet
⑤
⑤
- 47 -
Name
Gas oven MFGO 7060
with open sub-counter
Art. no.:
Material: Stainless steel
Realization:
Gas power: 28.5 kW
Dimensions device: W 1200 x D 700 x H 910 mm
1582101
Operating mode: Gas
Gas oven
Hobs:
- Number of hobs: 6
- Distribution of hobs: 3 x 3.5 kW, 3 x 6 kW
Gas type:
- Natural gas H
- Propane nozzles are enclosed
Ignition type: manual ignition
Pilot flame
Gas burner with ignition guard
Cast iron grille
Height-adjustable feet
Height-adjustable: 910 - 955 mm
Sub-counter
Type: open
Dimensions: W 1190 x D 630 x H 410 mm
Weight: 79.2 kg
We reserve the right to make technical changes!
- 48 -
MFGO 7040 / 1582051
B A
A B
A 3,5 kW
B 6,0 kW
②
①
③
④
⑤
①
②
③
④
⑤
Cast iron grate
Gas burners (4)
Operation elements
Open sub-counter unit
Height-adjustable feet
- 49 -
Name
Gas oven MFGO 7040
with open sub-counter
Art. no.:
1582051
Material: Stainless steel
Operating mode: Gas
Gas oven
Hobs:
- Number of hobs: 4
- Distribution of hobs: 2 x 3.5 kW, 2 x 6 kW
Gas type:
- Natural gas H
- Propane nozzles are enclosed
Realization:
Ignition type: manual ignition
Pilot flame
Gas burner with ignition guard
Cast iron grille
Height-adjustable feet
Height-adjustable: 910 - 955 mm
Sub-counter
Type: open
Dimensions: W 710 x D 620 x H 380 mm
Gas power: 19 kW
Dimensions device: W 800 x D 700 x H 910 mm
Weight: 56.4 kg
We reserve the right to make technical changes!
- 50 -
A 3,5 kW
MFG 7360 / 1582201
B A B
A B A
⑪
⑩
⑨
B 6,0 kW
⑤
②
①
③
④
⑧
⑥
Cast iron grate
①
Gas burners (6)
②
Operation elements
③
Open sub-counter unit
④
Shelves guides
⑤
⑦
Height-adjustable feet
⑥
Oven door handle
⑦
Oven door
⑧
Grate – shelf
⑨
Housing
⑩
Steam extractor
⑪
- 51 -
Name
Gas oven MFG 7360 with electric oven 2/1 GN
and open sub-counter
Art. no.:
Material: Stainless steel
Realization:
1582201
Operating mode: Gas / electric
Gas oven
Hobs:
- Number of hobs: 6
- Distribution of hobs: 3 x 3.5 kW, 3 x 6 kW
Gas type:
- Natural gas H
- Propane nozzles are enclosed
Ignition type: manual ignition
Pilot flame
Gas burner with ignition guard
Cast iron grille
Height-adjustable feet
Height-adjustable: 910 - 955 mm
Electric oven
Designed for 2/1 GN
3 guide levels
Top/bottom heat
Steam extractor
Oven temperature
adjustment range:
Gas power: 28.5 kW
100 °C – 300 °C
Electric power supply: 6.0 kW / 400 V 50/60 Hz 2 NAC
Dimensions device: W 1200 x D 700 x H 910 mm
Dimensions electric oven: W 650 x D 580 x H 260 mm
Dimensions open
sub-counter:
Weight: 129.4 kg
Equipment:
We reserve the right to make technical changes!
- 52 -
W 352 x D 535 x H 380 mm
1 grate, W 650 x D 530 mm
Gas pressure
Table 1 Gas categories in various countries
Country Categories Gas type
AT Austria II
BE Belgium II
BG Bulgaria II
CH Switzerland
CY Cyprus
CZ Czech Republic II
DE Germany
DK Denmark II
2H3B/P
2E+3+
2H3B/P
II
2H3B/P
II
2H3+
II
2H3B/P
II
2H3+
2H3+
II
2H3B/P
II
2ELL3B/P
2H3B/P
G20 - G30/G31 20 - 50/50
G20/G25 -
G30/G31
G20 - G30/G31 20 - 30/30
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31 20 - 28-30/37
G20 - G30/G31
G20 - G30/G31 20 - 30/30
G25
(mbar)
20/25 - 28-30/37
20 - 50/50
20 - 28-30/37
20 - 30/30
20 - 28-30/37
20 - 50/50
20
EE Estonia II
ES Spain II
FI Finland II
FR France II
United
GB
Kingdom
GR Greece
HR Croatia II
HU Hungary II
IE Ireland II
IS Iceland I
IT Italy II
LT Lithuania
LU Luxembourg I
2H3B/P
2H3+
2H3B/P
2E+3+
II
2H3+
II
2H3B/P
II
2H3+
2H3B/P
2HS3B/P
2H3+
3B/P
2H3+
II
2H3B/P
II
2H3+
2E
G20 - G30/G31 20 - 30/30
G20 - G30/G31 20 - 28-30/37
G20 - G30/G31 20 - 30/30
G20/G25 -
G30/G31
20/25 - 28-30/37
G20 - G30/G31 20 - 28-30/37
G20 - G30/G31
G20 - G30/G31
20 - 30/30
20 - 28-30/37
G20 - G30/G31 20 - 30/30
G20 - G30/G31
G25.1
25 - 30/30
25
G20 - G30/G31 20 - 28-30/37
G30/G31 30/30
G20 - G30/G31 20 - 28-30/37
G20 - G30/G31
G20 - G30/G31
20 - 30/30
20 - 28-30/37
G20 20
- 53 -
Gas pressure
Gas
Setting for
Ignition
Bypass
Country Categories Gas type
LV Latvia II
2H3B/P
G20 - G30/G31 20 - 30/30
(mbar)
MT Malta I
NL Netherlands II
NO Norway II
PL Poland II
PT Portugal II
RO Romania II
SE Sweden II
SI Slovenia
SK Slovakia
TR Turkey
3B/P
2L3B/P
2H3B/P
2WLwLs3B/P
2H3+
2H3B/P
2H3B/P
II
2H3B/P
II
2H3+
II
2H3B/P
II
2H3+
II
2H3B/P
II
2H3B/P
II
2H3+
G30/G31 30/30
G25 - G30/G31 25 - 30/30
G20 - G30/G31 20 - 30/30
G20/G27
G2.350
G30/G31
20/20
13
37/37
G20 - G30/G31 20 - 28-30/37
G20 - G30/G31 20 - 30/30
G20 - G30/G31 20 - 30/30
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
G20 - G30/G31
20 - 30/30
20 - 28-30/37
20 - 30/30
20 - 28-30/37
20 - 50/50
20 - 30/30
20 - 28-30/37
In the event of deviations from the values given above, proper functioning of the
device is not guaranteed.
Table 2 Nozzle and burner properties
Gas type
pressure
(mbar)
Nozzle
min/max
(GB, IE, GR - CAT. II
primary air
burner nozzle
(mm)
2H3+
)
nozzle
Burner 3.5 kW
G20 20 140 6 35 adjustable
G30/G31 28-30/37 92 8 20 45
Burner 6.0 kW
G20 20 185 4 35 adjustable
G30/G31 28-30/37 120 15 20 55
- 54 -
5. Installation and operation
5.1 Installation instructions
CAUTION!
All installation, connection, and maintenance works for the device, ventilation,
and combustion gas extraction devices must be performed by the qualified and
authorized technician according to the valid international, national and local
regulations.
• Read through these instructions carefully before the installation and operation.
• After receiving the device make sure that it has not been damaged during transport
and the package is not damaged. In case of damages or lack of parts it is required to
immediately inform the carrier, vendor/manufacturer and specify the article no. and
series no. (placed on the rating plate on the left external side of the device in case of
devices code-no. 1582011 and 1582201, or in the open sub-counter unit for devices
code-no. 1582101 and 1582051) and attach the photographical documentation.
• Make sure that there are no elements blocking the way to the installation place
through the doors, corridors, or other communication routes.
• CAUTION: The device may overturn during transport, which may damage the device
itself, other objects or cause the injuries. Use the means appropriate for the device
weight. The device should not be dragged or tilted, but lifted perpendicularly to the
ground and handled in the horizontal direction.
5.1.1 Installation
CAUTION!
According to the regulations the device must be installed only in
permanently ventilated rooms in order to prevent unacceptable
concentration of harmful combustion products in a room.
• The installation room must consist as much air as required for appropriate
combustion of gas. For appropriate combustion the intake air flux must not be
lower than 2 m3/h per kW of the rated device power (see rating plate on the
device). Moreover follow the safety regulations.
- 55 -
• Air must be taken directly from outside environment through the permanently
opened gaps or intake ducts connected with fresh air area.
• The device must be installed in the rooms adapted for combustion gas extraction.
The installation must be realized according to the valid standards.
• The devices belong to the following category:
Devices supplied with gas of category A and are not designed
for connecting to the combustion gas extraction system.
• The combustion gas produced by the devices must be removed with use of
appropriate hoods or other similar devices connected to efficient chimney stack or
directly outside.
• If there are no such devices the fan may be used for extracting the combustion gas
directly outside of power not lower than the recommended values.
• Before positioning the device check the dimensions and exact positions of the
electric and gas connections.
• Locate the device in a safe place, on a level surface capable of supporting the device's
weight with the maximum amount of food products.
• Never place the device on a flammable surface or one sensitive to high temperatures.
• Do not place the device near open flames, electric heaters or other heat sources.
• Never place the device directly next to walls, furniture or other objects made of
flammable materials. Keep a minimum distance of 200 mm from the sides and rear.
Keep a minimum distance of 600 mm between the upper surface of the device and
surfaces located above it. Proceed according to relevant fire safety regulations.
• If it is not possible to observe the above distances, apply protective measures
(e.g. heat-resistant coatings) that can resist temperatures of at least 65 °C.
Use only original spare parts!
• Regulate the level and height of the device with the adjustable legs. Large differences
in height or level may have a negative impact on the device's functioning.
- 56 -
5.1.2 Electric connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid specification
should be compared with that of the device (see rating plate).
Connect the device only in case of compliance!
• Before connecting the device make sure that the voltage and frequency values on
the rating plate are consistent with the existing electric installation.
The allowable voltage deviation is ±10%.
• Connect the device to the electric installation according to the valid international,
national, and local regulations.
• The device is equipped with the electric cable of type H07RN-F 5G2.5 CE14
without the plug.
• The device must be connected to the potential levelling circuit (ground).
The connection terminal is located under the left side of the device at sign .
- 57 -
5.1.3 Gas connection
WARNING!
The device installation and any adaptation to different gas type must
be performed only according to the valid regulations and by the
qualified professional personnel.
The device should be inspected by the professional personnel at
least once a year. In case of fire immediately close the gas valve and
use the appropriate fire extinguisher!
• The device is designed and certified for operation with the gas type specified on the
rating plate. Before the installation make sure that the local gas supply system (gas
type and pressure) conforms to the device preset.
• The gas connection is located on the left side of the device and is marked “GAS”.
• The device must be connected to the gas system only by the qualified gas installer
according to the local regulations.
• In generally accessible installation locations follow the safety regulations, as well as
fire and panic protection standards.
• The certified gas valve must be located in easily accessible place between the gas
system and the device allowing for quick gas supply cutting off.
• Make sure that the gas hose does not touch hot oven parts.
CAUTION!
After the installation make sure that the connections are properly fixed.
Never use flame for checking the tightness of the gas pipes, only the soap
solution or special foaming product for leak detection.
- 58 -
Operation in case of gas consistent with the device preset
Check if the gas type specified on the rating plate conforms to the supplied gas type.
Then check conformity to the following data.
a) Flow pressure control (fig. 1)
The flow pressure may be measured with use
of manometer, U-pipe, or electronic manometer
of resolution of at least 0.1 mbar.
- Remove bolt “A” from the measurement
connection “B”.
- Install the manometer.
- Start the device and check if the pressure
conforms to the specified values.
Fig. 1
CAUTION!
The device operates correctly only when the pressure in the gas system is
in range for different gas categories specified in table 1 “Gas categories in
various countries” on pages 53 and 54.
b) Main burner control
Activate the device, ignite the individual burners and see if the flame, ignition, and
setting of the smallest flame operate correctly. If not, check nozzles and setting of
primary air.
Changing the gas type / settings
• The device is designed and certified for operation with the gas type specified
on the rating plate (natural gas).
• When required, it may be adapted to different gas type with use of special
nozzles and settings. The delivery range includes nozzles for LPG.
• Change of gas type must be performed by the qualified gas installer.
- 59 -
a) Replacement of main burner nozzle
• Remove all adjustment knobs and disconnect the control panel from the device
in order to obtain access to the brackets of the nozzles.
• Remove the bolt fixing the nozzle bracket.
• Replace the removed nozzle with the one designed for a given gas type
(nozzle data are in table 2 “Nozzle and burner properties” on page 54).
Tighten the nozzle.
• Modify all burners according to the above instructions.
b) Replacement of ignition burner nozzle
Access to the ignition burner is possible only after removing the control panel.
Remove the closing nut from the ignition burner and replace or adjust nozzles
of the ignition flame accordingly to the gas type.
c) Primary air adjustment (fig. 2)
When the primary air is adjusted correctly the flame is
stable, so there will be no interruptions when the burner
is cold or back burning when the burner is hot.
The provided distance (“X”) for the primary air setting is
specified in fig. 2 and in table 2. After the replacement of
nozzles check setting of primary air for all burners.
Fig. 2
d) Ignition burner adjustment
Adjust the ignition burner and see if the flame is correct and covers the thermal
element. If not, see if correct nozzles are installed (table 2, page 54).
- 60 -
e) Flame reduction adjustment (fig. 3)
• After switching to the different gas type it is required to change the small flame
settings for the individual burners.
• Adjust it in the following way:
• ignite the burner;
• turn the adjustment knob counterclockwise to the smallest flame
(small flame symbol);
• remove the adjustment knob from the valve stem.
• When switching from LPG to the natural gas the
fine adjustment screw F(fig. 3) should be turned
counterclockwise with use of small screwdriver until
obtaining the required flame power.
• When switching from the natural gas to LPG
the fine adjustment screw F (fig. 3) should be
turned clockwise with use of small screwdriver
until obtaining the required flame power.
Fig. 3
• Then replace the adjustment knob and quickly turn it from the maximum position
to the minimum position, check the flame and make sure that the adjustment is
sufficient and the flame allows for heating the thermal element. If not, correct it.
• After the replacement or adjustment of the nozzles always make sure that the flame
is blue, stable, does not separate from the burner, and there is no back burning
while changing from the large flame to the small one.
CAUTION!
• After switching to the different gas type always check tightness with use of
appropriate spray or water with soap (never use the open flame!).
• After all replacement or adjustment activities reinstall all previously removed
parts to make the device ready for operation.
• After the modification remove the plate with the adjustment values and replace
it with the new one for the new gas type.
- 61 -
4.
2.
5.2 Tips for the user
CAUTION!
Carefully read the manual below as it includes the safety and operation
instructions. Store the manual to use it at any moment.
The defective installation, operation errors and maintenance and cleaning
mistakes as well as any modifications may cause the incorrect operation,
damages and injuries.
5.2.1 First start-up
• Make sure that there are no objects left in the electric oven and on
the cooking surface (equipment, package foils, manuals).
• Before the start-up carefully remove the protective foil from the device and
use the lukewarm water or appropriate solvent to remove the glue residuals.
• Before the start-up check the correctness of the installation, stability, and
levelling of the device, and if the electric and gas connections are correct.
• Do not cover the ventilation slots.
• The device elements removed during the installation and connecting must be
replaced.
• Before the device operation clean it according to the instructions in section 6
“Cleaning and maintenance”.
5.2.2 Operation elements
3. 5.
Oven temperature controller knob
1.
Oven function change knob
2.
Power indicator (green)
3.
Operation indicator (orange)
4.
Fig. 4
1.
- 62 -
Burner adjustment knob (4 or 6)
5.
5.2.3 Gas cooking surface
Ignition of burners
• Make sure that all knobs are in position OFF .
• Open the gas valve before the device.
• In order to ignite the burner press appropriate
knob and rotate it counterclockwise to the
position with the ignition flame symbol .
• Hold the knob pressed for 3-4 seconds and ignite
the flame with the igniter.
Fig. 5
• Hold the knob pressed for a few more seconds to obtain the flame continuity.
• Adjust the flame as required by turning the knob towards the large flame or
small flame , whereas the knob must be positioned in the range between those
points and never between the large flame and position OFF .
• In case of accidental flame extinguishing (e.g. draught, spillage, etc.) the safety valve
will operate and cut off the gas supply.
• In order to put out the flame turn the knob to position OFF .
• At the end of the work day close the gas cut-off valve.
Instructions and advices
• Avoid the flame exceeding the pot (frying pan) edge.
• When the food starts to boil reduce the flame to the lowest level so it will not be
extinguished by the boiling over food.
• Never leave the device unattended during heating of fats and oils as they may
ignite when overheated. There is the fire hazard!
- 63 -
• Use only pots with flat bottom.
Fig. 6
• Place the pots on the grate in such way that the flame is located in the centre.
CAUTION!
In case of longer standstill or damage of the device close the main gas valve
before the device.
Moreover it is recommended to perform the periodical inspections of the
device (at least once a year) by the qualified professional personnel.
5.2.4 Electric oven
• Before starting the oven make sure that there is only the equipment provided for a
given cooking/baking process inside (usually the grate – shelf on which the utensils
with food are placed is sufficient).
• Before the first use heat the oven without food in the maximum temperature for
45 minutes. Evaporation of the substances protecting the oven may cause
unpleasant odour which will not take place during further operation. After heating
ventilate the room with opened oven door.
• Always heat the oven to the required temperature before placing food inside.
• In order to obtain the optimal cooking/baking effect select the temperature and
function accordingly for each food.
Temperature adjustment
• Use the temperature controller knob to select
temperature in range of 50 °C – 300 °C for a
given food.
• Red operation indicator is on during heating of
the device and goes off after reaching the
required temperature.
• Now place the prepared food in the oven.
• When the temperature in the oven drops the
operation indicator will come on and the device
will be heated to the preset temperature.
Fig. 7
- 64 -
Functions
• Select the oven function accordingly for each food by positioning the function
selection knob appropriately; turn the knob clockwise.
The following functions are available:
position OFF
bottom heat
top heat
top and bottom heat
CAUTION!
When the oven is not used, turn the function selection knob to position OFF.
Levels
• There are 3 levels available in the oven:
1 bottom level, 1 middle level, 1 top level.
Fig. 8
• The middle level is appropriate for most tasks as
there is perfect stabilization of temperature preset
with the control knob in that area.
Fig. 9
Instructions and advices
• Due to sizes of food and use of various utensils from various materials of various
thickness (ceramics, glass, aluminium, steel) there may be deviations from times
specified in the recipes.
• In case of delicate food or prepared with use of raising agents avoid opening the
oven door to keep the internal temperature stable.
• In order to save energy during long cooking/baking processes the oven may be
turned off a few minutes earlier than specified in the recipe and do not open the
oven door to use the remaining heat.
- 65 -
6. Cleaning and maintenance
WARNING!
Before cleaning set the gas control knobs in position “OFF” and close
the main gas valve.
Disconnect the device with electric oven from the power supply (pull the
plug!).
Leave the device to cool down completely.
Never use water jet to wash the device.
Make sure that no water gets into the device.
Cleaning
o In order to assure reliable operation, hygiene and efficiency the device should be
cleaned everyday after work.
o Before cleaning disconnect the electric power supply, close the gas valve, and wait
for the device to cool down.
Gas cooking surface
o Remove grates and gas burners covers.
o Clean the cooking surface with soft cloth or sponge moistened with warm water.
It is possible to use the neutral washing agent when required. Dry the cooking
surface.
o Wash the cast iron grates and burners covers with soft cloth or sponge and
the neutral washing agent. Thoroughly rinse in clean water and dry.
o After cleaning the burners covers and grates replace the im appropriate places.
Electric oven
o The oven interior and the shelves guides should be thoroughly cleaned with soft cloth
or sponge and the washing agent for the stainless steel. Thoroughly rinse with warm
water, paying attention to not to leave any washing agent residuals. Then dry the
oven interior and the shelves guides.
o Do not use any abrasive clothes or other products which may damage the oven
surfaces.
- 66 -
Housing
o Clean the oven housing and door every day with use of lukewarm water and soap.
Then thoroughly rinse and wipe them dry.
o Clean the stainless steel surfaces (housing, cooking surface, and oven door) with
the special agents for the stainless steel only; inappropriate agents may cause
corrosion of the device. Follow the producer’s instructions on the packages of the
cleaning agents.
o Do not use any steel fibres, wire brushes, or steel scrapers for cleaning the
device, as it may cause depositing of iron particles, oxidation of which may cause
rusty spots.
o Do not use the agents containing chlorine (bleachers, hydrochloric acid, etc.).
o After cleaning dry and polish the surface with soft and dry loth.
Maintenance
o Periodically (at least once a year) order the device inspection to the qualified and
authorized servician. To do this contact the service company.
o Before any maintenance works disconnect the electric power supply, close the
main gas valve, and wait for the device to cool down.
o Before moving the device to the other location disconnect the electric and gas
connections correctly. Before the device activation in new location make sure that
all electric and gas connections are made according to the valid standards.
- 67 -
7. Waste disposal
Old devices
The electric devices are marked with this symbol. You must not
dispose of electric devices with household waste. When the
device may not be longer used each consumer is obliged to
dispose of the device at the dedicated local collection point,
separately from household waste.
NOTE!
Electric devices should be used and disposed of properly to prevent the impact on
the environment.
• Disconnect the device from the power supply and remove the power cord from
the device.
Bartscher GmbH phone: +49 5258 971-0
Franz-Kleine-Str. 28 fax: +49 5258 971-120
33154 Salzkotten Service-Hotline: +49 5258 971-197
Germany www.bartscher.com
- 68 -
Loading...
