Battery Removal
Stylus Removal
Charging Instructions
Slow Flash = Normal Charge
= LED Indicator Location
Solid Amber = Full Charge
Fast Flash = Charging Error
Four Slot Spare Battery Charger
Single Slot Serial Cradle
Four Slot Cradles
Charge-Only Cradle and Ethernet Cradle
1
2
3
1
You are allowed to replace the battery
in hazardous areas.
To charge the battery in hazardous
areas is strictly prohibited.
safe area
safe area
safe area
MC 9060ex-G
Quick Start Guide
See Product Reference Guide for more information
POST IN WORK AREAPOST IN WORK AREA
CLASS I DIV 1 - UL version
Accessories for safe area
Microphone
optional
Battery Insertion
Page 2
Optimum Body Posture
for Low Scanning
ALTERNATE LEFT
AND RIGHT KNEES
AVOID REACHING
AVOID EXTREME
WRIST ANGLES
MC 9060ex-G
Recommended Usage Guide
03-0300-0070 / 241291 / REV 1 / November 2005
Optimum Scanning Positions
Avoid Extreme Wrist Angles
WRONG
012345
012345
BARTEC GmbH, Max-Eyth-Strasse 16, 97980 Bad Mergentheim Deutschland/Germany
Local Contact:
POST IN WORK AREAPOST IN WORK AREA
TAKING BREAKS AND TASK ROTATION RECOMMENDEDTAKING BREAKS AND TASK ROTATION RECOMMENDED
ALTERNATE LEFT AND RIGHT HANDSALTERNATE LEFT AND RIGHT HANDS
CORRECT
012345
http://www.bartec.de/MC 9060ex
Optimum Upright Body Posture
CLASS I DIV 1 - UL version
AVOID REACHING
Trigger
Battery
Strap Lanyard
Stylus
Power
Scan Button
Indicator LED Bar
