110851 / 110851MA - 110852 / 110852MA 110853 / 110853MA - 110854 / 110854MA 110855 / 110855MA - 110856 / 110856MA 110857 / 110857MA - 110858 / 110858MA -
110864 / 110864MA
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: +49 5258 971-0
Fax: +49 5258 971-120
Technical Support Hotline: +49 5258 971-197
www.bartscher.com
Version: 1.0
Date of preparation: 2019-12-04
EN
Original instruction manual
1 Safety ............................................................................................................ 2
1.1 Explanation of signal words ..................................................................... 2
1.2 Safety instructions.................................................................................... 3
1.3 Intended use ............................................................................................ 6
1.4 Unintended use ........................................................................................ 6
2 General information ....................................................................................... 7
2.1 Liability and warranty ................................ ............................................... 7
2.2 Copyright protection ................................................................................. 7
2.3 Declaration of conformity ......................................................................... 7
3 Transport, packaging and storage ................................................................. 8
3.1 Delivery check ......................................................................................... 8
3.2 Packaging ................................................................................................ 8
3.3 Storage .................................................................................................... 8
4 Technical data ................................................................ ............................... 9
4.1 Technical specifications ........................................................................... 9
4.2 List of components of the appliance....................................................... 14
4.3 Functions of the appliance ..................................................................... 14
5 Installation and operation ............................................................................ 15
5.1 Installation .............................................................................................. 15
5.2 Operation ............................................................................................... 17
6 Cleaning and Maintenance .......................................................................... 22
6.1 Safety Instructions for cleaning .............................................................. 22
6.2 Cleaning ................................................................................................. 22
6.3 Maintenance .......................................................................................... 22
7 Possible malfunctions .................................................................................. 23
8 Disposal ....................................................................................................... 26
110851 / 110851MA 1 / 28
Safety
EN
Read this instruction manual before using and keep it available
at all times!
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
Diese Bedienungsanleitung beschreibt di e Installation, Bedienung und Wartung des Geräts und gilt als wichtige Inform ationsquelle und Nachschlagewerk. Die Kenntnis aller enthaltenen Sicherheitshi nweise und Handlungsanweisungen schafft die Voraussetzung für das sich ere und sachgerechte Arbeiten mit d em Gerät. Darüber hinaus müssen die für den Einsatzbereich des Geräts gelt enden örtlichen Unfallverhütungsvorsc hriften und allgemeinen Sicherheitsbesti mmungen eingehalten werden. Dies e Bedienungsanleitung ist Bestandteil d es Produkts und muss in unmittelbarer N ähe des Geräts für das In¬stall ations-, Bedienungs-, Wartungs- und R einigungspersonal jederzeit zugängli ch auf¬bewahrt werden. Wenn das Gerät a n eine dritte Person
weitergegeben wird, muss die Bedienungsa nleitung mit ausgehändigt werden.
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of signal words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
2 / 28 110851 / 110851MA
Safety
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
, die
1.2 Safety instructions
Electrical current
• Too high a mains voltage or incorrect installation may cause electric shock.
• The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
• To avoid short-circuit, the appliance should be kept dry.
• If there are malfunctions during operation, disconnect the appliance from the
power supply.
• Do not touch the appliance’s plug with wet hands.
• Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
• Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
• Do not transport the appliance, holding it by the power cord.
• Do not allow the power cord to come into contact with heat sources or sharp
edges.
• Do not bend, pinch nor knot the power cord.
• Always completely unwind the power cord.
110851 / 110851MA 3 / 28
Safety
EN
• Never place the appliance or other objects on the power cord.
• Always take hold of the plug to disconnect the appliance from the power supply.
Incorrect operation of the appliance ma y cause fire or explosion hazard due to igniti on of its content.
Fire hazard / flammable materials hazard / explosion hazard!
• Do not use any electric devices in the appliance.
• Do not store nor use petrol or other flammable liquids and gases in the vicinity of
this or any other appliance. Those gases may cause fire or explosion hazard.
• Do not put into the appliance any explosive materials, like sprays filled with
flammable propellants. Contents of containers filled with flammable gases and
liquids may leak in low temperatures, and the contents may catch fire from
sparks generated by an electric appliance. Explosion hazard!
• In the case of coolant leakage, pull the plug from the socket. Remove all
sources of ignition in the vicinity, ventilate room and contact technical service.
Avoid coolant getting in contact with eyes, as it may cause serious eye damage.
• Never use any flammable liquids for cleaning the appliance or its parts. Gases
released may cause fire or explosion hazard.
• In the case of fire, disconnect the appliance from the power supply before
attempting adequate fire-extinguishing actions.
• Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
• Defrosting process may not be sped up with mechanical means or heat energy
sources (candles or heaters) nor with any other means. Vapour produced may
cause short-circuit and too high temperatures may damage the appliance.
• All ventilation slots should not be obstructed during operation.
• Never attempt to damage cooling installation of the appliance.
Operating personnel
• The appliance may only be operated by qualified personnel and trained
specialist personnel.
• This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
• Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper use
• Unintended or prohibited use may cause damage to the appliance.
• The appliance may only be used when its technical condition is flawless and
allows for safe operation.
4 / 28 110851 / 110851MA
Safety
EN
• The appliance may only be used when all connections are executed according
to rules of law in force.
• The appliance may only be used when it is clean.
• Use only original spare parts. Never attempt to repair the appliance on your
own.
• Do not introduce any changes in the appliance nor modify it.
• Do not drill hole in the appliance nor install any objects on it.
• Do not place any heavy objects on the appliance.
110851 / 110851MA 5 / 28
Safety
EN
1.3 Intended use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Cooling of suitable food products.
1.4 Unintended use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
– Storing flammable or explosive objects and liquids, such as ether,
petroleum or adhesives;
– Storing explosive materials, like sprays filled with flammable propellants;
– Storing pharmaceutical products or preserved blood;
– Storing live pets.
6 / 28 110851 / 110851MA
General information
EN
2 General information
2.1 Liability and warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
– failure to observe instructions,
– unintended use,
– technical alterations introduced by the user,
– usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.
110851 / 110851MA 7 / 28
Transport, packaging and storage
EN
3 Transport, packaging and storage
3.1 Delivery check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
– in closed rooms;
– in dry and dust-free surrounding;
– away from aggressive agents;
– in a location protected against sunlight;
– in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
8 / 28 110851 / 110851MA
Technical data
EN
Name:
Refrigerated counter T2 / T2 MA
Art. No.:
110851 / 110851MA
Number of cabinets:
2
Cabinet dimensions (W x D x H) in mm:
335 x 570 x 554
Number of doors:
2
Number of guide rail pairs:
1
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption, in kWh/year:
752
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,35 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.342 x 700 x 850
Weight in kg:
88 / *89
4 Technical data
4.1 Technical specifications
Version / Characteristics of Refrigerated Counter
• Material: chrome-nickel steel
• Cooling: circulating air
• Cooling cabinets and drawers
• Climate class: 4
• Temperature control: thermostatic
• Temperature range: 0 °C – 10 °C
• Control: touch
• Digital display
• ON/OFF switch
• Indicator light: ON/OFF
• Automatic defrost function
• Evaporation of condensed water
• Door type: leaf door
• Right-hand side door, with the possibility for door hinge to be changed
• Type of shelves: grille, steel, coated with plastic
• Height-adjustable: 850 - 900 mm
110851 / 110851MA 9 / 28
Technical data
EN
Name:
Refrigerated counter S2T1-150 / S2T1150 MA
Art. No.:
110852 / 110852MA
Number of cabinets:
1
Cabinet dimensions (W x D x H) in mm:
335 x 570 x 554
Number of doors:
1
Number of guide rail pairs:
1
Number of drawers:
2
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
150
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption, in kWh/year:
752
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,35 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.342 x 700 x 850
Weight in kg:
99,5 / *100,5
Name:
Refrigerated counter S4-150 / S4-150
MA
Art. No.:
110853 / 110853MA
Number of drawers:
4
Norm format drawers
1/1 GN
Max. GN container depth in mm:
3 x 150, 1 x 100
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption, in kWh/year:
752
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,35 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.342 x 700 x 850
Weight in kg:
110,5 / *111,5
10 / 28 110851 / 110851MA
Technical data
EN
Name:
Refrigerated counter S4-150 / S4-150
MA
Art. No.:
110854 / 110854MA
Number of drawers:
6
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
100
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
D (EU Nr. 2015 / 1094)
Energy consumption in kWh/year:
1026
Coolant, amount in kg:
R600a / 0,096
Power supply:
0,35 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.342 x 700 x 850
Weight in kg:
131 / *132
Name:
Refrigerated counter S2T2-150 / S2T2150 MA
Art. No.:
110855 / 110855MA
Number of cabinets:
2
Cabinet dimensions (W x D x H) mm:
335 x 570 x 554
Number of doors:
2
Number of guide rail pairs:
1
Number of drawers:
2
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
150
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption in kWh/year:
931
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,452 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.792 x 700 x 850
Weight in kg:
122,2 / *123,2
110851 / 110851MA 11 / 28
Technical data
EN
Name:
Refrigerated counter S4T1-150 / S4T1150 MA
Art. No.:
110856 / 110856MA
Number of cabinets:
1
Cabinet dimensions (W x D x H) mm:
335 x 570 x 554
Number of doors:
1
Number of guide rail pairs:
1
Number of drawers:
4
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
150
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption, in kWh/year:
931
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,452 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.792 x 700 x 850
Weight in kg:
133,8 / *134,8
Name:
Refrigerated counter S6-150 / S6-150
MA
Art. No.:
110857 / 110857MA
Number of drawers:
6
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
5 x 150, 1 x 100
Drawer dimensions (W x D x H) in mm:
299 x 572 x 190
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption in kWh/year:
931
Coolant, amount in kg:
R600a / 0,064
Power supply:
0,452 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.792 x 700 x 850
Weight in kg:
144,2 / *145,2
12 / 28 110851 / 110851MA
Technical data
EN
Name:
Refrigerated counter S9-100/S9-100MA
Art. No.:
110858 / 110858MA
Number of drawers:
9
Norm format drawers:
1/1 GN
Max. GN container depth in mm:
100
Drawer dimensions (W x D x H) in mm:
299 x 572 x 100
Energy efficiency class:
D (EU Nr. 2015 / 1094)
Energy consumption in kWh/year:
1271
Coolant, amount in kg:
R600a / 0,096
Power supply:
0.452 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.792 x 700 x 850
Weight, in kg:
171 / *172
Name:
Refrigerated counter T3 / T3 MA
Art. No.:
110864 / 110864MA
Number of cabinets:
1
Norm format cabinet:
1/1 GN
Max. GN container depth, in mm:
40
Cabinet dimensions (W x D x H), mm:
1.250 x 585 x 500
Number of guide rail pairs:
6
Distance between guide rail pairs, mm:
60
Number of doors:
3
Load-bearing cap.per guide pair, kg:
50
Energy efficiency class:
C (EU Nr. 2015 / 1094)
Energy consumption, in kWh/year:
931
Coolant, amount in kg:
R600a / 0,096 kg
Power supply:
0.414 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
1.792 x 700 x 850
Weight, in kg:
111 / *112
We reserve the right to implement technical modifications!
Refrigerated Counters MA with 50 mm upturned edge
* Weight of refrigerated counters with upturned edge
110851 / 110851MA 13 / 28
Technical data
EN
1. Housing
2. Worktop
3. Ventilation openings
4. ON/OFF switch with integrated
power indicator light (green)
5. Digital temperature regulator
6. Door
7. Drawer
8. Height-adjustable feet (4 pcs.)
4.2 List of components of the appliance
4.3 Functions of the appliance
The appliance is designed for cooling and storage of suitable food products.
14 / 28 110851 / 110851MA
Installation and operation
EN
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
5 Installation and operation
5.1 Installation
Unpacking / Positioning
• Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
• If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
• Be careful not to damage the rating plate and warning labels fixed on the
appliance.
• Never place the appliance in humid or wet environment.
• Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
• The appliance should be placed on surfaces that are:
– even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• Nie należy umieszczać urządzenia w gorąc ym otoczeniu a ni w pobliżu m ateriałów łat wopalnych.
• The appliance requires sufficient airflow f or proper operation. Assure a minimu m lateral clearance of the appliance of 10 c m.
• Die Öffnungen am Gerät niemals abdec ken oder blockieren.
110851 / 110851MA 15 / 28
Installation and operation
EN
• Do not place the appliance in direct sunlight or in the vicinity of heat sources
(cooker, radiator, heating devices, etc.). Heat sources may negatively affect
power consumption, and restrict functions of the appliance, too.
• The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessary. The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessar y. The electric socket should be easily accessi ble so it is possible to quickly discon nect the power cord when necessary.
• Nie należy umieszczać urządzenia w gorąc ym otoczeniu a ni w pobliżu m ateriałów łat wopalnych.
• The appliance requires sufficient airflow f or proper operation. Assure a minimu m lateral clearance of the appliance of 10 cm .
• Die Öffnungen am Gerät niemals abdec ken oder blockieren.
• Place the appliance so that sufficient air circulation is ensured. Do not block nor
cover ventilation openings in the rear wall of the appliance.
• Leave at least 10 cm clearance from walls and other objects.
• Do not position the appliance in high humidity locations. Air relative humidity in
the place of installation should not exceed 60%. Excessive humidity may cause
rust and negatively influence the refrigerating efficiency of the device.
• The appliance should be installed only in rooms, in which ambient temperature
falls within the range of 10°C – 38 °C.
• Nie należy umieszczać urządzenia w gorąc ym otoczeniu a ni w pobliżu m ateriałów łat wopalnych.
• The appliance requires sufficient airflow f or proper operation. Assure a minimu m lateral clearance of the appliance of 1 0 cm.
• Die Öffnungen am Gerät niemals abdec ken oder blockieren.
• In order to avoid damage to the compressor, do not tilt the appliance more than
45° when positioning or transporting it.
• The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessar y. The electric socket should be easil y accessible so it is possible to quickly discon nect the power cord when necessary. The electric socket should be easily accessi ble so it is possible to quickly discon nect the power cord when necessar y.
• To install the appliance, perform the following steps:
– Remove the packaging of the appliance, except for the pallet.
– Lift the appliance with the lift truck and move it to the planned installation
location. Be careful not to damage the appliance. Control the stability in
order not to lose the balance of the appliance.
– Do not drag nor push the appliance, as it may fall down. This may also
cause the damage to external elements or feet.
– As soon as the appliance is in the planned installation location, remove
the pallet.
– Level the appliance by screwing in or out the height-adjustable feet.
– Remove the protective film from the appliance at the end.
Power supply connection
• Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
• Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
• The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
• Prior to first use, the appliance should be installed and left standing upright for at
least 2 hours, before it is connected to power supply.
• After a power failure or when the plug is removed from the socket, do not
reconnect the appliance to power supply for at least 5 minutes.
16 / 28 110851 / 110851MA
Installation and operation
EN
5.2 Operation
Tips for the User
• Fill the refrigerated counter only when the digital display shows that the required
temperature has been reached.
• Do not fill the refrigerated counter with warm food products nor liquids, as well
as uncovered food products.
• Use seal-tight containers for storing food products and beverages, to protect the
aromas of the food products and beverages and avoid mixing the aromas inside
the refrigerated counter.
• During the first filing or full filling of refrigerated counter always open and fill only
one cabinet to avoid tilting of the appliance.
• While placing food products in the refrigerated counter keep in mind that
sufficient space must be maintained between the internal walls of the device and
stored food products to assure free circulation of air inside the appliance.
• The more items in the refrigerated counter, and the longer the doors/drawers
are kept open, the higher the energy consumption.
• To limit loss of cold air minimize the opening time of doors/drawers. Moreover,
the doors/drawers should not be opened too often.
• To avoid occurrence of unpleasant odour in the device follow the recommended
storage periods of food products.
110851 / 110851MA 17 / 28
Installation and operation
EN
Preparation of the appliance
1. Prior to first operation, clean the appliance and its equipment according to
instructions in section 6 “Cleaning”.
2. Finally, dry the appliance and accessories thoroughly.
3. Plug the appliance into a suitable single socket.
4. Press the ON/OFF switch to “I” position, to switch the appliance on.
The green power indicator light in the ON/OFF switch lights up.
After switching on, the and LEDs are lit in the digital display.
Then the factory set temperature of is shown in the digital display.
5. Let the appliance reach the required operating temperature before you place
food products in the refrigerated counter.
Functions of operating elements and displays
The basic temperature setting is factory default and it equals the appliance
operating temperature of 0 °C – 10 °C.
With normal operation, the set value of the temperature sensor is displayed in the
digital display.
The LEDs in the digital display indicate the status of function activation (Table 1),
and with 3 buttons some functions may be activated/deactivated (Table 2).
18 / 28 110851 / 110851MA
Installation and operation
EN
Assigned
Function
Normal Operation
Start-up
ON
OFF
Flashes
1
Compressor
ON
OFF
Required
ON
2
Fan
ON
OFF
Required
ON 3 Defrosting
ON
OFF
OFF
ON
4
Auxiliary
output
Active output
Inactive output
-
ON
5
RTC clock
RTC available,
activated
(tEN=1) and at
least 1
programmed
time cycle
RTC unavailable
/ deactivated
(tEN=0) and no
programmed
time cycle
-
ON
6
Alarm
Active alarm
No active alarm
-
ON
7
Digits display
Consists of 3 displayed positions with a point and -199…999
interval. See /4, /5, /6 parameters for the sensor
measurement value display, values in °C/°F and a point
Table 1
Messages
110851 / 110851MA 19 / 28
EN
Functions of Buttons
Button
Normal Operation
Start-up
Single press of the
button
Combo press
of buttons
1
UP
ON/OFF
– For more than 3
sec.:
interchangeable
display of the
ON/OFF status
Pressed
concurrently:
Activation/dea
ctivation of
continuous
operation
-
3
DOWN
Defrost
– For more than 3
sec.:
Activation/deactivatio
n of defrosting
Pressed
concurrently
: Activation
of
parameter
RESET
procedure
Pressed for
more than 1
sec.: Display
of software
version
2
Set
Mute
– 1 sec.:
Display/setting of the
set value
– For more than 3
sec.:
Access to parameter
configuration (input
password 22)
– Switching off the
sound alarm
(buzzer)
-
Pressed for
more than 1
sec.: EZY
RESET
Table 2
Installation and operation
20 / 28 110851 / 110851MA
Installation and operation
EN
Setting the set value (set temperature value)
To introduce the setting or to change the set value, perform the following steps:
1. Press the button for 1 second.
The set value will start blinking immediately after.
2. Press the or button to increase or decrease the value.
3. Press the button, to confirm the new value.
Automatic defrosting
The appliance defrosts automatically 3 times over 24-hour period. The timer
initiates with the first activation.
If there is a need for the change of automatic defrosting phases, press the
button and hold it for more than 3 seconds.
The digital display shows the symbol.
The appliance will start defrosting immediately, and the next defrosting process will
commence after 8 hours.
Manual defrosting activation
Additionally, aside of the automatic defrosting, manual defrosting may be activated
any time:
1. Press the button for more than 3 seconds.
The defrosting is activated immediately. The digital display shows the symbol.
NOTE!
If introduction of additional settings or modifications of parameters are
necessary, contact technical service.
Switching the appliance off
1. If the appliance is not to be used for a longer period of time, set the ON/OFF
switch to the “O” (OFF) position.
2. Disconnect the appliance from the mains socket (pull the plug out).
110851 / 110851MA 21 / 28
Cleaning and Maintenance
EN
6 Cleaning and Maintenance
6.1 Safety Instructions for cleaning
• Before cleaning, disconnect the appliance from the power supply.
• Leave the appliance to cool down completely.
• Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
• Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
• For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
1. Clean the appliance regularly.
2. Remove all objects from the appliance and store them temporarily in a cool
room or in a refrigerator.
3. Remove all shelves from the appliance (if the appliance is equipped with them).
4. Clean the shelves with mild washing agent and soft cloth or sponge in warm
water.
5. Rinse the shelves with clean water and dry thoroughly with soft cloth.
6. Clean the door shelves and drawers regularly from the inside with a food-grade
cleaning disinfectant.
7. Clean the appliance from the outside with a soft, damp cloth.
8. Finally, dry thoroughly all washed surfaces.
9. After cleaning, leave the doors/drawers open for the appliance to dry
completely.
10. Regularly remove dust and fibres from the rear wall of the appliance with a soft
brush or dust brush.
11. If the appliance is not to be used for a longer period of time, clean it according to
the instructions above. Leave the appliance open to prevent generation of
unpleasant odours inside.
6.3 Maintenance
The following operations should be regularly performed by a qualified specialist, to
provide for prolonged and correct operation of the refrigerating unit:
22 / 28 110851 / 110851MA
Possible malfunctions
EN
Error
Possible Cause
Solution
No cooling.
Plug improperly inserted
into the socket.
Remove the plug and insert
it properly in the socket.
Electric power supply safety
fuse damaged.
Check the fuse, connect the
appliance to another socket.
No power supply.
Check electric power
supply.
Damaged temperature
controller.
Contact the service
company.
Damaged mains power
plug.
Contact the service
company.
Insufficient cooling
efficiency.
Incorrect setting
temperature.
Check the temperature
setting; press the
button to display the set
value.
– cleaning the condenser (front right compartment) with a suitable tool
(vacuum cleaner or a soft brush);
– checking of electrical connections;
– checking of the thermostat and the sensor.
7 Possible malfunctions
Mögliche
The table below contains descriptions of possible causes and solutions to
malfunctions or errors during operation of the appliance. When malfunction cannot
be removed, contact the technical service.
110851 / 110851MA 23 / 28
Possible malfunctions
EN
Error
Possible Cause
Solution
Insufficient cooling
efficiency.
Direct sunlight or heat
sources in immediate
vicinity.
Move the appliance away
from heat sources.
Poor air circulation around
the appliance.
Keep sufficient clearance
from walls or other objects.
The products placed inside
the appliance are too hot.
Leave the food products to
cool down before you place
them inside the appliance.
Products incorrectly
arranged in the appliance.
Provide for sufficient
clearance between objects
inside the appliance; do not
cover ventilation openings.
The appliance is overfilled.
Avoid overfilling of the
appliance, remove the
excess of food product.
Condenser obstructed with
dust.
Clean the condenser
thoroughly.
Strange or loud
noises.
The appliance is not placed
on even surface.
Place the appliance on an
even surface, level it with
the use of the heightadjustable feet.
Doors/drawers are not
closed.
Close the doors/drawers
tightly.
Appliance touches walls or
other objects.
Keep sufficient clearance
from walls or other objects.
Alarms and prompts
In the case of the alarm, the proper prompt flashes on the digital display,
interchangeably with the temperature value; also, the buzzer and the alarm replay
(if available) may be activated.
All alarms go off automatically (i.e. alarm prompt is stopped, when the cause for the
alarm is eliminated; only the 'CHt' alarm must be confirmed manually through
switching off and on again of the appliance with the use of button or
disconnection from the mains supply).
24 / 28 110851 / 110851MA
Possible malfunctions
EN
Alarm
Code
Buzzer and
Alarm Relay
LED
Description
RESET
E0
Active
ON
Sensor 1 error =
regulation
Automatically
E1
Inactive
ON
Sensor 2 error =
defrosting
Automatically
E2
Inactive
ON
Sensor 3 error =
condenser / product
Automatically
IA
Active
ON
External alarm
Automatically
dOr
Active
ON
Open door alarm
Automatically
LO
Active
ON
Low temperature alarm
Automatically
HI
Active
ON
High temperature alarm
Automatically
EE
Inactive
ON
Appliance parameters
error
Impossible
EF
Inactive
ON
Operation parameters
error
Manually
Ed
Inactive
ON
Defrosting due to
exceeded time limit
With the first,
correctly completed
defrosting
dF
Inactive
ON
Defrosting in progress
Automatically
cht
Inactive
ON
Initial alarm of the soiled
condenser
Automatically
CHt
Active
ON
Alarm of the soiled
condenser
Manually
EtC
Inactive
ON
Alarm of timers
Through the setting
of a timer
Table 3
When pressed, the button switches off the buzzer; but the displayed alarm
code and the alarm relay are deactivated only when the cause of the alarm is
eliminated. The available alarm codes are listed in Table 3 below.
110851 / 110851MA 25 / 28
Disposal
EN
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
8 Disposal
Electrical appliance
Electrical appliances should be returned to designated collection points.
Coolant
The propellant used in the appliance is flammable. It should be utilised pursuant to
national regulations in force.
