Barranca Diamond BD-125WP User Manual

BD-125WP

Owner’s Manual and Operating Instructions

Revision 102

04.2013

Manual Part # 169935

Caution: Read all safety and operating
instructions before using this equipment.
This manual MUST accompany the
equipment at all times.

Barranca Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
Toll-Free: [phone]
Phone: [phone]
Fax: [phone]
www.barrancadiamond.com

INTRODUCTION

Congratulations on your purchase of a BD-125WP Wet Stone Polisher. We are certain that you will
be pleased with your purchase. Barranca Diamond takes pride in producing the nest construction
power tools and diamond blades in the industry.

In order to help you, we have included this manual. This owners manual contains information neces­sary to operate and maintain your BD-125WP safely and correctly. Please take the time to familiarize
yourself with the BD-125WP by reading and reviewing this manual.

Read and follow all safety, operating and maintenance instructions. If you should have questions,
please feel free to call our friendly customer service department at [phone].

Regards,

Barranca Diamond

TABLE OF CONTENTS

SAFETY

Safety Precautions 3-6

California Proposition 65 Warning 6

Electrical Requirements & Grounding Instructions 7-9

Product Specications 10

ASSEMBLY

Unpacking 11

Contents 11

Assembly 12

SETUP, OPERATION, and CLEANUP

Setup 13-14

Operation 15

Cleanup 16

MAINTENANCE and TROUBLESHOOTING

Maintenance 16-18

THEORY

Theory of Polishing Pads 19

ACCESSORIES

Accessories 20

WARRANTY, RETURN, & CUSTOMER SERVICE

Warranty & Return & Customer Service 21-23

2

BD-125WP SAFETY

Read and follow all safety, operating and maintenance instructions. Failure to read and follow
these instructions could result in injury or death to you or others. Failure to read and follow these
instructions could also result in damage and/or reduced equipment life.

SAFETY MESSAGES

A safety message alerts you to potential hazards that could hurt you or others. Each safety message is preced­ed by a safety alert symbol ( ) and one of three words: DANGER, WARNING, or CAUTION.

DANGER

WARNING

CAUTION

You WILL be KILLED or SERIOUSLY INJURED if you do not follow directions.

You CAN be KILLED or SERIOUSLY INJURED if you do not follow directions.

You CAN be INJURED if you do not follow directions. It may also be used to alert
against unsafe practices.

DAMAGE PREVENTION AND INFORMATION MESSAGES:

A Damage Prevention Message is to inform the user of important information and/or instructions that
could lead to equipment or other property damage if not followed. Information Messages convey
information that pertains to the equipment being used. Each message will be preceded by the word
NOTE, as in the example below.

NOTE:

Equipment and/or property damage may result if these instructions are not followed.

GENERAL SAFETY PRECAUTIONS AND HAZARD SYMBOLS

In order to prevent injury, the following safety precautions and symbols should be followed at all times!

SAFETY PRECAUTIONS

ALWAYS read this Owner’s Manual before operating the machine.

ALWAYS keep the Guards in place.

REMOVE ADJUSTING KEYS AND WRENCHES

Form a habit of checking to see that keys and adjusting wrenches are removed from
the power tool before it is turned on.

KEEP WORK AREA CLEAN

Cluttered work areas and benches invite accidents.

DO NOT USE IN DANGEROUS PLACES

DO NOT use power tools in damp or wet locations nor expose them to rain. Always

keep the work area well lighted.

KEEP CHILDREN AWAY

All visitors and children should be kept a safe distance from work area.

3

BD-125WP SAFETY

MAKE THE WORKSHOP KID PROOF

Make the workshops kid proof by using padlocks, master switches or by removing starter
keys.

DO NOT FORCE THE TOOL

A power tool will do a job better and safer operating at the rate for which it was designed.

USE THE RIGHT TOOL

DO NOT force a tool or an attachment, to do a job that it was not designed to do.

USE THE PROPER EXTENSION CORD

If using an extension cord make sure it is in good condition first. When using an extension
cord, be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage that will result in a loss of power and
overheating. Table 1, Page 10 shows the correct AWG size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier gauge. The smaller
the gauge number, the heavier the cord.

USE PROPER APPAREL

DO NOT wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry that may

be caught in moving parts. Non-slip footwear is recommended. Wear protective hair
covering to contain long hair.

ALWAYS wear approved eye protection.

ALWAYS wear approved respiratory protection.

SECURE WORK

Clamps or a vise should be used to hold work whenever practical. Keeping your
hands free to operate a power tool is safer.

DO NOT OVERREACH

Keep proper footing and balance at all times by not overreaching.

MAINTAIN TOOLS WITH CARE

Keep tools clean for the best and safest performance. Always follow maintenance
instructions for lubricating, and when changing accessories.

ON / OFF

DISCONNECT TOOLS

Power tools should always be disconnected before servicing or when changing
accessories, such as blades, bits, cutters, and the like.

ALWAYS place the power ON/OFF switch in the OFF position when the tool is not in use.

4

(

(

)

)

BD-125WP SAFETY

USE RECOMMENDED ACCESSORIES

Consult the owner’s manual for recommended accessories. Using improper accessories
may increase the risk of personal or by-stander injury.

NEVER STAND ON THE TOOL

Serious injury could occur if a power tool is tipped, or if a cutting tool is unintentionally
contacted.

CHECK FOR DAMAGED PARTS

Before using a power tool, check for damaged part. A guard or any other part that is
damaged should be carefully checked to determine if would operate properly and perform
its intended function. Always check moving parts for proper alignment or binding. Check
for broken parts and mountings and all other conditions that may affect the operation of
the power tool. A guard, or any damaged part, should be properly repaired or replaced.

DIRECTION OF FEED

ALWAYS feed work into a blade or cutter against the direction of rotation. A blade

or cutter should always be installed such that rotation is in the direction of the arrow
imprinted on the side of the blade or cutter.

NEVER LEAVE A TOOL UNATTENDED

TURN POWER OFF - Do not leave a tool until it comes to a complete stop. Always
turn a power tool OFF when leaving the work area, or, when a cut is finished.

ELECTRICAL SHOCK

NEVER touch electrical wires or components while the engine is running. They can be

sources of electrical shock which could cause severe injury or burns.

ROTATING PARTS

Keep hands, feet, hair, and clothing away from all moving parts to prevent injury.
Never operate the motor with covers, shrouds, or guards removed.

OVER SPEED

NEVER tamper with the governor components or settings to increase the maximum

speed. Severe personal injury and damage to the engine or equipment can result if
operated at speeds above maximum.

DO NOT EXPOSE TO RAIN

DO NOT expose to rain or use in damp locations.

5

BD-125WP SAFETY

WARNING

Polishing and drilling generates dust. Excessive airborne particles may cause irritation to eyes, skin
and respiratory tract. To avoid breathing impairment, always employ dust controls and protection
suitable to the material being polished or drilled; see OSHA (29 CFR Part 1910.1200). Diamond
Blades improperly used are dangerous. Comply with American National Standards Institute Safety
Code, B7.1 and, Occupational Safety and Health Act covering Speed, Safety Guards, Flanges,
Mounting Procedures, General Operating Rules, Handling, Storage and General Machine Conditions

CALIFORNIA PROPOSITION 65 MESSAGE

WARNING

Some dust created by power sanding, sawing, grinding, drilling, and other construction activities con­tain chemicals known (to the State of California) to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:

• Lead, from lead-based paints

• Crystalline silica from bricks, cement and other masonry products

• Arsenic and chromium, from chemically treated lumber

For further information, consult the following sources:

http://www.osha.gov/dsg/topics/silicacrystalline/index.html
http://www.cdc.gov/niosh/docs/96-112/
http://oehha.ca.gov/prop65/law/P65law72003.html
http://www.dir.ca.gov/Title8/sub4.html

Your risk from these exposures varies depending on how often you do this type of work. To reduce
your exposure to these chemicals, work in a well-ventilated area, and work with approved safety
equipment, such as dust masks that are specially designed to lter out microscopic particles. Where
use of a dust extraction device is possible, it should be used. To achieve a high level of dust collec­tion, use an industrial vacuum cleaner.

6

BD-125WP SAFETY

ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS

In order to prevent potential electrical shock and injury, the following electrical safety precautions and
symbols should be followed at all times!

WARNING

In case of a malfunction or breakdown, grounding provides a path of least resistance for electric cur­rent to reduce the risk of electric shock. This tool is equipped with an electric cord having an equip­ment-grounding conductor and a grounding plug. The plug must be plugged into a matching outlet
that is properly installed and grounded in accordance with all local codes and ordinances.

• Do not modify the plug provided – if it will not t the outlet; have the proper outlet installed by a

qualied electrician

• Improper connections of the equipment-grounding conductor can result in a risk of electric
shock. The equipment-grounding conductor is the insulated conductor that has an outer surface
that is green, with or without yellow stripes. If repair or replacement of the electric cord or plug is
necessary, do not connect the equipment-grounding conductor to a live terminal

• Check with a qualied electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded

• Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that
accept the tool’s plug

• Repair or replace a damaged or worn cord immediately

WARNING

This tool is intended for use on a circuit that has an outlet that looks like the one shown in Sketch A.
The tool has a grounding plug that looks like the plug illustrated in Sketch A. A temporary adapter,
which looks like the adapter illustrated in sketches B and C, may be used to connect this plug to a
2-pole receptacle as shown in Sketch B, if a properly grounded outlet is not available. The temporary
adapter should be used only until a properly grounded outlet can be installed by a qualied electri­cian. The green-colored rigid ear, plug, and the like, extending from the adapter, must be connected
to a permanent ground such as a properly grounded outlet box.

NOTE: Use of a temporary adapter is not permitted in Canada.

Metal Screw

Grounding

Pin

(A)

ADAPTER

Grounding

Means

(C)

Cover of

Grounded

Outlet Box

Grounding

Pin

(B)

(D)

Circuit and Adapter Information

7

BD-125WP SAFETY

WARNING

The polisher requires a Ground Fault Circuit Interrupter (GFCI). To reduce the risk of electrocution,
keep all connections dry and off the ground. A GFCI is provided as an integral part of the power cord
for the tool. Receptacles are available having built-in GFCI protectors and may be used with this
equipment. When using an extension cord, the GFCI in the power cord and extension cord connec­tions need to be kept dry and off the ground.

WARNING

To avoid the possibility of the in-line GFCI getting wet, position it to the side of the work area. A “drip
loop” shown in the picture below, should be arranged by the user to properly protect the GFCI.

The “drip loop” is that part of the cord below the level of the GFCI or the connector, if an extension
cord is used. This method of positioning the cord prevents water traveling along the power cord, com­ing in contact with the GFCI, extension cord connections or receptacle.

If the GFCI, plug or receptacle get wet, DO NOT unplug the cord. Disconnect the fuse or circuit
breaker that supplies power to the tool. Then unplug and examine all components for presence of
water.

NOTE:

Drip Loop Information - Raise GFCI and plug off the oor with a cardboard carton
or brick or other non-conductive support to prevent water from traveling along the
power cord.

Extension Cord

Drip Loops

Drip Loop Information

GFCI Tool

8

BD-125WP SAFETY

WARNING

Use only extensions cords that are intended for outdoor use. These extension cords are identied
by a marking “Acceptable for use with outdoor appliances; store indoors while not in use.” Use only
extension cords having an electrical rating not less than the rating of the product. Do not use dam­aged extension cords. Examine extension cords before using and replace if damaged. Do not abuse
extension cords and do not yank on any cord to disconnect. Keep cords away from heat and sharp
edges. Always disconnect the extension cord from the receptacle before disconnecting the product
from the extension cord.

WARNING

To reduce the risk of electrocution, keep all connections dry and off the ground. Do not touch the
plug with wet hands.

WARNING

Use of undersized extension cords result in low voltage to the motor that can result in motor burnout
and premature failure. Barranca Diamond warns that equipment returned to us showing signs of be­ing run in a low voltage condition, through the use of undersized extension cords, will be repaired or
replaced totally at the customers expense. There will be no warranty claim.
To choose the proper extension cord,

• Locate the length of extension cord needed in table provided.

• Once the proper length is found, move down the column to obtain the correct AWG size

required for that length of extension cord. For example, a fty foot extension cord would require

an AWG size of 14 for a 230V volt circuit.

EXTENSION CORD MINIMUM GAUGE FOR LENGTH

VOLTS TOTAL LENGTH OF CORD IN FEET

25 ft.
AWG

115V 14 12 Not Recommended Not Recommended

230V 14 14 12 N/A

50 ft.
AWG

Table 1

100 ft.

AWG

150 ft.

AWG

9

BD-125WP SAFETY

PRODUCT SPECIFICATIONS

The BD-125WP Wet Stone Polisher is engineered as a handheld Wet Stone Polisher. The polisher
is designed with a 120V motor in a rugged plastic housing. BD-125WP Part# 167556, BD-125WP Kit
Part # 381504

MotorSpecications

Motor specications for the BD-125WP are listed in the table below.

Voltage 120V
Amperage 7.9
Frequency 50/60 Hz
RPM 3200 rpm
Weight 6 lbs.

Polishing Pad Capacity

The BD-125WP uses a three (3), four (4), or ve (5) inch (76, 102, or 127 mm) diameter, wet polishing
pad.

Tile Types

The BD-125WP can polish all variety of tile types including porcelain, terracotta, marble, quarry and
slate, or almost any other non-ferrous material.

Replaceable Motor Brushes

The BD-125WP is equipped with replaceable motor brushes to extend operating life.

SerialNumberandProductSpecicationLabelLocation

The Serial Number and Product Specication Label is located on the right side of the BD-125WP as
shown.

10

BD-125WP UNPACKING

dealer where it was purchased. This warranty DOES NOT cover normal wear or damage resulting from operator abuse. In no event shall Barranca Diamond be liable for consequential damages arising out

-

UNPACKING

Your BD-125WP Wet Stone Polisher has been shipped from the factory thoroughly inspected. Only
minimal assembly is required.

CONTENTS

NOTE:

The contents of your container will vary depending on if you purchased the standard
unit or the Kit.

In your container, you will nd one (1) BD-125WP, one (1) Handle, one (1) D-Handle, one (1) Motor
Cover, two (2) Motor Cover Bolts, one (1) Shroud, two (2) Shaft Wrenches, one (1) Plastic Carrying
Case, one (1) Owner's Manual and one (1) Warranty Card. Kit Only: One (1) set of Polishing Pads,
and One (1) Rubber Backer Pad.

BD-125WP D-Handle

Motor Cover BoltsMotor CoverHandle

BD-125WP

Owner’s Manual and Operating Instructions

Shroud

BARRANCA DIAMOND WARRANty CARD

Name

address

City

state

Zip COde

phONe

Fax

e-mail

prOduCt mOdel

part NumBer

maChiNe serial#

where did yOu purChase this saw FrOm? date purChased

q tile distriButOr q equipmeNt supply hOuse q lapidary distriButOr

q tOOl supply q Bldg material supply q reNtal equipmeNt hOuse

q IF sO, what type? tile q masONry q Other

Or CONtraCtOr

what Criteria was impOrtaNt iN ChOOsiNg this saw? (rate FrOm 1 tO 5, 5 BeiNg the mOst impOrtaNt)

pOwer preCisiON pOrtaBility availaBlity Other

priCe

COmmeNts Or suggestiONs:

BarraNCa diamONd warraNty

22815 Frampton Ave.,Torrance, CA 90501 USA 1.800.630.7682 www.barrancadiamond.com 1.310.257.3063

If within one (1) Year from the date of purchase, this Barranca Diamond saw fails due to defect in material or workmanship, Barranca will repair it, free of charge when the unit is returned to the

of the failure of any product if operated improperly. Barranca Diamond Products may act as a warranty station for motor/engine repairs based on an individual agreement with the manufacturer. This war

© 2008 All Rights reserved. Barranca Diamond • P/N 166528 BD Warranty Card (03/08)

ranty is in lieu of all other warranties express or implied.

Warranty

Card

Backer Pad

Wrench

Polishing Pad Set

(Kit Only)

Shaft

Wrenches

Rubber Backer

Pad (Kit Only)

Plastic Carrying

Case

Revision 100

12.2011

Manual Part # 169351

Caution: Read all safety and operating
instructions before using this equipment.
This manual MUST accompany the
equipment at all times.

Owner's

Manual

Barranca Diamond
22815 Frampton Avenue
Torrance, CA 90501
Phone: [phone]
Toll Free: [phone]
Fax: [phone]
www.barrancadiamond.com

11

BD-125WP ASSEMBLY

Handle

You have a choice of using a straight Handle or D-Handle.

(A)

Place D-Handle on polisher

and insert bolt.

NOTE:

The D-Handle and the motor cover cannot be used at the same time.

Shroud

(A)

Place Shroud on polisher

with the lever clamp open.

(B)

Tighten bolts on both sides.

(B)

Use the adjusting screw

to open the collar to the

correct size.

(C)

Or install the straight handle by

rotating clockwise to tighten.

It may be installed on left or

right side.

(C)

Secure Shroud by closing

lever clamp.

Motor Cover

Slide on Motor Cover and

secure with bolts.

(A)

NOTE:

The Motor Cover is designed to allow the user to
apply pressure directly to the polisher's gear box
without feeling the heat created by the tool.

12

BD-125WP SETUP

Pre-start Inspection

Prior to beginning work, a pre-start inspection of the polisher should be performed.

(A)

Verify the ON/OFF Switch is in

the OFF position.

NOTE:

The indicator light on the GFCI should glow red. The red light should go out when
the TEST button is pressed. This indicates that the GFCI is functioning properly.
Press the RESET button to reactivate the GFCI.

Setup for Operation

NOTE:

1. Velcro Backer Pads may be used for Barranca Diamond products such
as diamond polishing discs, sandpaper discs, and felt bufng discs. Choose
the correct Backer Pad for the job being performed; rubber Backer Pads for
contours edges, and bullnose surfaces. Rigid Backer Pads for straight edges
and at surfaces.

2. Located on the top of the gear box is a shaft lock button. Press it to stop shaft
from spinning when installing backer plate. Do not press shaft lock button when
polisher is running.

(B)

Inspect for missing or dam-

aged components.

(C)

Test and reset the GFCI. If it

does not test and reset properly,

replace immediately.

(A)
Install the Backer Pad onto the
Spindle (Do Not cross-thread).

(B)

Tighten the Backer Pad while

pressing shaft lock bottom.

13

(C)
Plug the GFCI into a power
outlet and test the GFCI for

proper operation.

BD-125WP SETUP

(D)

Verify the Cooling Flow Control

Valve is closed.

Pad Installation for Polishing

NOTE:

1. Choose the correct Polishing Disc for the material to be polished (start with a
50, 120 or 220 coarse grit Pad).

(A)

Align the Velcro Polish-

ing Disc to the Backer Pad.

Press disc evenly and rmly

onto the Backer Pad.

(E)

Connect Cooling Supply Line to

a water supply.

(B)

Verify the Polishing Disc is

centered on the Backer Pad

and the Cooling Ports are

not covered.

Material Setup

(A)

If necessary, clamp the material

to be polished to a work surface.

14

BD-125WP OPERATION

Polishing Operation

NOTE:

Smoothing of the surface during the use of the coarse polishing discs will deter­mine the quality of the nish that is achieved.

(A)

Place the ON/OFF Switch

in the ON position.

(D)

After working the area, shut

the water supply off.

NOTE:

Once all of the large scratches and marks have been removed, use the ner grit
polishing discs (400, 800, 1800 and 3500) for a quality nish. For a higher luster/
color, nished surface, use the extremely ne 8500 grit polishing disc.

(B)

Adjust water ow

(excessive water ow can result

in internal electrical problems).

(E)

Place the ON/OFF Switch

in the OFF position.

(C)

Using the coarse grit disc, re-

move all rough scratches

and cut marks.

(F)

Dry surface then rub the surface

with a lumber crayon to deter-

mine the depth of the remaining

scratches.

(G)

Repeat Steps A through F

until all large scratches have

been removed.

(H)

Change to ne grit discs for

a quality nish.

15

(I)

Repeat Steps A through F using

ne grit discs to complete polish-

ing of the surface.

BD-125WP MAINTENANCE

NOTE:

Cleaning

Clean using a damp cloth.

Dry when nished cleaning.

For a mirror nish, make a paste of cerium oxide and water (or tin oxide and
water) apply the paste to a felt wheel and run the wheel against the surface using
only slight pressure. Once the paste dries, wash the surface with water and dry.

(A)

Motor Brush Change-Out

(A)

Using a at blade screwdriver

remove the Motor Brush

Housing cover.

(B)

Remove the Motor Brush

Assembly.

(C)

Ensure the Motor Brush Housing

is free of all carbon pieces.

16

BD-125WP MAINTENANCE

NOTE:

When performing Steps E and F, ensure the Motor Brush Assembly remains
correctly seated at all times.

(D)

Insert the new Motor Brush

Assembly.

Loss of Cooling Flow

(E)

Using a at blade screw-

driver install the Motor Brush

Housing cover.

(F)

Repeat Steps A through

E for second Motor Brush

Assembly.

(A)

Verify the Water Flow Control

Valve is open.

Electrical Problems

(A)

Verify the ON/OFF Switch is in

the ON position.

(B)

Ensure the Water Supply

Line is connected properly.

(B)

Verify all electrical connections

and ensure the GFCI is

not tripped.

(C)

Verify circuit breaker is not

tripped, if it is tripped – reset

the circuit breaker once.

17

BD-125WP MAINTENANCE

(D)

Check power source voltage

is 120V, if it is not 120v –

move to another circuit.

(E)

Inspect the Motor Brushes.

18

BD-125WP THEORY

Polishing pads are designed to achieve a monument quality nish on all straight or shaped surfaces.
The unique design of the polishing pads allows for rapid and even surface removal rates of the mate­rial being polished with minimal effort. When used correctly, these pads provide a clear advantage
over all other polishing methods.

Important Points in the Polishing Process

Polishing pads are designed for use with water only, to minimize the wear on the pads and prevent
hazardous dust. Water acts to cool the polishing pad material, ush away grindings, and eliminate
hazardous dust.

Never skip grit sizes during the polishing process. Skipping polishing pads of different grit sizes will
result in an unsatisfactory nish to the polished surface.

Diamond polishing pads wear out prematurely due to the overworking of the material or by not us­ing a sufcient amount of water. Failure to spend adequate time polishing with each grit size pad will
result in an unsatisfactory nish.

Selection of the exible Velcro™ (rubber) backer pads for shaping and curved work is highly recom­mended. Use the rigid backer pad for the straight edge and at face material.

19

BD-125WP ACCESSORIES

ACCESSORIES

ITEM NUMBER DESCRIPTION PRODUCT

Various, see Catalog or visit

1

2

3

our web site at:

www.barrancadiamond.com

or call 800.421.5830

Various, see Catalog or visit

our web site at:

www.barrancadiamond.com

or call 800.421.5830

Various, see Catalog or visit

our web site at:

www.barrancadiamond.com

or call 800.421.5830

Polishing Discs

PVA Dry Grinding Discs

Grinding Wheels

Various, see Catalog or visit

4

5

6

our web site at:

www.barrancadiamond.com

or call 800.421.5830

Various, see Catalog or visit

our web site at:

www.barrancadiamond.com

or call 800.421.5830

370040

Diamond Cup Wheels

BD-PVQ Quick-Change
Dry Polishing Sponge
Wheels

BD-370BP
4" Rubber Backer Plate

20

BD-125WP LIMITED WARRANTY

Barranca DiamonD LimiteD Warranty

Please complete the warranty registration card and return. Any problems encountered should be directed to
Barranca Diamond Customer Service department at [phone] M-F 8am - 5pm PST.

NOTE THIS INFORMATION FOR FUTURE USE:

MODEL NUMBER:

SERIAL NUMBER:

PURCHASE PLACE:

PURCHASE DATE:

Barranca Diamond warrants to the original retail purchaser for a period of 90 days except as noted, from the
date of purchase all products covered by this Warranty to be free of defects in materials and workmanship.

This Warranty shall not apply to any parts that have been subjected to misuse or improper service, that had
been damaged in transit or handling, or that have been altered or repaired by unauthorized representatives.
This Warranty does not cover defects caused by or resulting from misuse, abuse, neglect or damage caused
by accident or the failure to provide reasonable maintenance. This Warranty is void if the product or any of its

individual components is altered or modied by the purchaser or if the product is used in a manner or with a

blade not recommended by the manufacturer.

Any claim arising under this Warranty must be submitted by the original purchaser within the warranty period

specied above, and shall include proof of purchase. During said warranty period Barranca Diamond shall,

at its option, either replace or repair, at no charge to the original purchaser, any parts or components that are
found to be defective by Barranca Diamond. Barranca Diamond shall not be responsible for or obligated to
pay for freight or other transportation related costs or expenses in connection with any defective products or
components that are either returned to Barranca Diamond’s facility or any authorized repair station and/or any
replacement products or components that are shipped from Barranca Diamond pursuant to this Warranty.

Parts and labor needed to maintain products and the replacement of components due to normal wear and tear
are the purchaser’s responsibility and are not covered by this Warranty. All products or components replaced
under warranty become the property of the manufacturer. All replacement parts will be considered to be part of
the original product and any warranty on such parts will expire coincidentally with the original Warranty. Barran­ca Diamond will pay for parts and labor in connection with warranty repairs conducted by Barranca Diamond
or its authorized repair centers. Replacement part(s) installed by anyone else will be provided without a charge
for such replacement part(s), but this Warranty will not apply to labor charges in connection therewith.

IN NO EVENT SHALL ANY LIABILITY UNDER THIS WARRANTY EXCEED THE REPLACEMENT COST OF
ANY DEFECTIVE PRODUCT OR COMPONENT THEREOF, AND BARRANCA DIAMOND SHALL NOT BE LI­ABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR ANY OTHER DAMAGE OR LOSS
NOT EXPRESSLY ASSUMED AS SET FORTH HEREIN.
The foregoing constitutes an expressed warranty on the terms set forth above and is the only warranty or
warranties applicable to the products it covers. All other warranties, including, without limitation, the implied

warranty of merchantability and/or tness for a particular purpose or use being denied. This limited warranty is

expressly in lieu of all other warranties, whether expressed or implied.

21

BD-125WP LIMITED WARRANTY

SpecicsApplicabletoLimitedWarrantyofDiamondBladesandCoreBits:

Laser Welded Blade and Bit Warranty:

If the laser weld between the segment and the steel core or barrel fails during normal use, the blade
or bit will be replaced free of charge. Blades and bits damaged due to careless or improper use are
not covered under this warranty.

Brazed Blade, Bit, and Cup Wheel Warranty:

If the brazed bond between the segment and the core, barrel, or cup fails within the rst .050 of seg­ment wear, the blade, bit, or cup will be replaced free of charge. Blades, bits, and cup wheels dam­aged due to careless or improper use are not covered under this warranty.

Continuous Rim Blade Warranty:

If the bond between the rim and the core fails during normal use, the blade will be replaced free of
charge. Blades and bits damaged due to careless or improper use are not covered under this war­ranty.

Exclusions:

Barranca Diamond does not warrant the following components, which carry their own manufacturer’s
warranty for the indicated periods:

Electric Motors Manufacturer’s Warranty

Baldor: 1 year
Ryobi: 1 Year
Soga: 1 Year

Gas Engines Manufacturer’s Warranty

Honda: 2 years

Engine Power Information

Engine power ratings are calculated by the individual engine manufacturer and the rating method
may vary among engine manufacturers. Barranca Diamond Products makes no claim, representation
or Warranty as to the power rating of the engine on this equipment and disclaims any responsibility
or liability of any kind whatsoever with respect to the accuracy or the engine power rating. Users are
advised to consult the engine manufacturer’s owners manual and website for specic information
regarding the engine power rating.

22

BD-125WP ORDERING & RETURN

rePLacement PartS

Replacement parts for this tool may be ordered from your Barranca Diamond distributor or directly from Bar­ranca Diamond. Please have the following information ready before calling:

• Model and serial number of the machine

• Date of purchase

• Description of parts being ordered (see parts list)

retUrn materiaLS ProceDUre

To expedite the service relative to the return of a product purchased through Barranca Diamond, please have
the following information available:

• Model and serial number of the machine

• Date of purchase

• Distributor’s name

Then please call Barranca Diamond at [phone] or toll free at 800-630-7682 to obtain a Return Goods
Authorization number (RGA) authorizing the return.

Please Note:

• Ensure your item(s) are prepaid to the destination

• Return items must have been purchased within the previous twelve (12) months

• Follow the packaging instructions in the following section

• Be sure to include the RGA number, return address and your phone number on or within the

return shipping box.

PacKaGinG inStrUctionS

Ship the equipment using its original shipping crate if possible. Secure inside the shipping crate. Ensure all
parts are secured in the packaging to prevent movement. Do not ship the equipment partially exposed.

23

Barranca Diamond Products, Inc.

1315 Storm Parkway
Torrance, CA 90501

Toll-Free: [phone]

Phone: [phone]

Fax: [phone]

www.barrancadiamond.com
