BARNSTEAD|THERMOLYNE F21100, F21120, F21130, F21120-33, F21130-33 Operation Manual And Parts List
...
Type F21100
Tube Furnace
OPERATION MANUAL
AND PARTS LIST
SERIES 1260
Model # Voltage Control
F21125 120 Manual
F21120 240 Manual
F21120-33 230 Manual
F21130 240 Single Set Point
F21130-33 230 Single Set Point
F21135 120 Single Set Point
LT1260X3 • 9/21/04
2
Safety Information..................................................................................................................................3
Alert Signals ..........................................................................................................................................3
Warnings ................................................................................................................................................3
Introduction ............................................................................................................................................5
Intended Use......................................................................................................................................5
General Usage ..................................................................................................................................5
Principles of Operation ......................................................................................................................5
General Specifications for Furnaces......................................................................................................6
Environmental Conditions..................................................................................................................6
Declaration of Conformity ......................................................................................................................7
Unpacking ..............................................................................................................................................8
Installation ..............................................................................................................................................9
Operation of Manual and Automatic Models ........................................................................................10
Manual Control Models (F21124, F21125, F21120, F21120-33)..........................................................10
Pyrometer ........................................................................................................................................10
Operation All Modes Single Set Point Termperature Control (F21130, F21130-33, F21135) ..............11
Single Set Point Controller ..................................................................................................................12
Single Ramp and Dwell ........................................................................................................................16
Furnace Loading ..................................................................................................................................19
Preventive Maintenance ......................................................................................................................20
General Cleaning Instructions..........................................................................................................20
Troubleshooting....................................................................................................................................21
Maintenance and Servicing..................................................................................................................24
To Replace Vestibule End Caps ......................................................................................................24
To Replace The Heating Element Tube (Without Case Assembly) ................................................24
To Replace Pyrometer (Manual Control Models) ............................................................................25
To Replace Manual Temperature Control Switch ............................................................................25
To Replace Furnace Chamber ........................................................................................................26
To Replace Type K (Chromel/Alumel) Thermocouple (Manual Control Models) ............................26
To Replace Type Platinel II Thermocouple (Single Set Point Control Models) ..............................27
Replacement Parts List........................................................................................................................29
Ordering Procedures............................................................................................................................29
Wiring Diagrams ..................................................................................................................................30
Warranty ..............................................................................................................................................32
Table of Contents
3
General Information
Alert Signals
Warnings alert you to a
possibility of personal injury.
Warning
Note
Notes alert you to pertinent facts and
conditions
Caution
Cautions alert you to a possibility of
damage to the equipment.
Hot Surface
Caution: Hot Surface. Avoid Contact.
To avoid burns do not touch this furnace
on the exterior or interior surfaces during use or for a period of time after use.
Safety Information
Your BarnsteadThermolyne Tube Furnace has been
designed with function, reliability, and safety in mind. It is
your responsibility to install it in conformance with local electrical codes. For safe operation, please pay attention to the
alert boxes throughout the manual.
Warnings
To avoid electrical shock, this furnace must:
1. Use a properly grounded electrical outlet of correct voltage and current handling capacity.
2. Disconnect from power supply before servicing.
3. Always use a properly sized combustion tube.
To avoid personal injury:
1. Do not use in the presence of flammable or combustible materials; fire or explosion may result.
This device contains components which may
ignite such materials.
2. Refer servicing to qualified personnel.
4
WARNING
This warning is presented for compliance with California Proposition 65 and other regulatory agencies and
only applies to the insulation in this product. This product contains refractory ceramic, refractory ceramic fiber
or fiberglass insulation, which can produce respirable dust or fibers during disassembly. Dust or fibers can
cause irritation and can aggravate pre-existing respiratory diseases. Refractory ceramic and refractory ceramic fibers (after reaching 1000°C) contain crystalline silica, which can cause lung damage (silicosis). The International Agency for Research on Cancer (IARC) has classified refractory ceramic fiber and fiberglass as possibly carcinogenic (Group 2B), and crystalline silica as carcinogenic to humans (Group 1).
The insulating materials can be located in the door, the hearth collar, in the chamber of the product or under
the hot plate top. Tests performed by the manufacturer indicate that there is no risk of exposure to dust or respirable fibers resulting from operation of this product under normal conditions. However, there may be a risk of
exposure to respirable dust or fibers when repairing or maintaining the insulating materials, or when otherwise
disturbing them in a manner which causes release of dust or fibers. By using proper handling procedures and
protective equipment you can work safely with these insulating materials and minimize any exposure. Refer to
the appropriate Material Safety Data Sheets (MSDS) for information regarding proper handling and recommended protective equipment. For additional MSDS copies, or additional information concerning the handling
of refractory ceramic products, please contact the Customer Service Department at Barnstead International at
1-800-553-0039.
Warning
Please note the following warnings.
Warning
5
Introduction
Intended Use
The type 21100 furnaces are small, inexpensive furnaces
ideally suited for school, chemical and industrial laboratories. They are intended for applications requiring temperatures up to 1100°C for manual control bases or temperatures up to 1200°C for the electronic single set point
control bases. See specification sheet for continuous and
intermittent operating temperatures.
General Usage
Do not use this product for anything other than its intended usage.
Principles of Operation
The furnace chamber is heated by heating elements embedded in a refractory material. The tubular chamber is
insulated with a ceramic fiber insulation. The furnace
chamber is supported by the control base which also
houses the electrical connections. Two types of controls
are used:
1. Manual Control - A percentage input control which
compensates for line voltage fluctuation and ambient
temperature changes. The temperature is measured by a
thermocouple and is displayed on a pyrometer.
2. Single Set Point Control - An electronic control which
enables the user to bring the furnace up to a pre-set temperature and hold the temperature.
Introduction
Model Number F21135, *F21125 F21130, *F21120 F21130-33, *F21125-33
Dimensions - In.
(cm)
Overall Width 16 (40.6) 16 (40.6) 16 (40.6)
Height 14.63, *14.75 14.63, *14.75 14.63, *14.75
(37.2, *37.5) (37.2, *37.5) (37.2, *37.5)
Chamber Width 12 (30.5) 12 (30.5) 12 (30.5)
Height 1.0 & 2.0 Dia. 1.0 & 2.0 Dia. 1.0 & 2.0 Dia.
(2.5 & 5) (2.5 & 5) (2.5 & 5)
Weight - lbs (Kg) 19 lbs 5 oz (8.8) 19 lbs 5 oz (8.8) 19 lbs 5 oz (8.8)
*19 lbs 12 oz (9.0) *19 lbs 12 oz (9.0) *19 lbs 12 oz (9.0)
Electrical Ratings
Volts 120 240 230
Amps 11.25 5.6 5.4
Watts 1350 1350 1240
Freq. 50/60 50/60 50/60
Phase 1 1 1
Temperature 100 - 1200°C 100 - 1200°C 100 - 1200°C
Ratings °C *371 - 1100°C *371 - 1100°C *371 - 1100°C
* For models with manual control.
Temperatures specified, obtained with both 1.0” Dia. and 2.0” Dia. ceramic process tubes, 17” long.
6
General Specifications
Environmental Conditions
Operating: 17°C - 27°C; 20% to 80% relative humidity, non-condensing. Installation Category II
(over-voltage) in accordance with IEC 664. Pollution Degree 2 in accordance with IEC 664.
Altitude limit: 2,000 meters.
Storage: -25°C to 65°C; 10% to 85% relative humidity.
7
Declaration of Conformity
(for 230 volt, CE Models Only)
Barnstead International hereby declares under its sole responsibility that this product conforms with the technical
requirements of the following standards:
EMC: EN61000-3-2 Limits for Harmonic current emissions
EN61000-3-3 Limits for voltage fluctuations and flicker
EN61326-1 Electrical equipment for measure, control, and laboratory use; Part I:
General Requirements
Safety: EN61010-1 Safety requirements for electrical equipment for measurement, control,
laboratory use; Part I: General Requirements
EN61010-2-010 Part II: Particular requirements for laboratory equipment for the heating of
materials
per the provisions of the Electromagnetic Compatibility Directive 89/336/EEC, as amended by 92/31/EEC and
93/68/EEC, and per the provisions of the Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC.
The authorized representative located within the European Community is:
Electrothermal Engineering Ltd.
419 Sutton Road
Southend On Sea
Essex SS2 5PH
United Kingdom
Copies of the Declaration of Conformity are available upon request.
8
Unpacking
Unpack furnace from box and remove packing material
from inside furnace chamber. The furnace is supplied with
a three wire cord and plug & 2-JC211x1 (1") diameter tube
mounting vestibules. Furnace does not contain a refractory
process tube.
Unpacking
Note
Contact the dealer from which your
furnace was purchased to obtain
proper process tube and information
regarding its use.
9
Installation
Caution
Be sure ambient temperature does
not exceed 104°F (40°C); ambients
above this level may result in damage to the control.
Allow at least six inches of space
between the furnace and any combustible surface. This permits the heat
from the furnace case to escape so as
not to create a possible fire hazard.
Note
Furnace comes with both 1" and 2"
dia. end caps. Install the end cap
which fits the tube you plan to use.
To avoid electrical shock, this furnace
must be installed by a competent, qualified electrician who insures compatibility among furnace specification, power
source and ground code requirements.
Warning
Installation
SITE SELECTION: Install furnace on a sturdy surface and allow space for ventilation.
The electrical specifications are located on the specification plate on the back of the furnace. Consult Barnstead/Thermolyne if your electrical service is different
than those listed on the specification plate. Prior to connecting your Type 21100 furnace to your electrical supply, be sure the power or control switch is in the OFF
position.
10
Operation
Caution
Monitor furnace if percent time input is
set greater than 40% on and particularly when the control is set on “9” or
above. The furnace may overheat and
burn out the elements or thermocouple
if not properly monitored under these
conditions.
Caution
Do not use in the presence of flammable or combustible chemicals. Fire or
explosion may result; this device contains components which may ignite
such materials.
Hot Surface
“Caution: Hot Surface. Avoid Contact.”
To avoid burns, do not touch this furnace on the exterior or interior surfaces during use or for a period of time
after use.
Operation of Manual and
Automatic Models
Observe These Warnings Before Operating
Your Furnace:
Manual Control Models (F21120-33,
F21125, F21120)
The control switch is a combination ON/OFF switch and
temperature control. The furnace is ON at any setting of
the control switch except in the OFF position. Turn the
control switch counterclockwise to set rate of heating.
Cycle Light: The amber cycle light will illuminate whenever the power is being applied to the elements.
The marks on the control indicate the percent of time
power is applied to the heating elements. An increase in
percent time “On” results in a higher chamber temperature.
Adjust control switch to maintain desired temperature setting. To turn the furnace off, turn control either fully clockwise or fully counterclockwise to the OFF position.
Pyrometer
The pyrometer with a thermocouple indicates the chamber
temperature. It does not control the furnace in any manner.
It is provided to enable the operator to observe the temperature within the chamber.
11
Operation
All Modes Single Set Point
Temperature Control (Automatic)
(F21130, F21130-33, F21135)
Warning
To avoid personal injury do not use in the
presence of flammable or combustible
chemicals; fire or explosion may result.
This device contains components which
may ignite such materials.
Hot Surface
Caution: Avoid Contact. To avoid burns,
this furnace must not be touched on the
exterior or interior surfaces during use or
for a period of time after use.
Warning
Always wear safety glasses or a safety
shield and high temperature gloves when
loading or unloading the furnace. Long
sleeved, fire retardant clothing and a fire
retardant apron is also recommended.
Power Switch
Both the ON/OFF power switch and the digital display
will illuminate when power is switched ON. The furnace
will begin to heat to the controller's current setpoint.
Cycle Light
The amber cycle light will illuminate whenever the
power is being applied to the heating elements. The
cycle light will turn on and off as the furnace reaches
the setpoint.
12
The single setpoint model furnace controller is a sin-
gle setpoint controller which provides a single digital
display to indicate the current chamber temperature or
setpoint temperature. This temperature controller features sensor break protection and self-tuning capability.
Basic Operation
When the controller is turned ON it will perform a short
self-test and then display the measured value (process
value) in the HOME DISPLAY.
Buttons and Indicators
OP1 (Output 1): Illuminates when the logic output is
ON.
OP2 (Output 2): Illuminates when the relay output is
ON (will go out during an alarm situation).
PAGE button: Allows you to select a new list of parameters.
SCROLL button: Allows you to select a parameter
within a list of parameters.
DOWN button: Allows you to decrease a value.
UP button: Allows you to increase a value.
To View or Change the
Setpoint
To view the setpoint, press and release the UP or
DOWN buttons. If you want to change the setpoint,
continue pressing until the desired setpoint value is
displayed and then release the button. Afew seconds
after the button is released, the controller will accept
the new value and revert to the HOME DISPLAY.
Single Setpoint Controller
Output 1
UP ARROW
Button
Temperature
Display
Display
Window
DOWN ARROW
Button
PAGE
Button
SCROLL
Button
Output 2
Note
If at any time you want to return to the
HOME DISPLAY, simultaneously press
the PAGE and SCROLL buttons.
Single Setpoint Models
13
SINGLE SETPOINT CONTROLLER
desired setpoint value is displayed and then release the
button. Afew seconds after the button is released, the controller will accept the new value and revert to the HOME
DISPLAY.
To View the Display Units
From the HOME DISPLAY press the SCROLL button. The
display will show the temperature units in °C/F/K and then
return to the HOME DISPLAY. (Call Customer Service if you
require a different temperature unit.)
To View the % Output Power
From the HOME DISPLAY press the SCROLL button twice.
Press and release the UP or DOWN button to view the %
output power. This value is a read-only value and cannot be
changed.
Controller Parameters
Home display
°C: Temperature units in Celsius. Temperature units can not
be changed without entering the configuration. Contact
Customer Service if a different temperature unit is required.
OP: % output power demand.
IdHi: Deviation high alarm.
Al List
IdHi: Deviation high alarm.
Atun List
tunE: One-shot autotune enable.
Pid List
Pb: Proportional band (in display units).
SINGLE SETPOINT CONTROLLER
14
ti: Integral time in seconds.
td: Derivative time in seconds.
ACCS List Code: Access code (Code needed to enter
or change the other configuration parameters which are
not normally accessible.) Not accessable.
Alarms
The controller will flash an alarm message in the home
display if an alarm condition is detected.
2FSH: Measured value full scale high alarm.
IdHi: Measured value deviation high alarm.
S.br: Sensor break: check that sensor is connected cor-
rectly.
L.br: Loop break: check that the heating circuits are
working properly.
Ld.F: Heater Circuit fault: indication of either an open or
short solid sate relay, a blown fuse, missing supply or
open circuit heater.
Sensor Break Protection
This controller provides sensor break protection in the
event the thermocouple opens. If an open thermocouple
condition occurs, the digital display will blink “S.br” and
the power to the heating element will be shut OFF
(Cycle light will extinguish).
Over-Temperature Protection
(OTP)
The OTP will be in effect during any alarm condition
when the temperature of the furnace has deviated
beyond the limit. The “Deviation High” alarm is the only
alarm value which can be changed. To change it, press
S
INGLE SETPOINT CONTROLLER
Note
The following alarm messages are factory default settings and may vary if you
have changed the configuration of your
controller:
IDHi: = 50°C
2FSH = 1225°C
15
the SCROLL button until “IdHi” appears on the display.
Press the UP or DOWN button to select the OTP value
you desire. We recommend a value of 20° above your
working temperature to provide protection for your workload.
Tuning
This controller incorporates a self-tuning feature which
determines the optimum control parameters for the best
temperature accuracy with your load and setpoint. Use
this feature the first time you use your furnace and each
time you change either your setpoint or the type of load
you are heating. Barnstead|Thermolyne recommends
you use this feature to provide the best temperature
accuracy the controller can attain. To use the tuning feature:
1. Adjust the setpoint to your desired value.
2. Press the PAGE button until display reads,
“Atun.”
3. Press the SCROLL button. Display will read,
“tunE.”
4. Press the UP or DOWN button to select, “on.”
5. Simultaneously press the PAGE and SCROLL
buttons to return to the HOME DISPLAY. The
display will alternately flash between “tunE”
and the HOME DISPLAY while tuning is in
progress.
6. The controller will then turn the heating on and
off to induce an oscillation. When the measured value reaches the required setpoint the
first cycle will end.
7. Tuning will be complete after two oscillation
cycles and then the tuner will turn itself off.
8. Normal control function will resume after the
controller calculates tuning parameters.
Note
Furnace must be at ambient
temperature before starting a tune.
SINGLE SETPOINT CONTROLLER
Note
Tune has completed when “tunE”
stops flashing on display.
Note
“Stat” and “Sp.rr” in Sp list must be
set to OFF or “tunE” will not initiate.
16
Single Ramp & Dwell
Mode 1 (Opt. 1)
Mode 2 (Opt. 2)
Mode 3 (Opt. 3)
Mode 4 (Opt. 4)
Mode 5 (Opt. 5)
Functions
This type of controller has single ramp and dwell programming capabilities. The Ramp and Dwell can be configured
to five different modes.
1. Mode 1 (Opt. 1) is a Ramp (if needed) to the Setpoint temperature, a Dwell, and then a cool down.
2. Mode 2 (Opt. 2) is the same as mode 1, except
the controller continues to heat at the Setpoint
after the Dwell has completed. (This mode does
not cool down.)
3. Mode 3 (Opt. 3) is the same as mode 1, except
the Dwell time includes the Ramp (if needed).
4. Mode 4 (Opt. 4) is the same as mode 2, except
the Dwell time includes the Ramp (if needed).
5. Mode 5 (Opt. 5) is a Dwell (delay time) before the
controller Ramps (if needed) to the Setpoint temperature.
Program Overview
•Aprogram mode can be set by changing the
“tm.OP” variable to “Opt. 1, Opt. 2, Opt. 3, Opt. 4,
or Opt. 5.
•ARamp rate may be set by changing the “SPrr”
variable to a value. The Ramp rate units are in
degrees per minute.
• The Dwell time can be set by changing the “dwEll”
variable to the desired value. Dwell time units are
in minutes.
• The program Status can be set by changing the
“StAt” variable to “run” or “oFF.” This variable will
start or stop the program.
17
Program Setup
1. Press the PAGE button until the “SP” is displayed.
2. Press the SCROLL button once, “SPrr” (Ramp
Rate) will be displayed, set the desired Ramp rate
with the UP or DOWN buttons, if the ramp to setpoint feature is needed. If the Ramp rate is not
needed, then set to “OFF” with the UP or DOWN
buttons.
3. Press the SCROLL button once, “tm.OP” (Ramp &
Dwell mode) will be displayed, select the desired
mode with the UP or DOWN buttons. (Opt. 1, Opt.
2, Opt. 3, Opt. 4, Opt. 5)
4. Press the SCROLL button once, “dwEll” will be displayed, set the desired Dwell time with the UP or
DOWN buttons. (Dwell in minutes.)
5. Press the PAGE button until the Actual temperature
is displayed.
Running the Program
1. Press the SCROLL button until “StAt” is displayed,
set to “run” with the UP or DOWN buttons.
2. Press the PAGE button to display Actual temperature.
Stopping the Program
Press the SCROLL button until “StAt” is displayed, set to
“oFF” with the UP or DOWN buttons.
Clearing the Flashing End
Press the PAGE and SCROLL buttons at the same time.
SINGLE R
AMP & DWELL
CONTROLLER
Note
The program must be stopped and
the controller must be displaying the
actual temperature before beginning
the Setup.
18
Verifying a Running Program
Press the SCROLL button until “StAt” is displayed. The display will show “run” if the program is running, or “oFF” if it is
not running. Press the PAGE button to display Actual temperature.
SINGLE R
AMP & DWELL
CONTROLLER
19
Furnace Loading
For best results of furnace loading and temperature uniformity, use only the center six inches of the furnace
chamber.
Keep objects away from thermocouple.
Use insulated tongs and mittens when loading and un-
loading furnace.
Always wear safety glasses.
Use the proper process tube.
Furnace Loading
Caution
Do not overload your furnace chamber.
Failure to observe this caution could
result in damage to furnace components.
20
Preventative Maintenance
Contamination is a major cause of element failure, therefore, when possible, remove the fume forming material
before heating. (e.g., cleaning cutting oil from tool steel).
Housekeeping is vital to your electric furnace—KEEP IT
CLEAN! Run your furnace up to 871°C empty occasionally to burn off the contamination that may exist on the
insulation and elements. Run for approximately two
hours with the process tube removed.
Element life is reduced somewhat by repeated heating
and cooling. If the furnace is to be used again within a
few hours, it is best to keep it at the operating temperature or at a reduced level such as 260°C.
During normal use the thermocouple in your furnace can
become oxidized and cause inaccurate readings; therefore, we suggest that if you regularly use your furnace
you should change your thermocouple once every
six months to assure the accuracy of your meter
readings.
General Cleaning Instructions
Wipe exterior surfaces with lightly dampened cloth containing mild soap solution.
Preventative Maintenance
Warning
To avoid electrical shock, this furnace
must always be disconnect from the
power supply prior to maintenance and
servicing.
Refer servicing to qualified personnel.
21
Troubleshooting
WARNING
THIS FURNACE CONTAINS REFRACTORY CERAMIC INSULATION WHICH CAN PRODUCE RESPIRABLE FIBERS AND DUST WHEN HANDLED. THESE FIBERS CAN CAUSE IRRITATION AND CAN AGGRAVATE PRE-EXISTING RESPIRATORY DISEASE. THE INTERNATIONAL AGENCY FOR RESEARCH ON
CANCER (IARC) HAS CLASSIFIED REFRACTORY CERAMIC FIBER AS POSSIBLY CARCINOGENIC.
AFTER SERVICE REFRACTORY CERAMIC FIBER DUST MAY CONTAIN CRYSTALLINE SILICA, WHICH
MAY CAUSE LUNG DAMAGE (SILICOSIS) AND WHICH HAS BEEN CLASSED BY IARC AS APROBABLE
CARCINOGEN.
The refractory ceramic materials are located in the hearth collar and in the chamber of the furnace. Tests performed by the manufacturer indicate that there is no significant risk of exposure to dust or respirable refractory ceramic fiber resulting from operation of the equipment under normal conditions. However, there may be a
risk of exposure to respirable refractory ceramic dust or fiber when repairing or maintaining the insulating materials, or when otherwise disturbing the materials in a manner which causes release of dust or fibers therefrom. Through the use of proper handling procedures you can work safely with these insulating materials and
minimize any exposure. Accordingly, before you repair or replace any insulating materials, or perform any other servicing on this product which could disturb or cause exposure to dust from insulating materials, you
should consult the appropriate Material Safety Data Sheets (MSDS’s) for such products with respect to proper
handling and appropriate protective equipment. For additional MSDS’s, or additional information concerning
the handling of refractory ceramic products, please contact the Customer Service Department of Barnstead
International.
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING
Disconnect from the power supply prior to maintenance and servicing.
Refer servicing to qualified personnel.
Troubleshooting
22
The Troubleshooting section is intended to aid in defining and correcting possible service problems. When using
the chart, select the problem category that resembles the malfunction. Then proceed to the possible causes
category and take necessary corrective action.
Problem Possible Causes Corrective Action
The power switch light does not The furnace is not connected Check furnace connection to
illuminate. to power supply. power supply.
No display on Single Set Point ON and OFF power switch Replace power switch.
Control defective.
The furnace does not heat. No power. Check power source and fuses
or breakers.
Thermocouple is open or Replace thermocouple or check
thermocouple leads reversed. thermocouple connections.
Controller malfunction. Verify and correct all parameters
and configuration values.
If “malfunction” persists, replace
control.
Element burned out. Replace element.
Solid state relay defective. Replace solid state relay.
Chamber section not connected Reconnect chamber section to
to base. base.
Slow heatup. Low line voltage. Install line of sufficient size and
proper voltage. (Isolate furnace
from other electrical loads.)
Heavy load in chamber. Lighten load in chamber to
allow heat to circulate.
Wrong heating element. Install proper element.
Low SPrr setting. Increase setting.
TROUBLESHOOTING
23
Problem Possible Causes Corrective Action
Repeated element burnout. Overheating furnace. Keep furnace under maximum
temperature. Closer supervision
of control setting.
Control malfunction. Replace control.
Incorrect element. Install proper element.
Oxidized thermocouple leading Replace thermocouple.
to inaccurate reading.
Wired improperly. Check wiring diagram for correct
wiring of your furnace.
Inaccurate temperature readout. Oxidized or contaminated Replace thermocouple.
thermocouple.
Poor thermocouple connection. Tighten connections.
Improper loading procedures. Use proper loading procedures.
Poor ventilation of base. Clear area around furnace base.
Thermocouple connections Reconnect thermocouple
reversed. correctly.
*Static charge on pyrometer case. Dispel static charge by
breathing on cover, treat for static charge.
Control out of calibration. Contact Barnstead International
P.I.D. values invalid. Re-tune control.
Control malfunction. Verify and correct all parameter
and configuration values.
If “malfunction” persists,
replace control.
*Applies to the manual temperature control models.
TROUBLESHOOTING
24
Maintenancing and Servicing
To Replace Vestibule End Caps
a. Disconnect furnace from power supply.
b Remove the metal end cap.
c. Remove old vestibule. Insert the new vestibule, aligning
the two holes in the vestibule with the holes on the bracket.
d. Before pushing the metal end caps back onto the chamber,
insert the two screws through the holes in the metal end
cap and vestibule. Then, start the two screws into the
holes in the bracket two or three turns, push the metal end
cap onto the chamber and finish tightening the two screws.
e. Reconnect furnace to power supply.
To Replace Heating Element
a. Disconnect furnace from power supply.
b. Disconnect the cord from furnace chamber to control base.
Identify the color and placement of the thermocouple
extension wires and disconnect from control base.
c. Remove furnace chamber from the bracket.
d. Remove both end caps and vestibules of furnace chamber.
e. Remove terminal plate with four screws to expose wiring.
(Note placement and connection of thermocouple and ele-
ment wires.)
f. Remove two element lead wires from terminal block. Also,
remove thermocouple by removing two screws on terminal
block then pulling it straight back.
g. Remove the four screws that secure heating element tube
inside the case, then slide out the old heating element
tube.
h. Insert new heating element tube and thread each element
lead wire through the brass bushings.
i. Secure heating element tube to case.
j. Reinstall thermocouple and connect thermocouple and new
element lead wires to terminal block.
k. Replace terminal plate.
l. Insert the screw on the terminal plate through the mounting
bracket and secure with knob.
m. Replace both end caps and vestibules.
n. Reconnect power cord from furnace chamber to control
base.
o. Reconnect thermocouple extension wires to control base
Maintenancing and Servicing
Note
Perform only maintenance
described in this manual. Contact
an authorized dealer or our factory
for parts and assistance.
25
terminal block. Looking from the rear of the furnace,
reconnect the red wire to the terminal on the far right side
of the block. The yellow wire connects to the terminal
second from the right side of the terminal block.
p. Reconnect furnace to power supply.
To Replace Pyrometer (Manual Control
Models
a. Disconnect furnace from power supply.
b. Remove furnace chamber from control base.
c. Turn control base upside down and remove bottom cover.
d. Remove black and red wires from terminal block on back
of unit.
e. Remove pyrometer from dial plate of control base.
f. Insert new pyrometer and secure to dial plate.
g. Looking from the rear of the furnace, reconnect red ther-
mocouple extension wire to the terminal on the far right
side of the terminal block. Reconnect black thermocou-
ple extension wire to the terminal second from the right
side of the terminal block.
h. Replace bottom cover.
i. Turn control base upright and secure furnace chamber to
it.
j. Reconnect furnace to power supply.
To Replace Manual Temperature
Control Switch
a Disconnect furnace from power supply.
b. Remove furnace chamber from control base.
c. Turn control base upside down and remove bottom cover.
d. Remove control knob with two Allen set screws.
e. Remove two screws by pulling straight out.
f. Disconnect wires from control. Identify or mark wires dis-
connected from control to insure proper placement and
connection when reinstalling. Remove defective control.
g. Looking from the rear of the furnace, insert new control
with the H1(vertical lead) and H2(horizontal lead) leads
on top and secure to dial plate.
h. Replace knob by sliding knob over shaft.
i. Reconnect the wires identified or marked in Step (f) to
new control.
j. Replace bottom cover.
k. Turn control base upright and secure furnace chamber to
it.
MAINTENANCING AND SERVICING
26
l. Reconnect furnace to power supply.
To Replace Furnace Chamber
a. Disconnect furnace from power supply.
b. Remove black knob holding furnace chamber to bracket
and remove furnace chamber.
c. Remove terminal plate on back of furnace chamber.
(Note placement and connection of wires.)
d. Disconnect thermocouple extension wires and power
cord from terminal block.
e. Remove back terminal plate on new furnace chamber.
f. Insert power cord and thermocouple extension wires
through their proper holes in the bracket on the new fur-
nace chamber. (See Figure 2 for placement and connec-
tion of wires.)
g. Replace back terminal plate.
h. Insert screw on back terminal plate through bracket slot
and secure with knob.
i. Reconnect furnace to power supply.
To Replace Type K (Chromel/Alumel) Thermocouple (Manual Control Models)
a. Disconnect furnace from power supply.
b. Remove knob that holds furnace chamber to the bracket
and remove the furnace chamber.
c. Remove terminal plate on back of furnace chamber.
d. Remove two screws that secure the old thermocouple
and remove thermocouple by pulling straight back.
e. Insert the new thermocouple until tip extends approxi-
mately 1/4" into the heating chamber. Connect the lead
marked (+) on insulator of thermocouple to the terminal
across from yellow thermocouple extension wire, and
fasten the other thermocouple lead (-) to the remaining
terminal. (See Figure 2.)
(A polarity test of the lead wire is easily made with the
use of a magnet. On chromel/alumel thermocouples and
extension wires, the non-magnetic wire is positive (+ )
and the magnetic wire is negative (- ).
f. Replace terminal plate.
g. Insert the screw on the terminal plate through the
mounting bracket and secure with knob.
h. Reconnect furnace to power supply.
MAINTENANCE AND SERVICING
27
To Replace Type Platinel II Thermocouple (Single Set Point Control Models)
a. Disconnect furnace from power supply.
b. Remove knob that holds furnace chamber to the
bracket and remove the furnace chamber.
c. Remove terminal plate on back of furnace chamber.
d. Remove two screws that secure the old thermocou-
ple and remove thermocouple by pulling straight
back.
e. Insert the new thermocouple until tip extends ap-
proximately 1/4" into heating chamber.
f. Connect the blue and yellow beaded thermocouple
lead to the terminal across from yellow thermocou-
ple extension wire and the other thermocouple lead
to the remaining terminal. (See figure 2)
g. Insert the screw on the terminal plate through the
mounting bracket and secure with knob.
h. Reconnect furnace to power supply.
M
AINTENANCE AND SERVICING
28
MAINTENANCE AND SERVICING
Figure 2 All Models
29
Replacement Parts List
Replacement Parts List
Series 1259
Part Number Description Model Number
EL211X1B 120V Element F21125, F21135
EL211X2B 230V Element F21120, F21130, F21130-33, F21120-33
TC211X1A Thermocouple, Chromel/Alumel All Manual Control Models
TC662X1A Thermocouple, Platinel II All Electronic SSP Models
CN71X105 Electronic SSP Control All Electronic SSP Models
CNX60 Manual Control F21125
CNX61 Manual Control F21120, F21120-33
ME1260X1 Pyrometer F21120, F21120-33, F21125
RYX34 Solid State Relay F21130, F21130-33, F21135
440-0020 Fuse, Type ABC, 250V, 8 Amp F21120, F21120-33, F21130, F21130-33
2-58147 Fuse,15 Amp F21125, F21135
SWX143 Main Power Switch F21125, F21135
SWX144 Main Power Switch F21120, F21120-33, F21130, F21130-33
CAX44 Filter, EMI F21130-33, F21120-33
CS1260X4 Furnace Chamber Complete, 240V F21120, F21120-33, F21130, F21130-33
CS1260X3 Furnace Chamber Complete, 120V F21125, F21135
Ordering Procedures
Ordering Procedures
Please refer to the Specification Plate for the complete model number, serial number, and series number when
requesting service, replacement parts or in any correspondence concerning this unit.
All parts listed herein may be ordered from the Barnstead International dealer from whom you purchased this
unit or can be obtained promptly from the factory. When service or replacement parts are needed we ask that you
check first with your dealer. If the dealer cannot handle your request, then contact our Customer Service Department at 563-556-2241 or 800-553-0039.
Prior to returning any materials to Barnstead International, please contact our Customer Service Department for
a “Return Materials Authorization” number (RMA). Material returned without a RMA number will be refused.
30
Wiring Diagrams
Wiring Diagram for Models F21120, F21120-33, F21125
Ref. Description
No.
C1 Capacitor
C2 Capacitor Line Filter
CN1 Control
F1 Fuse
F2 Fuse
H1 Heating Element
M1 Meter
P1 Cycle Light, Amber
S1 Switch
TB1 Terminal Block
TB2 Terminal Block
TC Thermocouple
WH1 Cable Element Power
WH2 Cable T/C Extension
Diagram Component List
31
Wiring Diagram for Models F21130, F21130-33, F21135
WIRING D
IAGRAMS
Ref. Description
No.
F1 Fuse
F2 Fuse
H1 Heating Element
P1 Cycle Light, Amber
S1 Switch
TB1 Terminal Block
TB2 Terminal Block
TB3 Terminal Block
TC Thermocouple
WH1 Cable T/C Extension
WH2 Cable T/C Extension
Diagram Component List
32
Barnstead International (“BARNSTEAD”) warrants that if a product manufactured by Barnstead shall be free of
defects in materials and workmanship for one (1) year from the first to occur of (i) the date the product is sold by
BARNSTEAD or (ii) the date the product is purchased by the original retail customer (the “Commencement Date”).
Except as expressly stated above, BARNSTEAD MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED,
WITH RESPECT TO THE PRODUCTS AND EXPRESSLY DISCLAIMS ANY AND ALL WARRANTIES, INCLUDING
BUT NOT LIMITED TO, WARRANTIES OF DESIGN, MERCHANT ABILITY AND FITNESS FOR APARTICULAR
PURPOSE.
An authorized representative of BARNSTEAD must perform all warranty inspections. In the event of a defect covered by BARNSTEAD’s warranty, BARNSTEAD shall, as its sole obligation and exclusive remedy, provide free
replacement parts to remedy the defective product. In addition, for products sold by BARNSTEAD within the continental United States or Canada, BARNSTEAD shall provide provide free labor to repair the products with the
replacement parts, but only for a period of ninety (90) days from the Commencement Date.
BARNSTEAD’s warranty provided hereunder shall be null and void and without further force or effect if there is any
(i) repair made to the product by a party other than BARNSTEAD or its duly authorized service representative, (ii)
misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination,
overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts
that are obtained from a party who is not an authorized dealer of BARNSTEAD.
Heating elements, because of their susceptibility to overheating and contamination, must be returned to the BARNSTEAD factory and if, upon inspection, it is concluded that failure is due to factors other than excessive high temperature or contamination, BARNSTEAD will provide warranty replacement. As a condition to the return of any
product, or any constituent part thereof, to BARNSTEAD’s factory, it shall be sent prepaid and a prior written authorization from BARNSTEAD assigning a Return Materials Number to the product or part shall be obtained.
IN NO EVENT SHALL BARNSTEAD BE LIABLE TO ANY PARTY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, OR FOR ANY DAMAGES RESULTING FROM LOSS OF USE OR
PROFITS, ANTICIPATED OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THE SALE, USE OR
PERFORMANCE OF ANY PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, TORT (INCLUDING NEGLIGENCE), ANY THEORY OF STRICT LIABILITY OR REGULATORYACTION.
The name of the authorized Barnstead International dealer nearest you may be obtained by calling 1-800-446-6060
(563-556-2241) or writing to:
One Year Limited Warranty
2555 Kerper Boulevard
P.O. Box 797
Dubuque, Iowa 52001-0797
Phone: 563-556-2241 or 800-553-0039
Fax: 563-589-0516
E-mail: mkt@barnstead.com
www.barnstead.com
Loading...
