Dear Barracuda Networks Customer,
Thank you for choosing the Barracuda Web Security Gateway
appliance. Barracuda Networks oers a complimentary telephone
installation appointment with this purchase to help you plan your
installation, congure your system, and verify the operation of your
Barracuda Web Security Gateway appliance following installation.
Please contact our Technical Support team to schedule your
complimentary telephone installation appointment.
Of course, this complimentary telephone installation appointment
is not designed to replace the local support you may receive
from your Barracuda Networks reseller. If you prefer, please do not
hesitate to contact your Barracuda Networks reseller, whom we
will be happy to coordinate with in order to provide additional
deployment support.
Thank you again for choosing the Barracuda Web Security Gateway
appliance. We encourage you to contact your reseller or our
Technical Support team that is available around the clock to assist
with technical questions or concerns. We look forward to helping
you with your current and future needs in the areas of security,
networking, and data protection.
Sincerely,
BJ Jenkins
CEO
Table of Contents
English
Setup
Support
Security
Warranty
Deutsch
Sicherheit
Garantie
Español
Seguridad
Garantía
Français
Sécurité
Garantie
Italiano
Sicurezza
Garanzia
Türk
Güvenlik
Garanti
Japanese
セキュリティ
保証
1-4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
To install the Barracuda Web Security Gateway:
1. Secure the appliance in your environment.
2. Connect an Ethernet cable from your network switch to the Ethernet port on
the front of the appliance (located on the back of model 210).
3. Connect your monitor and keyboard cable.
4. Connect your power source; the AC input voltage range is 100-240 volts at
50/60 Hz. Turn on the appliance.
With a monitor connected, after it is fully booted, the login prompt displays.
1. Log in using admin/admin.
2. Congure the IP Address, Subnet Mask, Default Gateway, Primary DNS
Server, and Secondary DNS Server as appropriate for your network.
3. Save your changes.
If you do not want to use the default IP address and do not have a monitor and
keyboard to access the console, you can change the IP address from the BASIC >
IP Conguration page in the web interface.
Setup
2
Install
Barracuda recommends reading these instructions fully before starting
to install. This guide is for conguring an inline deployment. For other
deployment options, refer to the Barracuda TechLibrary:
https://techlib.barracuda.com/BWF/DeploymentOptions
To install and congure, you need the following:
• Barracuda Web Security Gateway, AC Power Cord (included)
• Ethernet Cables
• VGA Monitor (recommended)
• PS2 Keyboard (recommended)
1
Getting Started
3
Congure IP Address and Network
2
In a browser, enter http:// followed by the Barracuda Web Security Gateway IP
address and the default HTTP port, for example, http://192.168.200.200:8000.
1. Log in to the web interface using admin/admin.
2. Go to BASIC > IP Conguration, and enter Default Hostname and Default
Domain. These names are associated with anti-spyware emails. For example,
barracuda.<yourdomainname>.com
3. Click Save.
1. Go to BASIC > Dashboard, and under Subscription Status, verify the
Energize Updates subscription status is Current.
2. If the status is Not Activated, click the activation link and complete your
subscription activation. If you are connected to the Internet, the activation
status automatically updates once you reload the BASIC > Dashboard page;
otherwise, you can manually enter the activation code on the
BASIC > Dashboard page.
If your Barracuda Web Security Gateway is located behind a corporate rewall,
open the following ports on your rewall to ensure proper operation:
5
Congure the Appliance
Setup
4
Open Firewall Ports
Port Direction TCP UDP Usage
22 Out Yes No Technical Support Services
25 In/Out Yes No Email and bounce messages
53 Out Yes Yes Domain Name Service (DNS)
80 Out Yes No Virus, Spyware, and Category Denition Updates
123 Out No Yes Network Time Protocol (NTP)
6
Activate Subscription
Note: The default Operating Mode is set to Audit which will be changed
to Active in a later step.
3
Go to BASIC > Administration and change the administrator password.
The Barracuda Web Security Gateway is now ready for testing:
1. Disconnect the Ethernet cable from your internal network switch (router, hub)
that goes to your rewall, and connect it to the WAN port of the Barracuda
Web Security Gateway.
2. Connect the cable from the LAN port of the Barracuda Web Security Gateway
to the internal switch where your rewall was connected.
After this is complete, return to the BASIC > IP Conguration page and set
the Operating Mode to Active.
Setup
8
Change the Administrator Password
Go to ADVANCED > Firmware Update. If there is a new Latest General
Release available:
1. Click Download Now; allow the download to complete. Do not power o
during update or download.
2. Click Apply Now; the appliance automatically reboots once the process
is complete.
7
Update the Firmware
9
Inline Ethernet Connection
Note: Use the steps in this section if you are not deploying the system as a forward proxy.
4
Verify network connectivity by using a machine in your existing network to
browse the web. After successful connectivity is veried, you can adjust the
settings of the Barracuda Web Security Gateway to better suit your needs. Your
Barracuda Web Security Gateway is now ready to use.
For best results, continue with Step 1: Network Considerations in the Barracuda
TechLibrary: https://techlib.barracuda.com/BWF/NetworkConsiderations
See the Barracuda Networks Support Forum for Frequently Asked Questions
(FAQs) and other helpful tips for using your Barracuda Web Security Gateway:
https://community.barracudanetworks.com
Online Support
• To open a Technical Support case online, please visit
https://www.barracuda.com/support_case
• For help from other Barracuda Networks customers, please visit the Barracuda
Networks Support Forum at https://forum.barracuda.com. Please register to
post questions and exchange information.
Telephone Support
• For urgent matters, please call Technical Support at +1 408.342.5300.
Phone lines are open 24 hours a day, 7 days a week.
Documentation
• Technical documentation is available online at https://techlib.barracuda.com
Setup / Support
10
Test Connectivity
5
Electrical Safety
Follow these basic electrical safety precautions to protect yourself from harm and to protect the appliance
from damage:
• Be aware of the power switch locations on the appliance chassis, the emergency power-o switch for the housing
room, the disconnection switch, and the electrical outlet. This awareness allows quick removal of electrical power
from the system should an electrical accident occur.
• Do not work alone when working with high voltage components.
• When working around exposed electrical circuits, another person familiar with the power-o controls should be
nearby to switch o the power if necessary.
• Use only one hand when working with powered-on electrical equipment. This prevents making a complete
circuit, which can cause electrical shock. Use extreme caution when using metal tools, which can easily damage
electrical components or circuit boards when they come into contact with them.
• Do not use mats designed to decrease electrostatic discharge to protect from electrical shock. Instead, use rubber
mats that have been specically designed as electrical insulators.
• The power supply power cord must include a grounding plug and must be plugged into grounded electrical outlets.
• To prevent re or shock hazard, do not expose the unit to rain or moisture, or install this product near water.
• Avoid installing this product during a lightning storm.
• Ensure that the air vents (openings along the sides and back) are never blocked and that there is sucient airow
through the vents to prevent over-heating.
General Safety
• Keep the area around the appliance clean and free of clutter.
• Locate a safe and dry location to set this product, keeping it away from wet surfaces/surroundings.
• While working on the system, do not wear loose clothing, such as neckties and unbuttoned shirt sleeves, which
can contact electrical circuits or be pulled into a cooling fan.
• Remove any jewelry or metal objects from your body, which can act as excellent metal conductors, creating short
circuits, and potentially harming you if they contact printed circuit boards or powered areas.
• For plugged in equipment, the socket-outlet must be installed near the equipment and be easily accessible.
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) is generated by two objects with dierent electrical charges coming into contact
with one another. An electrical discharge, which can damage electronic components and printed circuit boards,
neutralizes this dierence.
• Use a grounded wrist strap designed to prevent static discharge.
• Keep all components and printed circuit boards (PCBs) in their antistatic bags until ready for use.
• Touch a grounded metal object before removing the board from the antistatic bag.
• Do not let components or PCBs contact your clothing, which may result in a charge despite wearing a wrist strap.
• Handle a board by its edges only; do not touch its components, peripheral memory modules, or contacts.
• When handling chips or modules, avoid touching their pins.
• Put the server board and peripherals back into their antistatic bags when not in use.
• For grounding purposes, make sure your computer chassis provides excellent conductivity between the power
supply, the case, the mounting fasteners, and the server board.
• After accessing the inside of a system, close the system back up and secure it to the rack unit with the retention
screws after ensuring that all connections have been made.
