C26 - C50
104049 - 104050
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: +49 5258 971-0
Fax: +49 5258 971-120
Technical Support Hotline: +49 5258 971-197
www.bartscher.com
Version: 1.0
Date of preparation: 2021-08-24
EN
Original instruction manual
1 Safety ............................................................................................................ 2
1.1 Explanation of Signal Words .................................................................... 2
1.2 Safety instructions.................................................................................... 3
1.3 Intended Use ........................................................................................... 5
1.4 Unintended Use ....................................................................................... 5
2 General information ....................................................................................... 6
2.1 Liability and Warranty .............................................................................. 6
2.2 Copyright Protection ................................................................................ 6
2.3 Declaration of Conformity ........................................................................ 6
3 Transport, Packaging and Storage ................................................................ 7
3.1 Delivery Check ......................................................................................... 7
3.2 Packaging ................................................................................................ 7
3.3 Storage .................................................................................................... 7
4 Technical Data ............................................................................................... 8
4.1 Technical Specifications .......................................................................... 8
4.2 Functions of the Appliance ..................................................................... 10
4.3 List of Components of the Appliance ..................................................... 11
5 Installation and operation ............................................................................ 12
5.1 Installation .............................................................................................. 12
5.2 Operation ............................................................................................... 14
6 Cleaning ...................................................................................................... 15
6.1 Safety Instructions for Cleaning ............................................................. 15
6.2 Cleaning ................................................................................................. 16
6.3 Descaling ............................................................................................... 17
7 Possible Malfunctions .................................................................................. 18
8 Disposal ....................................................................................................... 20
104049 1 / 22
Safety
EN
Read this instruction manual before using and keep it available
at all times!
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
Diese Bedienungsanleitung beschreibt di e Installation, Bedienung und Wartung d es Geräts und gilt als wichtige Infor mationsquelle und Nachschlagewer k. Die Kenntnis aller enthaltenen Sicherh eitshinweise und Handlungsanweisunge n schafft die Voraussetzung f ür das sichere und sachgerechte Ar beiten mit dem Gerät. Darüber hinaus müssen die für den Einsatzbereich des Geräts geltenden örtlichen Unfall verhütungsvorschriften und allgemeine n Sicherheitsbestimmungen eingehalten werden. Diese Bedienungsanleit ung ist Bestandteil des Produkts und muss in unmittelbarer Nähe des Ger äts für das In¬stallations-, Bedienu ngs-, Wartungs- und Reinigungspers onal jederzeit zugänglich auf¬bewahrt werd en. Wenn das Gerät an eine dritt e Person
weitergegeben wird, muss die Bedienungsa nleitung mit ausgehändigt werden.
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
2 / 22 104049
Safety
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
, die
1.2 Safety instructions
Electrical Current
• Too high a mains voltage or incorrect installation may cause electric shock.
• The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
• To avoid short-circuit, the appliance should be kept dry.
• If there are malfunctions during operation, disconnect the appliance from the
power supply.
• Do not touch the appliance’s plug with wet hands.
• Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
• Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
• Do not transport the appliance, holding it by the power cord.
• Do not allow the power cord to come into contact with heat sources or sharp
edges.
• Do not bend, pinch nor knot the power cord.
104049 3 / 22
Safety
EN
• Always completely unwind the power cord.
• Never place the appliance or other objects on the power cord.
• Always take hold of the plug to disconnect the appliance from the power supply.
• Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Incorrect operation of the appliance ma y cause fire or explosion hazard due to igniti on of its content.
Fire hazard / flammable materials hazard / explosion hazard!
• Do not use any electric devices in the appliance.
• Do not store nor use petrol or other flammable liquids and gases in the vicinity of
this or any other appliance. Those gases may cause fire or explosion hazard.
• Do not put into the appliance any explosive materials, like sprays filled with
flammable propellants. Contents of containers filled with flammable gases and
liquids may leak in low temperatures, and the contents may catch fire from
sparks generated by an electric appliance. Explosion hazard!
• In the case of coolant leakage, pull the plug from the socket. Remove all
sources of ignition in the vicinity, ventilate room and contact technical service.
Avoid coolant getting in contact with eyes, as it may cause serious eye damage.
• Never use any flammable liquids for cleaning the appliance or its parts. Gases
released may cause fire or explosion hazard.
• In the case of fire, disconnect the appliance from the power supply before
attempting adequate fire-extinguishing actions.
• Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
• Defrosting process may not be sped up with mechanical means or heat energy
sources (candles or heaters) nor with any other means. Vapour produced may
cause short-circuit and too high temperatures may damage the appliance.
• All ventilation slots should not be obstructed during operation.
• Never attempt to damage cooling installation of the appliance.
Operating personnel
• This appliance is not intended to be used by persons (including children) with
limited physical, sensory or mental capabilities, nor by persons with limited
experience and/or limited knowledge.
• Children should be supervised to ensure that they are not playing with or
switching the appliance on.
Improper Use
4 / 22 104049
Safety
EN
• Unintended or prohibited use may cause damage to the appliance.
• The appliance may only be used when its technical condition is flawless and
allows for safe operation.
• The appliance may only be used when all connections are executed according
to rules of law in force.
• The appliance may only be used when it is clean.
• Use only original spare parts. Never attempt to repair the appliance on your own.
• Do not introduce any changes in the appliance nor modify it.
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Ice cubes preparation.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
104049 5 / 22
General information
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
– failure to observe instructions,
– unintended use,
– technical alterations introduced by the user,
– usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.
6 / 22 104049
Transport, Packaging and Storage
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
– in closed rooms;
– in dry and dust-free surrounding;
– away from aggressive agents;
– in a location protected against sunlight;
– in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
104049 7 / 22
Technical Data
EN
Name:
Ice-cube maker C26
Art. No.:
104049
Material:
stainless steel
Number of ice cube sizes:
1
Ice cube size (W x H), in mm:
28 x 40
Ice cube weight, in g:
18 - 20
Ice cubes output / work cycle:
16
Max. output, in kg / h:
25 / 24
Storage container capacity, in kg:
7
Coolant, amount in kg:
R290 / 0,048
Climate class:
ST
Water connection:
3/4"
Water outlet, Ø in mm:
Ø 21
Connected load:
0,24 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
398 x 542 x 682
Weight, in kg:
30,0
4 Technical Data
4.1 Technical Specifications
We reserve the right to implement technical modifications.
8 / 22 104049
Technical Data
EN
Name:
Ice-cube maker C50
Art. No.:
104050
Material:
stainless steel
Number of ice cube sizes:
1
Ice cube size (W x H), in mm:
29 x 40
Ice cube weight, in g:
19 - 21
Ice cubes output / work cycle:
24
Max. output, in kg / h:
50 / 24
Storage container capacity, in kg:
13
Coolant, amount in kg:
R290 / 0,055
Climate class:
ST
Water connection:
3/4"
Water outlet, Ø in mm:
Ø 25
Connected load:
0,38 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
548 x 611 x 823
Weight, in kg:
47,0
We reserve the right to implement technical modifications.
104049 9 / 22
Technical Data
EN
Version / Design
• Ice cube design: cone-shaped (hollow cone)
• Cooling: air-cooled
• Fill level sensor
• Production by means of pumping system
• Cooling: compressor
• Control: key
• ON/OFF switch
• Indicator light
• The set includes:
– 1 water supply tube
– 1 water drain tube
– 1 ice cube shovel
4.2 Functions of the Appliance
The ice-cube maker is designed for production of cone-shaped ice cubes (hollow
cone). It may output up to 25 kg or 50 kg of ice cubes within 24 hours.
10 / 22 104049
Technical Data
EN
Fig. 1
1. ON/OFF switch
2. Messages
3. Storage container lid
4. Compressor cover
5. Housing
6. Ventilation openings
7. Power cord with mains plug
8. Water connection
9. Drain port
10. Gaskets
11. Water supply tube
12. Ice cube shovel
13. Drain tube
4.3 List of Components of the Appliance
104049 11 / 22
Installation and operation
EN
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
5 Installation and operation
5.1 Installation
Unpacking / Positioning
• Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
• If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
• Be careful not to damage the rating plate and warning labels fixed on the
appliance.
• Never place the appliance in humid or wet environment.
• Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
• The appliance should be placed on surfaces that are:
– even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• Nie należy umieszczać urządzenia w gorąc ym otoczeniu a ni w pobliżu m ateriałów łat wopalnych.
• The appliance requires sufficient airflow f or proper operation. Assure a minimu m lateral clearance of the appliance of 10 cm.
• Die Öffnungen am Gerät niemals abdec ken oder blockieren.
• Do not position the appliance in high humidity locations. Air relative humidity
should not exceed 70%.
• Do not place the appliance in direct sunlight or in the vicinity of heat sources
(cooker, radiator, heating devices, etc.). Heat sources may negatively affect
power consumption, and restrict functions of the appliance, too.
• In order to avoid damage to the compressor, do not tilt the appliance more than
45° when positioning or transporting it.
• The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessar y. The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessar y. The electric socket should be easily accessi ble so it is possible to quickly discon nect the power cord when necessar y.
• Maintain minimum clearance from walls and objects: 10 cm at both sides and
20 cm at the rear.
12 / 22 104049
Installation and operation
EN
• The appliance should be installed only in rooms, in which ambient temperature
falls in the range of 10–32°C.
Water Connection
1. Install the appliance near a water connection.
ATTENTION!
Connect the appliance only to a supply connection of potable water.
Otherwise install a water purification appliance.
2. Connect water supply tube to a tap.
3. Connect the other end of the tube to the water connection at the back of the
appliance.
4. Insert gasket rings.
NOTE!
The hydraulic pressure should amount to 2–3 bar. With higher pressure
install a pressure reducer.
Water Drain
1. Connect one end of the drain tube with a rubber sleeve to drain connection at
the back of the appliance.
2. Fit the other end of the drain hose to a sewerage pipe or a water container.
3. Make sure the sewerage pipe or a water container are below the level of ice-
cube maker's drain port, so that water could flow easily.
Power supply connection
• Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
• Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
• The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
• If in winter the ice-cube maker is brought from the outside to a room, leave it for
a few hours to heat up and reach the room temperature before switching it on.
• Before connecting the appliance to the power supply, wait 1 hour for the coolant
to stabilize.
• After a power failure or when the plug is removed from the socket, reconnect the
appliance to the power supply after 5 minutes at the earliest.
104049 13 / 22
Installation and operation
EN
Fig. 2
1. ON/OFF switch with integrated power indicator light (red)
2. Operation indicator light (green)
3. 'Error/Fault' message (red)
4. 'Ice Full' message (red)
5. 'Water Low' message (red)
• The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necess ary. The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessar y. The electric socket should be easily accessi ble so it is possible to quickly discon nect the power cord when necessar y.
5.2 Operation
Control Elements / Displayed Messages
Before Use
1. Prior to first operation, clean the appliance and its equipment according to
instructions in section 6 'Cleaning'.
2. Then dry the appliance thoroughly.
3. Check all connections and make sure the water shut-off valve is open.
4. Plug the appliance into a suitable single socket.
Appliance Operation
1. Switch the ON/OFF switch on the operation panel to 'I' position.
The red power indicator light in the ON/OFF switch lights up.
The green operation indicator light is lit and the ice cube production process is
started.
The process consists of the following stages:
– water flows in;
– ice cubes are produced;
– ice cubes are ejected;
14 / 22 104049
Cleaning
EN
– the ready ice cubes are stored.
When the storage container is full, the 'Ice Full' message on the operation panel is
shown and the appliance automatically finishes the process.
2. Open the storage container lid and use the ice cube shovel to take the ready ice
cubes out.
After taking out the ice cubes, the appliance re-starts production.
CAUTION!
Due to hygienic reasons, ice cubes produced during the first production
process should be disposed of; do not use them to cool beverages nor
food products.
If water supply is insufficient, the 'Water Low' message is shown in the operation
panel and the appliance switches off automatically.
3. Check water supply to ice-cube maker.
If an error occurs, the 'Error/Fault' message is shown and the appliance switches
off automatically.
WARNING!
Instant switching on of the appliance following an automatic switch off
may lead to compressor damage.
If the appliance switched automatically off (insufficient water supply, full ice cube
storage container, power failure, etc.), do not switch it back on immediately.
Wait 3–5 minutes, and then re-start the appliance.
4. When the appliance is no longer in use, switch it off using ON/OFF switch and
disconnect from the power supply (pull the plug out).
NOTE!
If the appliance will not be used for a prolonged time, drain water from
water tank, using drain screw at the rear wall of the appliance. Wipe the
water tank with a dry cloth.
6 Cleaning
6.1 Safety Instructions for Cleaning
• Before cleaning, disconnect the appliance from the power supply.
• Leave the appliance to cool down completely.
104049 15 / 22
Cleaning
EN
• Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
• Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
• For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
1. At the end of each working day, as well as after a long period without operating
the appliance, clean the appliance thoroughly.
2. Clean the appliance inside and outside with warm water and a mild cleaning
agent.
3. Rinse in fresh water.
4. After cleaning, dry and polish the surface with a soft and dry cloth.
5. Clean the condenser once in 2–3 months.
16 / 22 104049
Cleaning
EN
6.3 Descaling
Inappropriate water may lead to scale deposit in the water tank of the appliance.
Such deposits negatively affect the operation of the appliance. For this reason, the
appliance should be regularly descaled.
ATTENTION!
Only a service company may descale the appliance.
1. Remove the top cover of the appliance.
2. Close the water supply.
3. For descaling, prepare a solution of warm water (1 litre) and 1 package of a
commercially available descaling agent. Follow the instructions of the agent's
manufacturer.
4. Fill the water bowl with the solution.
5. Leave the agent for a couple of minutes for it to act. The time needed may vary
depending on the extent of scale deposits.
6. Switch the appliance on and let the solution flow until the water bowl is empty
and rises.
7. Perform the process with the solution 3 times.
8. Using fresh water, conduct 2–3 output cycles, to remove all residues of
descaling solution.
CAUTION!
After descaling, dispose of the produced ice cubes; do not use them for
cooling beverages nor food products!
104049 17 / 22
Possible Malfunctions
EN
Error
Possible Cause
Solution
Appliance does not
work, indicator lights
and indicators do not
light up
Interrupted power supply
Check the electric power
supply
The appliance is off
Switch the appliance on
Appliance does not
work, only power
supply indicator light
in the ON/OFF switch
light up
Incorrect supply voltage
Check the electric power
supply
Damaged PCB board
Contact the service
company
Appliance does not
work, 'Ice Full'
indicator light is lit
Storage container is full
Remove ice cubes from the
storage container
Ambient temperature is
below 6°C
Keep the ambient
temperature above 7°C
Restart the appliance
Appliance does not
work, 'Ice Full' and
'Fault' indicator lights
are lit
Damaged or not connected
storage container sensor
Contact the service
company
Appliance does not
work, 'Fault' indicator
light is lit
Damaged or not connected
condenser sensor
Contact the service
company
7 Possible Malfunctions
Mögliche
The table below contains descriptions of possible causes and solutions to
malfunctions or errors during operation of the appliance. When malfunction cannot
be removed, contact the technical service.
In such a case, provide article number, model name and serial number. These data
may be found in the rating plate.
18 / 22 104049
Possible Malfunctions
EN
Error
Possible Cause
Solution
'Water Low' and 'Ice
Full' indicator lights
blink simultaneously or
'Fault' indicator light
blinks fast
Coolant is leaking
Contact the service
company
Damaged compressor
Contact the service
company
Ambient temperature is
below 6°C
Keep the ambient
temperature above 7°C
Restart the appliance
'Fault', 'Water Low'
and 'Ice Full' indicator
light blink
simultaneously and
slowly
Hall-effect sensor is not in
a correct position or is
damaged
Contact the service
company
Sensor does not respond
Check if the sensor
condition is acceptable and
if it is in its location
'Fault' indicator blinks
fast
Motor stater damaged
Contact the service
company
Micro-switch does not work
Contact the service
company
Water tank obstructed by
ice cubes
Remove ice cubes from the
storage container
Appliance stops after
approx. 2 minuted and
the 'Water Low'
indicator light blinks
No water supply
Water supply valve closed
Check water supply
Open water supply valve
Water level sensor
damaged or not in correct
position
Contact the service
company
'Water Low' indicator
lights continuously
Appliance was without
water supply for over 24
hours
Switching the appliance off
After restoring the water
supply, connect and restart
the appliance
104049 19 / 22
EN
Error
Possible Cause
Solution
Ice cubes remain in
water container
Solenoid valve does not
work
Contact the service
company
Remains of ice cubes in
water tank
Switch the appliance off
Remove the remains of ice
cubes
Ice cubes are not
produced, no indicator
lights are lit
Damaged solenoid valve
Contact the service
company
Compressor does not work
Contact the service
company
Ice cubes feature
uneven sizes
Coolant is leaking
Contact the service
company
Too high a temperature in
water tank
Keep the ambient
temperature above 7°C
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
8 Disposal
Electrical Appliance
Disposal
Electrical appliances should be returned to designated collection points.
Coolant
The propellant used in the appliance is flammable. It should be utilised pursuant to
national regulations in force.
