PRO 250-G
174303
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: +49 5258 971-0
Fax: +49 5258 971-120
Technical Support Hotline: +49 5258 971-197
www.bartscher.com
Version: 1.0
Date of preparation: 2019-05-27
EN
Original instruction manual
1 Safety ............................................................................................................ 2
1.1 Explanation of signal words ..................................................................... 2
1.2 Safety instructions.................................................................................... 3
1.3 Intended use ............................................................................................ 5
1.4 Unintended Use ....................................................................................... 5
2 General information ....................................................................................... 6
2.1 Liability and warranty ................................ ............................................... 6
2.2 Copyright protection ................................................................................. 6
2.3 Declaration of conformity ......................................................................... 6
3 Transport, packaging and storage ................................................................. 7
3.1 Delivery Check ......................................................................................... 7
3.2 Packaging ................................................................................................ 7
3.3 Storage .................................................................................................... 7
4 Technical data ................................................................ ............................... 8
4.1 List of components of the appliance......................................................... 8
4.2 Technical specifications ......................................................................... 10
4.3 Functions of the appliance ..................................................................... 11
4.4 Protective Elements of the Appliance .................................................... 11
5 Installation and operation ............................................................................ 13
5.1 Installation .............................................................................................. 13
5.2 Operation ............................................................................................... 14
6 Cleaning ...................................................................................................... 18
6.1 Safety Instructions for cleaning .............................................................. 18
6.2 Cleaning ................................................................................................. 18
7 Possible Malfunctions .................................................................................. 21
8 Disposal ....................................................................................................... 22
174303 1 / 24
Safety
EN
Read this instruction manual before using and keep it available
at all times!
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
Diese Bedienungsanleitung beschreibt di e Installation, Bedienung und Wartung d es Geräts und gilt als wichtige Inform ationsquelle und Nachschlagewer k. Die Kenntnis aller enthaltenen Sicherheits hinweise und Handlungsanweisungen sch afft die Voraussetzung für das sich ere und sachgerechte Arbeiten mit d em Gerät. Darüber hinaus müssen die für den Einsatzbereich des Geräts gelte nden örtlichen Unfallverhütungsvorsc hriften und allgemeinen Sicherheitsb estimmungen eingehalten werden. Diese Bedienungsanleitung ist Bestandt eil des Produkts und muss in unmitt elbarer Nähe des Geräts für das In¬stall ations-, Bedienungs-, Wartungs- und R einigungspersonal jederzeit zugängli ch auf¬bewahrt werden. Wenn das Gerät a n eine dritte Person
weitergegeben wird, muss die Bedienungsa nleitung mit ausgehändigt werden.
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of signal words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
2 / 24 174303
Safety
EN
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
, die
1.2 Safety instructions
Electrical current
• Too high a mains voltage or incorrect installation may cause electric shock.
• The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
• To avoid short-circuit, the appliance should be kept dry.
• If there are malfunctions during operation, disconnect the appliance from the
power supply.
• Do not touch the appliance’s plug with wet hands.
• Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
• Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
• Do not transport the appliance, holding it by the power cord.
• Do not allow the power cord to come into contact with heat sources or sharp
edges.
• Do not bend, pinch nor knot the power cord.
• Always completely unwind the power cord.
• Never place the appliance or other objects on the power cord.
• Always take hold of the plug to disconnect the appliance from the power supply.
174303 3 / 24
Safety
EN
Supervised usage only
• Only supervised appliance may be used.
• Always remain in an immediate vicinity of the appliance.
Operating Personnel
• The appliance may only be operated by qualified personnel and trained
specialist personnel.
• This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
• Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Safety During Operation of the Slicer
• Never put hands between the pusher handle and the blade or the movable slice
thickness partition until they are completely secured (slice thickness adjustment
knob set to “0” position).
• During slicing operation keep hands away from the blade in order to avoid cuts
and accidents. In order to avoid accidents, always use the pusher handle to
push the product to be sliced to the movable slice thickness partition.
• The blade is very sharp; caution is advised when checking the blade sharpness.
During operation wear cut protection gloves class 5 of DIN EN 388 standard!
• During operation, the operator should wear safety clothing that meets local
sanitary standards.
4 / 24 174303
Safety
EN
Improper Use
• Unintended or prohibited use may cause damage to the appliance.
• The appliance may only be used when its technical condition is flawless and
allows for safe operation.
• The appliance may only be used when all connections are executed according
to rules of law in force.
• The appliance may only be used when it is clean.
• Use only original spare parts. Never attempt to repair the appliance on your
own.
• Do not introduce any changes in the appliance nor modify it.
1.3 Intended use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Cutting of cold meats and cheese.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
– Cutting of products that are not food products.
– Cutting products with bones.
– Cutting frozen products.
174303 5 / 24
General information
EN
2 General information
2.1 Liability and warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
– failure to observe instructions,
– unintended use,
– technical alterations introduced by the user,
– usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.
6 / 24 174303
Transport, packaging and storage
EN
3 Transport, packaging and storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
– in closed rooms;
– in dry and dust-free surrounding;
– away from aggressive agents;
– in a location protected against sunlight;
– in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
174303 7 / 24
Technical data
EN
1. Blade
2. Sharpener
3. Blade protective cover
4. Pusher handle with pusher
5. Pusher grip
6. Food tray
7. Carriage with handle
8. Base
9. Carriage locking knob
10. Adjustable feet (4x)
11. Slice thickness adjustment knob
12. STOP button (red)
13. Operation indicator light (orange)
14. START button (green)
15. Slice tray
16. Carriage handle
17. Movable slice thickness partition
18. Pusher handle guard
19. Blade protective cover retaining
screw
20. Slice guide
21. Movable slice thickness partition
guard
22. Cleaning brush
4 Technical data
4.1 List of components of the appliance
Key to Figure 1
8 / 24 174303
Technical data
EN
Fig. 1
174303 9 / 24
Technical data
EN
Name:
Slicer PRO 250-G
Item No.:
174303
Material:
Aluminium
Blade diameter in mm:
250
Maximum rotational speed in RPMs:
300
Cutting thickness range in mm:
0 - 15
Cutting length in mm:
200
Cutting height in mm:
160
Degree of protection:
IP33
Power supply:
0.16 kW / 230 V 50 Hz
Dimensions (W x D x H) in mm:
410 x 560 x 400
Cable length in mm:
2
Weight in kg:
22,25
4.2 Technical specifications
We reserve the right to implement technical modifications!
Version / Characteristics
• Design: oblique blade / gravity blade, gear appliance
• Carriage design: 1 handle, detachable
• Designed for: cold meats, cheese
• Sharpener
• Pusher
• Slice guide
• Blade protective cover
• Control: button
• ON/OFF button
• Indicator light: ready for operation
10 / 24 174303
Technical data
EN
No.
(Fig. 1)
Name
Safety measures to eliminate risk
2
Sharpener
Serves as a top blade protective cover during
operation; protects against cut wounds.
When the sharpener is removed during
operation the appliance stops. After correct
fitting of the sharpener, the appliance does not
start automatically, but must be re-started with
the START button.
3
Blade protective
cover
Blade protective cover is equipped with locking
system, which makes it impossible to start the
appliance if the protective cover is removed or
fitted incorrectly.
17
Movable slice
thickness partition
Protective measure against unintended starting
of blade drive.
7
Carriage
Locking system renders it impossible to start the
blade drive with the carriage dismounted.
The carriage may be dismounted, for example,
for cleaning, only when the slice thickness
adjustment knob is set back to “0” position and
the carriage is completely pulled towards the
slice thickness adjustment knob.
4.3 Functions of the appliance
The slicer is an appliance, which makes it possible to rapidly slice different kinds of
cold meats, meat and cheese.
4.4 Protective Elements of the Appliance
Mechanical Protective Elements
174303 11 / 24
Technical data
EN
No.
(Fig. 1)
Name
Safety measures to eliminate risk
18
Pusher handle guard
The guard is fitted permanently and renders it
difficult to grab the sliced product with hands
and protects against possible chip-offs.
4
Pusher handle with
pusher
Prevents cut wounds stemming from contact
with the blade.
5
Pusher grip
Prevents hands from slipping.
No.
Fig. 1
Name
Safety measures to eliminate risk
12+
14
Switches
After power cut the appliance may be switched
on only by pressing the START button.
Protective cover of
electrical installation
compartment (under
the appliance)
Prevents indirect contact with live components.
Electrical protection
(see electrical
diagram)
Central protective contact.
Motor near the motor housing.
Electric Protective Elements
Residual Risks
Despite all mechanical and electrical protective means the appliance is equipped
with according to the regulations (both in the operational phase and during cleaning
and maintenance), residual risks exist that cannot be completely precluded. In this
instruction manual they are indicated by the warning word WARNING. Observe also
warning indications on warning stickers placed on the appliance.
Residual risks (e.g. danger of injury) may be present also when slicing smaller
pieces or pushing residues. To this end, the appliance is equipped with the pusher
handle with pusher.
After disassembly of the appliance for cleaning, pay particular attention to the blade,
as with the sharpener removed, part of the blade is exposed.
12 / 24 174303
Installation and operation
EN
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
5 Installation and operation
5.1 Installation
Unpacking / Positioning
• Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
• If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
• Be careful not to damage the rating plate and warning labels fixed on the
appliance.
• Never place the appliance in humid or wet environment.
• Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
• The appliance should be placed on surfaces that are:
– even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
• When selecting the place to set the appliance in, consider the dimensions of the
appliance (section “Technical Specification”). Provide enough space to securely
operate the appliance.
• Operation location must be well lit.
• Place the appliance in a way making the operator be constantly able to see the
ON/OFF switch and slice thickness adjustment knob.
174303 13 / 24
Installation and operation
EN
To securely use the slicer, keep at least 20 cm distance from the slicer and walls,
objects, cupboards, etc.
• The distance from the floor should be approx. 80 cm.
Power supply connection
• Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
• Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
• The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
• Do not use the appliance with an external timer or remote control.
5.2 Operation
Before the First Use
1. Remove transport protection means from the appliance:
– plastic blade cover;
– preserving film.
2. Before use, clean the appliance according to the instructions set out in point 6
“Cleaning”.
3. Check before starting:
– if the parts removed for cleaning are refitted correctly;
– if the carriage is fitted with the carriage locking knob;
– if the sharpener is correctly fitted;
– opening of the movable slice thickness partition with the slice thickness
adjustment knob by rotating it clockwise and counter-clockwise;
– if the food tray is sliding freely by moving it with the handle;
– if the pusher handle moves freely by raising and lowering it with the
pusher grip.
14 / 24 174303
Installation and operation
EN
WARNING!
Danger of injury inflicted by sharp blade!
Never assume the position in which hands, fingers or other parts of the
body may come into contact with the blade.
Never put hands between the pusher handle (4) and the blade (1) or the
movable slice thickness partition (17) until they are completely closed
(slice thickness adjustment knob (11) set to “0” position).
Keep hands away from the blade (1) during operation. Use the pusher
grip with pusher (4).
Slicing Process
1. Prior to loading the slicer with food products for slicing, the slice thickness
adjustment knob should be set to “0” position (red point) and start the
appliance.
2. Lift the pusher handle (4) and put the food product to be sliced on the food tray
(6) so that it is between the movable slice thickness partition (17) and the
pusher handle with pusher (4).
3. Assume correct position: make sure to stand in a vertical position in relation to
the working table.
4. Set the desired slice thickness with the slice thickness adjustment knob (11) in
the range of 1–15 mm.
5. Start the appliance through pushing of the green START button (14).
The orange operational control lamp lights (13).
6. Hold the pusher grip (5) with the right hand and place the left hand ready next to
the slice guide (20) in order to remove the slices (do not touch the blade).
7. Slowly move the carriage (7) (carriage tray + pusher handle + grip) by slightly
pressing the product towards the blade (1).
The product to be sliced comes into contact with the blade; the slice slides via the
slice guide (20) and falls on the slice tray (15) positioned behind the movable slice
thickness partition (17).
7. When the slicing operations are finished, switch the slicer off with the red STOP
button (12) and set the slice thickness adjustment knob (11) to “0” position. Do
not allow the appliance to run idle.
174303 15 / 24
Installation and operation
EN
Fig. 2: The sharpener mounted
Fig. 3: Removal of the sharpener
Fig. 4: Preparation for sharpening
Fig. 5: Blade sharpening
8. The sliced product may now be removed from the slice tray (15).
9. When the surface of a sliced product becomes frayed or coarse and the cutting
operations become cumbersome, the blade must be sharpened.
Blade Sharpening
The slicer’s blade is sharpened with the appliance’s sharpener.
1. Disconnect the appliance from the socket (pull the plug).
2. Prior to sharpening, the blade must be cleaned.
3. Before sharpening, carefully clean the edge of the blade with denatured alcohol
to degrease it.
4. Dry the blade thoroughly.
5. Carry out the sharpening process as indicated below:
– remove the sharpener from the appliance (Fig. 2);
– rotate the sharpener by 180° and set it onto the mandrel, until you feel
resistance (Fig. 3).
16 / 24 174303
Installation and operation
EN
The sharpener is now ready for blade sharpening (Fig. 4).
Prior to blade sharpening, make sure the slicer is prepared the same way as for the
slicing process. Proceed in the following way:
1. Connect the appliance to the power supply.
2. Turn the appliance on by pressing the START button (14).
3. For 5 – 10 seconds, keep the rear wall grinding button pressed (Fig. 4).
4. Then, for the same period of time, press the front smoothing button.
5. At the end of the sharpening process keep both buttons — rear wall button and
front wall smoothing button — pressed for 2 – 3 seconds in order to deburr the
blade (Fig. 4).
ATTENTION: Deburring should not take longer than 2 – 3 seconds to avoid
the cutting edge deformation.
6. Turn the appliance off by pressing the STOP button (12).
7. Check if the blade is sharp enough.
Blade sharpness may be checked with the use of slice of paper, running it through
blade edge. Sharp blade will cut the paper instantly.
8. Clean the grinding stones after sharpening. They should always be kept clean,
to have them operate correctly. Follow the instructions in section 6 “Cleaning”.
9. In order to clean the blade (1), remove the blade protective cover (3). Follow the
instructions in section 6 “Cleaning”.
10. To finish with, refit the blade protective cover (3).
11. Set the sharpener (2) back in its initial position (Fig. 1), proceeding in reverse
order.
NOTE: Sharpening process gradually diminishes the blade diameter.
Diameter of a new blade is 250 mm. If the blade diameter is smaller than
240 mm, further sharpening is no longer possible and the blade must be
exchanged with a new one.
174303 17 / 24
Cleaning
EN
Fig. 6
Fig. 7
6 Cleaning
6.1 Safety Instructions for cleaning
• Before cleaning, disconnect the appliance from the power supply.
• Leave the appliance to cool down completely.
• Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
• Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
• For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
1. At the end of each working day, and more frequently if needed, thoroughly clean
all parts of the appliance that come into contact with food products.
2. Perform the following prior to cleaning:
– disconnect the appliance from power supply (pull the plug)
– set the slice thickness adjustment knob (11) in “0” position
– move the carriage (7) towards the slice thickness adjustment knob (11),
until you hear clear the sound of clicking.
18 / 24 174303
Cleaning
EN
Fig. 8
3. Turn off the carriage locking knob (9) (Fig. 7).
4. Remove the complete carriage assembly from the appliance, together with food
tray (6), pusher handle (4) with pusher and guard (18).
5. Loosen the blade protective cover retaining screw (19) at the rear wall of the
appliance.
6. Remove the blade protective cover (3) with the help of both handles (Fig. 6).
7. Remove the slice guide (20) from the appliance, by raising and removing it from
screws (Fig. 8).
8. Wash the removed parts thoroughly in warm water with gentle cleaning agent.
9. Rinse with clean water to remove remains of the cleaning agent.
10. Thoroughly dry the cleaned elements before re-attaching.
WARNING! The blade of the appliance is extremely sharp — do not touch
any blade edges! During cleaning of the blade wear cut protection gloves
of class 5 of DIN EN 388.
11. Remove the sharpener (2) from the appliance.
12. Clean the blade (1) of the appliance with a sponge or a wet cloth.
13. Clean the permanently fixed central blade safety cover (under the blade
protective cover (3)). Remove food products left-overs that accumulated on the
blade protective cover, using the enclosed cleaning brush (22).
14. Clean the sharpener’s grinding stones (2) thoroughly with the enclosed cleaning
brush; to end with, use denatured alcohol. Keep them clean at all times.
15. All other sharpener’s elements should be cleaned in warm water with mild
cleaning agent.
16. Clean the slice tray (15) and base (8) with wet cloth. Wipe with a cloth
moistened in clean water.
17. Dry all cleaned surfaces thoroughly.
18. Refit the removed parts back in the appliance:
174303 19 / 24
Cleaning
EN
Fig. 9
Fig. 10
– fit the blade protective cover (3) with two handles back onto the opening
of central safety cover; at the end, screw on the blade protective cover
retaining screw (19) at the rear wall of the appliance;
– fit the sharpener (2) on top, as a protective element;
– refit the appliance with a complete carriage assembly and screw it in with
the carriage locking knob (9).
Maintenance
The slicer must be regularly lubricated with a precision mechanics oil in locations
(A, B, C, D) presented in Fig. 9 and 10. The appliance and oiling nipples should be
thoroughly cleaned as per the above indications.
NOTE: Do not use edible oil for lubrication.
Daily Maintenance
[A] — Oiling of the carriage guide
[B] — Oiling of the carriage
Indicated locations should be oiled daily or when slight resistance may be sensed.
Use the enclosed precision mechanics oil.
20 / 24 174303
Possible Malfunctions
EN
Malfunction
Possible reason
Solution
The machine does not
work
No power
Check the electric power
supply
Damaged electrical
installation
Contact the supplier
Blade protective cover
fitted incorrectly
Screw in the blade
protective cover retaining
screw
Damaged condenser
Contact the supplier
Damaged switch
Contact the supplier
Damaged motor
Contact the supplier
Noises after starting
Damaged spiral gear
Contact the supplier
Damaged ball bearing
Contact the supplier
Damaged blade retaining
element
Contact the supplier
Unsatisfactory slicing
results
Blunt blade
Contact the supplier
The appliance is soiled
Clean the soiled parts
The carriage runs with
difficulties
Lubricate the carriage
Monthly Maintenance
[C] — Oiling of the food tray with a few drops of oil
Quarterly Maintenance
[D] — Once per three months grease rotational elements of the sharpener (mandrel
and sleeves)
7 Possible Malfunctions
Mögliche
174303 21 / 24
Disposal
EN
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
8 Disposal
Electrical appliance
Electrical appliances should be returned to designated collection points.
22 / 24 174303
Loading...
