Aurora 22
190187
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: +49 5258 971-0
Fax: +49 5258 971-120
Technical Support Hotline: +49 5258 971-197
www.bartscher.com
Version: 1.0
Date of preparation: 2020-01-22
EN
Original instruction manual
1 Safety ............................................................................................................ 2
1.1 Explanation of signal words ..................................................................... 2
1.2 Safety instructions.................................................................................... 3
1.3 Intended use ............................................................................................ 6
1.4 Unintended use ........................................................................................ 6
2 General information ....................................................................................... 7
2.1 Liability and warranty ................................ ............................................... 7
2.2 Copyright protection ................................................................................. 7
2.3 Declaration of conformity ......................................................................... 7
3 Transport, packaging and storage ................................................................. 8
3.1 Delivery check ......................................................................................... 8
3.2 Packaging ................................................................................................ 8
3.3 Storage .................................................................................................... 8
4 Technical data ................................................................ ............................... 9
4.1 Technical specifications ........................................................................... 9
4.2 List of components of the appliance....................................................... 10
4.3 Functions of the appliance ..................................................................... 12
5 Installation and operation ............................................................................ 12
5.1 Installation .............................................................................................. 12
5.2 Operation ............................................................................................... 13
6 Cleaning ...................................................................................................... 17
6.1 Safety Instructions for cleaning .............................................................. 17
6.2 Cleaning ................................................................................................. 18
6.3 Descaling ............................................................................................... 19
7 Possible malfunctions .................................................................................. 21
8 Disposal ....................................................................................................... 22
190187 1 / 24
Safety
EN
Read this instruction manual before using and keep it available
at all times!
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
Diese Bedienungsanleitung beschreibt di e Installation, Bedienung und Wartung des Geräts und gilt als wichtige Inform ationsquelle und Nachschlagewerk. Die Kenntnis aller enthaltenen Sicherheitshi nweise und Handlungsanweisungen schafft die Voraussetzung für das sich ere und sachgerechte Arbeiten mit d em Gerät. Darüber hinaus müssen die für den Einsatzbereich des Geräts gelt enden örtlichen Unfallverhütungsvorsc hriften und allgemeinen Sicherheitsbesti mmungen eingehalten werden. Dies e Bedienungsanleitung ist Bestandteil d es Produkts und muss in unmittelbarer N ähe des Geräts für das In¬stall ations-, Bedienungs-, Wartungs- und R einigungspersonal jederzeit zugängli ch auf¬bewahrt werden. Wenn das Gerät a n eine dritte Person
weitergegeben wird, muss die Bedienungsa nleitung mit ausgehändigt werden.
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of signal words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
2 / 24 190187
Safety
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
, die
1.2 Safety instructions
Electrical current
• Too high a mains voltage or incorrect installation may cause electric shock.
• The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
• To avoid short-circuit, the appliance should be kept dry.
• If there are malfunctions during operation, disconnect the appliance from the
power supply.
• Do not touch the appliance’s plug with wet hands.
• Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
• Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
• Do not transport the appliance, holding it by the power cord.
• Do not allow the power cord to come into contact with heat sources or sharp
edges.
• Do not bend, pinch nor knot the power cord.
• Always completely unwind the power cord.
190187 3 / 24
Safety
EN
• Never place the appliance or other objects on the power cord.
• Always take hold of the plug to disconnect the appliance from the power supply.
Flammable materials
• Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
• To avoid fire hazard, clean the appliance regularly.
• Do not cover the appliance with, e.g., aluminium foil or cloths.
• Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
• Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
• In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
• Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Hot surfaces
• Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
• Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
• You may transport and clean the appliance after it cools down entirely.
• It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
4 / 24 190187
Safety
EN
Health hazard due to germs!
• The water tank must be regularly emptied and disinfected to eliminate the
possibility of accumulation of harmful and dangerous germs.
Supervised usage only
• Only supervised appliance may be used.
• Always remain in an immediate vicinity of the appliance.
Operating personnel
• The appliance may only be operated by qualified personnel and trained
specialist personnel.
• This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
• Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper use
• Unintended or prohibited use may cause damage to the appliance.
• The appliance may only be used in a technically flawless condition, providing for
safe use.
• The appliance may only be used with connections in a technically flawless
condition, providing for safe use.
• The appliance may only be used clean.
• Use only original spare parts. Never attempt to repair the appliance on your
own.
• Do not attempt to modify nor alter the appliance.
190187 5 / 24
Safety
EN
1.3 Intended use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Brewing coffee with the use of ground coffee, a filter and cold water.
1.4 Unintended use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
– Preparing other beverages.
– Brewing liquids containing sugar, sweeteners, acids, lyes, or alcohols.
– Storing and heating up flammable, harmful, and quickly evaporating
liquids or materials, etc.
6 / 24 190187
General information
EN
2 General information
2.1 Liability and warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
– failure to observe instructions,
– unintended use,
– technical alterations introduced by the user,
– usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.
190187 7 / 24
Transport, packaging and storage
EN
3 Transport, packaging and storage
3.1 Delivery check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
– in closed rooms;
– in dry and dust-free surrounding;
– away from aggressive agents;
– in a location protected against sunlight;
– in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
8 / 24 190187
Technical data
EN
Name:
Coffee machine Aurora 22
Item No.:
190187
Material:
Stainless steel
Jug volume, in l:
1,9
Number of hobs:
1
Max. output, number of cups:
12
Brewing time of 1.9 l, in min.:
8
Minimum brewing volume, in l:
0,5
Power supply:
1,4 kW / 230 V / 50-60 Hz
Dimensions (W x D x H) in mm:
215 x 405 x 520
Weight in kg:
8
4 Technical data
4.1 Technical specifications
We reserve the right to implement technical modifications!
Version / Characteristics
• Version: basket filter
• Control: rocker switch
• ON/OFF switch
• Descaling signal
• Indicator lights:
– Ready
– ON/OFF
– Descaling
• Stainless steel heating element
• The set includes: 1 thermal jug with pump system, stainless steel
190187 9 / 24
Technical data
EN
Fig. 1
1. Cover flap for cold water fill
opening
2. ON/OFF switch with integrated
operation indicator light (red)
3. Heating-up indicator light (green)
4. Descaling indicator light (red)
5. Filter basket with insert
6. Water tank
7. Bottom hob
8. Thermo pump jug
4.2 List of components of the appliance
10 / 24 190187
Technical data
EN
Heating-up indicator light (green)
It remains on during the entire brewing process. When the
brewing process is finished, a series of three beeps is heard
and the green indicator light goes off.
Descaling indicator light (red)
The descaling indicator light flashes when it is necessary to
descale the device. If it is not possible to clean the coffee
machine immediately, it is still possible to brew several pots
of coffee before descaling.
Fig. 2
Description
Art. no.:
Basket filter, paper, 250 pieces
Order unit: 1 box (250 filters)
Top diameter: 250 mm
Bottom diameter: 90 mm
Size: W 150 x D 150 x H 85 mm
Weight: 0.45 kg
190015250
Basket filter, paper, 1,000 pieces
Order unit: 1 box (1,000 filters)
Top diameter: 250 mm
Bottom diameter: 90 mm
Size: W 150 x D 150 x H 85 mm
Weight: 1.79 kg
190014
Descaling agent B15-30, 30 pcs.
Order unit: 1 box (30 bags, 15 g
each)
Version: powder, highly concentrated
Dimensions: W 68 x D 4 x H 100 mm
Weight: 0.45 kg
190065
Indicator Lights
Auxiliary equipment (not included in the delivery!)
190187 11 / 24
Installation and operation
EN
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
4.3 Functions of the appliance
The appliance is designed for brewing coffee with the use of a filter and cold water.
5 Installation and operation
5.1 Installation
Unpacking / Positioning
• Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
• If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
• Be careful not to damage the rating plate and warning labels fixed on the
appliance.
• Never place the appliance in humid or wet environment.
• Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
• The appliance should be placed on surfaces that are:
– even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
• Leave at least 10 cm clearance from flammable walls and items.
12 / 24 190187
Installation and operation
EN
WARNING!
Risk of burns!
The filter basket and the coffee dregs are hot after the brewing process.
In order to remove the coffee dregs, remove the filter basket carefully.
Risk of burns!
During the brewing a small amount of hot steam is produced.
Maintain caution when removing the thermal pump jug from the hob.
ATTENTION!
Never fill hot water into the water tank.
Do not fill water into the hot device. Wait until it has cooled down.
Power supply connection
• Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
• Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
• The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
• Do not use the appliance with an external timer or remote control.
5.2 Operation
Before the first use
1. Before using the coffee machine for the first time, circulate water 2 or 3 times
without coffee, to rinse the appliance (section "Coffee Preparation").
2. Due to the design of the appliance, after the first use, a small amount of water
remains in the water container. Take this into consideration when refilling the
tank with water.
190187 13 / 24
Installation and operation
EN
3. The water tank should always be filled
with the amount of water that equals the
volume of the enclosed thermal pump
jug.
The amount of coffee brewed will be the
same as the amount of water poured.
If, accidentally, the water tanks is filled with
an excessive amount of water, the excess
of water will flow through the overflow hose
(a).
Fig. 3
ATTENTION!
When brewing coffee without filter basket
insert, the paper filter may clog the outlet
opening of the filter basket and may make it
impossible for coffee to flow to the thermal jug.
After washing, the removable insert must be
fitted in the bottom of the filter basket, so that it
is not discarded accidentally when removing
coffee dregs.
Fig. 4
4. Before use, the thermal pump jug and filter basket with insert should be
thoroughly washed in warm water and a mild cleaning agent, and then rinsed with
fresh water and dried thoroughly after washing.
5. Wipe the appliance housing with a moist cloth and wipe dry with a soft cloth.
6. Plug the appliance into a suitable single socket.
The coffee machine is ready for use.
14 / 24 190187
Installation and operation
EN
Fig. 5
Fig. 6
1. Open the fill opening flap.
2. Fill the water tank with fresh
drinking water with the necessary
volume of water, up to 1.9 litres.
3. The minimum amount necessary
for brewing coffee is 0.5 litre.
4. Remove the filter basket.
5. Into the filter basket, insert
Bartscher paper basket filter (art.
No. 190014 or 190015250).
6. Add a proper amount of ground
coffee into paper basket filter.
According to your liking, add 35 –
50 g of coffee per a litre of water.
7. Place the filter basket in the guides
and slide it all the way to the rear
until it 'clicks' into place.
Coffee preparation
ATTENTION!
Fill the water tank only with fresh drinking water. Never pour sugar, coffee,
tea or milk into the fill opening of the coffee machine.
190187 15 / 24
Installation and operation
EN
8. Open the cover of the thermal pump jug and remove the pump’s tube.
9. Open the thermal pump jug’s cover to the side.
10. Place the open thermal pump jug on the bottom plate, in such a manner that the
thermal pump jug opening is located below the drip opening of the filter basket.
11. Switch the appliance on with the ON/OFF switch.
The red operation indicator light in the ON/OFF switch comes on.
The green heating-up indicator light will be lit and will remain on during the entire
brewing process.
Coffee will begin to brew. After a short time, the hot coffee will start flowing into the
thermal pump jug.
When the brewing process is finished, the coffee machine automatically turns itself
off and the green heating indicator light goes off.
The coffee is ready to be served.
12. Remove the thermal pump jug from the bottom plate.
13. Re-insert the pump tube back into the can.
14. Close the pump lid until the buttons click into place.
16 / 24 190187
Cleaning
EN
Fig. 7
Fig. 8
1. To pour drinks from the thermal
pump jug, pull the pump lid up until
it clicks.
2. Next, press the pump lever to start
the pump mechanism.
3. Press the lever as many times as
required to fill in the container (cup,
glass) with the desired amount of
beverage.
Coffee dispensing from the thermal pump jug
Overheating protection
The appliance is equipped with the overheating protection. If overheating occurs
during dry operation or scaling, it engages and switches the appliance off. When the
cause is removed, the coffee machine may be switched on again in order to restore
its operational readiness, by pressing the RESET button at the rear side of the
appliance.
6 Cleaning
6.1 Safety Instructions for cleaning
• Before cleaning, disconnect the appliance from the power supply.
• Leave the appliance to cool down completely.
• Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
• Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
190187 17 / 24
Cleaning
EN
ATTENTION!
Always, prior to cleaning, moving or transport of the coffee machine,
empty the water tank.
WARNING!
Risk of burns!
Water in the water tank becomes very hot.
Drain the rest of water from the tank only when the appliance and water
has cooled down enough. To end with, tighten the drain screw.
1. Drain the water remaining in the water
tank with the use of drain screw (b) at the
rear side of the appliance (at the bottom).
2. After each use, clean the thermal pump
jug and filter basket with insert with warm
water and mild cleaning agent.
3. Rinse the cleaned elements in fresh water
and dry.
Fig. 9
• For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
4. Wipe the housing of the appliance with a soft, moist cloth, and dry at the end.
5. Conduct the brewing process as described in section "Coffee Preparation"; do
not use ground coffee if the appliance has not been used for a prolonged time.
18 / 24 190187
Cleaning
EN
NOTE!
To reduce limescale deposits, it is recommended to use filtered water!
CAUTION!
Injury hazard!
Use safety gloves and goggles during descaling!
Cleaning the Thermal Pump Jug
Hard water may leave calcium deposits inside the thermal pump can. Coffee usually
colour the deposits and leave the brownish deposit. To remove these deposits,
follow the below indications:
– prepare a solution of hot water and descaling agent (art. No. 190065);
– open the lid of the thermal pump jug and remove the pump tube;
– fill the thermal pump jug with the prepared solution;
– re-insert the pump tube back into the thermal jug;
– leave the solution in the jug for 20 minutes;
– pour the solution out;
– rinse the thermal pump jug and the pump tube thoroughly with clean
water several times;
– wipe the outside of the thermal pump jug with a soft cloth at the end;
– after cleaning, leave the thermal pump jug open to dry completely.
6.3 Descaling
Depending on the water hardness level in the place of usage, limescale may be
deposited inside of the appliance's elements during the operation of the coffee
machine. In order to maintain the appliance in the best possible condition, and to be
certain that every brewing process yields the best results, the appliance should be
descaled regularly.
The coffee machine is equipped with the descale indicator light (red) which
activates after exceeding a certain level of limescale. When the descale indicator
light flashes, the device needs to be descaled, otherwise the proper operation and
quality of brewed coffee cannot be ensured.
If it is not possible to clean the coffee machine immediately, it is still possible to
brew several pots of coffee before descaling.
For descaling the appliance we recommend the tried and proven agent:
190187 19 / 24
Cleaning
EN
Descaling agent Bartscher B15-30 (art. No. 190065).
Perform the following steps:
– dissolve 1 bag (15 g) of the descaling agent in 500 ml of fresh water;
NOTE: Observe the minimum amount of brewing liquid for the appliance!
– pour the descaling solution into the coffee machine's water tank;
– place the right paper basket filter in the filter basket;
– insert the filter basket into guides (without ground coffee);
– place the enclosed thermal pump jug under the filter basket;
– switch the appliance on, as with the regular brewing process;
– when a small amount of solution flows to the thermal pump jug, switch
the appliance off with the ON/OFF switch;
– wait approx. 5–6 minutes so that the remaining part of the solution may
act on limescale deposits;
– switch the appliance on anew and wait, until the rest of the descaling
solution flows;
– as soon as the whole descaling solution has flown through, switch the
appliance off;
– remove the descaling solution from the thermal pump jug;
– after descaling, repeat the brewing process 2–3 times with the use of
fresh water only;
– to end with, drain the water remaining in the water tank with the use of
drain screw at the rear side of the appliance (at the bottom);
– clean the filter basket and the thermal pump jug thoroughly.
The appliance is now ready to resume brewing coffee.
20 / 24 190187
Possible malfunctions
EN
Problem
Cause
Solution
The appliance is
switched off, but
the red operation
indicator light in
the ON/OFF switch
does not come on.
Incorrectly connected plug.
Connect the plug.
The premises connection
fuse tripped.
Disconnect the appliance
from mains supply, reset the
fuse and re-connect the
appliance.
Damaged operation
indicator light.
Contact the supplier.
Damaged switch.
Contact the supplier.
When switched on,
the fuse is tripped
immediately.
Short circuit.
Contact the supplier.
The appliance is
switched on, the
green heating-up
indicator light does
not come on and
hot water does not
flow.
Too little of brewed liquid.
Observe the minimum
amount of brewed liquid.
Damaged level switch.
Contact the supplier.
7 Possible malfunctions
Mögliche
The table below contains descriptions of possible causes and solutions to
malfunctions or errors during operation of the appliance. When malfunction cannot
be removed, contact the technical service.
190187 21 / 24
EN
Problem
Cause
Solution
The appliance
switches off.
The overheating protection
was triggered: too little
water or no water in the
water tank.
Pull the plug out.
Wait for the appliance to
cool down.
Press the RESET button at
the rear side of the
appliance.
Thermostat broken.
Contact the supplier.
Descaling indicator
light (red) flashes.
Limescale in the coffee
machine exceeds the critical
level.
Descale the coffee machine
(section: “Descaling“).
The appliance is
switched on, the
green heating-up
indicator light
comes on but hot
water does not flow
out.
Heating element of the
brewing function damaged.
Contact the supplier.
Damaged thermostat.
Contact the supplier.
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
8 Disposal
Electrical appliance
Disposal
Electrical appliances should be returned to designated collection points.
22 / 24 190187
