Gebrauchs
anleitung
Instruction manual
Mode
d’emploi
Gebruiksaanwijzing
Instrukcja
obsługi
V4/
0315
114001
114002
114003
114004
114005
114006
Infrarot-Wärmebrücke
Infrared food warmer
Pont thermique, infrarouge
de page 25 à page 36
Seite 1 bis 12
from page 13 to 24
D/A/CH
GB/UK
F/B/CH
Infrarood-warmtebrug
blz. 37 t/m 48
Mostek grzewczy IR
strony od 49 do 60
NL/B
PL
GB/UK
ENGLISH
Translation
of the original instruction manual
Table of contents
1.Safety ........................................................................................................................ 14
1.1 Safety instructions ................................................................................................ 14
1.2 Key to symbols ..................................................................................................... 15
1.3 Hazard sources .................................................................................................... 16
1.4 Proper use ............................................................................................................ 18
2. General information ................................................................................................ 19
2.1 Liability and Warrantees ....................................................................................... 19
2.2 Copyright protection ............................................................................................. 19
2.3 Declaration of conformity ...................................................................................... 19
3. Transport, packaging and storage......................................................................... 20
3.1 Delivery check ...................................................................................................... 20
3.2 Packaging ............................................................................................................. 20
3.3 Storage ................................................................................................................. 20
4. Technical data ......................................................................................................... 21
5. Installation and operation ....................................................................................... 21
5.1 Installation ............................................................................................................ 21
5.2 Operation .............................................................................................................. 22
6. Cleaning ................................................................................................................... 23
7. Waste disposal ........................................................................................................ 24
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 13 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Safety instructions
• Please keep these instructions and give them to future owners of the device.
• Do not use the device in case it does not function properly, has been damaged or
dropped.
• The device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
• Children should be observed to ensure that they are not playing with the device.
• Only a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
• Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
- 14 -
• To prevent hazards and to ensure optimum efficiency, no modifications or alterations
to the device that are not explicitly approved by the manufacturer may be undertaken.
• Never allow the power cable to come into contact with heat sources or sharp edges.
The power cable should not hang over the side of the working surface. Ensure that no
one can step on or trip over the cable.
• The power cable must not be folded, bent or tangled, and must always remain fully
unrolled.
• Never place the device or other objects on the power cable.
• Do not lay the cable over carpets or heat insulations. Do not cover the cable.
Keep away the cable from operating range and do not dunk it into water.
• Inspect the power cable regularly for damage. Never use the device if the cable is
damaged. If the power cable is damaged, have an authorised service center or
qualified electrician replace it.
• Never leave the device unattended when in use.
• The device is not adapted for use with an external timer or remote control.
• Do not move or tilt the device when in operation.
• Only use the device indoors.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards which could lead to injury.
To avoid them please follow the instructions very carefully and proceed with
particular attention in these cases.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.
To avoid them please follow the instructions very carefully and proceed with
particular attention in these cases.
- 15 -
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
To avoid them please follow the instructions very carefully and proceed with
particular attention in these cases.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.3 Hazard sources
DANGER!
Electric shock hazard!
To avoid the hazard results please follow the safety instructions below.
Do not use the device in case of incorrect operation, damages or dropping on the
floor. When the cable is damaged it should be replaced by the service company or
qualified electrician in order to avoid the hazards.
The supply cable must be disconnected from the socket only by pulling the plug.
Never carry or lift the device by the supply cable.
In any case do not open the device housing. In case of electrical or mechanical
modifications the electric shock hazard will occur.
Never immerse the plug in water or other liquids.
Do not use any acid agents and make sure no water ingresses the device.
Never operate the device with moist hands or standing on wet floor.
Remove the plug from its socket:
- when the device is not used,
- in case of anomalies during operation,
- before cleaning.
- 16 -
DANGER!
Suffocation hazard!
Prevent access of children to the package materials like plastic bags and
foamed polystyrene elements.
WARNING!
Burn hazard!
To avoid the hazard results please follow the safety instructions below.
The surface of the device gets very hot during the work. To avoid injury, do not
touch the hot surface with bare hands.
The device also remain hot for a long time after the device is turned off.
Wait for the device to cool before cleaning or moving.
WARNING!
Fire or explosion hazard!
In case of improper operation there is the fire or explosion hazard due to ignition of the
device content.
To avoid the hazard results please follow the safety instructions below.
Never place any kitchen tools, towels, paper etc. on the device when the device is
in use. This could cause fire and/or damage to the device.
Never operate the device near flammable materials (petrol, spirit, alcohol, etc.).
Heat causes them to evaporate, and contact with heat sources can lead to serious
injury and damage.
In case of fire before the fire extinguishing activities remove the plug from the socket
or disconnect the device from the power supply.
Caution: Do not spray the device with water when it is still connected to the power
supply: Electric shock hazard!
- 17 -
1.4 Proper use
The operational safety of the device is assured only in case of proper use, according
to the operation manual.
All technical activities like installation and maintenance must be performed by the
qualified service personnel only.
Infrared food warmer is only meant for keeping the heat of dishes.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.
- 18 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
- violation of advice concerning operation and cleaning;
- use other than designed;
- alterations made by user;
- use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.
- 19 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
- Do not store outdoors.
- Keep it dry and dust-free.
- Do not expose it to aggressive media.
- Do not expose it to direct sunlight.
- Avoid mechanical shocks and vibration.
- In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.
- 20 -
4. Technical data
Name Infrared food warmer
Code-no.:
Material: Aluminium
Connection: 230 V 50 Hz
Power: 650 W 800 W 950 W 1250 W 1100 W 1730 W
Range of
temperature
keeping:
Dimensions
(mm):
Weight: 4 kg 5 kg 5 kg 6 kg 5 kg 7 kg
Accesories:
Subject to technical changes and alterations!
114001 114002 114003 114004 114005 114006
up to 60°C
D 210 x H 105
W 760 W 920 W 1070 W 1370 W 1220 W 1830
legs-frame (code-no.: 114000, outside of the delivery range)
5. Installation and operation
5.1 Installation
Positioning
• Unpack the device and remove all packing material. Remove the protective wrap
from the device.
CAUTION!
Never remove the rating plate and any warning signs from the device.
• Install the legs frame (it is not included in the delivery) to the heat leakage.
• Place the device on top of an even, stable, dry, and water-resistant surface which
supports the weight of the device and is not heat sensitive.
• Never place the device in wet or humid places.
• Never place the device on a flammable surface.
• Never place the device near an open flame, electric ovens, heating ovens and other
sources of heat.
• Pay attention to a sufficient distance (at least 30 cm) from walls and other
inflammable or prone to fading objects.
- 21 -
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid specification should
be compared with that of the device (see rating plate). Connect the device only
in case of compliance!
Connect the device only to properly installed single socket with
protective terminal.
Do not disconnect the supply cable by pulling it, always pull the plug.
• The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
• Place the device so that the plug is easily accessible and can be quickly removed
from its socket in case of necessity.
5.2 Operation
• Connect the device to a single grounded socket.
• Turn on the device with the use of a lever.
• Put warm dishes under the heat leakage to keep their temperature. Pay attention to
the distance between the infrared lamp and the dishes. This distance should be
approx. 30 cm.
NOTE!
Only with the right distances the ideal temperature of serving hot meals
without lowering the quality by overcooking can be kept.
• Separate the device from the mains outlet, when it is no longer used (pull the
mains plug!)
- 22 -
6. Cleaning
CAUTION!
Disconnect the unit from the power supply (unplug!) before cleaning.
The unit is not designed to be rinsed with running water.
Do not use a pressure washer to clean the device!
Be careful and do not let the water into the unit.
o The device should be cleaned regularly.
o Clean the casing of the device with a damp and soft cloth and a mild cleaning agent.
o Stubborn stains can be removed with a special cleaning agent for aluminium and
stainless steel.
o Only use a soft cloth and make sure you never use any kind of abrasive agents
which could scratch the surface.
o After the cleaning procedure, you should use a soft and dry cloth to wipe dry and
polish the surface.
Storing the device
o If the device is to remain unused for a longer period of time, clean it according to the
above instructions and store in a dry, clean place safe from frost and sun and
inaccessible to children.
o Do not place any heavy objects on the device.
- 23 -
7. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit
for use before disposal. For that purpose disconnect device from mains
supply and remove mains connection cable from the device.
CAUTION!
For the disposal of the device please consider and
act according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 24 -
Loading...
