V
5/0613
AT90
A120786
GB/UK
ENGLISH
Translation
of the original instruction manual
Read these instructions before using and keep
them available at all times!
1. General information ........................................................................................ 20
1.1 Information about the instruction manual ............................................................ 20
1.2 Key to symbols .................................................................................................... 20
1.3 Liability and Warrantees ...................................................................................... 21
1.4 Copyright protection ............................................................................................ 21
1.5 Declaration of conformity ..................................................................................... 21
2.Safety .............................................................................................................. 22
2.1 General information ............................................................................................. 22
2.2 Safety instructions for use of the device .............................................................. 22
2.3 Intended use ....................................................................................................... 23
3. Transport, packaging and storage .................................................................. 24
3.1 Delivery check ..................................................................................................... 24
3.2 Packaging ........................................................................................................... 24
3.3 Storage ................................................................................................................ 24
4. Technical data ................................................................................................ 25
4.1 Overview of parts ................................................................................................ 25
4.2 Technical specification ........................................................................................ 26
5. Installation and operation ............................................................................... 26
5.1 Safety instructions ............................................................................................... 26
5.2 Installation and connection .................................................................................. 27
5.3 Operation ............................................................................................................ 28
5.4 Cooking methods ................................................................................................ 31
6. Cleaning and maintenance ............................................................................. 34
6.1 Safety advice ....................................................................................................... 34
6.2 Cleaning .............................................................................................................. 34
6.3 Safety instructions for maintenance .................................................................... 35
7. Possible Malfunctions .................................................................................... 35
8. Waste disposal ............................................................................................... 36
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 19 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.
WARNING! Hot surface!
This symbol is a warning that the device surface is hot when in use. Ignoring this
warning may result in burns!
- 20 -
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.
- 21 -
2.Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.
- 22 -
CAUTION!
o Please keep these instructions and give them to future owners of the device.
o All people using the device should follow the instructions and tips contained in these
instructions.
o Only use the device indoors.
2.3 Intended use
ATTENTION!
The device has been designed and built for commercial use and should be
operated only by qualified personnel in kitchen facilities.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The convection oven is designed for the following purposes:
- preparation of meat, fish and vegetables;
- baking of bread, cakes and pies;
- heating of food;
- defrosting of frozen products;
- roasting;
- preparation of chilled and frozen foods.
The convection oven should not be used for:
- heating of premises;
- drying of clothes;
- storage of combustible objects;
- warming and heating of inflammable, hazardous to health, easily volatilizing or
other liquids or substances of similar effect.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.
- 23 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
- Do not store outdoors.
- Keep it dry and dust-free.
- Do not expose it to aggressive media.
- Do not expose it to direct sunlight.
- Avoid mechanical shocks and vibration.
- In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.
- 24 -
4. Technical data
4.1 Overview of parts
⑩
⑨
⑧
⑦
⑥
Housing
①
⑤
①
②
③
④
Glass door
②
Temperature control knob (50 °C - 300 °C)
③
Heating control lamp (green)
④
Operation control lamp (green)
⑤
Adjustable feet
⑥
Main/time control knob (0 – 120 min)
⑦
Supporting rails
⑧
Baking tray
⑨
Glass door handle
⑩
- 25 -
4.2 Technical specification
Name Convection oven AT90
Item No.:
A120786
Design: housing: stainless steel, cooking cavity: enamelled
Temperature adjustment range: 0 °C to 300 °C
Time adjustment range: 0 – 120 min
Power requirements:
2,67 kW / 230 V~ 50/60 Hz
Slide rails: 4 (433 x 333 mm)
Distance between the trays: 70 mm
Dimensions: W 595 x D 615 x H 570 mm
Weight: 38,0 kg
Accessories: 4 baking trays (W 435 x D 315 x H 10 mm)
We reserve the right to make technical changes!
5. Installation and operation
5.1 Safety instructions
WARNING! Risk of electric shock!
The device must only be connected to a properly installed single socket with
protective contact.
Never remove the power cable by pulling the cable itself; always grab the plug
housing.
• Never allow the power cable to come into contact with heat sources or sharp edges.
The power cable should not hang over the side of the working surface. Ensure that no
one can step on or trip over the cable.
• The power cable must not be folded, bent or tangled, and must always remain fully
unrolled.
• Never place the device or other objects on the power cable.
• Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.
• Do not use the device in case it does not function properly, has been damaged or
dropped.
- 26 -
• Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
• Do not move or tilt the device when in operation.
• Never use the device with wet or moist hands.
• Never leave the device unattended when in use.
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with
that of the device (see type label).
Connect the device only in case of compliance!
Take note of the security advice!
5.2 Installation and connection
ATTENTION!
Any installation, maintenance and repair work should be executed only by an
authorized installation engineer!
• Unpack the device and dispose adequately all packaging material.
• Mount the adjustable feet to the device and set the desired height by screwing the
feets in or out. Do not use the device without installing the adjustable feet.
• Remove carefully the protective film from the outside walls so as to avoid adhesive
residues be left. If any adhesive residues remain, remove them with a suitable
solvent.
• Place the device on a flat, safe surface which can withstand the weight of the device
and is not heat sensitive.
• Never place the device on an inflammable surface.
• Do not place the device near open fireplaces, electric ovens, heating stoves or other
heat sources.
• Place the device so that the rear ventilation holes were not blocked or covered.
• Do not place the device near walls or other objects made of combustible materials.
Keep a minimum distance of 10 cm on all sides.
• Do not place any objects on the device.
- 27 -
NOTE!
The device is not suitable for built-in installation and series arrangement!
• The electrical circuit of the socket must be secured to at least 16A. Only connect
the device to a wall outlet; do not use any extension cords or power strips.
• Place the device so that the plug is easily accessible so as to quickly disconnect the
device if the need arises.
5.3 Operation
Preparation of the device
• Clean the device before start-up from inside and outside with a soft damp cloth and
mild detergent. Rinse it thoroughly with clean water.
• Before first use, heat up the device without food, in accordance with the instructions
contained in the chapter "Settings", to eliminate any unpleasant odors that come from
the thermal insulation. Choose the highest temperature and the longest time. A little
smoke or an odor may be generated. This is normal for the first operation and will not
happen again during subsequent use. Then open the glass door so the smoke
residues can escape.
• Clean the baking trays and grill grate with mild detergent. Rinse them with clean
water and then dry with a soft dry cloth.
Settings
NOTE!
Heat up the convection oven well before each use. Set the temperature about 30 °C
higher than the specified one and correct it after charging the convection oven,
which will help you to achieve an even result.
• Turn the device on by means of main / time control knob (rotate it clockwise to the
desired cooking time). Once you activate the knob, the green operation control lamp
will illuminate and the interior lights as well as the fan motors will be turned on.
• Set the desired temperature using the temperature control knob.
The green heating control lamp will illuminate. Once the set temperature is reached,
the green control lamp goes off and lights up again when the temperature in cooking
cavity decreases.
- 28 -
• After reaching the set temperature, place the desired food in cooking cavity of
convection oven.
WARNING! Risk of burns!
Some parts of the device become very hot during operation.
Always open and close the convection oven with the help of door handle.
Use protective gloves when you operate the device.
• There can be placed 4 baking trays in four slide rails of the convection oven at the
same time. When charging the device keep at least 40 mm distance between the
food and the baking tray above it, in order to maintain optimum heat distribution in
the cooking cavity.
• After the preset time elapses a signal sounds, the green time setting lamp goes off
and the device automatically switches off.
• Remove the cooked food.
• If the device is no longer used, turn it off (set the main / time control knob and
temperature control knob to the "0" position) and disconnect it from the power
supply (pull the plug!).
ATTENTION!
The device is equipped with an overheating protection device, which trips at
320 °C and shuts down the device. If the overheating protection device has
tripped, let the device be cooled for some time and press the RESET button at
the rear of the device to bring it back into operation.
Rules for the roasting/baking process
Roasting process in a convection oven with air circulation
The roasting process in a convection oven is realized with the recirculation of hot air inside
the device. This allows even roasting/baking due to uniform temperature distribution.
The advantage of the convection oven consists in the fact that the different dishes can be
roasted/baked at the same time (when the cooking temperature is the same), without the
risk of mixing different flavors.
- 29 -
Variable parameters during roasting/baking:
temperature
time
amount
Temperature
A precise temperature adjustment guarantees proper roasting/baking of dishes, both on
their outer part as well as inside them.
Too low temperature causes rather drying of food than its roasting.
Too high temperature, however, can lead to burning of the food on the outside, and the
interior still remains raw (a phenomenon that is sometimes desirable, especially in case
of meat).
Time
This variable depends on the amount of food which are to be prepared.
The larger the amount is, the longer the roasting/baking times and vice versa.
Too short cooking times compared to the correct ones do not allow for full preparation of
food; too long cooking times compared to the correct ones lead to burning of food on the
outside.
Amount
The amount of food affects the cooking time. A larger amount of food always leads to
longer cooking times and vice versa.
Use of baking molds/grill grate
It is recommended to use:
Baking molds of aluminum for pastries and non-frozen bread,
Baking molds of steel for starters, meat, fish, potatoes,
Grill grate for roasting of meat (such as steak, sausages,
bratwursts), frozen products (eg pizza, rolls,
baguettes).
NOTE!
Use only heat-resistant roasting tins or baking molds. Pay attention to the
instructions of the manufacturer!
- 30 -
5.4 Cooking methods
First dishes
Lasagne, pasta bake, Cannelloni should be cooked at a temperature between 185 °C 190 °C. In order to achieve a golden yellow crust, the temperature at the end of
cooking process should be increased to 220 °C - 230 °C.
Roasting
Beef, pork, chicken, turkey, lamb. Run the process at a temperature of 180 °C to
ensure that the meat is thoroughly roasted. In the final phase, the meat should be
scorched for a few minutes at a temperature of 240 °C - 250 °C to dry out.
Browning of meat
Chop, steak, sausages, hamburgers.
Insert the grill grate together with food to be roasted, slightly smeared with oil. Slide a
drip tray under the grill grate. Roast at 220 °C - 230 °C. In the final phase increase
temperature to 280 °C for a few minutes so that the dishes be slightly browned.
Roast beef
Roast at a temperature of 220 °C.
Fish
Roast plaice, cod, hake at a temperature of 200 °C.
Roast potatoes
Roast at a termperature of 170 °C -180 °C.
Pastries
Normally, carry out baking at a temperature of 180 °C. Avoid opening the convection
oven door during the baking process.
Bread
Bake at a termperature of 200 °C.
Cooking of frozen products
Let the frozen bread defrost and bake it at a temperature of 200 °C.
Pre-baked, frozen pizza should be slid into the hot oven in still frozen state and be
baked at a given temperature for a few minutes. Follow the instructions of the
manufacturer on the packaging!
- 31 -
Temperature
Cooking time
Roll/toast
Warm up at 220 °C.
Warming up of the meals
Process the meals at ca. 150 °C.
Defrosting of the meals
Defrost at 80 °C.
Cooking/baking table
Roasted/baked product
Cakes 135 – 160
Pastries
Biscuits 160 – 175 25 – 35
Small cakes 175 15 – 20
Cherry cake 175
Cakes with
yeast/baking
powder
Fruit pie 220
Puff pastry 210
Shortcrust pastry 200 – 225
Cake 175 40 - 50
Meringues 100 100 – 130
Biscuits 175 15 – 20
Baked goods
Shortcrust biscuits 150 – 175 5
Fruit cakes 200 8
Croissants 180 18 – 20
Bread/butter soufflé 175 – 190 45
Pudding
Egg custard 165 45
Fruit pudding 160 45
Stuffed cannelloni 190 20
First dishes
Egg soufflé 185 25
Lasagna 190 27
Macaroni soufflé 190 40
in °C
in min ca.
depending on the
weight
- 32 -
Temperature
Cooking time
Well roa
sted turkey
Thoroghly
roasted
Chicken
Duck
Roasted/baked product
Bratwursts (lean) 225 10 – 15 min
Roast joints 225 15 – 30 min
Fast roasts
Liver 250 10 – 15 min
Roast sirloin 250 15 – 30 min
Chicken breasts 200 30 min
Lamb pink
Haunch 5 – 2 kg 175 50 min per kg
Roast lamb 175 30 min per kg
Lamb shoulder 175 50 min per kg
* until the last 30
minutes of cooking
**during the last 30
minutes of cooking
in °C
in min ca.
160 – 175
175 – 200 30 min per kg
Meat
Wild
pork
Ham more than 2 kg 175 50 min per kg
Loin and shoulder 175 60 min per kg
Beef medium
Beef tenderloin 2 kg 175 30 min per kg
Roast beef 175 30 min per kg
Fillet steak 175 – 200 20 min per kg
2 kg golden
yellow roasted and
175 50 min per kg
stewed
2 kg with juice, not
dry
180 60 min per kg
Wild rabbit 2 kg 175 60 – 90 min
Deer 170 – 200 90 min
Pheasant 175 – 200 35 – 90 min
- 33 -
Temperature
Cooking time
Roasted/baked product
in °C
in min ca.
Fried potatoes, crispy 175 60 min
Side dishes
Braised potatoes
thoroughly cooked with
150 – 175 30 min per kg
sauce
Fish
Fillets (small) 200 15 – 20 min
Fish 1 ½ kg 200 30 – 40 min
6. Cleaning and maintenance
6.1 Safety advice
o Before beginning with repair or cleaning works make sure the device has been
disconnected from power supply and has cooled down.
o Do not use any acid agents and make sure no water ingresses the device.
o To protect yourself from electric shock, never immerse the device, its cables and
the plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets.
Therefore, you must not use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
o Clean the device after each use to prevent burning of residues from baking or roasting.
o Clean the device inside and outside with a damp soft cloth and mild detergent.
o For heavy stains, use commercially available oven cleaners.
o Clean the baking trays with paper towels or a damp cloth. Put a little oil on the baking
tray in order to remove stubborn residues and let them soak for about 5 to 10 minutes.
Then wipe with a damp cloth or kitchen paper.
o Clean the applied accessories such as grill grate, baking mold, etc. under running
warm water with a soft cloth or sponge and mild detergent. Rinse with clean water and
dry it thoroughly.
o Never clean the device with sharp or hard kitchen utensils and never use any kind
of abrasive cleaning agents to avoid damaging the surface of the device.
o Use soft dry cloth for drying and polishing the surface after cleaning.
- 34 -
6.3 Safety instructions for maintenance
o Inspect the power cable regularly for damage. Never use the device if the cable is
damaged. If the power cable is damaged, have an authorised service center or
qualified electrician replace it.
o In case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
o Only a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
7. Possible Malfunctions
Problem Cause Remedy
Device connected to
the power supply, but
the green operation
control lamp is not lit.
Device connected to
the power supply, but
does not heat up.
• Mains plug not inserted
properly.
• Main/time control knob
not set.
• Temperature not set.
• Heating element is
defective.
• Disconnect mains plug and
insert it properly.
• Set the main/time control
knob.
• Temperature not set.
• Heating element is defective.
Device is connected to
power supply, but
does not work.
Cooking/roasting
result is uneven.
• Overheating protection
device has tripped.
• Fan is defective.
• Temperature control
knob is defective.
• Distance between food
and baking tray above
the food is too low.
• Let the device cool down.
Press the RESET button at
the rear. When overheating
protection device trips, contact
service or notify your dealer.
• Contact a dealer
• Contact a dealer
• Keep the minimum distance
of 40 mm.
- 35 -
Problem Cause Remedy
• Light bulb is defective. • Disconnect the device from
the power supply and let it
Cooking cavity lamp is
defective.
cool down. Unscrew the bulb
and replace it with the one
having the same technical
characteristics (220 V, 15 W).
If you cannot eliminate the malfunction:
- Disconnect the device from the power supply (pull the plug!),
- Do not open the housing,
- Notify customer service or contact a dealer.
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act
according to the national and local rules and
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: +49 (0) 5258 971-0
Germany fax: +49 (0) 5258 971-120
- 36 -
regulations.
Loading...
