INSTRUCTIO NS f or use
Model: MK8 120
FLOAT MACHINE
MK8 120
WITH MECHANICAL
CONTROLS
BARIKELL s.r.l
Via Razzaboni,118
41100 – Modena ( Italy)
Tel 059.311178 fax 059.311111
2
3
INNOVATION:
NEW LIFT HOOK
4
Thank you for buying our product. W e have taken
every possible care to ensure that it arrives in
perfect conditions. Nevertheless, in the unlikely
event that you find some damage when you
receive the machine, or if we can help you in an y
way, please do not hesitate to contact our
Customer Service department.
This manual contains all the information
necessary for proper use of the machine. Please
carefully follow the instructions and keep it in a
suitable and accessible place.
The contents of this manual may be
modified without prior notice or other
obligations in order to incorporate
changes and improvem ents to the units
already shipped.
It should be specifie d that f or reasons of
visibility and clarity some figures are
shown
with the machine not in the
correct configuration for use.
No part of this manual may be reproduced or
translated without permission in writing from the
manufacturer.
Table of Contents
1. SYMBOLS ...................................................................................................................................................... 7
2. GENERAL PRECAUTIONS FOR USE .......................................................................................................... 7
3. TECHNICAL SPECIFICATIONS .................................................................................................................... 8
3.1. Machine description .................................................................................................................................. 8
3.2. Technical data ............................................................................................................................................ 8
3.3. Main parts of the machine and contro ls ................................................................................................. 9
3.4. Seat adjustment ......................................................................................................................................... 9
3.5. Blade inclination adjustment .................................................................................................................... 9
3.6. Adjusting the drive levers ........................................................................................................................ 9
3.7. Ambient conditions ................................................................................................................................... 9
3.8. Not permitted uses ................................................................................................................................... 9
4. DELIVERY AND INSTALLATION ................................................................................................................ 9
4.1. Delivery ....................................................................................................................................................... 9
4.2. Component assembly ............................................................................................................................ 10
4.3. Water supply ............................................................................................................................................ 10
4.4. Fuel .......................................................................................................................................................... 10
4.5. Engine oil .................................................................................................................................................. 10
5. USE............................................................................................................................................................... 10
5.1. Preliminary checks .................................................................................................................................. 10
5.2. Starting ..................................................................................................................................................... 10
5.3. Driving the float machine ........................................................................................................................ 11
5.4. Use ............................................................................................................................................................ 11
5.5. Stopping ................................................................................................................................................... 12
5.6. Stopping in emergency conditions ....................................................................................................... 12
6. HANDLING AND TRANSPORT .................................................................................................................. 12
7. MAINTENANCE ........................................................................................................................................... 12
7.1. Engine maintenance ................................................................................................................................ 12
7.2. Machine maintenance ............................................................................................................................. 12
7.3. Battery ...................................................................................................................................................... 13
7.4. Cleaning the machine.............................................................................................................................. 13
7.5. Replacing the floats................................................................................................................................. 13
7.6. Replacing the blades ............................................................................................................................... 13
7.7. Replacing the belts .................................................................................................................................. 13
7.8. Reduction gear oil level ......................................................................................................................... 14
7.9. Storage instructions. ............................................................................................................................... 14
7.10. Troubleshooting .................................................................................................................................... 14
8. DISPOSAL ................................................................................................................................................... 15
9. GUARANTEE ............................................................................................................................................... 15
1. Symbols
Below follows a short legend with an indicat ion of
the symbols used throughout the manual (those
considered most significant).
WARNING DANGER: draws the
attention to situations or problems
which may cause injury to persons or
risk of death..
IMPORTANT: draws the attention to
situations or problems connected with
machine efficiency but which do not
pose a risk to the safety of persons.
The following instructions are indicated on the
machine ( fig. 2):
N.
Descrizione
1
Danger:
• Carefully read the instruction manual
• Do not let unauthorised persons come near the
working area
• Carry out maintenance work only when the mac hine is
off and after having pulled out the key and read the
instruction manual.
• Do not remove the protection and safety devices
• Rotating parts: risk of injuring the limbs.
• Hot surfaces: risk of burns
• Rotating tools: risk of injuring the limbs.
2
Protect hearing with earmuff s
3
CE plate
Observe the warnings on the plates.
Inobservance may cause d eath or injur y
to the personnel. Ensur e that th e plat es
are always present and legible. If
otherwise, apply or replace them.
2. General precautions for use
•
The operator is personally
responsible for the oper ating safety
of the machine.
• Carefully read this manu
al before
starting, use, maintenance or other
operations on the machine.
•
The purpose of this manual is to
bring to the attention of the
operator, with illustrations and
texts, the fundamental instructions
and the criteria to follo w for us e and
maintenance of the machine.
In order to operate in safety:
•
Check that the machine has not
been damaged during transport,
and if so, immediately notify the
manufacturer or the area
representative.
•
Allow only authorised personnel
to use the machine.
• Operator
s not working on the
machine must keep the safety
distance when the machine is
running.
•
Periodically clean the machine,
removing any foreign materials
which may comprom ise operation
or cause injury to the operator
• Before using the m achine, ensur e
that all the protection dev ices are
properly in place and in good
working order.
Should the protection devices be
faulty or damaged, replace them
immediately.
• Carry out maintenanc e work only
after having read the instruction
manual and having pulled out the
ignition key or detache d the spark
plug.
•
Any repairs may exclusively be
carried out by qualifie d personnel
using original spare parts.
Otherwise, the user may be
exposed to serious risk
• Do not wear clothes that may get
caught up in moving parts, such as
loose-
fitting garments, scarves,
coats, etc. It is recommended to
wear approved garments for
accident-
prevention purposes, for
example: hard hats, anti-slip
shoes, earmuffs, safety goggles,
heatproof gloves, safety mask.
Ask your employer about the
safety regulations in f orce and the
safety devices.
3. Technical specifications
3.1. Machine description
The double rotary float m achine model MK8 120
has been designed and constructed to float
concrete and bituminous floors of warehouses,
car parks, cycle t rac ks, parking areas, pa vements,
etc. For this purpose the machine is equipped with
two rotors, one turning clockwise and the other
anticlockwise.
Both the engine and t he operator’s seat ar e fixed
to a frame connected to both rotors.
The very low posit ion of th e seat h as th e fol lowing
advantages:
• Superior planarity of the floor surface (as a
result of lowering of the machine barycenter)
• Perfect vision
The seat can be adjusted t o the most comf ortable
driving position for the operator. All the steering
components, joysticks, joints, drive shaft and
reduction gears are protected by a tunnel to
prevent cement encrustations from accumulating
over time, which could le ad to more rapid wear of
the mechanical components.
3.2. Technical data
Description
Unit of
measur
e
3355 3357 3358 3559 3561
Dimensions:
[mm] 2450x1205x1040 2450x1205x1040 2450x1205x1040 2450x1205x1040 2450x1205x1040
Packaging dimensions
[mm] 2530x1280x1100 2530x1280x1100 2530x1280x1100 2530x1280x1100 2530x1280x1100
Operating weight
[kg ] 316 315 323 330 300
Shipping weight
[kg ] 320 320 320 320 320
Motorization:
- Kohler Honda B&S Vanguard B&S Vanguard Kohler
Power installed:
[Hp] 27 24 31 35 36
Starting:
- Electric Electric Electric Electric Electric
Cooling:
- Air Air Air Air Air
Fuel:
- Gasoline Gasoline
Gasoline
Gasoline
Gasoline
Fuel tank capacity:
lt 11 11 11 11 11
Max engine rotation speed:
[rpm] 3600 3600 3600 3600 3600
Min - max blade rotation
speed:
[rpm] 70 -125 70 - 125 70 - 125 70 - 125 70 - 125
Rotor diameter:
[mm] 1200 1200 1200 1200 1200
Number of blades:
- 8 8 8 8 8
Max. forward speed
[m/min] 90 90 90 90 90
Acoustic pressure level:
[dB] 92,4
(1)
92,4
(1)
92,4
(1)
92,4
(1)
92,4
(1)
Acoustic pressure level at
driver’s seat:
[dB] 92,3
(1)
92,3
(1)
92,3
(1)
92,3
(1)
92,3
(1)
Acoustic power level:
[dB] 108,2
(1)
108,2
(1)
108,2
(1)
108,2
(1)
108,2
(1)
Quadratic mean value of
acceleration:
m/s
2
0,8 - 1
0,8 - 1 0,8 - 1
0,8 - 1 0,8 - 1
(1)
Measured with petrol-powered engine
An exact description of the Model and Seria l Number will make it easi er f or our Technical Service to respond
quickly and efficiently.
Therefore, always indicate the machine model and serial number when you contact Technical Service.
(fig. 2).
3.3. Main parts of the machine and controls
See Fig. 1
N.
Description
1
Right rotor
2
Left rotor
3
Right float adjustment knob
4
Left float adjustment knob
5
Accelerator
6
Protection cage
7
Battery
8
Fuel tank
9
Water tank
10
Right control
11
Left control
12
Right headlight
13
Left headlight
14
Seat
15
Engine
NB: For reasons of description the
machine may be represented without the
protection devices. The machine cannot
and must not be operated in these
conditions. At the time of ins tall ation, e ver y
precaution must be taken to ensure that
the protection and s
afety devices are in
place and efficient.
3.4. Seat adjustment
(Fig.3) For horizontal adjustment operate the
lever (4) located under the seat (1), find the
desired position and release the lever (4).
3.5. Blade inclination adjustment
(Fig.4) T he blade inclination can be adjus ted with
the knobs (1) and (2).
Turn the knob (1) clockwise to inc rease the blade
inclination of the right rotor ( Fig.1 No.1).
Turn the knob (2) clockwise to inc rease the blade
inclination of the left rotor ( Fig.1 No.2).
To decrease the inclination turn the knobs
anticlockwise.
3.6. Adjusting the drive levers
The drive levers (Fig.1 No.10 and 11) can be
adjusted to the most c omfortable position for the
operator.
To move the drive control levers forward or
backward, operate as follows (Fig. 5):
1. Place the blades in horizontal position
using the knobs (see Par. 3.5)
2. Unscrew the counternuts (1) which lock
the forks of the control levers.
3. Remove the fork pins (2).
To move the levers outward ( FORW ARD) turn the
forks clockwise.
To move the levers towards the seat
(BACKWARD) turn the forks anticlockwise.
To move the drive control levers left or right,
operate as follows (Fig. 6):
1. Remove the nut (1).
2. Loosen the nuts (2 and 3).
3. Remove the joint (4).
Turning the joint clock wise the levers m ove to the
left.
Turning the joint an ticlockwise the le vers move to
the right.
Reposition the joint and tighten the nuts (1-2-3).
3.7. Ambient conditions
The machine should be used sheltered from
atmospheric agents.
The places where the m achine is used should be
well ventilated and conform to the regulations in
force regarding hygiene and safety in the
workplace.
• Do not come close to the
machine with naked flames or similar.
•
Do not use the machine in
places where there is a risk of
explosion or fire.
IMPORTANT: The ex
hausts contain
carbon monoxide, a hazardous mortal
gas. Do not start the engin e in close d or
badly ventilated places.
3.8. Not permitted uses
It is prohibited to employ the machine for uses
different from those expressly indicated by the
manufacturer.
4. Delivery and installation
4.1. Delivery
All the material shipped, including the detached
parts, are checked before delivery.
Upon receipt check that th e machine has
arrived intact in all of its parts. If
otherwise, immediately contact our
dealer.
The machine is delivered in a crate weighing
about 320 kg.
Unload it with a fork lift truck of adequate capacity
and position it on a stable and horizontal surface.
Remove the top and side packaging and lift the
float machine with a crane using suitable metal
cables hooked onto the attac hments (Fig.7 No.1)
arranged on the 4 sides of the cage.
The float machine is shipped fully assembled
except for the seat and th e engine-side h eadlight;
moreover, the two steering levers are lo wered and
the battery cable is detached.
The machine handling operations must
be carried out in observance of the
regulations in force regarding safety in
the workplace.
Dispose of the packaging in the
appropriate manner in accordance with
the regulations in force in the c ountry of
use.
4.2. Component assembly
(fig.3)Seat assembly: fix the seat (1) to the
support plate (2) using the 4 bolts (3). Fully tighten
the nuts and connect the terminal
(fig.3) Headlight assembly: fit the headlight (5) in
such a way that it is tight enough to res ist rotation
and movement, fit the gr ound cable (7), sc rew on
and tighten the counternut, fit the power cable (6)
into the plugs.
(fig.6) Mounting the steering levers: insert
the central tie-rod joint in its housing (5) and the
side tie-rod joi nt (4) in the levers positioned near
the fuel tank, then screw down and tighten the
nuts.
(fig.8) Battery cable connection: remove the
cover (2) and connect the relevant cable to the
positive pole (4) of the battery (1), appropriately
tightening the terminal.
4.3. Water supply
(fig.8) The hydraul ic float machine MK8 120 has
an autonomous wetting system. The water is
sprayed in correspond ence to the rotors from the
nozzles connected to the water tank (5).
When filling the ta nk , be ca r ef ul not to c onf us e t he
water tank (5) with the fuel tank (6).
4.4. Fuel
WARNING: Danger of explosion and
fire.
Fill the tank in an open place away from
heat sources. Do not smoke. Do not
refuel when the engine is running or very
hot.
IMPORTANT:
Consult the engine manual for the type
of fuel to use.
1. Clean the area around the fuel filler cap.
2. Remove the cap.
3. Fill the tank up to 3-4 cm from the brim in
order to allow the fuel to expand.
4. Close the filler cap.
5. Alwa ys thoroughly clean the area around
the cap removing any small spills.
4.5. Engine oil
Refer to the engine manual attached.
Dispose of used oil in the appropriate
manner in accordance with the
regulations in force in the country of use
5. Use
5.1. Preliminary checks
Before proceeding with starting and use of the
float machine, do the following
1. Check the oil level in the engine and, if
necessary, top up (see Par. 4.5).
2. Check the fuel level in the tank and, if
necessary, refuel (see Par. 4.4).
3. Check that all the protection devices are
present and working.
4. Adjust the seat position horizontally to
obtain the best possible working position
(see Par.3.4)
5. Check that the blade is incl i ned by at least
1 cm in order to ha ve better control over
the float machine when starting (for
adjustment see Par. 3.5 )
6. Ensure that the float machine is
positioned on a flat surface with a
capacity of more than 300 kg/m
2
and that
there is sufficient space around the float
machine (at least 2 m).
7. Check that the two drive c o ntrol l ev ers are
in perpendicular position and adjust if
necessary (see Par. 3.6).
5.2. Starting
In order to prevent slippage and losing
control of the float machine when
starting and during the working phases
the operator must be seated in the
driver’s seat on the float machine and
always hold the acce lerator pedal in the
idle position.
To start the float machine operate as follows
(fig.9):
1. Sit in the driver’s seat af ter appropriately
adjusting its position and with the feet
resting on the footboard.
2. Check that the drive control (2) is in
neutral position.
3. (for petrol-powered engines only) Close
the CHOKE.
4. Position the accelerator hand-lever or
accelerator pedal (Fig.1) in the idle
position.
5. Hold one emergency stop lever (4)
pushed and turn the start key (3).
6. (for petrol-powered engines only) After
starting open the CHOKE.
The engine is started at reduced rpm, the clutch
has not yet engaged and the rotors do not yet
rotate (the clutch engages at 1500 rpm ). In order
to prevent slippage whic h might lead to rapid wear
of the clutch, firml y push the accelerator to reach
a value of 2500 rpm.
For more specific inf ormation on start ing
consult the engine instruction manual.
5.3. Driving the float machine
Use the machine at reduced speed unt il
you have fully mastered it and all the
possible movements.
To drive the machine in the desired direction,
there are two control levers (Fig.1 No. 10 and
11). Move the control slowly and not jerkily. To
stop the float machine movement return the
control levers to the rest position. The control
lever positions and the relevant movements are
described on page 3 of this manual.
5.4. Use
For reasons of stability it is
recommended to use th e machine on a
flat, stable and horizontal surface. Do
not use the machine on slopes of more
than 4%-5% gradient.
During th
e working phases, be
particularly careful not to l ose control of
the float machine (for example, due to
too much water on the surface to be
worked).
Check that there are no obstacles or
obstructions on the working surface or
projecting parts which may hinder
rotation of the blades
Preparing the surface:
Use a mechanical vibrating float or manual float to
level the floor surface in order to obtain a wellcompacted concrete f ooting and thus prep are the
ideal surface for floating and finishing. The float
machine does not improve planarity of a badly
floated or levelled floor.
Floating phase:
IMPORTANT: Before starting the
floating operation, check that the floats
have been mounted correctly on the
blades (Par. 7.5)
The floor is ready for the first pass when the
imprint of the shoe heel sinks into the concrete by
about 2-3 mm when walking on it.
The floating pass i ntervals depend on th e am bient
factor, temperature and atmospheric conditions
(cold or hot season). On averag e about 250-300
m
2
of surface are floated in 10 minutes.
When the concrete is still fresh, take care not to
work continuously on the same spot since,
considering the weight of the float machine, you
might cause damage to the planarity of the floor
surface.
During the floating phase the floats must not
bounce on the surface; this might be caused by
dirt between the blades and the floats
(if necessary, clean them after you have finishe d
work following the instructions given in the
paragraph on cleaning).
Finishing phase
When floating has been completed, detach the
floats from the blad es and clean the cement that
has collected during the floating phase off the
blades, the spider and the pr otection r im . Tur n the
blade-lifting knob clockwise (Fig. 4 No.1 and 2)
until the blades are inclined b y about 1 cm for the
first pass; for the subsequent smoothing
operations continue increasing the blade
inclination until obtaining the desired finish.
Once again, the tim e between one pass and the
next is determined b y the atmospheric conditions
(hot or cold season) and by the amount of water in
the concrete. If the concrete has hardened too
quickly in some areas, it can be moistened by
spraying a small amount of wat er using the b utton
(Fig. 9 No.5) located on the contr ol bars in order
to obtain the degree of finish desired.
IMPORTANT: Switch off the engine
after each operation. Never leave the
float machine standing with the engine
running, especially during the floating
phase when the concrete is still fresh.
5.5. Stopping
For more specific information on
stopping consult the engine instruction
manual.
(fig.9) To stop the float machine move the
accelerator (2); close the fuel cock and remove
the start key from the control panel (3).
5.6. Stopping in emergency conditions
the seat is connected to a m icro switch which cut
the electric power to the engine; in case of an
emergency, malaise or when losing control of the
float machine, immediately stand up.
6. Handling and transport
Horizontal movements
The float machine can co mfortably be moved on
horizontal surf aces on c onstruc tion sites usin g the
special trolley.
1. Pull the key out of the control panel.
2. Holding the handle of the trolley raised,
position it on the flo at machine straddling
the engine in such a way that the two
hooks near the wheels slide underneath
the protection rim until slipping into the
catch found under the bar of the rim.
3. Lower the handle of the trolley towards
the ground until the pivoting wheel
touches the floor and, holding the trolley
firmly down with the feet or with one hand,
hook it to the protection rim of the float
machine.
4. Move the machine by pushing or pulling
the handle until arriving at the new place
of work.
5. To unhook the trolley detach the hook
from the catch.
The moment the float machine is
unhooked from the trolley, it jolts upward
due to the effect of the machine weight;
therefore, firmly hold the trolley handle
during this operation.
Vertical movements
Never leave the floats attached to the
float machine when lifting it more than
100 cm off the ground since it could
detach and cause damage to persons
and things.
Lift the float machine us ing the lifting attac hments
(fig. 7 No. 2).
To lift the machine from one le vel to a noth er us e a
hoisting crane or lift truc k of suitable capac ity with
respect to the weight indicated in the technical
characteristics.
To transport the machine on a truck place the
blades in horizontal position using the control
knobs; transporting the float machine with the
blades inclined may damage the blade lifting
system.
7. Maintenance
1. All the m aintenance, inspection
and cleaning operations of the
machine must be carried out only
when the machine is off and cold.
2. Pull out the start key.
3.
Before proceeding with
maintenance, thoroughly clean the
float machine.
4. W hen the blades are worn they
may become sharp. Therefore,
during all the maintena nce phases,
wear protective gloves and pay
particular attention to their position.
7.1. Engine maintenance
See the engine use and maintenance manual.
7.2. Machine maintenance
The hydraulic float m achine m odel MK8 120 does
not require any particular maintenance,
nonetheless it is good practice to do the following:
Daily operations
1. W hen you have finished wor k, thoroughly
clean off the encrustations that have
accumulated on the f loat machine during the
working phases.
2. Clean the engine air filter, especially if
working in dusty conditions (follow the
instructions in the engine manual).
3. Check tightness of the screws and bolts
of the protection guards and the blades and,
if defective, replace them.
Weekly operations
1. Check wear and tensioning of the belts:
grease the cardan shafts.
2. Check the batter y charge and the level of
water in the cells, if necessary, top up
with distilled water only.
3. Clean any oxidation off the two battery
poles.
Operations after 100 hours of work
Check the oil level in t he t wo red uction gears (see
Par. 7.8).
Once the power trowel guarantee has expired, the
machines should be subjected to a complete checkup once a year. You can address to all our
authorized dealers all a r ound the world.
Barikell srl will refuse all responsibility in case of
incident whenever the check-ups won’t be done.
7.3. Battery
If the machine is not used for a long period of
time, disconnect the battery removing the cable
terminal from the positive pole (Fig.9 No.4). For
maintenance consult the instruction and use
leaflet of the battery.
IMPORTANT:
Recharge the battery in a dry place.
Protect the contacts fr om dirt and water
stagnation. Do not spray with water
Replacing the battery ( fig. 8)
Handle the battery with particular care
since it contains acid;
1. Remove the protective cover unhooking
the two hooks.
2. Remove the connection terminals (3 and
4) and take care to first remove the
negative one (3) in order to prevent a
short-circuit.
3. Extract the batter y (1) and replace it with
one with the same characteristics (45 Ah)
Dispose
of the battery in the
appropriate manner in accordance
with the regulations in force in the
country of use.
7.4. Cleaning the machine
Clean the float machine at the end of each
working day to prevent that cement hardens and
forms encrustations on the machine. Wash the
dirty parts with a brus h and water. Wet the parts
exposed to cement with “s tripping” oil (never fuel
oil). Do not oil the rubber moving parts (belts,
etc.).
7.5. Replacing the floats
Be careful when ins talling the machine: one r otor
turns clockwise and the other anticlockwise,
therefore you need to check that the various
components have been properly arranged.
Before mounting the floats, check that the blades
are clean, i.e. that there are no traces or residues
of cement mixes. The blades must be placed in
horizontal position using the knobs (Fig.4 No.1
and 2).
To replace the floats proceed as follows:
Slightly lift the float m achine off the gr ound (about
10 cm).
Mount the floats on the blades checking the
correct direction of rotation.
When the floats have been mounted, reposition
the float machine on the ground.
7.6. Replacing the blades
Always check the state of wear of the blades and
if they are damaged or bent, replace them. For
proper functioning they need to be replaced
entirely.
To replace them proceed as follows (Fig.10):
− Clean any working residue off the
float machine.
− Open the guard (2) by unscrewing
the two fixing bolts ( 1) and hook the guard to
the chain (3).
− Slightly lift the float machine off the
ground (about 10 cm).
− Remove the fixing bolts (5) of the
blades (4) on each arm.
− Mount the new blades f ixing the bolts
with the respective split washers (check the
state of the bolts and replace them if
necessary).
− When the blades have been
mounted, reposition th e float machine on the
ground.
− Reposition the guard (2) a nd tighten
the bolts (1).
7.7. Replacing the belts
(Fig.11) To replace the belts, operate as follows:
− Dismantle the belt protection guard
(2).
− Slightly lift the flo at machine off the
ground (about 10 cm ) in order to be able to
freely turn the pulley and t he clutch and thus
easily remove and replace the belts.
− Remove the worn belts and replace
them with others of the same size.
− Reposition the float machine on the
ground.
− Reposition the guard (2).
7.8. Reduction gear oil level
To check the oil level in the reduct ion g ears f ollo w
the instructions below:
(Fig.12) There are two caps on t he s ide of the two
reduction gears; the top c ap (1) determ ines the oil
level in the gearbox . Pa y par ticular attent ion when
you notice oil in the lower part of the float
machine; clean and chec k where the leak comes
from and take the appropriate action.
Should the oil need to be topped up, use Mobil
Glygoyle 30 synthetic oil or similar.
7.9. Storage instructions.
Never store the mac hine with f uel in the
tank in pla
ces where the fuel vapors
might come into contact with flames
and/or sparks
If you can foresee that the machine will not be
used for more than one m onth, drain t he fuel f rom
the tank in order to prevent the formation of
rubbery deposits, and detach the battery.
If storing the machine in places where the
temperature might drop to belo w 0°C drain out th e
water tank.
7.10. Troubleshooting
ANOMALIA
PROBABILE CAUSA
RIMEDIO
The float machine leaks
oil
Too much oil in reduction gear
Unscrew the cap
The screws of the reduction gear
covers are loose
Tighten the screws
Defective gaskets
Contact our technical service
Oil seal on central and side shaft worn
Contact our technical service
Oil leaks from engine
Contact our technical service
The engine does not start
No fuel
Fill the tank with the fuel indicated for
the engine used
Fuel cock closed
Open the fuel cock
()
Fuel filter clogged
Replace the filter
()
Choke fully open
Close the choke
()
Air filter dirty
Clean the air filter
()
No spark
Clean the spark plug and replace it if
necessary
()
Check the plug connection
()
Ignition difficulty, engine flooded
Unscrew the spark plug and dry it
()
Battery flat
Recharge or replace the battery (Par.
7.3)
Emergency stop on
Turn emergency stop off
Drop in engine rpm
Accelerator cable broken or bent
Replace the accelerator cable
Engine problems
Contact our technical service
Carburetor dirty
Contact our technical service
Air filter dirty
Clean or replace the air filter
()
The float machine does
not move forward and
backward
Tie rod broken
Replace tie rod
Fork pin broken or slipped off
Replace pin or fork
Bascule support jammed
Clean bascule support
The float machine does
not steer left or right
Ball joints broken
Replace ball joints
Rim supports broken
Replace rim supports
Steering supports out of place
Adjust steering supports
The blades do not lift
Steel cord broken
Replace blade-lifting cord
Steel cord nut lacking
Fit nut
Fork broken
Replace fork
The float machine
bounces on the floor
Cement hardened under spider or
blades
Clean the spider and the blades
Blades not evenly worn
Adjust the blade inclination
Central shaft bent
Contact our technical service
Drive control not perfectly vertical
Adjust the drive control position
Blades maladjusted
Adjust the blades
When the engine is
revved up the rotors do
not turn
Driving belts slack and/or worn
Tighten the driving belts (see Par.7.7) or
replace them
Clutch lining worn
Replace the lining
()
See engine use and maintenance manual
8. DISPOSAL
In the event of disposal comply
with the regulations in for ce in the
country where this operation is
carried out..
9. GUARANTEE
All new machines sold are covered by guarantee
for the structure and the u se of suitable materials
on the following conditions:
1) The guarantee is vali d for a period of t welve
(12) months.
2) The manufacturer undertakes to repair or
replace at his own discr etion those parts or
units that are found to be defective.
3) The parts repaired or replaced are covered
by the same guarantee as the original parts,
hence with validity of t welve m onths after t he
parts have been fitted.
4) The manufacturer reserves an appropriate
time to execute the work necessary and
deliver the spare parts.
5) All the transport expenses for the
replacement parts covered b y this guarantee
are at the expense of the purchaser.
6) Any repairs or operations carried out during
the period of guarantee by unauthorised
persons shall lead to forfeiture of the
guarantee.
7) During the period of guarantee the parts
replaced become the property of the
manufacturer.
8) For components not m anufactured b y us the
conditions of guarantee of the original
suppliers are valid. An y claims will hence be
transferred to the purchaser.
9) This guarantee is valid sol ely for the original
purchaser. Our liability expires:
a) the moment the original owner transfers
ownership of the machine
b) if modifications are made to the machine
c) if parts and devices not manufactured b y
us are added to the machine.
10) We do not undertake any liability for any
damage caused to the floor by bad
functioning or stopping of the float machine
during the working phases.
11) The guarantee does not cover damages
deriving from excessive stress (e.g.
continuing to operate the machine after
ascertaining a fault), improper use or
maintenance, use of unsuitable working
materials as well as failed obser vance of the
instructions for use. The same is valid for
damage caused by normal wear.
12) For the engines, the cond itions of guarantee
of the original suppliers are valid.
13) T he conditions of guarantee establis hed are
binding for all Barik ell Srl dealers. Any other
agreements will be considered valid only if
confirmed in writing by Barikell Srl.
14) The manpower and work required to replace
defective parts are at the expense of the
customer.
NOTES
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
………………………………………………………………………………………………………………………………
Loading...
