BAR LINE B 18 AS, B 18 WS, B 18 Datasheet

B 18

lso available in the self-contained range

A
for “Bistrot” cube:

B 21, B 31, B 40, B50, B65, B90

See pertaining literature for more details

BAR LINE - Self Contained Machine Bistrot Cube

B 18 AS/WS

Bar-Line Equipment range is the
newly released EU made ice makers
for Thimble-shaped rounded ice
cubes coming from Bar-Line.
Built in the Italian manufacturing
plant of Frimont Spa, ISO 9001
Certified, these units are built with
sturdy, corrosion resistant stainless
steel, and feature European made
componentry to assure maximum
quality and reliability.
Tested one by one, the Bar-Line self
contained units feature well
balanced ratio between production
and storage capacity, alongside with
reduced outer dimensions that
allow for built-in installations.
Front air louvers assure appropriate
airflow in critical installrequirements.

Contemporary, elegant design unites
excellent operational features with the
reliability obtained through years of
succesfull experience in ice making
technology.

Insulated bin door and ice storage bin
minimize air condensation and water
formation on equipment surfaces.

Electromechanic controls maximise
reliability and ease of repair during the
entire life of the equipment.

ICEU 35 AS/WS

B 18

B 18 AS/WS

334 mm

lso available in the self-contained range

A
for “Bistrot” cube:

B 21, B 31, B 40, B50, B65, B90

See pertaining literature for more details

5

97/599 mm

Air out-flow
of ICE Maker

OP ER ATI NG LIMITS

Air Temp. Range 10°C - 40°C

Water Temp. Range 5°C - 35°C

Water Pressure Min. 1 bar

Max. 5 bar

Electrical Voltage 230V/50Hz/pH

(on selected models)

All specifications and performance data
are subject to normal manufacturing variances.

All units have stainless steel finish.
Refrigerant: R-134a

457 mm

B 18 AS/WS

179 mm

Air in-take
of ICE Maker

116 mm

77 mm

60 mm

68 mm

Installation Note: allow 152 mm minimum space
at back for utility connections.

OR DE RI NG AND SP EC IF IC ATI ON INFORMATIO N

ICE Production

Model Cond. Bin Storage

No.Unit .

B 18 AS Air 20 6,5 230/50/1 R 134a

B 18 WS Water 20 6,5 230/50/1

BAR LINE - Self Contained Machine Bistrot Cube

We reserve the right to make changes in design
and construction at any time without obligation.

ADV-Bar-Line 9/2010

per 24 hrs. at

10°C Air/10°C Water

Kgs. Refrigerant

Kgs.

Characteristics

Voltage

104 mm

CORD SET

Ø20 mm WATER DRAIN

3/4” GAS WATER INLET

Kgs.

28
28

Max. Shipping

Weight

Kgs.

33
33

R 134a

Water

Consumption

Lt/60’

6

28

Electric

Consumption

kwh/24h

6,3

6,3

Net Weight

Frimont S.p.A.
Via Lainate 31/b - 20010 Pogliano Milanese - (Milano) Italy
Tel. [phone] - Fax [phone]
[e-mail] - www.barline.it
