User Manual - TRANSLATION
Mobile Computer
MC 92N0ex series
Type 17-A1A.-…./…….
Type B7-A2A.-…./…….
ATEX/IECEx Zone 1
ATEX/IECEx Zone 2 / 22
UL Class I, II, Division 1 and Class III
UL Class I, II, Division 2 and Class III
Docu
ment No.: 11-A1A2-7D0001
Status: 20
th
March 2019 / Revision B
R
eservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
Contents Page
English 1 – 79
Appendix Declaration of Conformity
Table of Content
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical data subject to change without notice..
Revision B / 03/2019
1. Basic Security Information................................................................................................................... 1
1.1 Information on this User Manual ....................................................................................... 1
Languages ........................................................................................................................ 2
Changes in the document ................................................................................................. 2
1.2 Handling the product ........................................................................................................ 2
1.3 Intended use ..................................................................................................................... 2
Exclusive purpose ............................................................................................................ 2
Unintended use ................................................................................................................ 3
1.4 Duties of the operator ....................................................................................................... 3
1.5 Safety information............................................................................................................. 3
General safety information ............................................................................................... 3
1.6 Maintenance ..................................................................................................................... 3
Servicing ........................................................................................................................... 3
Inspection ......................................................................................................................... 3
Repairs ............................................................................................................................. 4
Commissioning ................................................................................................................. 4
1.7 Protection type, test certificate and standards .................................................................. 4
1.8 Warranty ........................................................................................................................... 4
1.9 Co-applicable documents – Set of documents ................................................................. 6
1.10 Definitions ......................................................................................................................... 6
1.11 Configuration .................................................................................................................... 7
2. Product Description .............................................................................................................................. 8
2.1 Definition MC 92N0
ex
-IS Version ...................................................................................... 8
2.2 Definition MC 92N0
ex
-NI Version ...................................................................................... 9
3. Technical Data ..................................................................................................................................... 11
3.1 Explosion protection IS ................................................................................................... 11
3.2 Explosion protection NI ................................................................................................... 12
3.3 Other applicable standards ............................................................................................. 14
3.4 Features ......................................................................................................................... 15
Performance features ..................................................................................................... 15
Physical features ............................................................................................................ 15
User environment ........................................................................................................... 18
Application development ................................................................................................ 19
Voice and data transmission Wireless LAN .................................................................... 21
Voice and data transmission Wireless PAN ................................................................... 22
Headset .......................................................................................................................... 22
Barcode capture options ................................................................................................. 23
Reading distances .......................................................................................................... 24
Decodable barcode types ............................................................................................... 25
RFID Option ................................................................................................................... 25
3.5 Battery ............................................................................................................................ 29
3.6 External interfaces .......................................................................................................... 30
3.7 Product labelling ............................................................................................................. 31
3.8 Laser labels .................................................................................................................... 33
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Table of Content
Technical data subject to change without notice.
Revision B / 03/2019
4. Transport and Storage ....................................................................................................................... 34
4.1 Transport ........................................................................................................................ 34
4.2 Storage ........................................................................................................................... 34
5. Commissioning ................................................................................................................................... 35
5.1 Scope of delivery ............................................................................................................ 35
Accessories optional....................................................................................................... 35
5.2 Requirements in potentially explosive atmosphere ........................................................ 36
5.3 First steps ....................................................................................................................... 37
5.4 Structure ......................................................................................................................... 37
5.5 Handling accessories ..................................................................................................... 38
Insert/change battery ...................................................................................................... 38
Change keypad .............................................................................................................. 40
Insert SD card................................................................................................................. 43
Remove/replace screen protector .................................................................................. 44
Leather holster ............................................................................................................... 45
Headset .......................................................................................................................... 45
5.6 Connection to a PC ........................................................................................................ 46
Active Sync ..................................................................................................................... 46
Windows Mobile Device Center ...................................................................................... 46
Android ........................................................................................................................... 47
6. Operation ............................................................................................................................................. 48
6.1 Final inspection............................................................................................................... 48
6.2 Handling ......................................................................................................................... 48
6.3 Care and cleaning .......................................................................................................... 49
Care ................................................................................................................................ 49
Cleaning ......................................................................................................................... 49
Suitable materials ........................................................................................................... 50
6.4 Operation recommendations and requirements ............................................................. 51
Basic safety and health protection requirements ............................................................ 51
Instructions on the use of Wireless Devices ................................................................... 53
Equipment of the laser devices ...................................................................................... 54
LED Devices ................................................................................................................... 55
Restrictions to wireless devices ...................................................................................... 55
6.5 Frequency of Operation – FCC and IC ........................................................................... 56
6.6 Electromagnetic fields .................................................................................................... 58
International .................................................................................................................... 58
Handheld devices ........................................................................................................... 59
6.7 Optimise operating times/change energy settings .......................................................... 60
Automatic shutdown in the case of lengthy standby periods .......................................... 60
Change display backlight (increases the operating time of the battery) ......................... 61
Change keypad background lighting (increases the operating time of the battery) ........ 62
Switch off radio connections ........................................................................................... 63
6.8 Software versions ........................................................................................................... 64
OEM ............................................................................................................................... 64
AKU ................................................................................................................................ 65
Bluetooth ........................................................................................................................ 66
“Fusion”software ............................................................................................................. 67
Table of Content
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical data subject to change without notice..
Revision B / 03/2019
7. Faults and Troubleshooting ............................................................................................................... 68
7.1 Resetting the MC 92N0
ex
................................................................................................ 68
Windows Embedded Handheld and Windows Compact Devices ................................... 68
On an Android device ..................................................................................................... 71
7.2 USB connection does not work ...................................................................................... 72
8. Service, Inspection, Repair ................................................................................................................ 74
8.1 Service intervals ............................................................................................................. 74
8.2 Inspection ....................................................................................................................... 74
8.3 Service and repair work .................................................................................................. 74
Information on sending in for repairs .............................................................................. 75
9. Disposal ............................................................................................................................................... 76
10. Dispatch and Packaging Information ................................................................................................ 76
11. Accessories, Spare Parts ................................................................................................................... 77
12. Additional Information ........................................................................................................................ 79
12.1 Links ............................................................................................................................... 79
Appendix: Declaration of Conformity
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Basic Security Information
Technical data subject to change without notice.
Revision B / 03/2019
1/79
1. Basic Security Information
1.1 Information on this User Manual
Read carefully before putting the devices into operation.
The User Manual is a fixed part of the product. It must be kept in the direct vicinity of the
device and the installation, operating and service staff must have access to it at all times.
The User Manual contains important information, safety instructions and test certificates
which are necessary for the perfect function of the device in operation.
The User Manual is directed at all individuals concerned with the assembly, installation,
commissioning and servicing of the product. The applicable guidelines and standards for
areas with gas and dust atmosphere (99/92/EC, EN 60079-17, EN 60079-19,
IEC 60079-17, IEC 60079-19) must be observed when conducting this work.
Knowledge of the safety and warning information in this User Manual and the strict
compliance with it is essential for safe installation and commissioning. Accidents, injuries
and material damage can be avoided by
circumspect handling and systematically
following the instructions.
The figures in this User Manual serve to illustrate the information and descriptions. They
are not necessarily completely transferrable and may differ slightly from the actual
execution of the device.
The BARTEC company reserves the right to carry out technical changes at any time.
In no event will BARTEC company be responsible or liable for indirect or consequential
damages resulting from the use or application of this user manual.
Safety and warning information is particularly emphasised in this User Manual and marked
by symbols.
DANGER
DANGER describes a directly imminent danger.
If not avoided, death or severe injury
will be the consequence.
WARNING
WARNING describes a possibly imminent danger. If not avoided, death or severe
injury
may be the consequence.
CAUTION
CAUTION describes a possibly imminent danger. If not avoided, mild or slight injury may
be the consequence.
Basic Security Information
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
2/78
Technical data subject to change without notice..
Revision B / 03/2019
ATTENTION
ATTENTION describes a possibly damaging situation. If not avoided, the plant or objects
in its vicinity may be damaged.
Important information on effective, economic & environmentally compliant handling.
Languages
The original User Manual is written in German. All other available languages are translations
of the original User Manual.
The User Manual is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
Changes in the document
BARTEC reserves the right to change the content of this document without notification. No
warranty is assumed for the correctness of the information. In cases of doubt, the German
safety instructions apply because it is not possible to rule out errors of translation or printing.
In the case of legal disputes, the “General Terms and Conditions of Business” of the
BARTEC Group also apply.
The current versions of the datasheets, operating instructions, certificates and EC
declarations of conformity can be downloaded from https://www.bartec.de/en/ under
Products and Solutions in the product area “Automation & Enterprise Mobility”3 or on
support&download page from
http://automation.bartec.de/indexE.htm or may be
requested directly from BARTEC GmbH.
1.2 Handling the product
The product described in this User Manual left the factory in a perfect and tested state in
terms of safety. To maintain this state and to achieve a perfect and safe operation of this
product, it may only be operated in the manner described by the manufacturer. In addition,
the perfect and safe operation of this product requires correct transportation, proper storage
and careful operation.
The safe and perfect handling of the Mobile Computer is a prerequisite for its perfect and
correct functioning.
1.3 Intended use
Exclusive purpose
The Mobile Computer MC 92N0ex is a handheld piece of electrical equipment. It serves the
purpose of the mobile recording, processing and radio transmission of data within
potentially explosive atmospheres.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The admissible operating data of the device used must be considered.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Basic Security Information
Technical data subject to change without notice.
Revision B / 03/2019
3/79
Unintended use
Any other use is unintended and may lead to damage and accidents. The manufacturer
shall not be liable for any use extending beyond the exclusive purpose.
1.4 Duties of the operator
The operator undertakes to only permit persons to work with the Mobile Computers who
are acquainted with the basic regulations on safety and accident prevention, and who
have been inducted in the use of the Mobile Computer;
have read and understood the documentation, the safety chapter and the warnings.
The operator checks that the safety and accident prevention regulations applicable to the
respective case of use have been observed.
1.5 Safety information
General safety information
Do not dry wipe or clean devices in potentially explosive atmospheres!
Do not open devices in potentially explosive atmospheres.
General statutory provisions or guidelines on occupational health and safety, accident
prevention provisions and environmental protection laws must be heeded, e.g.
German Industrial Health and Safety Ordinance (BetrSichV) and nationally applicable
ordinances.
Use suitable clothing and shoes with respect to the danger of hazardous electrostatic
charges.
Avoid heat influences outside the specified temperature range.
Protect device from external influences! Do not expose device to caustic/aggressive
liquids, vapours or spray. In the case of malfunction or damaged enclosure, remove
the device immediately from the potentially explosive atmosphere and bring it to a
safe place.
1.6 Maintenance
The pertinent erection and operating provisions for electrical systems must be observed!
(e.g. Directive 99/92/EC, Directive 94/9/EC, BetrSichV and nationally applicable ordinances
EN 60079-14, IEC 60079-14 and the series DIN VDE 0100)!
Observe the national waste disposal regulations when disposing of the devices.
Servicing
No constant servicing will be necessary if operated correctly under consideration of the user
manual and environmental conditions. See Chapter “Service, inspection, repair” in this
respect.
Inspection
According to EN 60079-17, IEC 60079-17, EN 60079-19 and IEC 60079-19, the operator
of electrical systems in potentially explosive atmospheres is obliged to have these inspected
by an electrician to ensure correct condition.
Basic Security Information
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
4/78
Technical data subject to change without notice..
Revision B / 03/2019
Repairs
Repairs to explosion-protected devices may only be performed by authorised personnel
with original spare parts and according to the state of the art. The applicable provisions
must be observed in this respect.
Commissioning
It must be checked that all components and documents are available before commissioning.
1.7 Protection type, test certificate and standards
Labels on explosion protection and the test certificate are attached to the device. See
Chapter 3 “Technical data” with respect to labelling.
The guidelines and standards applicable to the Mobile Computer for devices and protected
systems for intended use in potentially explosive atmospheres are provided in Chapter 3
“Technical data”.
1.8 Warranty
WARNING
No changes or conversions may be made without the manufacturer’s written
consent.
If components other than those specified are used, explosion protection will no longer
be assured. It cannot be guaranteed that parts procured from other suppliers have been
designed and manufactured in conformance to safety requirements and with the
necessary stress tolerance.
Contact the manufacturer and obtain his approval before performing any changes
or retrofits. Use only original spare and expendable parts.
The manufacturer shall exclusively assume the complete warranty only
for spare parts
ordered from him.
Our “General Terms and Conditions of Sale and Delivery” shall apply in principle. These
shall be made available to the operator on signing of contract at the latest. Warranty and
liability claims in the case of injury and damage to property shall be excluded if they are
attributable to one or several of the following causes:
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Basic Security Information
Technical data subject to change without notice.
Revision B / 03/2019
5/79
Unintended use of the Mobile Computers.
− Incorrect assembly, commissioning, operation and servicing.
− Failure to observe the information in the User Manual with respect to transport, storage,
assembly, installation, commissioning, operation and service.
− Independent structural changes.
− Faulty monitoring of parts subject to wear and tear.
− Incorrectly performed repairs.
− Cases of disaster through the impact of foreign bodies and force majeure.
We grant a warranty period of one year starting from the date of delivery from the Bad
Mergentheim factory on the Mobile Computers and their accessories (exception: battery 6
months). This warranty covers all parts of the delivery and shall be restricted to the free
replacement or repair of the defective parts in our Bad Mergentheim factory. For this
purpose, any packaging supplied must be kept where possible. In the case of warranty, the
goods must be returned to us after written agreement. There shall be no claim to repair at
the sight of erection.
The versions, components, monitors and windows shown in this User Manual are merely
examples and may deviate from the actual display.
The information contained herein refers to the explosion-protected version of series
MC 92N0
ex
.
This User Manual contains all important information on the subject of explosion protection.
The original user manuals and product information of ZEBRA with information on handling
and commissioning are also available. In the case of overlaps, the information in this User
Manual shall take priority and shall supersede the information from ZEBRA.
Basic Security Information
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
6/78
Technical data subject to change without notice..
Revision B / 03/2019
1.9 Co-applicable documents – Set of documents
BARTEC
− User Manual to the Mobile Computer series MC 92N0ex – The use of the explosion-
protected version of the Mobile Computer series MC 92N0
ex
is described in this User
Manual.
− Technical datasheet for the explosion-protected version of the Mobile Computer series
MC 92N0
ex
– This technical datasheet contains the most important explosion-relevant
technical data as well as general technical data.
ZEBRA
The set of documentation of the MC9200 contains information on the respective user
requirements and covers the following:
− Quick Start Guide for the MC9200 – The commissioning of the Mobile Computer
MC9200 is described in this User Manual.
− User Manual for the MC92N0 – The functional use of the Mobile Computer MC MC9200
is described in this User Manual.
− Integration Manual for the MC9200 – The setting up of the Mobile Computer MC9200
including accessories is described in this User Manual.
1.10 Definitions
Some abbreviations are used in the documentation.
IS = Intrinsically Safe / Intrinsic Safety =>
is used as an umbrella term for Zone 1 and Division 1 versions
NI = Non-Incendive / non-sparking =>
is used as an umbrella term for Zone 2 and Division 2 versions
MC 92N0
ex
= Stands for the entire explosion-proof product series.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Basic Security Information
Technical data subject to change without notice.
Revision B / 03/2019
7/79
1.11 Configuration
This Manual refers to the following configurations:
Configuration
Version
Wireless
WLAN:
WIN CE/WEH: 802.11 a/b/g/n/d/h/i
Android: 802.11 a/b/g/n/d/h/i/k/r
WPAN:
WIN CE/WEH:
Microsoft-Stack: Bluetooth 2.1 EDR
Stonestreet-Stack: Bluetooth 4.0 plus BLE or WBA
Android: Bluetooth 4.0 BLE
Optional RFID
options
RFID-LF 125 kHz / 134 kHz
(Low Frequency)
RFID-HF 13,56 MHz
(High Frequency)
RFID-UHF (EU) 865,6 to 867,5 MHZ
(Ultra High Frequency)
RFID-UHF (US) 902 to 928 MHz
(Ultra High Frequency)
Display
VGA Color Display (3.7")
Memory
1 GB RAM / 2 GB Flash Memory
Scanner
options
1D-Laser Scanner Normal Range
1D-Laser Scanner Long Range
1D-/2D-Imager
1D-/2D-Imager Middle Range (only NI-version)
1D-/2D-Long Range Imager (only NI-version)
1D-/2D-Imager DPM (Direct Part Marking)
Operating
system options
Windows WEH 6.5.3
Windows CE 7.0
Android 4.4.4
Keypad
options
28 Keypad (Numeric keys can be used direct, Alpha keys and other
key functions can be used via function keys)
43 Keypad (Numeric- and function keys can be used direct, alpha
keys and other key functions can be used via function keys)
53 Keypad (Numeric- and alpha keys cen be used direct, other key
functions can be used via function keys)
53 Keypad with layout for VT Emulation
The Emulation software is not part of the device.
Other specific information on the keypad is provided under Technical Data or in the
ZEBRA documentation.
Product Description
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
8/78
Technical data subject to change without notice..
Revision B / 03/2019
2. Product Description
2.1 Definition MC 92N0ex-IS Version
The MC 92N0ex-IS Mobile Computer is a robust mobile computer designed for industrial
use and has been specially modified by BARTEC for use in hazardous (potentially
explosive) areas in
− ATEX/IECEx Zone 1
− UL Class I, II Division 1 and Class III
This means that the extensive communication and data acquisition options which are
already standard in other areas are available to the user in hazardous areas also.
Its ergonomic design and easy operation make it an ideal support in the attainment of fast
data availability in enterprise processes. Various versions of keypad are available for
manual data capture.
Other data capture options are provided by the integrated 1D or 1D/2D scan engine for
capturing barcodes and various optional RFID readers.
The ergonomically mounted scan triggers on the MC 92N0
ex
-IS allow data to be captured
easily in one-hand operation. Several technologies are available for data communication
with other systems and company divisions.
− Wireless LAN (WLAN),
− Wireless PAN (WPAN) (Bluetooth)
− Ethernet or USB connection through docking station
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Product Description
Technical data subject to change without notice.
Revision B / 03/2019
9/79
These modules, which are integrated in the device, allow a seamless transmission of voice
and data into the company’s network.
Other advantages in use are its sturdy construction, easy-to-read 3.7'' VGA colour display
with touch technology and highly efficient lithium-ion battery.
A 1 GHz dual-core processor in the MC 92N0
ex
-IS ensures fast process execution. Easy
application development is facilitated by the operating systems, Microsoft Windows WEH
6.5.3, CE 7.0 and Android 4.4.4 in conjunction with the Enterprise Mobility Developer Kits
(EMDK) or the additional Mobility DNA solutions from ZEBRA.
1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined
applications and data. For larger applications and volumes of data, BARTEC offers SD
memory cards.
2.2 Definition MC 92N0ex-NI Version
The MC 92N0ex-NI Mobile Computer is a robust mobile computer designed for industrial
use and has been specially modified by BARTEC for use in hazardous (potentially
explosive) areas in
− ATEX/IECEx Zone 2 / 22
− UL Class I, II Division 2 and Class III
This means that the extensive communication and data acquisition options which are
already standard in other areas are available to the user in hazardous areas also.
Product Description
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
10/78
Technical data subject to change without notice..
Revision B / 03/2019
Its ergonomic design and easy operation make it an ideal support in the attainment of fast
data availability in enterprise processes. Various versions of keypad are available for
manual data capture.
Other data capture options are provided by the integrated 1D or 1D/2D scan engine for
capturing barcodes and various optional RFID readers.
The ergonomically mounted scan triggers on the MC 92N0
ex
-NI allow data to be captured
easily in one-hand operation. Several technologies are available for data communication
with other systems and company divisions.
− Wireless LAN (WLAN),
− Wireless PAN (WPAN) (Bluetooth)
− Ethernet or USB connection through docking station
These modules, which are integrated in the device, allow a seamless transmission of voice
and data into the company’s network.
Other advantages in use are its sturdy construction, easy-to-read 3.7'' VGA colour display
with touch technology and highly efficient lithium-ion battery.
A 1 GHz dual-core processor in the MC 92N0
ex
-IS ensures fast process execution. Easy
application development is facilitated by the operating systems, Microsoft Windows WEH
6.5.3, CE 7.0 and Android 4.4.4 in conjunction with the Enterprise Mobility Developer Kits
(EMDK) or the additional Mobility DNA solutions from ZEBRA.
1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined
applications and data. For larger applications and volumes of data, BARTEC offers SD
memory cards.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
11/79
3. Technical Data
3.1 Explosion protection IS
ATEX Zone 1
Type
17-A1A3-0…/S……
17-A1A3-R..1/S…….
17-A1A3-R..3/S…….
17-A1A3-R..A/S…….
17-A1A3-R..B/S…….
MC 92N0
ex
-IS
MC 92N0
ex
-IS RFID
Ex protection
II 2G Ex q [ib] IIC T4 Gb
Type 17-A1A3-R..C/S…….
17-A1A3-R..D/S…….
MC 92N0ex-IS RFID
Ex protection
II 2G Ex q [ib] IIB T4 Gb
Certificate
PTB 13 ATEX 2019 X
Standards
EN 60079-0:2012
EN 60079-5:2007
EN 60079-11:2012
IECEx Zone 1
Type
17-A1A3-0…/S…….
17-A1A3-R..1/S…….
17-A1A3-R..3/S…….
17-A1A3-R..A/S…….
17-A1A3-R..B/S…….
MC 92N0
ex
-IS
MC 92N0
ex
-IS RFID
Ex protection
Ex q [ib] IIC T4 Gb
Type 17-A1A3-R..C/S…….
17-A1A3-R..D/S…….
MC 92N0ex-IS RFID
Ex protection
Ex q [ib] IIB T4 Gb
Certificate
IECEx PTB 13.0043X
Standards
IEC 60079-0:2011 Edition 6
IEC 60079-5:2007 Edition 3
IEC 60079-11:2011 Edition 6
ATEX and IECEx Directives
ATEX 2014/34/EU
EMV 2014/30/EU
RED 2014/53/EU
RoHS 2011/65/EU
Product labelling
0044
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
12/78
Technical data subject to change without notice..
Revision B / 03/2019
UL Class I, II, III Division 1
Type 17-A1A2-0…/S…….
17-A1A2-R…/S…….
MC 92N0ex-IS
MC 92N0ex-IS RFID
Ex protection
Class I Division 1 Groups C and D
Class II Division 1 Groups F and G
Class III
Certificate USA and Canada
E226123
Standards
USA Standard UL 913, 5 Edition.
National Standard of Canada C22.2 No. 157-92
3.2 Explosion protection NI
ATEX Zone 2/22
Type B7-A2A.-0.A0/S…….
B7-A2A.-0.J0/S…….
B7-A2A.-0.30/S…….
B7-A2A.-0.50/S…….
B7-A2A.-0.90/S…….
MC 92N0ex-NI
Ex protection
II 3G Ex ic IIC T6 Gc
II 3D Ex ic IIIB T80°C Dc IP64
-20 °C ≤ Ta ≤ +50 °C
Type B7-A2A.-0.L0/S…….
B7-A2A.-0.M0/S…….
B7-A2A.-R..1/S…….
B7-A2A.-R..3/S…….
B7-A2A.-R..A/S…….
B7-A2A.-R..B/S…….
MC 92N0ex-NI
MC 92N0
ex
-NI RFID
Ex protection
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIB T80°C Dc IP64
-20 °C ≤ Ta ≤ +50 °C
Typ
B7-A2A.-R..C/S…….
B7-A2A.-R..D/S…….
MC 92N0ex-NI RFID
Kennzeichnung
II 3G Ex ic IIB T4 Gc
II 3D Ex ic IIIB T80°C Dc IP64
-20 °C ≤ Ta ≤ +50 °C
Certificate
EPS 14 ATEX 1 782 X
Standards
EN 60079-0: 2012 + A11:2013
EN 60079-11:2012
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
13/79
IECEx Zone 2/22
Type B7-A2A.-0.A0/S…….
B7-A2A.-0.J0/S…….
B7-A2A.-0.30/S…….
B7-A2A.-0.50/S…….
B7-A2A.-0.90/S…….
MC 92N0ex-NI
Ex protection
Ex ic IIC T6 Gc
Ex ic IIIB T80°C Dc IP64
Type B7-A2A.-0.L0/S…….
B7-A2A.-0.M0/S…….
B7-A2A.-R..1/S…….
B7-A2A.-R..3/S…….
B7-A2A.-R..A/S…….
B7-A2A.-R..B/S…….
MC 92N0ex-NI
MC 92N0
ex
-NI RFID
Ex protection
Ex ic IIC T4 Gc
Ex ic IIIB T80°C Dc IP64
Typ B7-A2A.-R..C/S…….
B7-A2A.-R..D/S…….
MC 92N0ex-NI RFID
Kennzeichnung
Ex ic IIB T4 Gc
Ex ic IIIB T80°C Dc IP64
Certificate
IECEx EPS 14.0100X
Standards
IEC 60079-0:2011
IEC 60079-11:2011
ATEX and IECEx Directives
ATEX 94/9/EG
EMV 2004/108/EG
R&TTE 1999/5/EG
RoHS 2002/95/EG
Product labelling
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
14/78
Technical data subject to change without notice..
Revision B / 03/2019
UL Class I, II, III Division 2
Type B7-A2A4-0…/S…….
B7-A2A4-R…/S…….
MC 92N0ex-NI
MC 92N0ex-NI RFID
Ex protection
Class I Division 2 Groups A, B, C and D
Class II Division 2 Groups F and G
Class III
Certificate USA and Canada
E321557
Standards
ANSI/ISA 12.12.01, UL 60950,
Canada National Standard
CSA C22.2 Nr. 213-M1987
CAN/CSA C22.2 Nr. 157-92
3.3 Other applicable standards
See chapter: EU EU Certificate of Conformity
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
15/79
3.4 Features
Performance features
CPU
Dual-Core 1 GHz OMAP 4430-Processor
Operating system
Windows Embedded Handheld WEH 6.5.3
or
Windows Embedded Compact 7 (CE 7.0)
or
Android 4.4.4
Memory
1 GB RAM; 2 GB Flash
Extension slot
SD card slot
with SDHC support
(up to 32 GB)
Optionally extendable with SD card:
2 GB Order number 17-28BE-F006/0003
4 GB Order number 17-28BE-F006/0004
8 GB Order number 17-28BE-F006/0005
16 GB Order number 17-28BE-F006/0006
32 GB Order number 17-28BE-F006/0007
Interfaces
RS232
USB
Physical features
Dimensions:
MC 92N0ex-G:
MC 92N0
ex
-G with internal RFID:
MC 92N0
ex
-G with internal RFID
+ external antenna:
Height x width x depth
231 x 91 x 193 mm 9.1 x 3.6 x 7.6 inch
231 x 91 x 193 mm 9.1 x 3.6 x 7.6 inch
273 x 111 x 193 mm 10.7 x 4.4 x 7.6 inch
Dimensions
MC 92N0ex-K:
MC 92N0
ex
-K with internal RFID:
MC 92N0
ex
-KG with internal RFID
+ external antenna:
Height x width x depth
231 x 91 x 56 mm 9.1 x 3.6 x 2.3 inch
231 x 91 x 56 mm 9.1 x 3.6 x 2.3 inch
254 x 111 x 117 mm 10 x 4.4 x 4.6 inch
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
16/78
Technical data subject to change without notice..
Revision B / 03/2019
Weight
Depends on version and configuration
ATEX/IECEx
(including battery)
MC 92N0
ex
-G:
MC 92N0
ex
-G with internal RFID:
MC 92N0
ex
-G with internal RFID
+ external antenna:
MC 92N0
ex
-K:
MC 92N0
ex
-K with internal RFID:
MC 92N0
ex
-K with internal RFID
+ external antenna:
ca. 1060 g approx. 37 oz
ca. 1060 g approx. 37 oz
ca. 1140 g approx. 40 oz
ca. 980 g approx. 35 oz
ca. 980 g approx. 35 oz
ca. 1060 g approx. 37 oz
UL Division 1
(including battery)
MC 92N0
ex
-G:
MC 92N0
ex
-G with internal RFID:
MC 92N0
ex
-G with internal RFID
+ external antenna:
MC 92N0
ex
-K:
MC 92N0
ex
-K with internal RFID:
MC 92N0
ex
-K with internal RFID
+ external antenna:
ca. 830 g approx. 29 oz
ca. 830 g approx. 29 oz
ca. 910 g approx. 32 oz
ca. 700 g approx. 25 oz
ca. 700 g approx. 25 oz
ca. 780 g approx. 28 oz
UL Div 2 und ATEX Zone 2/22
(including battery)
MC 92N0
ex
-G:
MC 92N0
ex
-G with internal RFID:
MC 92N0
ex
-G with internal RFID
+ external antenna:
MC 92N0
ex
-K:
MC 92N0
ex
-K with internal RFID:
MC 92N0
ex
-K with internal RFID
+ external antenna:
ca. 780 g approx. 28 oz
ca. 780 g approx. 28 oz
ca. 830 g approx. 30 oz
ca. 640 g approx. 23 oz
ca. 640 g approx. 23 oz
ca. 690 g approx. 25 oz
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
17/79
Display
VGA mode:
QVGA mode:
3,7"-VGA- colour display
480 x 640 pixel (width x height)
240 x 320 pixel (width x height) (Windows CE only)
Touchscreen
Analogue-resistive touchscreen
Background lighting
LED technology
Network connections
Ethernet (via charge station);
USB 2.0, Host or Client
Interactive sensor technology
– Three-axes accelerometer for motion sensor
application for dynamic screen orientation
– power monitoring
– recognition of free fall
Keypad versions
– 28 Keypad (Numeric keys can be used direct,
Alpha keys and other key functions can be
used via function keys)
– 43 Keypad (Numeric- and Function keys can
be used direct, Alpha keys and other key
functions can be used via function keys)
– 53 Keypad (Numeric- and Alpha keys can be
used directly, other key functions can be used
via function keys)
– 53 Keypad with layout for VT Emulation
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
18/78
Technical data subject to change without notice..
Revision B / 03/2019
Numeric keypad
Numeric keypad
with
(F) function keys
Alpha numeric
keypad
Alpha numeric
keypad
with printing
for VT
emulation
28 keys
43 keys
53 keys
53 keys
No emulation software is installed on the Mobile Computers with the emulation key
version. The customer must order the emulation software separately from ZEBRA and its
distributors and install it himself.
The devices are modified to suit the selected keypad version. The end user can replace
the keypad later himself.
When replacing the keyboard, follow the instructions in this manual.
User environment
Operating temperature
only IS Version
Type 17-A1A.-…
-20 °C to +40 °C
-4 °F to +104 °F
Operating temperature
only NI Version
Type B7-A2A.-…
-20 °C to +50 °C
-4 °F to +122 °F
Operating temperature
during charging
0 °C to +40 °C
+32 °F to +104 °F
Storage temperature
(without battery)
-40 °C to +70 °C
-40 °F to +158 °F
Air humidity
5 % to 95 % (non-condensing)
Class of protection
(EN 60529)
only IS Version
IP 54
Type 17-A1A3-… (ATEX/IECEx Zone 1)
Class of protection
(EN 60529)
only IS Version
only NI Version
IP 64
Type 17-A1A2-…. (UL Division 1)
Type B7-A2A.-… (ATEX/IECEx Zone 2/22)
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
19/79
Application development
Software:
No functional changes were made to the device because of the explosion protection. All
tools and applications available from Zebra for the MC9200 are compatible with the
MC92N0ex version.
E.g. applications for:
- Communication and message exchange
- additional Mobility DNA solutions from Zebra (Enterprise Keyboard, Stage Now,
Enterprise Browser, Enterprise Start Screen, SimulScan, and more)
Software Development :
PSDK (Platform Software Development Kit) and EMDK (Enterprise Mobility Developer
Kit) is available via the ZEBRA Solutions Website.
Available for
−
C
− .Net
− Xamarin
− MC9200 Platform SDK (PSDK)
−
others
Browser support:
Enterprise Browser from ZEBRA for application development.
Mobility DNA Solutions from Zebra
Further applications are
available from ZEBRA, e.g.
CtLPanelWM
− for the processing of device settings.
Application Launcher
− for the classification of applications in categories
and access regulation for individual applications
or operating system.
Data Wedge
− Barcodes in applications can be read such as
Excel or Word using.
Enterprise Home Screen for Android
−
Provides administrators with an easy way to
control access to apps and settings on a Zebra
device without writing custom code.
others
− See the Zebra Support page for the MC9200:
https://www.zebra.com/us/en/supportdownloads/mobilecomputers/handheld/mc9200.html
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
20/78
Technical data subject to change without notice..
Revision B / 03/2019
RFID
As software for individual application development,
BARTEC offers a demo version in Open Source and
an SDK file. The SDK file is available for the C#
programming language and contains all necessary
resources for specific application development
under Windows® operating systems. The open
source demo serves to demonstrate the reading
and writing of RFID tags. On the other hand, it
provides the application developer with a good
basis for customer-
specific programming of the
readers.
− SDK is available for C#
− The SDK was created in Visual Studio 2008.
− Includes all necessary drivers and DLL files for
implementation.
− A RFID demo available in open source to show
how to implement the RFID reader in an
application.
Note:
The BARTEC RFID solution is not compatible with
RFID solutions from Zebra.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
21/79
Voice and data transmission Wireless LAN
WLAN radio module
Radio standard
Android:
IEEE 802.11 a/b/g/n/d/h/i/k/r
WinCE/WEH:
IEEE 802.11 a/b/g/n/d/h/i
Note:
IEEE802.11 a is not available in Thailand
Output power
100 mW (USA and International)
Data rate
IEEE802.11a: up to 54 Mbit/sec.
IEEE802.11b: up to 11 Mbit/sec.
IEEE802.11g: up to 54 Mbit/sec.
IEEE802.11n: up to
72,2 Mbit/sec.
Frequency range
(country-dependent)
IEEE802.11a: 5 GHz
IEEE802.11b: 2.4 GHz
IEEE802.11g: 2.4 GHz
IEEE802.11n: 2.4 GHz and 5 GHz
Operating channels
IEEE802.11a
IEEE802.11b/g
Channel 8 - 165 5040 MHz - 5825 MHz
Channel 1 – 13 2412 MHz - 2472 MHz
Channel 14 2484 MHz Japan only
The actual operating channels and frequencies are
subject to the applicable rules and the certification
authorities
Safety
WPA2 Enterprise, 802.1x; EAP-TLS; TTLS (CHAP,
MS-CHAP, MS-CHAPv2, PAP or MD5); PEAP (TLS,
MSCHAPv2, EAP-GTC); LEAP, EAP-FAST (TLS,
MS-CHAPv2, EAP-GTC), WPA2/AES, CCX v4,
FIPS 140-2 conform and IPv6
Language support
Voice over IP
Voice directed picking
Tech Speech Pro approved voice-enabled
applications over third-party VDP clients (Windows
operating system only)
Push-to-talk, workforce connect PTT express (client
included) with headset and handsfree, wired headset
support
Antenna
internal
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
22/78
Technical data subject to change without notice..
Revision B / 03/2019
Voice and data transmission Wireless PAN
Bluetooth
Windows operating system:
Microsoft stack:
(preinstalled by default) Bluetooth Version 2.1 with
EDR
Stonestreet stack
(can be optionally activated) Bluetooth 4.0 Plus BLE or
WBA
Android operating system:
Bluetooth version 4.0 with low energy consumption
Maximum Output Power
2.5 mW
Maximale Datenrate
up to 2.1 Mbit/s
Antenna
Internal chip aerial
Headset
Headset Connector
Ex-relevant information on the use of a headset.
Ex protection
Ex ib IIC
U0 = 8.6 V
I0 = 354 mA
P0 = 479 mW
C0 = 930 nF
L0 = 460 µH
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
23/79
Barcode capture options
Barcode capture
Available for the following
approvals/
Ex versions
Available
operating systems
Form
1D-Barcodes
Version IS
17-A1A.-…
Version NI
B7-A2A.-…
Windows
CE/WEH
Android
4.4.4
MC92N0
Gun
MC92N0
Brick
SE965-SR
1D Standard Range
Scan Engine
Yes Yes Yes Yes Yes Yes
SE1524-ER
1D Extended Range
Scan Engine
Yes Yes Yes Yes Yes No
1D-/2D Barcodes
SE4500-SR
1D-/2D OmniDirektional Imager
Engine
Ja Yes Yes Yes Yes Yes
SE4750-SR
1D-/2D OmniDirektional Imager
Engine
No Yes Yes Yes Yes No
SE4750-MR
1D-/2D OmniDirektional Middle
Range Imager Engine
No Yes Yes Yes Yes No
SE4600-LR
1D-/2D OmniDirektional Long
Range Imager
No Yes Yes No Yes No
DPM/1D-/2D Barcodes
SE4500-HD
DPM/1D-/2D Imager
Engine
Yes Yes Yes No Yes Yes
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
24/78
Technical data subject to change without notice..
Revision B / 03/2019
Reading distances
Barcode capture Reading distance
1D-Barcodes minimum maximum
SE965-SR
1D Standard Range
Scan Engine
2,5 cm
0.98 inch
130 cm
51.18 inch
SE1524-ER
1D Extended Range
Scan Engine
5 cm
1.97 inch
1370 cm
539.37 inch
1D-/2D Barcodes
SE4500-SR
1D-/2D Omni-Direktional
Imager Engine
5 cm
1.97 inch
60 cm
23.62 inch
SE4750-SR
1D-/2D Omni-Direktional
Imager Engine
4,5 cm
1.77 inch
88 cm
34.65 inch
SE4750-MR
1D-/2D Omni-Direktional
Middle Range Imager
Engine
5,5 cm
2.17 inch
440 cm
173.23 inch
SE4600-LR
1D-/2D Omni-Direktional
Long Range Imager
18 cm
7.09 inch
910 cm
358.27 inch
DPM/1D-/2D Barcodes
SE4500-HD
DPM/1D-/2D Imager
Engine
3,5 cm
1.38 inch
28 cm
11.02 inch
The various scan engines minimum and maximum ranges depend on the bar code
symbology/type and the module width (in mil) used.
The scan engines used comply with laser class CDRH Class II / IEC 825 Class 2
Further detailed information on the used scan engine can be found in the “User Manual“ or
“Integrator Guide” from ZEBRA
The decode range depends on the quality and size of the bar code and on the scan
engine’s software setting.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
25/79
Decodable barcode types
All supported 1D-Barcodes
All supported 2D-Barcodes
(only supported with Imager versions)
DPM Codes (only with
SE4500-HD)
mounted on
1D-Symbol/Codes
2D-Symbol/Codes
Code 11
Code 39
Aztec
Micro PDF-417
Metal
Code 93
Code 128
Australian 4-state
Maxi Code
Plastic
Codabar
Coupon code
Canadian 4-state
PDF-417
Glass
Chinesisch 2 of 5
Discrete 2 aus 5
Composite AB
QR Code
Interleaved 2 of 5
Trioptic 39
Composite C
TLC39
Method:
EAN-8
EAN-13
Data Matrix
UK 4-state
dot peening
UPCA
UPCE
Dutch Kix
US Planet
laser cut
UPC/EAN Supplementals
MSI
Japanese 4-state
US Postnet
cast
Webcode
RSS-14
PDF-417 Macro
USPS 4-state (US4CB)
punched
RSS Limited RSS Expanded
(Macro) Micro
PDF-417
microQR moulded
RFID Option
Four different RFID options
available
LF (Low Frequency)
HF (High Frequency)
UHF (EU) Ultra High Frequency)
UHF (US) Ultra High Frequency)
RFID Option
Available for the following
approvals/Ex versions
Available operating systems
Supported with SDK v2.0.3 or higher
RFID Frequency
Version IS
17-A1A.-…
Version NI
B7-A2A.-…
Windows
WEH6.5.3
Windows
CE7.0
Android
4.4.4
LF (Low Frequency) 125/134 kHz Yes Yes Yes
Not
supported
N Not
supported
HF (High Frequency) 13,56 MHz Yes Yes Yes
Not
supported
Not
supported
UHF (EU)
(Ultra High Frequency)
865,6 to 867,5 MHz
(EN 302 208)
Yes Yes Yes
Not
supported
Not
supported
UHF (US)
(Ultra High Frequency)
902,0 to 928,0 MHz
(FCC CFR 47 Part
15.247)
Yes Yes Yes
Not
supported
Not
supported
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
26/78
Technical data subject to change without notice..
Revision B / 03/2019
The maximum read / write ranges of the different RFID readers are dependent on various
environmental and ambient conditions and refer in the following to office environment.
e.g.
Transponder (Tag), size
Mounting surface (metal, wood or different)
Environment conditions
Magnetic influence from outside
Temperature
Humidity
RFID Option with internal reader
RFID Option with internal reader
+ mounted antenna
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
27/79
LF Reader (internal module)
For MC 92N0ex-G (Gun) and MC 92N0ex-K (Brick)
Combination with Scan Engine is not possible!
Nominal reading distance
up to approx. 5 cm
up to approx. 1.9 inches
Nominal writing distance
up to approx. 5 cm
up to approx. 1.9 inches
Antenna
Integrated as ferrite antenna or air coil antenna
Frequency range
125/134 kHz (automatic switching)
Transmitting power
100 mW ± 2dB
Supported standards
HITAG S256
HDX - RO
EM 4450/4550
HITAG S 2 kbit
HDX (Multipage)
EM4xxx (UNIQUE)
HITAG 1
EM4xxx (UNIQUE)
FDX-B
HITAG 2 FDX-B BDE
Q5 BDE ISO 11784/5
ATA5567
ISO 117845
ISO Animal
EM4305
ISO Animal
HF Reader (internal module)
For MC 92N0ex-G (Gun) and MC 92N0ex-K (Brick)
Combination with Scan Engine is not possible!
Nominal reading distance
HF ISO 15693
HF ISO 14443
approx. 7 cm to 12 cm approx. 2.8 to 4.7 inch
approx. 1 cm to 6 cm approx 0.4 to 2.4 inch
(with tags in check card format)
Nominal writing distance
HF ISO 15693
HF ISO 14443
approx. 7 cm to 12 cm approx. 2.8 to 4.7 inch
approx. 1 cm to 6 cm approx 0.4 to 2.4 inch
(with tags in check card format)
Antenna
Integrated
Frequency range
13.56 MHz
Transmitting power
100 mW ± 2dB
Supported standards HF ISO 15693
I-Code SLI Tag-IT HFI my-d vicinity
STM LRI512
Supported standards HF ISO 15693
mifare
mifare Ultra Light
my-d proximity
I-Code 1 (optional)
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
28/78
Technical data subject to change without notice..
Revision B / 03/2019
UHF Reader (internal module)
For MC 92N0ex-G (Gun) and MC 92N0ex-K (Brick)
Combination with Scan Engine is not possible!
Nominal reading distance
approx. 30 cm to 50 cm approx. 11.8 to 19.7 inch
Nominal writing distance
approx. 30 cm to 50 cm approx. 11.8 to 19.7 inch
Antenna
Integrated
Frequency range
Europa (EU)
USA (US)
865.6 to 867.5 MHz (EN 302 208)
902.0 to 928.0 MHz
(FCC CFR 47 Part 15.247)
Supported standards
EPC Class 1 Gen 2 tag
UHF Reader (internal module) with mounted antenna
For MC 92N0ex-G (Gun) and MC 92N0ex-K (Brick)
Combination with Scan Engine is not possible!
Nominal reading distance
approx. 150 cm approx. 59 inch
Nominal writing distance
approx. 30 cm to 50 cm approx. 11.8 to 19.7 inch
Antenna
Mounted external
Frequency range
Europa (EU)
USA (US)
865.6 to 867.5 MHz (EN 302 208)
902.0 to 928.0 MHz
(FCC CFR 47 Part 15.247)
Supported standards
EPC Class 1 Gen 2 tag
Further information on the RFID Reader and the available SDK software can be found
separately on the BARTEC Support Download page.
http://automation.bartec.de/indexE.htm
Category - Mobile Computers
MC92N0ex series
RFID SDK
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
29/79
3.5 Battery
Battery
Type 17-A1Z0-0001
Type 17-A1Z0-0023
Type B7-A2Z0-0044
(charge only outside of hazardous location)
Lithium Ion battery 7.2 / 2800 mAh (20.16 Wh)
for MC 92N0
ex
type 17-A1A3-…
Lithium Ion battery 7.4 / 2600 mAh (19.3 Wh)
for MC 92N0
ex
type 17-A1A2-….
Lithium Ion battery 7.4 / 2600 mAh (19.3 Wh)
for MC 92N0
ex
type B7-A2A4-...
Operating temperature
− During charging
−
During discharging
0 °C to +40 °C +32 °F to 104 °F
-20 °C to +50 °C -4 °F to 122 °F
Storage temperature
-20 °C to +50 °C -4 °F to 122 °F
Relative air humidity
20 % - 95 % (non-condensing)
Backup battery
Ni-MH battery 2.4 V/15 mAh (rechargeable)
Integrated in the device and only replaceable in
the factory.
Battery performance
approx. 8 hours depending on the device settings
Charging times
Depends on the selected charging station.
< 8 hours
UN38.3 compliant
Yes
The battery life depends on various usage factors and on the device settings such as e.g.
Use and setting of WLAN / Bluetooth
Backlighting
Frequency of scanner utilisation
Frequency of RFID utilisation
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
30/78
Technical data subject to change without notice..
Revision B / 03/2019
3.6 External interfaces
Restrictions:
− The 17-pole data interface should only be used outside the potentially explosive
atmosphere and exclusively with the devices stated by the manufacturer!
PIN
Signal name
Function
PIN
Signal name
Function
1
USB_GND
USB
10
Cradle_DET
Grounded with
device inside of
cradle
2
USB_D_Plus
USB
11
DTR
RS232C
3
TxD
RS232C
12
Not assigned
Not assigned
4
RxD
RS232C
13
Power_IN
12 V / 2.5 A max.
5
DCD
RS232C
14
CTS
RS232C
6
RTS
RS232C
15
USB_5V_DET
USB
7
DSR
RS232C
16
USB_D_Minus
USB
8
GND
Ground, 2.5 A
max.
17
EXT_Power_OUT
3.3 V / 500 mA
9
RI
RS232C
− The headset connection should only be used outside the potentially explosive
atmosphere and exclusively with the devices stated by the manufacturer!
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
31/79
3.7 Product labelling
Laser warning
CAUTION - CLASS 3R LASER LIGHT WHEN OPEN.
AVOID DIRECT EYE EXPOSURE.
ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS
D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU.
VORSICHT - LASERLICHT KLASSE 3R, WENN ABDECKUNG
GEÖFFNET. DIREKTE BESTRAHLUNG DER AUGEN VERMEIDEN.
Laser Mark of Compliance
Type: 17-A1A3-…./……..
Type: 17-A1A2-…./……..
Type: B7-A2A4-…./……..
Technical Data
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
32/78
Technical data subject to change without notice..
Revision B / 03/2019
Additional marking Zone 2
Type: B7-A2A4-…./……..
Laser warning
Type label
e.g. for ATEX/IRCEx Zone 1
Laser warning
CAUTION - CLASS 2 LED LIGHT.
WHEN OPEN. DO NOT STARE INTO THE BEAM.
ATTENTION - LUMINERE LED DE CLASSE 2.
EN CAS D’OUVERTURE. NE PAS REGARDER DANS LE FAISCEAU
VORSICHT - LED LICHT KLASSE 2.
WENN ABDECKUNG GEÖFFNET. NICHT IN DEN STRAHL BLICKEN.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Technical Data
Technical data subject to change without notice.
Revision B / 03/2019
33/79
Battery marking
Type 17-A1Z0-0001
Type 17-A1Z0-0023
Type B7-A2Z0-0044
3.8 Laser labels
In compliance with IEC 60825 and EN 60825, Clause 5 the following information is provided:
DEUTSCH
KLASSE 1 KLASSE 1 LASER PRODUKT
KLASSE 2 LASERLICHT
NICHT IN DEN LASERSTRAHL SEHEN
KLASSE 2 LASER PRODUKT
ENGLISH
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
FRENCH / FRANÇAIS
CLASSE 1 PRODUIT LASER DE CLASSE 1
CLASSE 2 LUMIERE LASER NE PAS REGARDER LE
RAYON FIXEMENT
PRODUIT LASER DE CLASSE 2
ITALIAN / ITALIANO
CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
CLASSE 2 LUCE LASER
NON FISSARE IL RAGGIOPRODOTTO
AL LASER DI CLASSE 2
PORTUGUESE / PORTUGUÊS
CLASSE 1 PRODUTO LASER DA CLASSE 1
CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO
LUMINOSO
PRODUTO LASER DA CLASSE 2
DUTCH / NEDERLANDS
KLASSE 1 KLASSE-1 LASERPRODUKT
KLASSE 2 LASERLICHT
NIET IN STRAAL STAREN
KLASSE-2 LASERPRODUKT
DANISH / DANSK
KLASSE 1 KLASSE 1 LASERPRODUKT
KLASSE 2 LASERLYF
SE IKKE IND I STRÅLEN
KLASSE 2 LASERPRODUKT
NORWEGIAN / NORSK
KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLYS IKKE STIRR INN I
LYSSTRÅLEN
LASERPRODUKT, KLASSE 2
FINNISH / SUOMI
LUOKKA 1 LUOKKA 1 LASERTUOTE
LUOKKA 2 LASERVALO
ÄLÄ TUIJOTA SÄDETTÄ
LUOKKA 2 LASERTUOTE
Transport and Storage
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
34/78
Technical data subject to change without notice..
Revision B / 03/2019
4. Transport and Storage
4.1 Transport
Report any transport damage or incomplete deliveries immediately after receipt in writing
to the forwarding company and BARTEC GmbH.
4.2 Storage
ATTENTION
Property damage through incorrect storage!
Observe storage temperatures.
Keep humidity away from the Mobile Computers.
Any damage caused through incorrect storage shall not be covered by the warranty
provisions of BARTEC GmbH.
Additional information on the batteries
The batteries of BARTEC (Type 17-A1Z0-0001, 17-A1Z0-0023 and B7-A2Z0-0044) are
developed and manufactured in accordance with the highest industrial standards. The
operating time or storage period of a battery is restricted, however. The actual life of a
battery is influenced by different factors, e.g. hot, cold, rough operating environment and
falling from a great height. If a battery is kept longer than six months, the performance may
be impaired on a permanent basis. Keep the batteries in a dry, cool place. For longer
periods of storage, remove the batteries from the device to prevent self-discharge, rusting
of metallic parts and the escape of electrolyte.
Batteries kept for the duration of 6 months or longer should be charged and then discharged
again at least every 3 months. If electrolyte has escaped, do not touch the areas affected
and dispose of the batteries as prescribed. Replace the battery if the operating time has
shortened considerably.
The standard warranty period for all BARTEC batteries is 6 months, whereby it is irrelevant
whether the battery was acquired separately or was contained in the scope of delivery of
the MC92N0
ex
.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
35/79
5. Commissioning
Before you assemble the device, make sure that all components and documents exist.
DANGER
Avoid electrostatic charging in potentially explosive atmosphere.
There is a risk of fatal injury in an explosive atmosphere!
Do not wipe or clean the devices with a dry cloth.
Wear suitable clothing and shoes.
Do not use rubber gloves or similar.
DANGER
Unintended use endangers explosion protection.
There is a risk of fatal injury in an explosive atmosphere!
Do not make any changes to the Mobile Computer.
In the case of functional disturbances or damage to the enclosure, the device
should be removed immediately from the potentially explosive atmosphere to a
safe place. Remove battery to decommission the device!
Do not use any battery replicas or batteries from other manufacturers.
5.1 Scope of delivery
1 x MC 92N0ex
1 x Lithium-ion battery
1 x Stylus
1 x Hand strap
1 x User Manual
Accessories optional
Authorised accessories from BARTEC:
− SD card
− Replacement stylus
− Battery
− Docking station for communication and charging
− Charging station
− Screen protector
− Leather holster
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
36/78
Technical data subject to change without notice..
Revision B / 03/2019
5.2 Requirements in potentially explosive atmosphere
Mobile Computer
1. The Mobile Computer may not be opened.
2. Do not use, swap or replace any non-specified components.
3. Do not retrofit any components to the internal plugs or slots.
Exception: SD-card
4. Protect the Mobile Computer from impact!
5. Do not expose the Mobile Computer to caustic/aggressive liquids, vapours, mists!
6. Avoid the impact of moisture outside the specifications.
7. Avoid thermal impact outside the specified temperature range.
8. Use the 17-pole data interface only outside the potentially explosive atmosphere and
exclusively with the devices specified by the manufacturer!
9. Use the headset connection only outside the potentially explosive atmosphere and
exclusively with the devices specified by the manufacturer!
Battery
1. The battery may not be opened.
2. Charge battery (type 17-A1Z0-0001, 17-A1Z0-0023 and B7-A2Z0-0044) only outside
of hazardous area.
3. The battery (type 17-A1Z0-0001 and 17-A1Z0-0023) may be changed in hazardous
areas.
4. The battery (type B7-A2Z0-0044) may only be changed outside the hazardous area.
5. Only use the battery for the purpose listed in this User Manual. Is only suitable for the
Mobile Computer MC 92N0
ex
.
Battery type 17-A1Z0-0001 is only suitable for MC 92N0ex-IS
type 17-A1A3-…./……..
Battery type 17-A1Z0-0023 is only suitable for MC 92N0ex-IS
type 17-A1A2-…./……..
Battery type B7-A2Z0-0044 is only suitable for MC 92N0ex-NI
type B7-A2A4-…./……..
6. There is a danger of burning if used incorrectly. Do not expose the battery to
temperatures of more than +50 °C (122 °F).
7. Battery acid may escape from the cells and cause burning in the case of damage.
8. Defective batteries must be disposed of immediately, whereby the provisions on battery
disposal applicable in the respective region must be observed.
9. The battery may explode if it catches fire!
10. Do not short circuit the battery!
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
37/79
Accessories
1. Only install or replace accessories outside the potentially explosive atmosphere.
2. Use accessories exclusively which have been tested or certified by BARTEC for this
purpose.
3. The end user can replace the SD card, screen protector, keypad and leather holster
himself.
5.3 First steps
Unpack the Mobile Computer.
Insert the battery into the Mobile Computer.
Charge the battery on the cradle.
Switch on the Mobile Computer.
Optional:
Charge the battery in a charger.
Insert a SD card.
Remove/replace screen protector.
The individual steps are explained on the following pages.
5.4 Structure
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
38/78
Technical data subject to change without notice..
Revision B / 03/2019
5.5 Handling accessories
DANGER
Non-certified accessories endanger explosion protection.
There is a risk of fatal injury in an explosive atmosphere!
Only use original accessories from BARTEC/ZEBRA.
Only permitted outside the potentially explosive atmosphere:
Charge battery.
Insert/replace SD card.
Remove/replace screen protector.
Further information is also provided by the ZEBRA documentation.
Insert/change battery
DANGER
Non-certified accessories endanger explosion protection.
There is a risk of fatal injury in an explosive atmosphere!
It must be ensured that only original battery are used in safety-oriented operation.
Only permitted outside the potentially explosive atmosphere:
The battery may only be charged outside the hazardous area!
The battery type B7-A2Z0-0044 may only be changed outside the hazardous area.
ATTENTION
Incorrect battery replacement may cause damage to property!
Change the battery of the MC 92N0ex only in the designated areas.
Put the MC 92N0
ex
into suspend mode before you remove the battery. Failure to
properly remove the battery may cause the MC 92N0
ex
to cold boot and potential
loss of data.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
39/79
Depending on configuration, the MC 92N0ex is supplied with a battery.
Type Order number
Accu replacement
in haz.loc.
Charging in safe
area
Battery (EU) for ATEX/IECEx
Lithium-ion battery 7.2 V / 2800 mAh
17-A1Z0-0001 Yes Yes
Battery (US) fo UL Division 1
Lithium-ion battery 7.4 V / 2600 mAh
17-A1Z0-0023 Yes Yes
Battery for UL Division 2 and ATEX Zone 2/22
Lithium-ion battery 7.4 V / 2600 mAh
B7-A2Z0-0044 Yes Yes
Work steps: (insert)
1. Charge the battery only outside hazardous areas.
2. The battery (type B7-A2Z0-0044) may only be inserted/changed outside the
hazardous area.
The battery (type 17-A1Z0-0001 and 17-A1Z0-0023) may be inserted/changed in
hazardous areas.
3. Use only batteries which have been tested or certified by BARTEC for this
purpose.
4. Insert the battery with the battery contacts facing forwards into the battery
compartment under the keypad.
5. Make sure that the battery’s charging contacts agree with the charging contacts in
the battery compartment.
6. Push the battery into the battery compartment until it locks into place.
Work steps: (change)
1. Turn off the MC 92N0
ex
with function mode “Safe Battery Swap”.
2. The battery (type B7-A2Z0-0044) may only be inserted/changed outside the
hazardous area.
The battery (type 17-A1Z0-0001 and 17-A1Z0-0023) may be inserted/changed in
hazardous areas.
3. Use only batteries which have been tested or certified by BARTEC for this
purpose.
4. To remove the battery, first unlock the side battery lock, then unlock the battery
lock.
5. Remove the battery from the Mobile Computer and insert a new one..
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
40/78
Technical data subject to change without notice..
Revision B / 03/2019
Change keypad
The MC 92N0ex has interchangeable modular keypads.
DANGER
Non-certified accessories endanger explosion protection.
There is a risk of fatal injury in an explosive atmosphere!
It must be ensured that only original keypads are used in safety-oriented operation.
The use of imitation keypads from other manufacturers will render the type of
ignition protection ineffective and there will then be a risk of fire or explosion.
Only permitted outside the potentially explosive atmosphere:
The keypad may only be changed outside the hazardous area!
Follow proper ESD precautions to avoid damaging the SD card. Proper ESD
precautions include, but are not limited to, working on an ESD mat and ensuring
that the operator is property grounded.
ATTENTION
Incorrect handling may cause damage to property!
Power off the MC 92N0
ex
before start of change parts.
Put the MC 92N0
ex
into suspend mode before you remove the battery. Failure to
properly remove the battery may cause the MC 92N0
ex
to cold boot and potential
loss of data.
Work steps:
1. Turn off the MC 92N0
ex
2. Remove the battery (see chapter 5.5.1 "Insert/change battery").
3. Take out the screws at the top edge of the keypad.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
41/79
4. Pull the keypad downwards in the direction of the arrow and then forwards to take it
out of the MC 92N0
ex
.
5. Check that the contacts and seals are clean and in good condition.
6. Insert both of the keyboard’s guide pins into the guide grooves (see illustration) on the
mobile computer housing.
7. Snap on the keypad in the direction (see following illustration) of the arrow and push
it upwards until the boreholes for the screws are over the threaded sleeves.
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
42/78
Technical data subject to change without notice..
Revision B / 03/2019
8. Check that the keypad is mounted correctly.
9. Tighten the screws (torque = 0.452 Nm / torque = 4.0 in-lbs); 0.5 Nm is advisable.
Attention: Always use the correct torque.
10. After the exchange of the keyboard a cold boot (see chapter 7.1 "Resetting the
MC 92N0
ex
") must be performed.
11. The current drivers are installed on the unit and initialized automatically by the cold
boot.
ATTENTION
Incorrect handling may cause damage to property!
Do not apply more than 0.5 NM or 4 in-lbs of torque when tightening the keypad
screws.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
43/79
Insert SD card
ATTENTION
Damage to the SD card through electrostatic
discharges!
Use an antistatic base.
Ensure that the operator is correctly earthed.
Use only specified SD cards
MC92N0
ex
-IS
specified
MC92N0
ex
-NI
freely selectable
2 GB Order number 17-28BE-F006/0003
4 GB Order number 17-28BE-F006/0004
8 GB Order number 17-28BE-F006/0005
16 GB Order number 17-28BE-F006/0006
32 GB Order number 17-28BE-F006/0007
Yes Yes
For MC92N0ex-IS version:
The listed SD cards are listed in the certificate. No other SD cards may be used.
For MC92N0ex-NI version:
The SD cards are not specified in the certificate. The customer can freely choose which
SD cards to be used.
Work steps:
1. Only install or replace the SD card outside the potentially explosive atmosphere.
2. Only use SD cards which have been tested and certified by BARTEC for this purpose.
3. Press the red button "ON/OFF" to suspend the MC 92N0
ex
.
4. Remove the battery (see chapter 5.5.1 "Insert/change battery")
5. Remove the two keypad screws and slide the keypad down and lift off
(see chapter 5.5.2 "Change keypad").
6. Lift the SD card retaining door and position the SD card, with the contacts down, into
the SD card holder (shown in the illustration).
7. Snap the retaining door closed.
8. Replace the keypad and re-attach using the two screws
(see chapter 5.5.2 "Change keypad")
9. Perform a warm boot that the keypad is recognized by the system
(see chapter 7.1 "Resetting the MC 92N0
ex
").
10. Check in the File Explorer or the settings, if the SD card has been recognized.
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
44/78
Technical data subject to change without notice..
Revision B / 03/2019
Remove/replace screen protector
The screen protector protects the touch screen and improves the user friendliness of the
device. With its relatively hard surface, the screen protector offers a mechanical protection
against scratches for example and reduces disturbing light reflections.
DANGER
Use of a screen protector changes the Ex protection type of the MC 92N0ex
to IIB.
There is a risk of explosion when you use the MC 92N0ex in combination with screen
protector in hazardous area with gas group IIC.
Use of screen protector change the Ex protection type of the MC 92N0 from IIC to
IIB.
ATTENTION
Incorrect handling may cause damage to property!
Use a screen protector so as not to impair the device warranty.
Only use screen protector (Type 17-A1Z0-0004) from BARTEC.
Observe the installation instructions for the screen protector.
Do not use any sharp objects to remove the screen protector!
Work steps
1. Only remove or replace the screen protector outside the potentially explosive
atmosphere.
2. Lift a corner of the screen protector and remove it from the display.
3. Attach the screen protector in accordance with the “Screen protector installation
instructions”.
You can order screen protector from your customer consultant or from BARTEC.
Installation instructions for
the screen protector are part of the delivery scope. Part
number: 17-A1Z0-0004 screen protector, pack of 5.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
45/79
Leather holster
BARTEC offers holsters to protect the MC 92N0ex series.
DANGER
Non-certified accessories endanger explosion protection.
There is a risk of fatal
injury in an explosive atmosphere!
Use only the original leather holsters.
Leather holster
− for MC 92N0
ex
-G and MC 92N0ex-K with belt clip/turned part 03-9809-0026
− Turned part for holster 03-9809-0027
− Shoulder strap 03-9829-0091
Headset
DANGER
Headset what are not compliant to the safety data of the headset connector
endanger a risk of explosion.
There is a risk of fatal injury in an explosive
atmosphere!
Use only headsets which observe the safety data in the EC Type Examination
Certificate.
Safety data of headset connector:
Ex protection
Ex ib IIC
U0 = 8.6 V
I0 = 354 mA
P0 = 479 mW
C0 = 930 nF
L0 = 460 µH
Commissioning
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
46/78
Technical data subject to change without notice..
Revision B / 03/2019
5.6 Connection to a PC
The MC 92N0ex-IS series is supplied with the Operating system Microsoft Windows
Embedded Handheld 6.5.3 (WEH 6.5.3), Windows Embedded Compact 7 (CE 7.0) or
Android 4.4.4.
For WEH6.5.3 and CE7.0:
Microsoft provides software free of charge for connection to a PC for synchronisation,
installation and data exchange.
• Active Sync
or
• Windows Mobile Device Center
For Android:
Android devices can be connected to a PC via USB and data can be exchanged via the File
Explorer. 3rd party providers also offer synchronization tools.
Active Sync
It is recommended to install ActiveSync (Version 4.5 or higher) on the host computer for
communication with different computers installed under Windows XP or earlier operating
systems.
ActiveSync synchronises the information from the Mobile Computer
with the host
computer. Changes made on the Mobile Computer or
the host computer exist on both
devices after synchronisation.
ActiveSync is available for download as freeware at www.microsoft.com.
Supporting operating system: Windows XP or earlier operating systems
More information on ActiveSync is available in the ZEBRA Integration Manual or on the
Microsoft website.
Windows Mobile Device Center
It is recommended to install the Windows Mobile Device Center on the host computer for
the communication with different host computers installed under Windows Vista,
Windows 7 or Windows 8.
The Windows Mobile Device Center synchronises the data from the
Mobile Computer
with the host computer. Changes made on the Mobile Computer or
the host computer
exist on both devices after synchronisation.
The Windows Mobile Device Center is available for download as freeware at
www.microsoft.com
.
Supporting operating systems: Windows Vista, Windows 7 or Windows 8
More information on Windows Mobile Device Center is available in the ZEBRA Integration
Manual or on the Microsoft website.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Commissioning
Technical data subject to change without notice.
Revision B / 03/2019
47/79
Android
There are several ways to exchange or synchronize data from Android devices with a
Windows PC.
1. Manually via USB.
When an Android device is connected to a Windows PC via USB, it appears as a
drive on the PC that can be selected.
2. Using a Cloud
Many users now use the cloud as an exchange platform for their data. The large
providers Google, Microsoft or Dropbox offer solutions for storing your data. This
way is particularly suitable for the automated comparison of even data of all kinds.
3. About the network
If cloud providers are out of the question or the devices are not integrated in the
Internet, the network is the right choice. In this case, install the appropriate
application on your Windows computer as well as on your mobile device. After you
have activated both, they will try an automatic pairing. You can then synchronize
your data between the paired devices either manually or automatically.
A variety of solutions for this type of pairing and synchronization can be found on
the Internet.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
48/78
Technical data subject to change without notice..
Revision B / 03/2019
6. Operation
The operator using an electric system in an potentially explosive environment must keep
the accompanying operation equipment in a good condition, operate and monitor it correctly
and conduct the requisite services and repairs. Before commissioning the devices, it must
be checked that all components and documents are available.
6.1 Final inspection
The following aspects must be checked before putting the device into operation:
Is there any damage to the display, scanner window or enclosure?
Is the battery used certified?
Is the battery compartment cover closed?
Does the screen protector (if used) have the requisite certification?
Is the SD card specified for the MC 92N0
ex
-IS?
6.2 Handling
Optimum standby position
Right:
The Mobile Computer is protected from damage.
Wrong:
The Mobile Computer can be damaged by objects on the surface or may fall down.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
49/79
6.3 Care and cleaning
We recommend that the devices be cleaned regularly depending on use and also treated
with care to ensure smooth and trouble-free operation.
Care
Display
− Only use with supplied stylus for the touchscreen
− Use screen protector
− Use a soft cloth to clean and do not use aggressive cleaners
Enclosure
− Protect device from impacts
− Do not expose to extreme load, e.g. strong knocks and falling
from great heights
Environment
− Do not expose to extreme temperatures and
− Do not leave in dirty, moist or wet environment
Battery
− Change regularly
− Discharge and charge regularly (every 3 months)
− If storing for a lengthy time, take the batteries out of the Mobile
Computer and keep them in a cool environment at about 0°C
to +10°C and at a state of charge of approximately 40-50 %.
− It is recommendable to charge the battery again once the state
of charge drops to approximately 5 %. It is not necessary to
discharge the battery completely. Charging the battery every
day doesn’t do any damage either. Batteries nowadays do not
have a “memory effect”.
−
If the battery state of charge drops from 100 % to half of that
too quickly, it is time to replace the battery. The battery’s
expected service life is approx. 500 charges with standard
usage.
Cleaning
DANGER
There is a risk of fatal injury in an explosive atmosphere!
Only clean the devices and the accessories outside the potentially explosive
atmosphere.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
50/78
Technical data subject to change without notice..
Revision B / 03/2019
The following precautionary measures should be taken for your own safety and to
ensure the operational safety of the device:
ATTENTION
Devices and accessories can be destroyed if handled incorrectly.
Generally separate the charger from the power supply.
Only clean the cradle contacts if the battery has been removed.
There should be no residue, e.g. fluff on the contacts.
There should be no moisture residue on the contacts.
Heed the safety precautions when drying with compressed air.
Suitable materials
− Alcohol cleaning cloths
− Lens cleaning cloths
− Cotton swabs
− Isopropanol
− Compressed air spray with tube
Enclosure − With alcohol cleaning cloths
Keys and intermediate spaces − With alcohol cleaning cloths
Screen − With alcohol cleaning cloths
Avoid collections of fluid and rub with smooth cloths
Scanner window − Cleaning agent for optical devices
Battery contacts in the
Mobile Computer
Remove the battery from the device to clean.
− Soak the cotton swabs in an alcohol solution to remove all grease
and dirt deposits on the contacts.
− Repeat cleaning several times
Before replacing the battery, the contacts must be completely dry and
no fluff should remain.
Contacts at the battery
To clean the contacts at the battery remove the battery from the device.
− Soak the cotton swabs in an alcohol solution to remove all grease
and dirt deposits on the contacts.
− Repeat cleaning several times
Before the battery is replaced in the device or the charging station or the
docking-station, the contacts at the battery must be completely dry and
no fluff should remain.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
51/79
Contacts in charging station or
docking-station
Separate the charging station or the docking-station from the power
supply to clean the charger contacts.
− Soak the cotton swabs in an alcohol solution to remove all grease
and dirt deposits on the contacts.
− Repeat cleaning several times
Before the charging station or the docking-station is reconnected to the
power supply, the contacts must be completely dry and no fluff should
remain.
6.4 Operation recommendations and requirements
Basic safety and health protection requirements
Consult your local health and safety officer to ensure that you are acquainted with the safety
regulations in your company which serve to protect employees at the work place.
Ergonomic recommendation
The following recommendations should be considered for everyday work at the workplace:
− Avoid one-sided, constantly repetitive movements.
− Body posture should be as neutral as possible.
− Avoid exercising great force.
− Keep objects which are used frequently within a functional distance.
− Adjust the working height to the body height and type of work.
− Erect objects without vibration.
− Avoid the exercise of direct pressure.
− Ensure that tables and chairs are adjustable.
− There must be sufficient room for body movements.
− Ensure that the working environment is suitable.
− Optimise workflows.
− Alternate between the left and right hand as frequently as possible when conducting
repetitive tasks.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
52/78
Technical data subject to change without notice..
Revision B / 03/2019
Vehicle installation
RF signals may impair incorrectly installed or inadequately shielded electronic systems in
vehicles (including safety systems). If you have any questions on your vehicle, get in touch
with the manufacturer or a sales person. You can also learn from the manufacturer whether
additional equipment has been fitted to the vehicle. An airbag has a strong impact. Do NOT
place objects, such as installed or portable radio equipment, in the area above the airbag
or in the area of deployment of the airbag. If the radio equipment was not correctly installed
in the vehicle, severe injuries may result if the airbag is triggered. Position the device within
good range. Ensure that you have access to the device without having to take your eye off
the road.
It is not permitted to connect a warning device which leads to horn sounds or light signals
when receiving a call in road traffic.
Road traffic safety
Do not take any notes and do not use the device when driving. Making a list of to-do’s or
browsing through the address book when driving has a negative influence on safe driving.
When driving on the roads, you must primarily think of your safety and that of the other road
users. You should therefore concentrate completely on the road. Check the legal provisions
on the use of wireless devices in road traffic of the respective region. Always observe these.
If you use a wireless device during driving, rely on your good judgment and remember the
following:
1. Become acquainted with the wireless device and its functions such as the shortcut
dialing or dial repetition. These functions may prove to be useful if you would like to
make a call without taking your eye off the road.
2. Where possible, use hands-free equipment.
3. Let your dialogue partner know that you are behind the steering wheel. Where
necessary, discontinue the call in dense traffic or poor weather conditions. Rain, sleet,
snow, ice and even very dense traffic represent dangers.
4. Dial the required numbers carefully and estimate the traffic situation. Make your calls
when you have brought your car to a stop or before you leave. Plan your calls such
that they can be made when the car is parked. If you really must make a call during
the trip, only dial a part of the number, check the road and look in the rear view mirror
and then dial the rest of the number.
5. Do not surccumb to stressful and emotional telephone conversations which could take
your attention from the road. Let your dialogue partner know that you are in a car and
refrain from conversations which could take your attention away from the road.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
53/79
6. Call for help using your mobile device if necessary. Dial the emergency services (9-11 in the USA and 1-1-2 in Europe) or other local emergency service numbers in the
event of fire, accidents or medical emergences. Remember that these calls are free
of charge on the wireless device! The call can be made independently of security code
or networks with or without the SIM card.
7. Help your fellow humans in emergency situations with your mobile device. If you
witness a serious accident, crime or other emergency, call the emergency service (91-1 in the USA and 1-1-2 in Europe) or another local emergency service number
because you could be the one who needs help next time.
8. Call the breakdown service or a special mobile radio number for support if you
encounter problems on the road. If you pass a car with a breakdown, which does not
represent a serious impediment to traffic, pass traffic lights which do not function, a
traffic accident with slight damage and without injured people or a possibly stolen car,
please get in touch with the road police or another special mobile radio number for
support.
“The mobile communication industry requests you to give safety priority when using your
device/telephone.”
Instructions on the use of Wireless Devices
Observe all warnings relating to the use of wireless devices.
Safety in aircraft
Switch off the wireless device when asked to do so by the ground staff and by employees
of the airline. If your device has a flight mode or a similar function, find out about its correct
use from the aircraft staff.
Safety in hospitals
Wireless devices emit radio frequencies and can cause disturbances to medical technical
electrical devices. Wireless devices should be switched off on request when you are in
hospitals, clinics or health establishments. This is intended to avoid any possible
interference with sensitive medical equipment.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
54/78
Technical data subject to change without notice..
Revision B / 03/2019
Heart pacemakers
Manufacturers recommend that a minimum distance of 15 cm be observed between a
wireless handheld device and a pacemaker to avoid potential interference. This guideline
is in line with independent research results and recommendations of Wireless Technology
Research.
− Wearers of heart pacemakers
− Persons with heart pacemakers should ALWAYS keep at least 15 cm away from the
activated device.
− The device may not be worn by these persons in the breast pocket.
− The device should be held to the ear which is furthest away from the heart pacemaker.
− If you have reason to assume that interference has arisen, you should SWITCH OFF
the device immediately.
Hearing aids
The wireless device may cause disturbances to hearing devices. Get in contact with the
manufacturer of your hearing device in the case of disturbances to ask about possible
solutions.
− The device may not be worn in the breast pocket of these persons.
− The device should be held to the ear which is furthest away from the heart pacemaker.
− If you have reason to assume that interference has arisen, you should SWITCH OFF
the device immediately.
Other medical equipment
Ask your doctor or the manufacturer of the medical device to determine whether putting the
wireless product into operation impairs the medical device.
Equipment of the laser devices
Devices from BARTEC/ZEBRA equipped with lasers comply with the Guidelines
21CFR1040.10 and 1040.11. (with the exception of the deviations set out in the Laser
Notice No. 50 dated 24 June 2007) and EN 60825-1:2001,2007 und EN 62471:2006. The
classification of the laser device is stated on a plate attached to the device.
Class 1 Laser devices are not considered to be hazardous when used for their intended
purpose.
CAUTION
Laser radiation! Risk of damage to eyesight!
Do not look into the laser beam.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
55/79
Laser devices of Class 2 work with a visible low volt light emitting diode. As for every bright
light source, for example the sun, you should not look directly into the light beam. There is
no information about the hazards of being briefly exposed to the laser light of a laser
scanner of Class 2.
The use of control elements, adjustments or the application of procedures which do not
comply with the instructions described here may lead to hazardous exposure to beams.
LED Devices
Complies with EN60825-1:2001 and EN 62471:2006.
Restrictions to wireless devices
The use of wireless devices is possibly forbidden or restricted. This applies primarily on
board aircraft, in hospitals, in the vicinity of explosive substances
or under other
hazardous conditions. If you are not sure which regulations apply to the use of the device,
ask permission before switching it on.
Radio Modules
The device contain approved radio module(s). These module(s) are identified below.
BARTEC/ZEBRA radio module supporting WLAN 802.11 a/b/g/n and Bluetooth.
Type(s): 21-148603-0B
Bluetooth® Wireless Technology
This is an approved Bluetooth® product. For more information or to view End Product
Listing, please visit https://www.bluetooth.org/tpg/listings,cfm
Country-specific roaming
This device has the International Roaming function (IEEE802.11d) which ensures that the
device is used on the channels prescribed for the respective country.
Ad-hoc operation
The ad-hoc operation is restricted to the channels 36–48 (5150–5250 MHz). The use of this
bandwidth is restricted to indoor areas; use outdoors is not permitted.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
56/78
Technical data subject to change without notice..
Revision B / 03/2019
6.5 Frequency of Operation – FCC and IC
5 GHz Only
The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150 -5250
MHz band is restricted to Indoor Use Only; any other use will make the operation of this
device illegal.
Industry Canada Statement
Caution: The device for the band 5150-5250 MHz is only for indoor usage to reduce
potential for harmful interference to co-Channel mobile satellite systems. High power radars
are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 56505850 MHz and these radars could cause interference and/or damage to LE-LAN devices.
Avertissement: Le dispositive fonctionnant dans la bande 5150-5250 MHz est réservé
uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage
préjudiciable aux systèmes de satellites mobiles utilisant les memes canaux.
Les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d.,
qu'ils ont la priorité) pour les bands 5250-5350 MHz et 5650-5850 MHz et que ces radars
pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
2.4 GHz Only
The available channels for 802.11 b/g operation in the US are Channels 1 to 11. The range
of channels is limited by firmware.
Radio Frequency Interference Requirements - FCC
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Note according to 15.21
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
57/79
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Label Marking: The Term "IC:" before the radio certification only signifies that "Industry
Canada" technical specifications were met.
Country approvals
Regulatory markings, subject to certification, are applied to the device signifying the radio(s)
is/are approved for use in the following countries: United States, Canada, Japan, China, S.
Korea, Australia, and Europe.
Detailed information on the test symbol for other countries is provided in the EU declaration
of conformity.
− Note: For 2.4-GHz-products: Europe covers, Belgium, Bulgaria, Denmark, Germany,
Estonia, Finland, France, Greece, Great Britain, Ireland, Iceland, Italy, Latvia,
Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Austria, Poland,
Portugal, Romania, Sweden, Switzerland, Slovakia, Slovenia, Spain, Czech Republic,
Hungary and Cyprus.
USA
In the USA, channels 1 to 11 are available for 802.11 b/g operation. The range of the
channels is limited by the firmware.
WARNING
Operation of the device without regulatory approval is illegal.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
58/78
Technical data subject to change without notice..
Revision B / 03/2019
Radio Transmitters for RLAN Devices:
The use of 5 GHz RLAN’s, for use in Canada, have the following restrictions:
− Restricted Band 5.60 – 5.65 GHz
This device complies with RSS 210 of Industry Canada. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils
radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes:
(1) le dispositif ne doit pas produire de brouillage préjudiciable, et
(2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Label Marking: The Term “IC:” before the radio certification only signifies that Industry
Canada technical specifications were met.
6.6 Electromagnetic fields
International
Reducing RF Exposure – Use Properly
Only operate the device in accordance with the instructions supplied.
International
The device complies with internationally recognized standards covering human exposure
to electromagnetic fields from radio devices. For information on “International” human
exposure to electromagnetic fields refer to the BARTEC and ZEBRA Declaration of
Conformity (DoC) at
https://www.zebra.com/us/en/about-zebra/company-information/compliance.html
Europe
Handheld Devices
This device was tested for typical body-worn operation. Use only BARTEC tested and
approved belt-clips, holsters, and similar accessories to ensure EU Compliance.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
59/79
US and Canada
Co-located statement
To comply with FCC RF exposure compliance requirement, the antenna used for this
transmitter must not be co-located or operating in conjunction with any other
transmitter/antenna except those already approved in this filling.
Handheld Devices
This device was tested for typical body-worn operation. Use only BARTEC tested and
approved belt-clips, holsters, and similar accessories to ensure FCC Compliance. The use
of third-party belt-clips, holsters, and similar accessories may not comply with FCC RF
exposure compliance requirements, and should be avoided.
The MC 92N0ex should only be worn on the body when switched off.
Handheld devices
To comply with the FCC guidelines for high frequency devices, the aerial of the transmitter
should be used in the direct vicinity of, or in an operation unit with, other transmitters/aerials
with the exception of those approved in this document.
SD card
The SD card slot provides a secondary, non-volatile memory. The slot is under the keypad
of the MC 92N0ex. Further information is provided in the documentation supplied with the
card. Observe the manufacturer’s recommendations on use.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
60/78
Technical data subject to change without notice..
Revision B / 03/2019
6.7 Optimise operating times/change energy settings
Factory settings of the MC 92N0ex-IS for the WWAN and WLAN radio devices: ON.
Instructions and notes for optimizing or changing settings for operating systems
• Windows Embedded Handheld 6.5.3 (WEH6.5.3)
• Windows Embedded Compact 7 (CE7.0)
• Android 4.4.4
can be found in detail in the ZEBRA Operating Instructions or the ZEBRA Integration Manual.
Automatic shutdown in the case of lengthy standby periods
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Settings symbol
> System symbol
> Power symbol
> Advanced tab
> Activate “Turn off device if not
used for” box and select a value
from the dropdown list.
> Confirm selection with “OK”.
For Windows Embedded Compact 7 (CE7.0)
Path specification:
Start => Settings => Control Panel => Power
For Android 4.4.4
Path specification:
Settings => Display => Sleep
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
61/79
Change display backlight (increases the operating time of the battery)
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Settings symbol
> System symbol
> Backlight symbol
> Battery Power tab
> Activate “Disable backlight if
device is not used for” box and select
a value from the dropdown list.
> Brightness tab
> Select Disable backlight option. The
brightness of the backlight can be
regulated with a controller.
> Confirm selection with “OK”.
For Windows Embedded Compact 7 (CE7.0)
Path specification:
Start => Settings => Control Panel => Backlight
For Android 4.4.4
Path specification:
Settings => Display => Brightness
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
62/78
Technical data subject to change without notice..
Revision B / 03/2019
Change keypad background lighting (increases the operating time of the battery)
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Settings symbol
> System symbol
> Keylight symbol
> Battery Power tab
Activate “Disable keylight if device if
not used for” option and select a value
from the dropdown list.
> Advanced tab
Select “Disable keylight” option. The
brightness of the backlight can be
regulated with a controller or
switched off.
> Confirm selection with “OK”.
For Windows Embedded Compact 7 (CE7.0)
Path specification:
Start => Settings => Control Panel => Keylight
For Android 4.4.4
Path specification:
Settings => Display => Keylight
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
63/79
Switch off radio connections
Products with Bluetooth® Wireless technology:
This device is an approved Bluetooth® product. Further information is available at
http://www.bluetooth.org/tpg/listings.cfm Manufacturer: ZEBRA
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
Windows Embedded Handheld 6.5.3 devices
have a simple and central possibility in the
form of the Wireless Manager to deactivate
and configure all wireless functions of the
device.
In the start menu under:
> Settings symbol
> Connections symbol
> Wireless Manager symbol
Activate/deactivate wireless connection:
> activate respective button.
> All button
For Windows Embedded Compact 7 (CE7.0)
Path specification:
1. Select the Fusion Driver icon on the start screen.
2. Use the drop-down menu to switch the WLAN (radio) on/off and settings
can be made.
For Android 4.4.4
Path specification:
Settings => Wi-Fi
Wireless connections depend on the configuration.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
64/78
Technical data subject to change without notice..
Revision B / 03/2019
6.8 Software versions
Existing software versions and operating systems in the MC92N0ex–IS:
The software is not relevant to the explosion protection of the device.
See the ZEBRA documentation for further information.
OEM
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Settings symbol
> System symbol
> System Info symbol
> System tab
For Windows Embedded Compact 7 (CE7.0)
Path specification:
Start => Settings => Control Panel => System Info => System =>
OEM Version
For Android 4.4.4
Path specification:
Settings => About device
• Build number
• Android security patch level
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
65/79
AKU
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Settings symbol
> System symbol
> About symbol
> Version tab
The last part of the build number contains
storage battery number.
For Windows Embedded Compact 7 (CE7.0)
No AKU number specified. OEM version according to chapter 6.8.1 required.
For Android 4.4.4
No AKU number specified. OEM version according to chapter 6.8.1 required.
Operation
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
66/78
Technical data subject to change without notice..
Revision B / 03/2019
Bluetooth
The “BTExplorer” application is only available if the “StoneStreet One Bluetooth Stack”
function is activated. Further information is provided in the ZEBRA
“User Manual on
Integration”.
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Moto BT UI Information symbol
> My Device Information symbol
For Windows Embedded Compact 7 (CE7.0)
Path specification:
Start => Programs => MotoBTUI => My Device Information
For Android 4.4.4
No Bluetooth information specified. OEM version according to chapter 6.8.1
required.
For Windows operating systems:
The MC92N0 with Bluetooth technology uses either the StoneStreet Bluetooth stack or
the Microsoft Bluetooth stack. To write an application that uses the StoneStreet One
Bluetooth stack APIs refer to the ZEBRA Solutions
Enterprise Mobility Developer Kit
(EMDK) Help. Further information is provided in the ZEBRA
“User Manual on
Integration”.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Operation
Technical data subject to change without notice.
Revision B / 03/2019
67/79
“Fusion”software
For Windows Embedded Handheld 6.5.3 (WEH6.5.3)
Symbols
In the start menu under:
> Wireless Companion symbol
> Wireless Status symbol
> Point 7 “Versions”
For Windows Embedded Compact 7 (CE7.0)
Path specification:
1. Select the Fusion Driver icon on the start screen.
2. Select Wireless Status in the drop-down menu
3. Select menu item 7) Versions
For Android 4.4.4
Path specification:
Settings => Wi-Fi
1. Open menu with tab on icon und select Advanced.
2. Version Fusion…
Faults and
Troubleshooting
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
68/78
Technical data subject to change without notice..
Revision B / 03/2019
7. Faults and Troubleshooting
DANGER
There is a risk of fatal injury in an explosive atmosphere!
Examine defective devices and any accessories only outside the potentially
explosive atmosphere.
Information on fault rectification is provided in the User Manual or the Integration Manual
on the ZEBRA website.
https://www.zebra.com/us/en/support-downloads.html
ZEBRA website for the MC9200 manuals for the non-Ex protected version
− Support and Downloads
− Mobile Computers
− Handheld Computer > MC9200
7.1 Resetting the MC 92N0ex
Windows Embedded Handheld and Windows Compact Devices
If the applications stop working while the MC 92N0ex is used, it is recommendable to reboot
the device.
There are two re-booting functions: warm boot and cold boot. If these types of rebooting
don’t help, the MC 92N0
ex
operating system can be reset to the factory defaults by a
„CleanBoot“.
On a Windows Compact (CE 7.0) device
− A warm boot starts the MC 92N0ex again and shuts down all running programs.
− A cold boot also restarts the MC 92N0
ex
, but erases all stored records and entries in
RAM. Data saved in flash memory or a memory card is not lost. In addition it returns
formats, preferences and other settings to the factory default settings.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Faults and
Troubleshooting
Technical data subject to change without notice.
Revision B / 03/2019
69/79
ATTENTION
Incorrect handling may cause damage to property!
Data stored in the flash memory or on a memory card is not lost. First perform a
warm boot. The MC 92N0
ex
is re-started and all stored data records and entries
are preserved. If the MC 92N0
ex
still does not respond after a warm boot, perform
a cold boot.
Any data previously synchronized with a computer can be restored during the next
ActiveSync operation.
Warm boot
To perform a warm boot
1. Hold down the Power button for approximately five seconds. As soon as the
MC 92N0
ex
starts to perform a warm boot release the Power button.
Cold Boot
ATTENTION
Incorrect handling may cause damage to property!
Performing a cold boot restores formats, preferences and other settings to the
default settings.
Performing a hard reset with an SD card installed in the MC9200 may cause
damage or data corruption to the data on SD card or the SD card itself.
To perform a cold boot:
1. Press the red Power button. The PowerKey Action window appears.
2. Tap Safe Battery Swap.
3. Press the primary battery release on the MC 92N0
ex
to partially eject the battery from
the MC 92N0
ex
(see chapter 5.5.1 Insert/change battery)
4. While the battery is partially released, simultaneously press and release the handle
trigger and the Power button.
5. Push the battery to fully re-insert it in the MC 92N0
ex
. One audible click can be heard
as the battery is fully inserted.
6. The MC 92N0
ex
reboots.
7. Calibrate the screen. See Calibrating the Screen in the ZEBRA User Guide to calibrate
the MC 92N0
ex
screen.
Faults and
Troubleshooting
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
70/78
Technical data subject to change without notice..
Revision B / 03/2019
On a Windows Embedded Handheld (WEH) 6.5.3 device
− A warm boot starts the MC92N0ex again and shuts down all running programs.
− A cold boot also restarts the MC92N0ex, but erases all stored records and entries in
RAM. In addition, some new drivers are installed
ATTENTION
Incorrect handling may cause damage to property!
Data stored in the flash memory or on a memory card is not lost. First perform a
warm boot. The MC 92N0
ex
is re-started and all stored data records and entries
are preserved. If the MC 92N0
ex
still does not respond after a warm boot, perform
a cold boot.
Any data previously synchronized with a computer can be restored during the next
ActiveSync operation.
Warm boot
To perform a warm boot
1. Hold down the Power button for approximately five seconds. As soon as the
MC 92N0
ex
starts to perform a warm boot release the Power button.
Cold boot
ATTENTION
Incorrect handling may cause damage to property!
Performing a cold boot restores formats, preferences and other settings to the
default settings.
Performing a hard reset with an SD card installed in the MC9200 may cause
damage or data corruption to the data on SD card or the SD card itself.
To perform a cold boot:
2. Press the red Power button. The PowerKey Action window appears.
3. Tap Safe Battery Swap.
4. Press the primary battery release on the MC92N0ex to partially eject the battery from
the MC92N0
ex
. (described in chapter 5.4.1 Insert battery)
5. While the battery is partially released, simultaneously press and release the handle
trigger and the Power button.
6. Push the battery to fully re-insert it in the MC92N0
ex
. One audible click can be heard
as the battery is fully inserted.
7. The MC92N0
ex
reboots.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Faults and
Troubleshooting
Technical data subject to change without notice.
Revision B / 03/2019
71/79
Clean Boot
ATTENTION
Incorrect handling may cause damage to property!
Performing a clean boot restores formats, preferences and other settings to the
factory settings.
Perform Clean Boot:
1. Download the File: “Clean Boot Package” from the Zebra website “Support und
Downloads“. Follow the instructions in the file to install the Clean Boot Package on
the MC 92N0ex..
There are two versions of the Clean Boot File:
1. Clean Boot
Resets the device to the factory setting.
The folder "Application" is not deleted/reset.
2. Clean Boot And Blank
Resets the complete device to the factory setting.
Also the folder "Application" is deleted/reset
On an Android device
There are two re-booting functions: soft reset and hard reset.
ATTENTION
Incorrect handling may cause damage to property!
Data stored in the flash memory or on a memory card is not lost. First, perform a
soft reset. The MC 92N0
ex
is re-started and all stored data records and entries are
preserved. If the MC 92N0
ex
still does not respond after a soft reset, perform a
hardreset.
Any data previously synchronized with a computer can be restored at the next connection.
Warm boot
To perform a soft reset
Perform a soft reset if applications stop responding.
1. Press and hold the On/Off button until the menu appears.
2. Touch Reset.
3. The device shuts down and restarts.
Faults and
Troubleshooting
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
72/78
Technical data subject to change without notice..
Revision B / 03/2019
Cold boot
ATTENTION
Incorrect handling may cause damage to property!
Performing a hard reset with an SD card installed in the MC9200 may cause
damage or data corruption to the data on SD card or the SD card itself.
To perform a hard reset (if the device is completely non-responsive, skip steps 1 and 2):
1. Press the red Power button.
2. Tab Safe Battery Swap. The indicator LED bar lights red.
3. Press the primary battery release on the MC92N0 to partially eject the battery from
the MC92N0.
4. While the battery is partially released, simultaneously press and release the trigger
and the Power button.
5. Push the battery to fully re-insert it in the MC92N0. One audible click can be heard as
the battery is fully inserted.
6. The MC92N0 reboots.
7. When the screen turns off, release the buttons
.
8. The MC92N0 reboots.
7.2 USB connection does not work
Problem:
Active Sync or Microsoft Mobile Device Center connection is not working.
Root cause:
Combination of several things.
• The Ex conversion also includes limiting the external circuits. This includes the USB
interface.
• Problem occurs especially on Dell and HP computers. However, it can also affect other
PC's.
Note:
Due to the modification for Ex i, the USB interface is at the lower limit of the interface
specification.
When connecting to computers, the manufacturers use interfaces that are also in the lower
part of the specification may lead to connection problems.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Faults and
Troubleshooting
Technical data subject to change without notice.
Revision B / 03/2019
73/79
Solution:
Use of an external USB hub with external power supply.
Important note:
• The USB interface used must be a maximum of USB 2.0
• USB 3.0 is not supported
Further solution if it does not work:
• Clean Boot to reset device.
=> In rare cases log files in the system additionally prevent a connection.
• If the devices are built before February 2015, then a technical change is required since
February 2015, the state of the art.
To check is necessary
Type number
Serial number
Affected devices:
Device Ex-certification Type Affected
MC92N0ex series
Zone 1
Zone 1:
PTB 13 ATEX 2019X
IECEx PTB 13 0043 X
17-A1A3-
xxxx/xxxxxxxx
Yes
MC92N0ex series
Division 1
Division 1:
UL File E226123
17-A1A1-
xxxx/xxxxxxxx
17-A1A2-
xxxx/xxxxxxxx
No
MC92N0ex series
Division 2/
Zone 2/22
Division 2:
UL 20151222-E321557
Zone 2/22
EPS 14 ATEX 1 782 X
IECEx EPS 14.0100X
B7-A2A1-
xxxx/xxxxxxxx
B7-A2A3-
xxxx/xxxxxxxx
B7-A2A4-
xxxx/xxxxxxxx
No
Disposal, Dispatch and
Packaging
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
74/78
Technical data subject to change without notice..
Revision B / 03/2019
8. Service, Inspection, Repair
Commissioning and service of Mobile Computers may be conducted exclusively by trained
and qualified staff! The staff is familiar with the installation, assembly, commissioning and
operation of the Mobile Computers, has been informed about the risks and has the
qualifications necessary for this work.
8.1 Service intervals
The mechanical state of the device should be regularly checked. The service intervals will
depend on the ambient conditions. We recommend that a service be conducted at least
once a year. Regular servicing is not necessary if the device is correctly operated in
accordance with the installation instructions and under appropriate consideration of the
ambient conditions.
DANGER
Prevent electrostatic charging in potentially explosive atmospheres.
There is a risk of fatal injury in an explosive atmosphere!
Do not dry wipe or clean devices.
8.2 Inspection
According to EN 60079-17, IEC 60079-17, EN 60079-19 and IEC 60079-19, the
owner/operator of electrical plants in potentially explosive atmospheres is obliged to have
these plants checked by an electrician to ensure that they are in a correct condition.
8.3 Service and repair work
In addition to Directive 99/92/EC, standards EN 60079-17, IEC 60079-17, EN 60079-19 and
IEC 60079-19 also apply to the servicing and repair as well as the testing of accompanying
operating devices.
Work connected with assembly/dismantling, operation and servicing may only be conducted
by trained specialists. All statutory requirements and other binding guidelines on
occupational health and safety, accident prevention and environmental protection must be
observed.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Service, Inspection, Repair
Technical data subject to change without notice.
Revision B / 03/2019
75/79
Information on sending in for repairs
The following information is required for the repair.
− Series number of the device (see manufacturer’s label)
− Model number or product name (see manufacturer’s label)
− Software type and version number (see Chapter 6.8)
Please read through the handling guidelines for the RMA process before you send in a
defective device for repair. Then complete the RMA form (Return Merchandise
Authorization), sign it and send it to our “Returns Centre”.
E-Mail: services@bartec.de
Fax: +49 7931 597-119
We cannot guarantee the processing within the contractually agreed period for any returns
received by us without RMA number.
The handling guidelines and the RMA form are available for download from our website:
http://www.bartec.de
> Service
> Automation & Enterprise Mobility
> RMA form
If you have any questions, please send us an e-mail or give us a call.
E-Mail: services@bartec.de
Telephone: +49 7931 597-444
Disposal, Dispatch and
Packaging
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
76/78
Technical data subject to change without notice..
Revision B / 03/2019
9. Disposal
The Mobile Computers contain metallic and plastic parts and electronic components.
Our devices are intended as professional electric devices for business use only, referred
to as B2B devices under the WEEE-Directive. The WEEE directive sets the framework
for waste electric and electronic equipment handling procedures which are to apply
throughout the EU. This means that you are not permitted to dispose of this equipment
in normal household refuse. It should not be given to the collection sites set up by the
public waste management authorities either but instead it should be disposed of in a
separate collection in an environmentally sound manner.
Any product we supply can be returned by our customers to us when the time has come
to dispose of it. We will ensure that it is disposed of in accordance with the respective
applicable statutory regulations.
The sender pays the costs of the dispatch/packaging.
10. Dispatch and Packaging Information
ATTENTION
Sensitive devices! Damage may be caused by incorrect packaging!
Use original packaging for transport.
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Accessories, Spare Parts
Technical data subject to change without notice.
Revision B / 03/2019
77/79
11. Accessories, Spare Parts
Mobile Computer MC 92N0ex-IS
Description Order number
Spare battery
7.2 V/2800 mAh, Li-Ion Battery ATEX/IECEx 17-A1Z0-0001
7.4 V/2600 mAh, Li-Ion Battery UL 17-A1Z0-0023
Spare keypad with blue overlay for ATEX / IECEx / UL - ATEX and Division 1
with 28 keys 05-0080-0438
with 43 keys 05-0080-0440
with 53 keys 05-0080-0441
with 53 keys for VT Emulation 05-0080-0442
Mobile Computer MC 92N0ex-NI
Description Order number
Spare battery
7.4 V/2600 mAh, Li-Ion Battery ATEX/IECEx/UL B7-A2Z0-0044
Spare keypad with green overlay for ATEX Zone 2 and Zone 22 / UL Division 2
with 28 keys 05-0080-0577
with 43 keys 05-0080-0578
with 53 keys 05-0080-0579
with 53 keys for VT Emulation 05-0080-0580
Accessories, Spare Parts
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
78/78
Technical data subject to change without notice..
Revision B / 03/2019
General
Description
Order number
SD cards
with 2 GB
17-28BE-F006/0003
with 4 GB
17-28BE-F006/0004
with 8 GB
17-28BE-F006/0005
with 16 GB
17-28BE-F006/0006
with 32 GB
17-28BE-F006/0007
Screen protector
5 pieces per package
17-A1Z0-0004
Leather Holster
for MC 92N0ex-G und MC 92N0ex-K with belt clip and
turned part
03-9809-0026
turned part for holster
03-9809-0027
Shoulder strap
03-9829-0091
Docking Station and accessories
Docking-Station
03-9915-0003
RS232 Connecting cable (Docking station <-> PC)
03-9919-0004
USB- Connecting cable (Docking station <-> PC)
03-9919-0008
Power supply
03-9911-0042
DC-power cable (Power supply <-> Docking station)
03-9919-0028
AC Line cord - 3 wired - EU
03-9609-0011
AC Line cord - 3 wired - US
03-9609-0021
4 slot Ethernet docking station and accessories
4-fach Ethernet docking station
03-9911-0026
Power supply
03-9911-0043
DC-power cable (Power supply <-> Docking station)
03-9919-0029
AC Line cord - 3 wired - EU
03-9609-0011
AC Line cord - 3 wired - US
03-9609-0021
4 slot Docking-Station and accessories
4-fach Docking-Station
03-9849-0052
Power supply
03-9911-0043
DC-power cable (Power supply <-> Docking station)
03-9919-0029
AC Line cord - 3 wired - EU
03-9609-0011
AC Line cord - 3 wired - US
03-9609-0021
4 slot Battery charger and accessories
4 slot Battery charger
03-9849-0062
Power supply
03-9911-0043
DC-power cable (Power supply <-> battery charger)
03-9919-0030
AC Line cord - 3 wired - EU
03-9609-0011
AC Line cord - 3 wired - US
03-9609-0021
Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Additional Information
Technical data subject to change without notice.
Revision B / 03/2019
79/79
12. Additional Information
12.1 Links
https://www.bartec.de/en/
BARTEC website
http://www.bartec.de/automation-download/
BARTEC Downoad website
https://www.zebra.com/de/de.htmlS
ZEBRA website
The ZEBRA page for the MC9200 User Manuals and software of the non-explosion
protected version
− Support and Downloads
− Mobile Computers
− Handheld Computer > MC9200
The ZEBRA product information page for the MC9200 of the non-explosion protected
version
− Products
− Mobile Computers
− Handheld Computers
− MC9200
http://www.Microsoft.com
Microsoft page for Active Sync or Windows Mobile Device Center
