Original
-
Gebrauchs
anleitung
CS1600
A150683
V1/1115
GB/UK
ENGLISH
Table of contents
1.Safety ........................................................................................................................ 18
1.1 Safety instructions ................................................................................................ 18
1.2 Key to symbols ..................................................................................................... 22
1.3 Proper use ............................................................................................................ 23
2. General information ................................................................................................ 24
2.1 Liability and Warrantees ....................................................................................... 24
2.2 Copyright protection ............................................................................................. 24
2.3 Declaration of conformity ...................................................................................... 24
3. Transport, packaging and storage......................................................................... 25
3.1 Delivery check ...................................................................................................... 25
3.2 Packaging ............................................................................................................. 25
3.3 Storage ................................................................................................................. 25
4. Technical data ......................................................................................................... 26
4.1 Overview of parts ................................................................................................. 26
4.2 Technical specification ......................................................................................... 27
5. Installation and operation ....................................................................................... 27
5.1 Installation ............................................................................................................ 27
5.2 Operation .............................................................................................................. 28
6. Cleaning ................................................................................................................... 31
7. Waste disposal ........................................................................................................ 32
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 17 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
Please keep these instructions and give them to future owners of the device.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Safety instructions
•
The device is not intended for use by individuals (including children)
with physical or mental disabilities, insufficient experience, and/or
insufficient knowledge unless such persons are under the care of a
person responsible for their safety or have received instructions
regarding appropriate use of the device.
•
Children should be observed to ensure that they are not playing with
the device.
•
Never leave the device unattended when in use.
- 18 -
Only use the device indoors.
•
•
The device is not adapted for use with an external timer or remote
control.
•
Prevent access of children to the package materials like plastic bags
and foamed polystyrene elements. Suffocation hazard!
•
This device may only be operated in technically proper and safe
condition.
•
Only a qualified technician and using original spare parts and
accessories should carry out repairs and maintenance of the device.
Do not attempt to repair the device yourself.
•
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous for the
user or lead to damages of the device or personal injury, and further,
the warranty expires.
•
To prevent hazards and to ensure optimum efficiency, no modifications
or alterations to the device that are not explicitly approved by the
manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the safety instructions below.
•
Never allow the power cable to come into contact with heat sources or
sharp edges. The power cable should not hang over the side of the
working surface. Ensure that no one can step on or trip over the cable.
•
The power cable must not be folded, bent or tangled, and must always
remain fully unrolled. Never place the device or other objects on the
power cable.
- 19 -
Do not lay the power cable over carpets or other inflammable
•
materials. Do not cover the cable. Keep away the cable from
operating range and do not immerse it into water.
•
Check the power cord regularly for damage. Do not use the appliance
if the power cord is damaged. If this cable is damaged, it must be
replaced by customer service or a qualified electrician in order to avoid
dangers.
•
The supply cable must be disconnected from the socket only by
pulling the plug.
•
Never carry or lift the device by the supply cable.
•
In any case do not open the device housing. In case of electrical or
mechanical modifications the electric shock hazard will occur.
•
Never immerse the appliance, the power cord and the power plug in
water or other liquids; do not put it under running water and clean any
parts of the appliance in the in the dishwasher.
•
Do not use any acid agents and make sure no water ingresses the
device.
•
Never operate the device with moist hands or standing on wet floor.
•
Remove the plug from its socket:
- 20 -
-
when the device is not used,
-
in case of anomalies during operation,
-
before cleaning.
HOT SURFACE! Burn hazard!
Follow the safety instructions listed in order to avoid the hazard:
•
The housing and the grill plates of the appliance become very hot.
during operation. Do not touch them with bare hands. Use always the
operating handle in order to open the device. Use appropriate kitchen
utensils for laying and taking of food.
•
Even after switching off the device is hot for some time, allow the
appliance to cool down sufficiently, before you clean it or move to
another place.
•
Never move this appliance during operation.
WARNING! Fire or explosion hazard!
Follow the safety instructions listed in order to avoid the hazard:
•
In order to avoid risk of fire and damage to the device, never place
kitchen utensils, towels, paper and the like on the grill plate during
operation.
•
Never operate the device near combustible, easily flammable
materials (e.g. petrol, spirit, alcohol etc.). They evaporate through
heating and in case of contact with ignition sources deflagrations
can occur which can lead to serious personal injuries and property
damages.
•
When a fire arises unplug the power cord from the socket before you
initiate appropriate measures for fire-fighting. Provide sufficient supply
of fresh air.
Caution: Never extinguish the fire with water when the power plug is
connected to the socket. Electric shock hazard!
- 21 -
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
- 22 -
1.3 Proper use
The operational safety of the device is assured only in case of proper use, according
to the operation manual.
All technical activities like installation and maintenance must be performed by the
qualified service personnel only.
The contact grill is intended only for grilling meat, fish and vegetables.
The contact grill is not suitable for cooking and frying of food in pots or pans on the
Ceran grill plate.
CAUTION!
Any use going beyond the intended purpose and/or any
different use of the device is forbidden and is not considered
as conventional.
Any claims against the manufacturer or his authorized
representative as a consequence of experiencing damages
resulting from unconventional use are impossible.
The operator is liable for all damages resulting from
inappropriate use.
- 23 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
- violation of advice concerning operation and cleaning;
- use other than designed;
- alterations made by user;
- use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
- 24 -
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
- Do not store outdoors.
- Keep it dry and dust-free.
- Do not expose it to aggressive media.
- Do not expose it to direct sunlight.
- Avoid mechanical shocks and vibration.
- In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.
- 25 -
10
4. Technical data
4.1 Overview of parts
11
1
2
3
4
- 26 -
9
8
7
6
5
Heat insulated operating handle
1
Cable guide
2
Lower smooth grill plate
3
Levelling feet
4
Operating light ON / OFF (green)
5
Heating indicator light (red)
6
Temperature control knob
7
Fat collecting pan
8
Fat drain channel
9
Housing
10
Upper smooth grill plate
11
4.2 Technical specification
Name Contact grill CS1600
Art.-No..:
Material: Housing: CNS 18/10; Grill plates: Schott-Ceran
Design:
Power 1,6 kW / 230 V~ 50 Hz
Temperature control
Dimensions of device Width 385 x Depth 495 x Height 165/565 mm
Dimensions of grill plates: Width 250 x Depth 250 mm
Weight: 12,45 kg
We reserve the right to make technical changes!
A150683
Smooth grill plates
Heating indicator light
Operating light ON /OFF
Fat collecting pan
50 °C to 300 °C
5. Installation and operation
5.1 Installation
Positioning
• Unpack the device and remove all packing material.
• Remove the protective foil from the device. Would the residues of glue remain,
removed them with an appropriate solvent.
CAUTION!
Never remove the rating plate and any warning signs from the device.
• Place the device on top of an even, stable, dry, and water-resistant surface which
supports the weight of the device and is not heat sensitive.
• Never place the device in humid or wet environment.
• Never place the device on the flammable surfaces.
• Never place the device near flammable and combustible materials.
- 27 -
• The installation surface must be well accessible and sufficiently large. To enable
comfortable use of the device and to provide good air circulation on all sides, keep
the least distance of 20 cm to all sides of the appliance and 50 cm above and in
front of it.
• Set up the appliance device in such manner that the plug is accessible, so that the
appliance can be quickly disconnected from the power network if necessary.
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid specification should
be compared with that of the device (see rating plate). Connect the device only
in case of compliance!
Connect the device only to properly installed single socket with
protective terminal.
• The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
5.2 Operation
Preparing the device
• Clean the appliance before first use according to instructions in Section 6 „Cleaning“.
• Insert the fat collecting cap.
• Connect the device to a grounded single socket . The green operating light ON /OFF
lights up and indicates that the device is connected to the power supply.
• Heat the device without food up to 200 °C (Section „Grilling of food“) in order to
possibly remove production residues. During the first heating a light smoke formation
can occur, because of inside industrial fats escape. This smoke is not harmful
and it does not occur no longer during the further use of the device.
Provide enough fresh air supply during heating.
- 28 -
Grilling of food
• In order to grill foods, set the desired temperature with the temperature control knob
and heat up the device. The adjustable temperature is between 50 °C and 300 °C.
The optimum temperature for grilling is 250 °C - 280 °C.
• The red heating indicator light lights up while the appliance is heated up.
• Prepare in the meantime, the food desired for grilling.
• As soon as the set temperature is reached, the red heating indicator light goes out.
• Open the heated appliance by lifting the upper grill plate with the operating handle
up to the stop.
• Spread some edible vegetable oil with a heat-resistant brush on the lower grill
plate and lay the food. Close the device by lowering the upper grill plate using
the operating handle.
• Do not leave the device during the grilling process unsupervised.
HOT SURFACE!
The contact grill becomes very hot during operation on the outer sides.
Never touch the appliance during operation or shortly after operation.
Use always the operating handle of the device to open and close the it.
• Open the device after the grilling process with the operating handle and take the
prepared food.
WARNING! Risk of burns!
Protect your hands and face against possible fat splashes!
• Avoid use of hard or sharp objects, in order to prevent damage to the grill plates.
Use wooden spatula, heat resistant tongs or heat-resistant plastic forks in order to
take the grilled food.
• Should the contact grill no longer be used, turn the temperature control knob to „0“
and disconnect the device from the socket (pull the power plug!).
- 29 -
)
The device is equipped with an overheating protection. It switches off the device
in case of overheating. When triggering the overheating protection disconnect the
device from the socket (pull the power plug!) and allow cooling.
Remove with a screwdriver the plastic protective cap on the
back side of the appliance (underneath the label RESET) and
press the RESET pin.
Should the overheating protection trigger repeatedly within a
short time, notify the customer service.
Fat collecting pan
• At the front side of the lower grill plate there is located the fat collecting pan which
collects the outflowing vegetable fats and animal remains fats.
CAUTION!
Never operate the appliance without the fat collecting pan inserted properly.
• During the grilling process the grill juices
and fat flow in the fat drain channel (9)
through the opening (9a) into the fat
collecting pan (8).
• Check and empty the fat collecting pan (8
regularly. Clean them if necessary, dry
9
9a
Instructions for preparation of food
• The contact grill is intended for careful preparation of food with little addition of fat.
• Before you lay the desired food, give a little oil on the lower grill plate. At the best
use the oil with a high smoke point, such as rapeseed or sunflower oil.
• Meat, bacon, etc. require very little oil, because they contain their own fat; when
grilling fish or vegetables you should give a little more oil to the lower grill plate.
The addition of oil reduces sticking or burning of food on the grilling surface.
8
them and insert it again in the device.
• Before cleaning always allow the device,
the fat collection pan and the contents to
cool completely.
- 30 -
• In order to avoid transmission of odours or taste from one food to the other, remove
the food residues from the grill surface between individual grill processes.
• Prepare foods in this sequence: vegetables after steak or fish.
• Never cut food with a knife directly on the grill surface, because the surface may
be scratched by it.
6. Cleaning
CAUTION!
Disconnect the device from the power supply (unplug!) before
cleaning. Let the device cool down.
The device is not designed to be rinsed with running water.
Do not use a pressure washer to clean the device!
Be careful and do not let the water into the device.
o Clean the device at the end of a workday or as required also between the grill
processes.
o Use to clean the device a soft cloth only and never use harsh or abrasive cleaners,
which can scratch the device.
o Never use aggressive cleaning agents or sprays.
o Remove the grill residues from the lower grill plate by wiping them with a paper
towel or by scraping with a suitable Ceran scraper through the opening in the fat
drain channel in the fat collecting pan.
o Clean the upper and lower grill plates with a soft cloth soaked in warm water with
addition of mild detergent. Wipe additionally with clear water.
o Pull out the fat collecting pan from the device. Empty and clean it with a mild
cleaning agent and a soft cloth or sponge. Rinse with clear water and then dry the
fat collecting pan thoroughly, before it is inserted again into the device.
o Wipe the housing and the operating handle of the device with a soft, damp cloth.
o Dry all cleaned surfaces thoroughly afterwards.
- 31 -
Storage of the device
o If the device is not used for a long time, clean it thoroughly as described and store it
in a place which is clean, dry, frost-free, protected from the sun and inaccessible for
children. Do not place any heavy objects on the device.
7. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit
for use before disposal. For that purpose disconnect device from mains
supply and remove mains connection cable from the device.
CAUTION!
For the disposal of the device please consider and
act according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 32 -
Loading...
