M 5110 / 116.615
M 7110 / 116.617
M 5230 / 116.613
M 10110 / 116.620
V2/0912
GB/UK
1. General information ................................................................................................ 26
1.1 Information about the instruction manual ............................................................ 26
1.2 Key to symbols .................................................................................................... 26
1.3 Liability and Warrantees ...................................................................................... 27
1.4 Copyright protection ............................................................................................ 27
1.5 Declaration of conformity ..................................................................................... 28
2.Safety ........................................................................................................................ 28
2.1 General information ............................................................................................. 28
2.2 Safety instructions for use of the device .............................................................. 28
2.3 Intended use ....................................................................................................... 29
3. Transport, packaging and storage......................................................................... 30
3.1 Delivery check ..................................................................................................... 30
3.2 Packaging ........................................................................................................... 30
3.3 Storage ................................................................................................................ 30
4. Technical data ......................................................................................................... 31
4.1 Steam convection oven properties ...................................................................... 31
4.2 Technical specification ........................................................................................ 32
Keep this instruction manual
ready to hand at the product!
5. Installation and operation ....................................................................................... 33
5.1 Safety instructions ............................................................................................... 33
5.2 Installation and connection .................................................................................. 34
5.3 Operation ............................................................................................................ 37
6. Cleaning and maintenance ..................................................................................... 45
6.1 Safety advice ....................................................................................................... 45
6.2 Cleaning .............................................................................................................. 45
6.3 Safety instructions for maintenance .................................................................... 46
7. Possible Malfunctions ............................................................................................ 47
8. Waste disposal ........................................................................................................ 48
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
25
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.
WARNING! Hot external surface!
This symbol is a warning that the device surface is hot when in use. Ignoring this
warning may result in burns!
26
WARNING! The container holds hot liquid!
When containers hold liquid or products that turn liquid during cooking, do not
higher shelves to place the containers so that the operator can always look into
the container inside.
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
27
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.
2.Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.
28
CAUTION!
o The device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
o Children should be observed to ensure that they are not playing with the device.
o Preserve this manual safely. When passing on/selling the device to a third party, the
manuals must be handed over along with the device.
o Every person using the device must act in accordance to the manuals and under
consideration of the safety advice.
o The device is to be used indoors only.
2.3 Intended use
CAUTION!
This device has been designed and built for commercial use only and should be
operated by qualified personnel only.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The steam convection oven is intended only for preparation of appropriate food
products.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.
29
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
- Do not store outdoors.
- Keep it dry and dust-free.
- Do not expose it to aggressive media.
- Do not expose it to direct sunlight.
- Avoid mechanical shocks and vibration.
- In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.
30
4. Technical data
4.1 Steam convection oven properties
• Produced from 18/10 chrome-nickel steel
• Operated by dials
• Maximum capacity of 10 1/1 GN or 600 x 400 mm baking trays
• Functions: recirculated air, steam cooking, convection-cooking
• Reversing engine direction (clockwise and counter clockwise rotation) ensuring
optimal cooking compartment temperature
• Two-speed fan regulation
• Direct-injection steaming
• Steam extractor, adjustable
• Cooking compartment light
• Convenient GN side-loading tray (device for 5 x 2/3 with side rails)
• LED internal temperature display
• Prepared to mount internal temperature probe
• Prepared to mount manual spray 116.005
• Double-pane doors, internal door can easily be opened for cleaning
• Removable support rails
Safety features
The device is equipped with the following security and safety features:
Safety thermostat in the cooking compartment: if the cooking compartment overheats,
the safety thermostat is activated and the supply of electricity to hearing elements is
interrupted.
CAUTION!
The safety features can only be reactivated by qualified service personnel,
as further control measures must be performed.
The door switch interrupts the device’s functioning when the door is open: the heating
and circulation systems are turned off.
31
4.2 Technical specification
Name Electric steam convection oven
Model:
Article no.:
Capacity:
Distance between
trays:
Temperature range: 50 °C – 280 °C
Power: 6.3 kW / 400 V 50 Hz 3 NAC 9.6 kW / 400 V 50 Hz 3 NAC
Water connection: 3/4“
Water pressure: max. 3 bar
Dimensions: W 890 x D 815 x H 635 mm W 890 x D 815 x H 815 mm
Weight: 81,8 kg 101,2 kg
Equipment:
M 5110 M 7110
116.615 116.617
max. 5 x 1/1 GN
74 mm
1 grille 1/1 GN, 1 tray 1/1 GN;
1 exhaust pipe, 1 pressurised water hose
max. 7 x 1/1 GN
Name Electric steam convection oven
Model:
Article no.:
Capacity:
Distance between
trays:
Temperature range: 50 °C – 280 °C
M 5230 M 10110
116.613 116.620
max. 5 x 2/3 GN
74 mm
max. 10 x 1/1 GN
Power: 3.2 kW / 230 V 50 Hz 1 NAC 12.6 kW / 400 V 50 Hz 3 NAC
Water connection: 3/4“
Water pressure: max. 3 bar
Dimensions: W 620 x D 755 x H 635 mm W 890 x D 815 x H 1015 mm
Weight: 62,0 kg 115,2 kg
Equipment:
We reserve the right to make technical changes!
32
1 grille 2/3 GN, 1 tray 2/3 GN 1 grille 1/1 GN, 1 tray 1/1 GN
1 exhaust pipe, 1 pressurised water hose
Additional equipment (not included with device)
Internal temperature probe
Article no. 116.000
1 pair of guide rails suitable for 600 x 400 trays
Article no. 116.002
Base for steam convection ovens on 5, 7, 10 x 1/1 GN
CNS 18/10
Capacity: max 10 x 1/1 GN
Dimensions: W 850 x D 700 x H 741 mm
Article no. 115.068
Manual spray
hose length 2 m
with shut-off valve to the fixed water connection 1/2"
including handle for mounting to the convection-steam furnace, series M + E
Article no. 116.005
5. Installation and operation
5.1 Safety instructions
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with
that of the device (see type label). Connect the device only in case of compliance!
Take note of the security advice!
• See that the cable does not touch any heat sources or sharp edges. Do not let the
cable dangle over the counter edge.
WARNING! Hot surface!
During operation some elements of the device very become hot.
To avoid burns, do not touch hot elements!
33
• Do not use the device in case it does not function properly, has been damaged or
dropped.
• Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
• Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.
5.2 Installation and connection
CAUTION!
Installation and maintenance can only be performed by qualified personnel!
Installation
• Unpack the device and remove all packing material.
• Place the device on a flat, secure surface that can support its weight and is resistant
to high temperatures.
• Never place the device on a flammable surface.
• Do not place the device near an open flame, electric or coal oven, or other heat
source.
• Never place the device directly against walls, kitchen furniture or other flammable
objects. Proceed according to relevant fire safety regulations.
• Keep a minimum of 100 mm between the device and walls/other objects on the left
and right sides and at the rear, and 150 mm from the top.
• To make dampening and height adjustments, use the adjustable legs as shown in
the above diagram. Large differences in height or tilt can negatively impact the
device’s operation.
• Place the device in a well-ventilated area. The device may only be installed in a
space with proper ventilation, optimally under an oven hood that will direct fumes to
the outside.
• Ensure that ventilation openings are not blocked in any way.
• Before first use, remove the protective foil from the device. Peel the foil off slowly, so
as not to leave any glue. If some glue remains, remove it using an appropriate solvent.
CAUTION!
The device is not designed to be built-in!
34
Connection
Connection to an electricity source
• Before connecting the device to an electricity source, ensure that the voltage and
frequency values given on the panel correspond to those of the electrical network.
The maximum permissible voltage difference is ± 10%.
• Check if there is an SL connection fulfilling legal requirements. Use an appropriately
cut cable when connecting the device to electricity.
• A multipolar breaker must be installed between the device and the electricity supply.
The distance between contacts should be at least 3 mm, and it should be located in
an easily-accessible place.
• Connect the device to the electricity supply in compliance with all international,
domestic and local regulations.
• The device must be connected to the equipotential bonding system (grounding).
The connection clamp is located under the right rear side of the device, under
this sign .
Water connection
• Ensure that the device is located near water connections.
• If a new installation is to be put in, flush it out with water to remove all dirt and
impurities before connecting the device so as to protect the magnetic valves.
• Connect the pressurised water hose (included) using the 90° connection bevel to the
connector (3/4“) of the device. Location of the connector: at the rear, at the right side
under the device. Connect the other end of the pressurised water hose to the cold
water network with the stopcock.
CAUTION!
Hydraulic pressure cannot exceed a maximum of 3 bars.
Use a reducing valve for higher pressures.
• To ensure the device functions properly and prevent the formation of deposits in the
water boiling compartment, the water hardness can measure not more than 7° dH .
CAUTION!
If water hardness is above 7 °dH, it is necessary to install a water softening
mechanism.
35
Drain connection
• At the condensate-collecting tray located in
front of the oven, there is a drain hose (with
an inner diameter of 10 mm). This hose drains
excess liquids from the condensate-collecting
tray away and runs in the rear part below the
device (see A - picture on the right). To drain
the water to the drainage system, extend the
available hose as needed.
• Fasten the supplied drain pipe to the outlet hole
located under the device to ensure the outflow of
liquids from the cooking compartment.
The drain pipe must be connected with a suitable
hose (∅ 22 mm) to the drainage system.
Activation and acceptance of electrical installations
Prior to activation of electrical devices, all inspections must be thoroughly conducted in
order to confirm compliance of the device and its installation with all legal, technical and
safety norms.
The following conditions must be fulfilled:
→→→→ The temperature around the installation must be above + 4 °C.
→→→→ The cooking compartment must be empty.
→→→→ All packing elements must be completely removed, together with the
protective film on the internal walls.
→→→→ Ventilation ducts cannot be blocked in any way.
→→→→ Any elements of the device disassembled during installation must be
reassembled.
→→→→ The main electric switch must be turned on, and the water stopcock installed
Acceptance of the electrical device must be complimented by a test cooking cycle,
which will determine if the device is in working order and without defects or other
problems.
by the device must be open.
→ Turn the device on using the function dial
→ Set the cooking/baking cycle:
M 1
.
Time: 10 minutes Temperature: 150 °C Steaming : position 2 dial
M 4
36
The following conditions must be met for acceptance:
→→→→ The device’s lighting comes on automatically after the time is set.
→→→→ The device turns off when the door is opened, and turns on after it is closed.
→→→→ The thermostat for controlling temperature in the device is activated when
the desired temperature is reached. The heating element(s) are
temporarily turned off.
→→→→ The ventilator motor changes the flow direction automatically every 3 minutes.
→→→→ In dual-ventilator devices the motors operate in the same direction.
→→→→ The hose leading to the ventilator has been checked for water leaks.
→→→→ An audible alarm is heard for approx. 15 seconds after the cooking/
baking cycle finishes.
IMPORTANT
When the device is turned on, an audible signal may be heard. This is normal, and
will turn off automatically after a few seconds.
If the process is interrupted while setting the cooking/baking phase, set the function dial
M1
in the OFF position.
5.3 Operation
• Clean the device thoroughly prior to use (see 6.2 „Cleaning“).
• Prior to turning the device on, check that the installation is properly performed
and secure, that the device is level, and that the electrical and water connections
are properly set up.
CAUTION!
Before cooking/baking preheat the device to a temperature 20-25% above the
desired cooking/baking temperature. After this temperature is reached, place the
food product inside the compartment.
Next, lower the temperature to that desired for preparing the desired food product.
37
SET
ON/OFF
I 3
I 2
I 1
I 4
I 8
LED 1
M 1
M 2
M 4
M 3
LED 2
I 6
S 1
S 2
S 3
I 7
T 1
I 9
I 10
D 1
T 5
T 3
T 4
T 2
I 5
Control panel
38
M 1
Function dial
I 1
OFF
Cooking/baking with
I 2
recirculated air
I 3
Cooking/baking with steam
I 4
Steam convection cooking
M 2
Temperature dial
Max. cooking/baking temperature
I 5
with steam (approx. 110 °C)
Temperature range in °C
S 1
(50 °C – 280 °C)
M 3
Time dial
I 6
Position – unlimited time
S 2
Time in minutes (0 – 120)
M 4
Steam dial
S 3
Steam scale (1 – 10)
Time / internal temperature
T 1
probe switch
I 8
Time activation
Internal temperature probe
I 9
activation
T 2
Ventilator speed switch
I 7
Ventilator speed level 2
I 10
Ventilator speed level 1
Digital internal temperature
D 1
indicator
Reduce internal probe
T 3
temperature button
Increase internal probe
T 4
temperature button
T 5
LED 1
LED 2
button for setting internal
probe temperature
ON/OFF indicator
Heating element(s)
indicator
I 2
I 8
M 1
M 2
M 4
M 3
I 6
S 1
S 2
S 3
I 7
T 1
I 10
T 2
Cooking/baking with recirculated air
To set cooking/baking with the use of
RECIRCULATED AIR, turn the M 1 function
dial clockwise to the position
I 2
.
Next, set the cooking/baking temperature by
turning the
M 2
temperature dial clockwise to
the desired value.
Lastly, set the cooking/baking time by
turning the
M 3
time dial clockwise to the
desired value.
After the set time has expired an alarm will
sound, the device will turn off and cooking
will finish.
To cook without setting the time, turn the
time dial to
I 6
(unlimited time).
Ventilator speed is set by pressing the
switch
T 2
. Choose the desired level and set
the switch to the desired position
I 7 or I 10
.
Attention:
Check that the switch
(time activation).
T 1
is in position
I 8
Cooking/baking with recirculated
air and steam
To add steam to the process of cooking/
baking with RECIRCULATED AIR, turn the
dial
M 4
to the desired position (1 – 10).
Turn it clockwise to increase steam in the
compartment, and counterclockwise to
reduce steam. When the dial is facing
upwards, the steam mechanism is turned off.
39
I 3
I 8
M 1
M 2
M 3
I 6
S 2
I 7
T 1
I 10
T 2
I 5
S 1
Cooking/baking using steam
To set cooking/baking with the use of STEAM,
turn the function dial
position
I 3
.
M 1
clockwise to the
Next, set the cooking/baking temperature by
turning the temperature dial
M 2
clockwise to
the desired value.
For traditional cooking/baking with steam,
it is recommended to set a temperature of
110 °C in the device, which is equivalent to
the symbol
I 5
.
Lastly, set the cooking/baking time by turning
the time dial
M 3
clockwise to the desired
value.
After the set time has expired an alarm will
sound, the device will turn off and cooking
will finish.
To cook without setting the time, turn the
time dial to
I 6
(unlimited time).
Ventilator speed is set by pressing the
switch
T 2
. Choose the desired level and set
the switch to the desired position
I 7 or I 10
.
Attention:
Check that the switch
T 1
is in position
I 8
(time activation).
40
I 4
I 8
M 1
M 2
M 3
I 6
S 1
S 2
I 7
T 1
I 10
T 2
Steam convection cooking
(cooking/baking with the use of recirculated air/ steam)
To set STEAM CONVECTION cooking
(cooking/baking with the use of recirculated
air/steam) turn the function dial
clockwise to the position
Next, set the cooking/baking temperature by
turning the temperature dial
the desired value.
Lastly, set the cooking/baking time by
turning the time dial
desired value.
After the set time has expired an alarm will
sound, the device will turn off and cooking
will finish.
To cook without setting the time, turn the
time dial to
I 6
(unlimited time).
Ventilator speed is set by pressing the
switch
T 2
. Choose the desired level and set
the switch to the desired position
Attention:
Check that the switch
(time activation).
I 4
.
M 2
M 3
clockwise to the
T 1
is in position
M 1
clockwise to
I 7 or I 10
I 8
.
41
to the
I 3
I 2
I 1
I 4
I 5
I 8
M 1
M 2
M 4
M 3
I 6
S 1
S 2
S 3
I 7
T 1
I 9
I 10
D 1
T 5
T 3
T 4
T 2
Cooking/baking with the use of internal temperature probe
After selecting the desired cooking/baking
mode and setting the function dial in one of
the positions
I 2 – I 3 – I 4
temperature.
Turn the temperature dial
desired value.
While cooking/baking with the internal
temperature probe always set the time
dial
M 3 to position I 6
(unlimited time).
Other parameters (steaming/ventilator
speed) should be set as desired.
To activate the internal temperature probe,
set the switch
T 1
to position
Choose the desired internal food
temperature using the digital indicator
follows:
• Press the button SET
indicator
• Press buttons
D 1
will flash.
T 3
or
the internal food temperature.
• To confirm the settings selected, press
button SET
T 5
again.
When the desired internal food
temperature has been reached, an alarm
will sound, the device will turn off and
cooking will finish.
Attention:
The internal temperature probe should be
inserted into the food product to be prepared
until its tip is in the centre of the food product
(in the thickest section).
, set the
M 2
clockwise
I 9
.
T 5
. The
T 4
to raise or lower
D 1
as
42
the baking chamber that forms during baking/cooking.
, we recommend setting
A
B
C
Securing / removing the internal temperature probe
To connect the internal temperature probe take out the
plug A (image on the left) from the opening at the top
left side of the oven, press and hold the red detent B
and insert the internal temperature probe C into the
opening provided.
Release the red detent B. To remove the probe
press the detent B again, pull the internal
temperature probe C and release the detent B.
Push the plug A in again.
CAUTION!
To avoid damaging the internal temperature probe, insert it into the device only
above the glass door.
Steam extractor
The steam extractor's task is to remove moisture from
Set the steam extractor lever as needed in one of the
following positions:
• Left: Closed
• Right: Open
Even with a closed extractor, there is no danger of high pressure occurring in the baking
compartment, as this is under the constant control of the valve.
When cooking/baking with STEAM and with RECIRCULATED AIR
the steam extraction lever to "Closed".
43
I 6
M 3
S 2
M 1
LED 1
I 1
Internal lighting
The cooking compartment lighting functions automatically and is connected with the
device’s functioning. At the end of a cooking/baking cycle (e.g. when the time dial
displays “0” or the internal temperature reaches the set value) the lighting goes off.
Turning the device off
To finish cooking, turn the temperature dial
M 3
to the position "0" (also when cooking/
baking with the internal temperature probe).
Turn off the device and set the dial
position
LED 1
I 1
(OFF).
will go off.
M 1
to
44
6. Cleaning and maintenance
6.1 Safety advice
o Before beginning with repair or cleaning works make sure the device has been
disconnected from power supply and has cooled down.
o Do not use any acid agents and make sure no water ingresses the device.
o To protect yourself from electric shock, never immerse the device, its cables and
the plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets.
Therefore, you must not use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
o To ensure the device’s proper functioning, hygiene and power, clean it at the end of
every work day.
o Before cleaning, disconnect the device power supply, close the water valve and
leave it to cool.
o Remove the rails from the device and wash them thoroughly with warm water and
a mild cleaning agent; rinse in clean water and dry.
o For washing the cooking compartment, use lukewarm water and appropriate cleaning
agents. Rinse the compartment thoroughly with clean water and ensure no residue
remains. Dry the cooking compartment.
o Use only special stainless steel cleaning agents as inappropriate chemicals may
cause corrosion.
o Do not use cleaners containing chlorine (whiteners, hydrochloric acid, etc.).
o After cleaning use a soft, dry cloth to dry and polish the surface.
45
Cleaning the glass door
o The dual glass pane in the door makes the unit
easy to clean. The internal pane can be tilted or
removed as needed.
o To do so, loosen the upper and lower locks that
hold the internal pane by turning them clockwise
(fig. ❶).
❶
o Tilt the internal pane (fig. ❷).
o Wash both sides of the internal pane and door of
the unit with an appropriate cleaning agent.
o Do not use harsh or abrasive cleaning aids.
o Close the internal pane or properly insert it after
cleaning and reset the locks to their initial position
by turning them counter-clockwise.
❷
CAUTION!
When replacing the internal pane, remember to attach it with the stripes running
in the direction of the unit's door, otherwise the door will not be sealed shut.
6.3 Safety instructions for maintenance
o Check the mains connection cable for damage from time to time. Never operate the
device when the cable is damaged. A damaged cable must immediately be replaced
by customer service or a qualified electrician to avoid dangers.
o In case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
o Only a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
46
Internal lighting does
7. Possible Malfunctions
Problem Solution
• Check the power supply
The device does
not turn on.
If the device does not turn on after trying some of the above solutions,
contact customer service.
The ventilator stops
working while the
device is in use
If the problem occurs again, contact customer service.
not work.
If the problem occurs again, contact customer service.
Water does not
reach the hose.
If the problem occurs again, contact customer service.
Thermal probe
does not work.
If the problem occurs again, contact customer service.
• Check if the device’s fuses are damaged.
• Check if the device’s door is closed properly.
• Check if the cooking/baking parameters are properly set.
• Check if the device does not display any error messages.
• Turn the device off and wait until the motor overheating safety
device turns itself on again.
• Check if ventilation ducts are blocked.
Use only temperature-resistant light bulbs!
Change the light bulb as follows:
• Check if the multipolar switch is open and the device has
cooled.
• Open the internal glass pane (6.2 „Cleaning“).
• Remove the protective glass cover.
• Change the light bulb.
• Check if the water flow stopcock is open.
• Check if the time dial is set to position
I 6
(unlimited time).
The situations given above are only examples of potential problems. If these or
other similar problems occur, turn the device off immediately and stop using it.
Contact qualified personnel or the producer to inspect and repair the device.
47
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act
according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
48
Loading...
