BARSKA AA10614 User Manual
ANCHOR MASTER
**IMPORTANT**
TRY TO TAKE IT APART. DO NOT LOOK DIRECTLY AT THE
SUN WITH THE SCOPE AS IT WILL CAUSE DAMAGE TO
YOUR EYE.
2= Mahogany wood tripod
3= Support tray
4= Lock and levers
5 = Objective Lens
6 = Eyepiece
7 = Focus Knob
to have a Phillips-head screwdriver and a Crescent wrench.
*NOTE* Please be careful not to scratch your scope.
2. Attach the legs of the tripod at the base of the mount.
3. Carefully slide one of the leg attachments shaft through
the top of the attached leg through the holes of the
mount. Make sure that the support tray brackets
are facing up.
5
3
2
6
4. Gently stand the scope and tripod, slowly spread the
legs of the tripod.
5. With the shining side of the support tray facing up,
screw in its brackets.
Start by loosening the lock and levers and gently guide the
scope to your desired position.
and levers.
2. Point the objective lens to an object and look through
the eyepiece.
3. With slow and tiny motions, rotate the focus knob
slowly, until your view of the object is sharp and
in focus.
2. To remove any remaining dirt or smudges, add
one or two drops of isopropyl alcohol to the cloth,
then wipe gently.
3. Store your scope in a moisture-free area.
Optical tube with mount attached 1 unit
Acorn nuts 3 pcs
Support tray 1 unit
Washers and bolts 3 sets
