OIL FURNACE

INSTALLATION INSTRUCTIONS

MODELS

FH085D36E FH110D48E FH110D60E
FLF085D36E FLF110D48E FLF110D60E
FLR085D36E FLR110D48E FLR110D60E
FLR140D60E FC085D36E

WARNING

READ ALL INSTRUCTIONS CAREFULL Y BEFORE BEGINNING THE
INSTALLATION.

THIS INST ALLATION MUST COMPL Y WITH THESE INSTRUCTIONS AND
THE REQUIREMENTS OF ALL GOVERNING CODES AND ORDINANCES FOR
THE INST ALLATION LOCA TION.

IT IS THE RESPONSIBILITY OF INSTALLER TO KNOW AND UNDERSTAND
ALL OF THESE REQUIREMENTS.

F AILURE TO DO SO COULD CREATE A HAZARD RESUL TING IN PROPER TY
DAMAGE, BODIL Y INJURY OR DEATH.

FOR YOUR SAFETY

DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE V APORS OR
LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.

IMPORTANT NOTICE

THIS FURNACE IS NOT INTENDED FOR USE AS A CONSTRUCTION
HEA TER. USE OF THIS FURNACE DURING CONSTRUCTION AND FINISHING
PHASES OF A STRUCTURE IS CONSIDERED AS "OPERA TION IN A
CORROSIVE A TMOSPHERE" AND "UNUSUAL, NEGLIGENT OR IMPROPER
USE" AND AS SUCH ARE CONSIDERED EXCLUSIONS BY THE BARD
MANUFACTURING COMPANY LIMITED WARRANTY.

Bard Manufacturing Company
Bryan, Ohio 43506

Since 1914...Moving ahead just as planned.

Manual: 2100-422B
Supersedes: 2100-422A
File: VOL. I, TAB 3
Date: 09-23-03

Copyright 2003

CONTENTS

Getting Other Information and Publications .........1

Installation and Operating Instructions

Equipment Selection...............................................2

Locating the Furnace..............................................2

Installing the Furnace .............................................6

Duct Work...............................................................6

Installing a Cooling Unit..........................................6

Wiring ...............................................................7

Oil Line Piping ......................................................10

Beckett AFG Oil Burner ........................................10

Beckett “CleanCut” Oil Pump ............................... 11

Beckett Solid State Igniter ....................................11

Beckett R7184B Primary Control.......................... 11

Beckett R7184B Primary Operational Guide ........12

Burner Set up and Adjustments ........................... 14

Short Form Adjustment Procedure .......................16

Combustion Air Requirements..............................20

Louvers and Grilles...............................................25

Venting Options ....................................................25

Thermostat ...........................................................25

T ABLES

Table 1 Minimum Clearances ............................. 2

Table 2 Dimensions FLF/R Models.................... 3

Table 3 Electrical Data ........................................ 7

Table 4 Furnace Data ....................................... 14

Table 5 Correlation of % of CO

Reserve Air .......................................... 19

, O2 and

2

Table 6 No. 2 Fuel Oil Efficiency Chart ............. 19

T able 7 Recommended Start-Up Settings ........ 19

Table 8 Sq.Ft. Required as

Unconfined Space................................ 22

Table 9 Minimum Ventilation Openings............. 23

Table 10 Temperature Rise Ranges, Limit

Control Settings, and

Heating Blower Speeds........................ 26

Table 11 Filter Sizes for Gas Furnaces............... 27

CHARTS

Chart 1 FH085D36E Data................................. 33

Chart 2 FH1 10D48E Data ................................. 33

Chart 3 FH1 10D60E Data ................................. 33

Chart 4 FLF/FLR085D36E Data ....................... 33

Chart 5 FLF/FLR1 10D48E Data ........................ 33

Chart 6 FLF/FLR1 10D60E Data ........................ 33

Chart 7 FLR140D60E Data............................... 34

Chart 8 FC085D36E Data................................. 34

Filters

Upflow & Counterflow Filter Information .............237

Lo-Boy Models – Filter Locations .......................28

Maintenance

Lubrication ............................................................29

Inspect Air Filter....................................................29

Final Inspection and Test......................................29

Service Hints ........................................................29

Combination Combustion Chamber/Burner

Mounting System..................................................30

To Remove Burner Only .......................................31

To Remove Entire Combustion Chamber

Mounting System..................................................31

Common Causes of Trouble.................................32

Care of Finish .......................................................32

Cleaning of the Heat Exchanger...........................32

Blower System Resistance Charts ................. 33-34

Wiring Diagrams............................................. 35-37

FIGURES

Figure 1 FL/R Models Dimensions................... 3

Figure 2 FH Models Dimensions...................... 4

Figure 3 FC Models Dimensions...................... 5

Figure 4 T ypical Unit Setup - FLF .................... 8

Figure 5 T ypical Flue Installation

Requirements - FLF........................... 9

Figure 6 T ypical Single Inside

Tank Installation ............................... 10

Figure 7 Electronic Blower Control ................ 13

Figure 8 T ypical Smoke-CO

Characteristic... 17

2

Figure 9 Pressure Gauge Connection to

Pressure Gauge Port....................... 18

Figure 10 Electrode Adjustments..................... 20

Figure 1 1 Combination Air Boot Assembly ...... 21

Figure 12 All Air From Inside Building.............. 22

Figure 13 All Air From Outdoors ...................... 23

Figure 14 All Air From Outdoors Through

Ventilated Attic................................. 24

Figure 15 All Air From Outdoors - Inlet Air

From Ventilated Crawl Space and

Outlet Air to Ventilated Attic............. 24

Figure 16 T ypical Installation of 16x25x1

Filter Rack........................................ 27

Figure 17 T ypical Installation of 20x25x1

Filter Rack........................................ 27

Figure 18 Filter Installation - Lo-Boy Models ... 28

Figure 19 Removal of Burner Only .................. 30

Figure 20 Removal of Entire Combustion

Chamber Mounting System ............. 31

i

GETTING OTHER INFORMA TION and PUBLICATIONS

These publications can help you install the furnace. You
can usually find these at your local library or purchase
them directly from the publisher. Be sure to consult
current edition of each standard.

National Fuel Gas Code ........... ANSI Z223.1/NFPA54

National Electrical Code ...................... ANSI/NFPA 70

Standard for the Installation .............. ANSI/NFPA 90A

of Air Conditioning and Ventilating Systems

Standard for Warm Air...................... ANSI/NFPA 90B

Heating and Air Conditioning Systems

Standard for Chimneys, Fireplaces, Vents ... NFPA 211
and Solid Fuel Burning Appliances

Load Calculation for .......................... ACCA Manual J

Residential Winter and Summer Air Conditioning

FOR MORE INFORMATION, CONTACT
THESE PUBLISHERS:

ACC A Air Conditioning Contractors of America

1712 New Hampshire Ave. N.W.
Washington, DC 20009
Telephone: [phone]
Fax: [phone]

ANSI American National Standards Institute

11 West Street, 13th Floor
New York, NY 10036
Telephone: [phone]
Fax: [phone]

ASHRAE American Society of Heating Refrigerating,

and Air Conditioning Engineers, Inc.

1791 Tullie Circle, N.E.
Atlanta, GA 30329-2305
Telephone: [phone]
Fax: [phone]

Duct Design for Residential .............. ACCA Manual D

Winter and Summer Air Conditioning
and Equipment Selection

NFPA National Fire Protection Association

Batterymarch Park
P.O. Box 9101
Quincy, MA 02269-9901
Telephone: [phone]
Fax: [phone]

Manual 2100-422
Page 1

INST ALLATION and OPERA TING INSTRUCTIONS

EQUIPMENT SELECTION

An accurate heating load calculation must be conducted
using American Society of Heating, Refrigeration and
Air Conditioning Engineers (ASHRAE) or Air
Conditioning Contractors of America (ACCA) manuals.
Do not add a large safety factor above the calculated
value. If the calculated heating load requirement
exceeds the heating capacity rating of a given model,
use only the next larger size available. Never increase
by any more than absolutely necessary based upon
available equipment heating capacities. Always select
based upon heat capacity (output), never use input
capacities.

NOTE: It is the personal responsibility and

obligation of the purchaser to contract a
qualified installer to assure that installation
is adequate and is in conformance with
governing codes and ordinances.

LOCATING THE FURNACE

When installing the furnace be sure to provide adequate
space for easy service and maintenance. Locate the
furnace as close to the chimney as practical, giving
consideration to the accessibility of the oil burner,
controls, and blower for service. Allow a minimum of
24 inches at front of furnace for servicing oil burner.
Allow adequate room for filter and blower
maintenance. Clearance from combustible material as

stated on the furnace and repeated in Table 1 must be
maintained. For damp basement installations, a raised

concrete pad is recommended. This will help keep the
bottom of the furnace dry and reduce the risk of rusting.

An oil burner must have a generous supply of
combustion air to operate properly. The flow of
combustion and ventilating air must not be obstructed
from reaching the furnace. See “Combustion Air
Requirements” section.

The furnace area must be kept clear and free of
combustible materials, gasoline and other flammable
vapors and liquids.

This unit is not designed for mobile home or trailer
installations. Always install furnace in a level position.

TABLE 1

MINIMUM CLEARANCES

sehcnI—secanraelCnoitallatsnImuminiM

1

ledoM

E63D580HF
E84D011HF
E06D011HF

E63D580CF

j

For the first three (3) feet from plenum. After three (3) feet, no clearance required.

C

Combustible flooring

NC

Noncombustible floor

*

Maintained on one side or the other to achieve filter access and/or blower service.

**

Floor must be noncombustible. For furnace only installation can be installed on combustible
flooring only when installed on special base part no. CFB7 available from factory. When air
conditioning coil cabinet DCB23-22 is used then use special base part no. CFB23.

4
4
4

6

E63D580FLF

6

E63D580RLF

6

E84D011FLF

6

E06D011FLF

6

E84D011RLF

6

E06D011RLF

6

E06D041RLF

6

1
1
1

0

81
0
0

81

81

81

1

2
2
2

2
2
2
2

2
2
2
2

2
2
2

2
2
2
2

2
2
2
2

2
2
2

2
2
2
2

2
2
2
2

tcuD

2
2
2

2
2
2
2

2
2
2
2

eulF
epiProolFtnorFkcaBsediSpoTsediStnorFkcaBsediS

9
9
9

9
9
9
9

9
9
9
9

C
C
C

CN
CN
CN
CN

CN
CN
CN

CN **

ecivreSmuminiM

secnaraelCecanruFmunelP

—

42

—

42

—

42

42
42
42
42

42
42
42

—

42

—
—
—

42
42
42
42

42
42
42

*81
*81
*81
*81

*81
*81
*81

—

Manual 2100-422
Page 2

Manual 2100-422

Page 3

FIGURE 1

FLF/R MODELS DIMENSIONS

C

A

H

OIL

ENTRANCE
OPTIONAL

OIL

ENTRANCE

OPTIONAL

LOW VOLTAGE

ENTRANCE

OPTIONAL

HIGH VOLTAGE

ENTRANCE

"FLF" FLUE

KNOCKOUT

REAR FLUE

ON "FLR" MODELS

FILTER

DOOR

FRESH AIR

KNOCKOUT

B

"FLF" FLUE

KNOCKOUT

LOW VOLTAGE

ENTRANCE

HIGH VOLTAGE

ENTRANCE

OPTIONAL

OIL ENTRANCE

FLF/FLR 085, 110 AND 140

SPECIFICATION SHEET

MIS-1815 A

EF

G

D

J

"FLF" FLUE
KNOCKOUT

RETURN

DUCT

SUPPLY

DUCT

RIGHT SIDE VIEWFRONT VIEWLEFT SIDE VIEW

TOP VIEW

j

Washable type filter 1” nom. thickness

TABLE 2

FLF/R MODELS DIMENSIONS (INCHES)

ledoM

rebmuN

tenibaC

munelP

sgninepOnoitcenoCeulFsretliFriA 1

A

htdiW

B

htpeD

C

thgieH

ExD

ylppuS

FxD

nruteRnoitacoL

G

.aiDHJ eziS

.oN
desU

E63D580FLF
E63D580RLF

32
32

521.84

521.84

526.63

526.63

02x22
02x22

41x22
41x22

tnorF

raeR

6
6

526.13

526.13

521.5

521.5

1x02x61
1x02x61

1
1

E84D011FLF
E06D011FLF
E84D011RLF
E06D011RLF

32
32
32
32

521.84

521.84

521.84

521.84

526.04

526.04

526.04

526.04

02x22
02x22
02x22
02x22

41x22
41x22
41x22
41x22

tnorF

tnorF
raeR
raeR

6
6
6
6

526.53

526.53

526.53

526.53

521.5

521.5

521.5

521.5

1x02x02
1x02x02
1x02x02
1x02x02

1
1
1
1

E06D041RLF62052.05526.7402x5261x52raeR6521.24---1x52x021

Manual 2100-422

Page 4

FIGURE 2

FH MODELS DIMENSIONS

53" (FH085)

59" (FH110)

23"

VESTIBULE

DOOR

FRONT VIEW

30 1/2"

21 7/8"

19 7/8"

FLUE

KNOCKOUT

SUPPLY

OPENING

FH085 AND FH110

SPECIFICATION SHEET

19 1/4"

16"

RETURN

OPENING

(CUT OUT)

OPTIONAL

OIL

ENTRANCE

OIL

ENTRANCE

FRESH AIR
KNOCKOUT

OPTIONAL

HIGH VOLTAGE

ENTRANCE

OPTIONAL

LOW VOLTAGE

ENTRANCE

FLUE

KNOCKOUT

RETURN

OPENING

(CUT OUT)

LEFT SIDE VIEW

TOP VIEW

OPTIONAL

OIL

ENTRANCE

LOW VOLTAGE

ENTRANCE

FLUE

KNOCKOUT

HIGH

VOLTAGE

ENTRANCE

RIGHT SIDE VIEW

REAR CLEANOUT

DOOR

MIS-1814 A

FC085

FIGURE 3

FC085 MODEL DIMENSIONS

21 7/8"

19 7/8"

SUPPLY
OPENING

SPECIFICATION

SHEET

FLUE

KNOCKOUT

OPTIONAL

HIGH VOLTAGE

ENTRANCE

OPTIONAL

LOW VOLTAGE

ENTRANCE

OIL ENTRANCE

OPTIONAL

OIL ENTRANCE

23"

30 1/2"

TOP VIEW

FLUE
KNOCKOUT

54 1/4"

FLUE
KNOCKOUT

REAR

CLEANOUT

DOOR

LOW VOLTAGE
ENTRANCE

HIGH VOLTAGE
ENTRANCE

FRESH AIR

KNOCKOUT

LEFT SIDE VIEW

RETURN
OPENING

BOTTOM VIEW

FRONT VIEW

19 1/8"

OPTIONAL
OIL ENTRANCE

RIGHT SIDE VIEW

18 1/8"

MIS-1826

Manual 2100-422
Page 5

INSTALLING THE FURNACE

INSTRUMENTS REQUIRED FOR PROPER
SETUP OF THE FURNACE

It is important that a set of instruments capable of the
following requirements be used for the setup of this
furnace to ensure proper and safe operation:

1. Oil pump pressure gauge that measures up to
150 PSI.

2. Smoke gun to pull smoke samples from flue.

3. Draft gauge that will measure -.02” water column
(W.C.)

4. Duct static pressure gauge 0-1.0” W.C. range.

5. Temperature gauge that can read from 50° F up to
700° F.

6. A gauge to measure CO2 or O2.

DUCT WORK

The air distribution system should be designed and
installed in conformance with manuals published by Air
Conditioning Contractors of America (ACCA) as set
forth in Manual D, or ASHRAE publications.

IMPORTANT

When a furnace is installed so that supply
ducts carry air circulated by the furnace to
areas outside the space containing the
furnace, the return air must also be handled
by a duct(s) sealed to the furnace casing and
terminating outside the space containing the
furnace This is to prevent drawing possible
hazardous combustion products into the
circulated air.

INSTALLATION

A typical installation is shown in Figures 4 and 5. All
parts of the furnace installation (furnace, oil tank and
piping systems, combustion and ventilation air, venting,
etc.) must comply with NFPA31, Installation of Oil
Burning Equipment -- latest edition. This drawing
shows the typical connecting parts needed to correctly
install this furnace. Make sure that all parts of the
heating system comply with the local codes.

Check the furnace and your load calculation to verify
that the unit is properly sized. (Refer to Equipment
Selection” section on Page 2.)

The correct size of unit needed may be substantially
smaller than the unit being replaced due to home
improvements and technology advancements since the
initial installation.

INADEQUATE SUPPLY AIR and/or RETURN
AIR DUCT SYSTEMS

Short cycling because of limit control operation can be
created by incorrectly designed or installed supply and/
or return air duct systems.

The duct systems must be designed using ASHRAE or
ACCA design manuals and the equipment CFM and
external static pressure ratings to insure proper air
delivery capabilities.

On replacement installations, particularly if equipment
is oversized, the duct systems can easily be undersized.
Modifications may be required to assure that the
equipment is operating within the approved

temperature rise range when under full rated input
conditions, and that no short cycling on limit controls is

occurring.

INSTALLING A COOLING UNIT

When the furnace is used in connection with a cooling
unit*, the furnace shall be installed parallel with or on
the upstream side of the cooling unit to avoid
condensation in the heating element. With a parallel
flow arrangement, the dampers or other means used to
control flow of air shall be adequate to prevent chilled
air from entering the furnace, and if manually operated,
must be equipped with means to prevent operation of
either unit, unless the damper is in the full heat or cool
position.

* A cooling unit is an air conditioning coil, heat

pump coil or chilled water coil.

When installing a cooling unit above an FH or FL
(below on an FC) series furnace, the coil must be
spaced far enough from the furnace outlet to assure
proper operation of the furnace. Bard supplied coils,
when used with Bard supplied coil cabinets, are
automatically positioned.

For top discharge FH and FL models, when coils are
installed without using Bard coil cabinets or coils of
another brand are used, the coil drain pan should be
located a minimum of two (2) inches above the top of
the furnace cabinet. If a greater clearance is specified
by the coil manufacturer then it would apply.

NOTE: IF DRAIN PAN IS ANYTHING OTHER

THAN A STEEL PAN PARTICULAR
ATTENTION MUST BE GIVEN TO THE
INSTALLATION INSTRUCTIONS FOR
THE COIL TO MAKE SURE IT IS
ACCEPTABLE FOR USE WITH THESE
OIL FURNACES HAVING MAXIMUM
OUTLET AIR TEMPERATURE OF 200° F.

See CFM versus static pressure curves on pages 33-36
for additional information.

Manual 2100-422
Page 6

WIRING

FIELD WIRING

FACTORY WIRING

All units are fully factory wired. Multispeed blowers
are factory wired on high speed for cooling/manual fan
operation. Heating speeds are wired for the largest
input and may need lower speed for field installed low
input nozzle. If replacement wire is necessary, use 105
degrees C minimum. See electrical data, Table 3.

ELECTRICAL DATA

latoT

ledoMHP-ZH-stloV

E63D580HF1-06-5112.93/15.77/17.15151

E84D011HF1-06-5112.212/15.017/17.16102

E06D011HF1-06-5112.414/35.217/17.19102

E63D580FLF1-06-5113.713/16.57/17.15151

E63D580RLF1-06-5113.713/16.57/17.15151

E84D011FLF1-06-5112.212/15.017/17.16102

E84D011RLF1-06-5112.212/15.017/17.16102

E06D001FLF1-06-5112.414/35.217/17.19102

E06D001RLF1-06-5112.414/35.217/17.19102

E06D041RLF1-06-5112.414/35.217/17.19102

E63D580CF1-06-5113.73/16.57/17.15151

spmA

PHALFPHALF

All wiring must conform to the National Electrical
Code and all local codes. A separate fuse or breaker
should be used for the furnace.

TABLE 3

rotoMrewolBrotoMrenruB

emiT.xaM

muminiM

tiucriC

yticapmA

esuFyaleD

RCAHro

rekaerBtiucriC

Manual 2100-422
Page 7

FIGURE 4

TYPICAL UNIT SETUP

FLF UNIT SHOWN

WARNING

ALL WIRING MUST

CONFORM TO THE

NATIONAL ELECTRIC

!

CODE AND ALL LOCAL

Left side
high voltage
(unit power)
entrance

Left side
low voltage
(thermostat)
entrance

Left side oil
line entrance
for opt. air boot

Left side
oil line
entrance

CODES.

TYPICAL UNIT

SETUP

(FLF UNIT SHOWN)

Inspection
door

Right side
low voltage
(thermostat)
entrance

To thermostat
and optional
A/C unit

Oil line
(see burner
pump inst. for
hookup info.)

Air Boot
knockout
(optional)

Control panel
(junction box
in FH units)

Manual 2100-422
Page 8

Right side
high voltage
(unit power)
entrance

Right side
oil line
entrance

To power
source

Shut off switch
(if not fused,
power line must
include fuse or
circuit breaker)

Power Wires:
Black (HOT)
White (NEUTRAL)
Green (GROUND)

MIS-1836

FIGURE 5

TYPICAL FLUE INSTALLATION REQUIREMENTS

FRONT FLUE LOWBOY MODEL SHOWN

(REPRESENTS ALL MODELS)

L
n

e
d

C

h

Thimble

INSTALLER NOTE:

Follow all appropriate

standards for installing

needed venting system.

Draft Regulator
(Be sure to follow
installation inst.

1/4 inch per

1 foot rise

i

supplied with
regulator).

90° Rotatable
Flue Box on front
flue models
(remove appropriate
cabinet knockout).
Mounting screws
located under flue
box cover.

Flue Box
Cover

Clean-out Door
(keep closed)

m

n
e
y

i

Optional Fresh
Air Boot (remove
rect. knockout).

Optional
Flue
Locations

Oil Burner

MIS-1825

Manual 2100-422
Page 9

OIL LINE PIPING

First determine whether the pipe system is to be a single
line system or a two line system. All connections must
be absolutely air tight or you will have a malfunction of
the burner. When installing the piping, a good oil filter
should be installed close to the burner. A single line
system is recommended for gravity feed.

A typical single inside tank installations shown in
Figure 6. For installation details for this and other tank
configurations, refer to NFPA31 -- latest edition. All
tank and pipe setups must comply with NFPA31.

TYPICAL SINGLE INSIDE TANK INSTALLATION

Vent Cap

BECKETT AFG OIL BURNER

This furnace is equipped with a high static Beckett AFG
oil burner which is designed to produce adequate draft in
nearly any vertically vented application. The burner
employs the latest time tested controls of the highest
quality. The controls consist of a high voltage Beckett
solid state igniter, a Beckett “CleanCut” oil pump with
an integral solenoid valve, and a Beckett R7184B
primary control.

FIGURE 6

2" Cap

1-1/4"
Vent Pipe

Oil
Tank

2" Fill Pipe

Return Line

Guage

Bushing,
2" x 1-1/2" or
1-1/4"

Gate Valve
3/8" x 4"

nipple

6"

3/8" x 3/8"
Adapter

Legs (either 1-1/4"x10"
or 1-1/2"x10" nipples)

Manual 2100-422
Page 10

Bushing

Oil Filter

3/8" O.D. Copper
Fuel Tubing

MIS-1823

These controls were selected for their proven high
quality, dependability, and serviceability. With proper
maintenance this burner assembly will provide many
years of reliable service.

All units are shipped with the oil burner installed, and
with high rate oil nozzle installed designed for use with
No. 1 or No. 2 fuel oil. Inspect firepot refractory

before firing to be sure it has not been jarred out of
position in shipment. Burner air tube must not
extend beyond inside surface of firepot. Burner
head should be centered on the combustion chamber
opening. See Figures 19 and 20.

WARNING

Never attempt to use gasoline in your furnace.
Gasoline is more combustible than fuel oil and
could result in a serious explosion causing
damage, injury or death.

BECKETT SOLID STATE IGNITER

This igniter differs from the traditional iron core
transformer in that it produces a 14,000 volt spark
instead of a 10,000 volt spark of the iron core
transformer. This hotter spark provides for cleaner,
faster ignitions. Being solid state technology this
igniter is less susceptible to problems caused by voltage
variations. It also has a greater ability to ignite cold
and/or inconsistent oil. The solid state igniter is wired
to the primary control the same as an iron core
transformer.

BECKETT R7184B PRIMARY CONTROL

The R7184B Interrupted Electronic Oil Primary is a
line voltage, safety rated, interrupted ignition oil
primary control for residential oil burners. The R7184B
used with a cad cell flame sensor, operates the oil
burner and oil valve. The primary controls fuel oil,
senses flame, controls ignition spark and is designed to
notify a remote alarm circuit before going into lockout
when equipped with a flame monitoring system.

The following is a detailed explanation of each control
included in the Becket AFG Oil Burner, how each
operates, how to set up the burner, and how to
troubleshoot problems should they occur.

BECKETT “CLEANCUT” OIL PUMP

This oil pump is equipped with an oil solenoid valve
installed in the pump housing. This feature provides
quick cutoffs resulting in reduction in smoke after the
burner shuts down. This is a time proven pump design
and is capable of both one and two pipe systems. This
pump requires a pre-purge style primary control such as
the R7184B primary. All installation and set up
instructions are outlined in the “Oil Pump
Specification” section of the installation instructions
manual.

This primary control possesses the latest technology, is
a very simple control to operate and provides additional
troubleshooting features to ease service and reduce
down time. The operational guide for the R7184B
primary control is provided following on
Page 12.

Manual 2100-422
Page 11

BECKETT R7184B PRIMARY

OPERATIONAL GUIDE

Pre-Purge Delay – 15 seconds on delay
LED Codes – Flashing 1/2 second on / 1/2 second off – system is locked out or in restricted mode

(hard lockout).

– Flashing 2 seconds on / 2 seconds off – control is in recycle mode (soft lockout).
– ON – CAD cell is sensing flame
– OFF – CAD cell is not sensing flame.

Ignition Trials – On any given call for heat the
control will allow three ignition trials. After the three
trials the control will go into a soft lockout mode. The
LED will flash 2 seconds on and 2 seconds off when
in this recycle mode. The control may then be reset
by pressing the RED reset button on the control. If
within the same original call for heat the control will
again allow three ignition trials followed by another
soft lockout and a 2 second on / 2 second off LED
code. The control my be reset one additional time by
pressing the red reset button. This will allow three
final ignition trials. If all three of the final ignition trials

Checking CAD Cell – With a call for heat and the burner ignited, press and release the red reset button. The
LED will go out and then flash 1, 2, 3, or 4 times before returning to the run mode. The CAD cell resistance
must be below 1600 ohms for proper operation.

– 1 flash – Less than 400 ohms
– 2 flashes – More than 400 and less than 800 ohms
– 3 flashes – More than 800 and less than 1600 ohms
– 4 flashes – More than 1600 and less than 5000 ohms

Burner Option – Flame Quality Monitor
This control is trained to recognize and remember a
good flame based on initial burner set up. Control
then monitors the flame via the CAD cell signal for
deviation in the combustion characteristics of the
burner. If the control senses a deviation on the high
side or on the low side from the original set up
condition for three consecutive cycles, it will trigger
an alarm circuit which can be tied to an audible local
device to signal the home owner or into the home
security system. Upon being notified of the of the

fail then the control goes into a hard lockout or
Restricted Mode. This series of ignition failures must
all occur with the original call for heat in order to
reach the Restricted Mode. The LED will now flash
1/2 second on / 1/2 second off indicating the
restricted mode. The control can be resurrected from
the restricted mode only by pressing and holding the
red reset button for approximately 30 seconds until
the LED flashes twice. Removing unit power or
resetting the thermostat will not reset the control

alarm, the security agency will notify the dealer of
choice based upon information supplied by the home
owner. The system will also be capable of being
connected to a phone line that will contact the dealer
directly with the alarm. This alarm will typical sound
3 to 5 days prior to the primary control going into
lockout giving the service agency a prior notice
before a sooting condition or other failure can occur
resulting in untold savings. This monitor system is
available through your local distributor under the
Honeywell part no. QS7100F.

Electronic Blower Control Board (EBC)

This furnace is equipped with an Electronic Blower
Control (EBC) which controls all comfort air blower
operations. This EBC has three relays; one for
heating speed, one for cooling speed, and one which
isolates the T–T signal from the oil primary control.

This EBC is designed to be very simple and
dependable. This basic control allows for easy
troubleshooting and maintenance. As illustrated in
Figure 7 all connections are well marked. The

Manual 2100-422
Page 12

blower on and off timings for both heating and
cooling speeds are timed automatically. The heating
blower off delay can be selected from four different
timings by moving the selection jumper. The timings
are as follows:

Heating Blower ON delay – 75 seconds from a call
for heat.

Heating Blower OFF delay – Selectable in seconds:
150, 180. 210 or 240. Factory shipped at 240.

Cooling Blower ON delay – 6 seconds from a call for
cooling.

Cooling Blower OFF delay – 60 seconds.

FIGURE 7

TRANSFORMER 24V
SECONDARY
CONNECTIONS

THERMOSTAT

CONNECTIONS

OIL PRIMARY T-T
CONNECTIONS

LINE VOLTAGE
CONNECTION (HOT)

UNUSED BLOWER MOTOR
SPEED CONNECTIONS

LINE VOLTAGE
CONNECTION (COM, L2)

ELECTRIC AIR
CLEANER CONNECTION

HUMIDIFIER

CONNECTION

HEATING BLOWER

SPEED CONNECTION

COOLING BLOWER

SPEED CONNECTION

3 AMP FUSE

HEATING BLOWER

OFF DELAY

ADJUSTMENT

IN SECONDS.

MIS-1819

ELECTRONIC BLOWER CONTROL

Manual 2100-422
Page 13

TABLE 4

FURNACE DATA

dradnatSdellatsnIecanruFnoitpOdellatsnIdleiF

s

2

1

elzzoN

rebmuNledoM

E63D580FLF57.000,501000,5856.000,19000,4755.000,77000,36

E63D580RLF57.000,501000,5856.000,19000,4755.000,77000,36

E84D011FLF00.1000,041000,31158.000,911000,69ANANAN

E84D011RLF00.1000,041000,31158.000,911000,69ANANAN

E06D011FLF00.1000,041000,31158.000,911000,69ANANAN

E06D011RLF00.1000,041000,31158.000,911000,69ANANAN

E06D041RLF52.1000,571000,24101.1000,451000,521ANANAN

E63D580CF57.000,501000,5856.000,19000,4755.000,77000,36

E63D580HF57.000,501000,5856.000,19000,4755.000,77000,36

E84D011HF00.1000,041000,31158.000,911000,69ANANAN

E06D011HF00.1000,041000,31158.000,911000,69ANANAN

j
k

eziS

70 degree hollow cone spray pattern, 100 PSIG pump pressure
Annual fuel utilization efficiency and heating capacity based upon U.S. Government standard

test using D.O.E. isolated combustion rating procedure.

tupnI

HUTB

gnitaeH

yticapaC

HUTB

BURNER SETUP AND ADJUSTMENT
PROCEDURES

All oil burner installations should be performed by a
qualified installer in accordance with regulations of the
National Fire Protection Standard for Oil-Burning
Equipment, NFPA31 -- latest edition, and in complete
compliance with all local codes and authorities having
jurisdiction. A qualified installer is an individual or
agency who is responsible for the installation and
adjustments of the heating equipment and who is
properly licensed and experienced to install oil-burning
equipment in accordance with all codes and ordinances.

The proper installation and adjustment of any oil burner
requires technical knowledge and the use of combustion
test instruments. The following procedure must be
followed to correctly adjust the burner to match the
specific characteristics of the installation.

IMPORTANT

1

2

elzzoN

eziS

tupnI

HUTB

1. PREPARATION STEPS

A. Calibrate and Check Operation of

Measuring Equipment Follow
manufacturer’s recommended procedures for
calibration and equipment check out.

B. Prepare Heating Unit for Testing Drill two

1/4 inch holes in the flue between the heating
plant and the barometric draft regulator. If
space permits, the holes should be located in a
straight section of the flue, at least two flue
diameters from the elbow in the flue pipe and at
least one diameter from the draft regulator. The
purpose of the two holes in the flue pipe is to
speed up testing and reduce instrument
handling.

C. Clean and Seal Heating Plant Make sure the

burner blast tube, fan housing, and blower
wheel are clear of dirt and lint. Seal any air
leaks into the combustion chamber.

2

gnitaeH

1

yticapaC

HUTB

elzzoN

eziS

tupnI

HUTB

gnitaeH

yticapaC

HUTB

Always use combustion test instruments when
making burner adjustments and draft gauge
when setting the barometric damper. It is
virtually impossible to make accurate and
reliable adjustments using the “eyeball”
method.

Check all oil lines and connections for leaks.
Connect pressure gauge by removing bleed fitting and

screwing in pressure gauge. See Figure 9.

Manual 2100-422
Page 14

D. Nozzle Inspection Annual replacement of

nozzle is recommended. The nozzle size
should match the design load . DO NOT
OVERSIZE. (Determination of oversizing can
be determined prior to your adjustment. If the
firing rate should be reduced refer to Table 4.)
Short cycles and low percent :on: time result in
higher overall pollutant emissions and lower
thermal efficiency. An in-line oil filter will
reduce service problems due to nozzle clogging.

It should be located as close as possible to the
oil burner. Care should be taken to prevent air
leakage in the oil suction line. Use continuous
runs of copper tubing and use minimum
number of joints and fittings. Always use flare
fittings.

E. Adjustment of Electrodes Adjust ignition

electrodes as specified in Figure 10.

F. Operate Burner Operate burner, adjust air

setting for good flame by visual observation,
and run for at least 10 minutes or until
operation has stabilized.

G. Check Burner Pressure Bleed air from

pump and nozzle piping. Check pump pressure
and adjust to 100 psi, if necessary.

2. COMBUSTION ADJUSTMENT STEPS

H. Set Draft Check the draft reading over the

fire with a draft gauge through a hole in the
inspection door. The hole is above the flame
level. Adjust the barometric draft regulator on
the flue to give the over fire of -.02” W.C.

I. Check Smoke Readings After burner has

been operating 5 or 10 minutes, make a smoke
measurement in the flue, following the smoke
tester instructions. Oily or yellow smoke spots
on the filter paper are usually a sign of
unburned fuel, indicating very poor
combustion (and likely high emissions of
carbon monoxide and unburned hydrocarbons.)
This condition can sometimes be caused by too
much air, or by other factors. If this condition
cannot be corrected, major renovation or even
burner replacement may be necessary.

J. Develop Smoke - CO2 Curve Record

measurements of smoke and CO

from the

2

flue. Then establish the smoke - CO2 curve by
taking readings over a range of air settings, as
shown in Figure 8.

To do this, start with the air gate set at nearly
full open and then take smoke and CO
readings at progressively lower air settings, as
necessary to visualize the general shape of the
curve. (The CO2 readings will increase as the
air setting is decreased, unless combustion is
incomplete.) Do not set the air gate to give a
smoke reading above No. 4 or No. 5. Plot the
points on graph paper, as in Figure 8. Usually
3 or 4 readings are enough to establish the
curve.

In adjusting each air setting, it is helpful to
note the various positions of air gate at which
measurements are made so that the final setting
can be located quickly.

K. Adjust Air Setting Examine the smoke - CO

2

plot and, keeping in mind the curve of
Figure 6,note the location of the “knee” where
the smoke number begins to rise sharply.
Noting the air gate position marks, adjust the
air setting to a CO

level 1/2 to 1 percent lower

2

than the CO2 level at the “knee”. (This
provides a tolerance against possible shifts in
the setting over a period of time.) Do not
increase the air setting any more than necessary
on the lower portion of the curve below the
“knee”

The characteristic curve for some burners may
not yield a distinct “knee” in the curve. In such
cases, the setting should be made near the
minimum smoke, (using judgement).

Lock the air adjustment and repeat draft,
CO2 and smoke measurements to make sure
the setting has not shifted.

3. COMBUSTION DIAGNOSIS

L. Check Performance A well-matched and

well-tuned burner should be capable of
operation with smoke not greater than No. 2
and at a CO2 level not less than 10%.

If this cannot be reached, check the following:

1. Air leaks into the combustion chamber or
heat exchanger can dilute the combustion
gases and prevent normal CO2 readings.
Such leaks should be sealed with furnace
cement or other high-temperature sealant.

To check for dilution by leakage, measure
the CO2 at as high a point as possible over
the fire, using a stainless steel tube
inserted through the fire door sample hole
(as described earlier for overfire draft
measurements), and compare this with the
CO2 measured in the flue. A difference of
more than 1 percent CO2 between the flue
and overfire reading usually indicates air
entry through leaks that have not been

2

properly sealed.
Seal between the probe and inspection door

sample hole during test. The inspection
door hole should be sealed when not being
used to avoid leakage of air through it.
(See Step H.)

2. If the CO2 level of 10% cannot be reached
without exceeding No. 2 smoke, poor
mixing of air and fuel is likely.

It may be necessary to replace the
combustion head or try different settings.

Manual 2100-422
Page 15

4. FINAL CHECKS

M. Measure Stack Temperature Operating the

unit at an excessive firing rate will generate
more heat than the heat exchanger can utilize
and result in unnecessary heat loss up the
chimney. Other causes of excessive heat loss
are badlysooted heat exchanger surfaces and
excessive draft. The temperature of the flue gas
provides an indication of these heat losses.

Measure flue temperature by subtracting the
room air temperature from the thermometer
reading. Excessive stack loss is indicated of the
net stack temperature during steady operation
exceeds 600° F.

N. Check Ignition Check operation over repeated

cycles to insure prompt ignition on starting.

O. Check Pump Cutoff Slow pump cutoff at the

end of a firing cycle can cause smoke and other
pollutant emissions. Check for prompt pump
cutoff by observing flame or by testing smoke at
shutdown. If poor cutoff is observed, make sure
air is purged from the pump and nozzle line.
Air trapped in the pump or nozzle line will
expand when heated, thus causing oil to drip
into the combustion chamber after shutdown. If
poor cutoff persists, repair or replace pump.
Also make sure the pump solenoid is working.
If not replace.

SHORT FORM ADJUSTMENT
PROCEDURE

Some burner service organizations may wish to
perform a shorter procedure for the adjustment of oil
burners. The following is an example of such a short
form prepared by the National Association of Oil Heat
Service Managers.

1. SERVICE AND CLEAN BURNER

Follow company procedure to complete the
cleaning and servicing. Operate burner for ten
minutes while tools are gathered and are cleaned.

2, CHECK DRAFT

Set draft regulator, if necessary. Regulator should
be adjusted to achieve a -.02” W.C. over fire
condition. The more restricted and lengthy the
flue, the higher the draft necessary to obtain the
accepted over fire conditions.

3. SMOKE TEST

Follow the instructions of the manufacturer of the
smoke tester and take a smoke sample. Adjust the
air to obtain a preliminary reading of about No. 3
spot. Then readjust the air to obtain the lowest
possible reading, but do not open the air
adjustment more than absolutely necessary to
obtain a trace or No. 0 spot.

4. CO2 TEST

Check CO2 levels. This level should be between
10% and 12%.

Manual 2100-422
Page 16

FIGURE 8

TYPICAL SMOKE – CO2 CHART WITH ADJUSTMENT RANGE

High

8

6

Normal

adjustment

4

range

Tolerance

Bacharach Smoke Number

to "knee"

"Best" air

2

setting

Plotted point

0

6

8

Air Settings

Plotted point

"Knee"

10

Percent CO in Flue Gas

2

12

CO Curve
from plotted
points

Plotted point

Low

2

14

8

6

4

Bacharach Smoke Number

2

0

6

810

12

Percent CO in Flue Gas

2

Technician's
plotting area

14

MIS-1827

Manual 2100-422
Page 17

FIGURE 9

PRESSURE GAUGE CONNECTION TO BLEED PORT

Remove Bleed
Port to attach
pressure guage.

Manual 2100-422
Page 18

Pressure Gauge

MIS-1660

TABLE 5

CORRELATION OF PERCENT OF CO2, O

AND RESERVE AIR

2

nobraC

edixoiD

4.51

0.51

5.41

0.41

5.31

0.31

5.21

0.21

5.11

0.11

5.01

0.01

negyxO

0.0

6.0

2.1

0.2

6.2

3.3

0.4

6.4

3.5

0.6

7.6

4.7

riAevreseR

).xorppA(

0.0

0.3

0.6

0.01

0.51

0.02

0.52

0.03

0.53

0.04

0.54

0.05

TABLE 6

NO. 2 FUEL OIL EFFICIENCY CHART

(NET STACK TEMP. DEGREES F)

2

O%

16.984.883.782.681.580.489.287.186.085.974.873.772.677.41

24.982.880.789.587.486.384.282.181.089.877.776.674.570.41

32.989.787.685.583.481.389.187.084.972.870.778.576.472.31

49.887.784.681.588.386.283.180.087.875.772.679.476.375.21

57.883.780.686.483.380.286.083.979.776.673.579.376.277.11

64.880.785.581.487.283.189.975.870.776.572.478.274.170.11

70.885.680.585.380.285.080.975.770.675.470.375.170.073.01

002052003053004054005055006056007057008O%

2

TABLE 7

RECOMMENDED START-UP SETTINGS

dellatsnIyrotcaFnoitpOdellatsnIdleiF

riA

ecanruF

.oNledoM

E63D580HF620-0209/GFA57.0656.0555.05

E84D011HF720-0209/GFA00.120158.08ANANAN

E06D011HF720-0209/GFA00.120158.08ANANAN

E63D580FLF620-0209/GFA57.0656.0555.05

E84D011FLF
E06D011FLF

E63D580RLF130-0209/GFA57.0656.0555.05

E84D011RLF
E06D011RLF

E06D041RLF330-0209/GFA52.108 01.106ANANAN

E63D580CF620-0209/GFA57.0656.0555.05

j

70 degree hollow cone spray pattern, 100 PSIG pump pressure

.oNtraP

1

elytSrenruB

elzzoN

720-0209/GFA00.120158.08ANANAN

230-0209/GFA00.120158.08ANANAN

dnaB

gnitteS

riA

1

rettuhS

gnitteS

riA

dnaB

elzzoN

gnitteS

riA

1

rettuhS

gnitteS

riA

dnaB

elzzoN

gnitteS

Manual 2100-422
Page 19

riA

rettuhS

gnitteS

SPACING OF ELECTRODES

The electrodes should be spaced 5/32” apart. They
should extend 1/16” beyond the end and 5/16” above
the center of the nozzle tip as shown in Figure 10.

GUN ASSEMBLY ADJUSTMENT

The gun assembly can be adjusted in the slot inside of
fan housing by loosening screw holding slot cover in
position. Nozzle tip should ordinarily be located 1-1/8”
behind the front face of the cone.

REMOVING GUN ASSEMBLY

Disconnect the oil line at the fan housing and remove
lock nuts on copper tube fitting. Loosen igniter hold
down clamps, then swing igniter up and backward. Gun
assembly can now be removed through this opening.

COMBUSTION AIR REQUIREMENTS

This furnace must be installed in a location where a
sufficient supply of combustion air is available for the
complete combustion of the fuel oil. Keep in mind that
a certain amount of excess air is required as well to
ensure complete combustion of the fuel oil.

When structures are constructed too tightly to supply
sufficient combustion air, air from outside the structure
is required to be brought in directly to the furnace. This
furnace has been conveniently designed to accept a
combustion air boot which is attached directly to the
outdoors by means of a 4” pipe. This pipe can be rigid
or flexible, but it is recommended that a metallic
material be used. Refer to Figure 11. The air boot used
for this design is a Field Controls model number
CAS-2B-90E that can be purchased through your local
distributor. Follow all installation procedures as
specified in the instructions packaged with the air boot
kit.

5/32 GAP

1/16

FIGURE 10

ELECTRODE ADJUSTMENTS

1-1/8

5/16

NOZZLE

MIS-160

Manual 2100-422
Page 20

COMBUSTION

AIR BOOT

ASSEMBLY

KNOCKOUT

INTAKE

AIR

TUBE

FOR OIL LINE

FIGURE 11

COMBINATION AIR BOOT ASSEMBLY

USE THIS

BURNER
ASSEMBLY

REMOVE PUMP TO
ASSEMBLE INNER
AIR BOOT

INSERT OUTER AIR
BOOT AND SECURE
FLANGE TO UNIT

MAKE ALL SETTINGS
ACCORDING TO MANUAL
FOR AIR BOOT.

REMOVE KNOCKOUT
IN LEFT SIDE

MIS-1833

Manual 2100-422
Page 21

APPLIANCES LOCATED IN CONFINED
SPACES

In unconfined spaces in buildings, infiltration may be
adequate to provide air for combustion, ventilation, and
dilution of flue gases. However, in buildings of
unusually tight construction, additional air shall be
provided using the method described under “All Air
From Outdoors” in Figure 13.

An unconfined space (such as an open basement) must
have a minimum volume of 50 cubic feet per 1,000
BTUH of total of all appliances in area. Adjoining
rooms may be counted as one area only if there are not
doors between the rooms.

Shown in Table 8 are the required minimum areas in
square feet to qualify as an unconfined space for
various total BTUH input ratings. The table is based on
a room(s) with 8 foot ceiling heights.

If the unconfined space is within a building having
insufficient air because of tight construction, the air for
combustion and ventilation shall be obtained from
outdoors or from spaces freely communicating with the
outdoors. Under these conditions a permanent opening
or openings have a total free area of not less than one
square inch per 5,000 BTU per hour (28 square inches
per hour ) of total input rating of all appliances shall be
provided. For combustion air options see Page 20,
“Combustion Air Requirements”.

FIGURE 12

APPLIANCES LOCATED

IN CONFINED SPACES

ALL AIR FROM INSIDE THE BUILDING

TABLE 8

SQUARE FEET REQUIRED TO

QUALIFY AS UNCONFINED SPACE

latoT

HUTB

tupnI

000,06
000,08

000,58
000,501

000,511
000,021

000,041
000,541

000,061
000,002

573
005

135
656

917
057

578
609

0001
0521

ecapSdenifnocnU

nIaerAmuminiM

teeFerauqS

thgieHgnilieC'8

ALL AIR FROM INSIDE BUILDING

The confined space shall be provided with two
permanent openings, one near the top of the enclosure
and one near the bottom. Each opening shall have a
free area of not less than one square inch per 1,000
BTU per hour (140 square inches per gallon per hour)
of the total input rating of all appliances in the
enclosure freely communicating with interior areas
having in turn adequate infiltration from the outside.
(See Figure 12.) Also see Table 9 on the following
page for specific ventilation opening requirements for
the furnace only.

MIS-1336

Manual 2100-422
Page 22

The flow of combustion and ventilating air must not
be obstructed from reaching the furnace.

NOTE: Each opening shall have a free area of

not less than one square inch per 1,000
BTU per hour (140 square inches per
gallon per hour) of the total input
rating of all appliances in the
enclosure.

TABLE 9

MINIMUM VENTILATION OPENINGS

noitalitneV.niM

gninepO

ledoM

E63D580HF04261x8821

E84D011HF08281x9261

E06D011HF08281x9261

E63D580FLF09291x8251

E63D580RLF09291x8251

E84D011FLF
E06D011FLF

E84D011RLF
E06D011RLF

E06D041RLF06391x5.9081

E63D580CF04261x8821

hcnIerauqS

04391x9171

04391x9171

eziS.nI.qS

ALL VENTILATION AIR FROM OUTDOORS

A. The confined space shall be provided with two

dednemmoceR

gninepO

)deriuqeR2(

permanent openings, one in or near the top of the
enclosure and one in or near the bottom. The
openings shall communicate directly, or by means
of ducts with outdoors or to such spaces (crawl or
attic) that freely communicate with outdoors. (See
Figures 13, 14, & 15.)

B. When directly communicating with outdoors or by

means of vertical ducts, each opening shall have a
free area of not less than one square inch per 4,000
BTU per hour (35 square inches per gallon per
hour) of total input rating of all appliances in the
enclosures. If horizontal ducts are used, each
opening shall have a free area of not less than one
square inch per 2,000 BTU per hour (70 square
inches per gallon per hour) of total input of all
appliances in the enclosure.

MIS-1337

FIGURE 13

APPLIANCES LOCATED IN CONFINED SPACES

ALL AIR FROM OUTDOORS

NOTE: Each air duct opening shall have a

free area of not less than one square
inch per 2,000 BTU per hour (70
square inches per gallon per hour) of
the total input rating of all appliances
in the enclosure.

Manual 2100-422
Page 23

FIGURE 14

APPLIANCES LOCATED IN CONFINED SPACES

ALL AIR FROM OUTDOORS THROUGH VENTILATED ATTIC

NOTE: The inlet and outlet air openings

shall each have a free area of not
less than one square inch per
4,000 BTU per hour (35 square
inches per gallon per hour) of the
total input rating of all
appliances in the enclosure.

MIS-1338

FIGURE 15

APPLIANCES LOCATED IN CONFINED SPACES

ALL AIR FROM OUTDOORS

INLET AIR FROM VENTILATED CRAWL SPACE AND OUTLET AIR TO VENTILATED ATTIC

NOTE: The inlet and outlet air openings

shall each have a free area of not
less than one square inch per 4,000
BTU per hour (35 square inches
per gallon per hour) of the total
input rating of appliances in the
enclosure.

MIS-1339

Manual 2100-422
Page 24

LOUVERS AND GRILLES

In calculating free area for ventilation and combustion
air requirements, consideration shall be given to the
blocking effect of louvers, grilles, or screens protecting
openings. Screens used shall not be smaller than 1/4
inch (6.3 mm) mesh and shall be readily accessible for
cleaning. If the free area through a design of louver or
grille is known, it shall be used in calculating the size
opening required to provide the free area specified. If
the design and free area is not known, it may be
assumed that wood louvers will have 30-35 percent free
area and metal louvers and grilles will have 60-75
percent free area.

A barometric damper is supplied with the furnace and
must be installed in the flue pipe observing the
instructions packaged with the damper control. The
barometric damper opening must be located in the same
atmospheric pressure zone as the combustion air inlet to
the furnace. The furnace must not be vented into the
same chimney with any solid fuel burning appliance
such as a wood burner or pellet burner. Masonry
chimneys must be lined with a listed system or other
approved material that will resist corrosion, softening or
cracking from flue gas temperatures up to 1800° F. See
Standard for Installation of Oil Burning Equipment
NFPA31 latest edition and Standard for Chimneys
NFPA211 latest edition for additional information.

VENTING OPTIONS

This furnace is designed to be vented conventionally
into a vertical chimney or horizontally through a side
wall with an optional Field Controls side wall power
venting system.

Note that the FH, FC and FLF series furnaces have been
designed to allow for bringing the vent system through
the cabinet side for increased venting flexibility. To
take advantage of this feature, simply remove the
desired knockout from either side or top of unit and
rotate flue box accordingly by removing four (4) screws
under cleanout plate as shown in Figure 4. Make sure
smoke pipe gasket is in place before reinstalling flue
box screws.

VERTICAL VENTING

If the unit is to be vertically vented make sure the flue
pipe from the furnace to the chimney is the same size
diameter as the flue outlet of the furnace which is 6”.
The flue pipe must have no reductions in diameter, be
made of a corrosion-resistant material having an
upward pitch of 1/4” for every foot of horizontal run,
and be made of material capable of handling
temperatures up to 1800° F.

HORIZONTAL VENTING

This furnace is designed to be horizontally vented
through a side wall with an optional side wall power
vent. The recommended side wall venter is the Field
Controls model number SWG-4HDS for 085 and 110
models, and SWG-5S for 140 models only. This venter
can be purchased through your local distributor. Follow
all installation instructions packaged with the venter
system.

THERMOSTAT

These furnaces are designed to be controlled with any
24V heating or heating/cooling thermostat. The
heat/cool thermostats must be designed for independent
heat/cool transformer circuits to assure that the 24V
transformer built into the oil primary control does not
conflict with the main furnace 24V transformer. The
heat anticipator should be set at 0.20A. This is a
nominal setting. The thermostat circuit should be
checked to verify setting.

Manual 2100-422
Page 25

TABLE 10

TEMPERATURE RISE RANGES, LIMIT CONTROL SETTINGS,

AND HEATING BLOWER SPEEDS

mumixaM

1

ledoM

E63D580HF

E84D011HF

E06D011HF

E63D580FLF

E84D011FLF

E06D011FLF

E63D580RLF

E84D011RLF

E06D011RLF

E06D041RLF

E63D580CF

elzzoNsegnaResiR

55.

56.

57.

58.

00.1

58.

00.1

55.

56.

57.

58.

00.1

58.

00.1

55.

56.

57.

58.

00.1

58.

00.1

01.1

52.1

55.

56.

57.

001-07
001-07

09-06

001-07

09-06

09-06
09-06

09-06
09-06
09-06

09-06
09-06

09-06
09-06

09-06
09-06
09-06

09-06
09-06

09-06
09-06

09-06
09-06

001-07
001-07

09-06

riAteltuO

.pmeT

002
002
002

002
002

002
002

002
002
002

002
002

002
002

002
002
002

002
002

002
002

002
002

002
002
002

woL
woL

woL

woL

woL
woL

woL
woL

woL
woL

rewolBgnitaeH

deepS

deM

woLdeM

woLdeM

deM

woLdeM

hgiHdeM

woLdeM

hgiHdeM

deM

woLdeM

hgiHdeM

woLdeM

hgiHdeM

woLdeM

hgiHdeM

deM

j

70 degree hollow cone spray pattern, 100 PSIG pump pressure

Manual 2100-422
Page 26

AIR FIL TERS

Only Lo-Boy models are shipped with air filters. Filter
kits are available from your local distributor for Upflow
and Counterflow models. Knockouts are provided in
the sides of the FH series models to facilitate the
cutting of the return openings.

The upflow filter kit part numbers are FR23 for a
16x25x1 filter size and FR24 for a 20x25x1 filter size.
These filter kits come complete with the filter and all
necessary brackets for installing on the furnace. Each
comes with a washable aluminum mesh filter. When
installing a five ton AC unit on the furnace, one FR24
or Two FR23 must be used due to the high airflow
requirements. It is important to note that a minimum of
one inch spacing is required between the filter and the
unit side. Do not exceed 400 fpm for fiberglass
(disposable) type filters and 575 fpm for washable type
filters. See Figure 16.

The counterflow filter kit part number FR25 comes
with two washable filters. If not installing the FR25 kit
remember not to exceed 400 fpm for fiberglass
(disposable) type filters and 575 for washable type
filters. See Figure 17.

See Table 11 for filter sizes and quantities.

TABLE 11

FILTER SIZES FOR OIL FURNACES

ledoMeziS

E63D580HF

yoB-iH

yoB-iH

yoB-iH

syoB-oL

syoB-oL

yoB-oL

wolfretnuoC

)1(1x52x61

E84D011HF

)1(1x52x61

E06D011HF

)1(1x52x02

E63D580FLF
E63D580RLF

)1(1x02x61

E84D011FLF
E84D011RLF
E06D011FLF

)1(1x02x02

E06D011RLF

E06D041RLF

)1(1x52x02

E63D580CF

)2(1x02x61

FIGURE 16

TYPICAL INSTALLATION OF FR26 AND

FR27 FILTER RACKS

19 1/4"

(2) screws

Filter

FIGURE 17

TYPICAL INSTALLATION OF FR25

FILTER KIT

Optional

Filter

Box

"FC"

Unit

70 5/16"

16"

Filter
Frame

Filter
Door

MIS-1839 A

MIS-1841

Manual 2100-422
Page 27

LO-BOY MODELS – FILTER LOCATIONS

Lo-boy models have the filter installed in the return air cabinet section of the furnace. It is accessible from the rear of
the furnace by removing the blower/filter access door. The electrical switch should be turned “off” prior to removing
the access door. Refer to Figure 18 below.

FIGURE 18

FILTER INSTALLATION – LO-BOY MODELS

UNIT FILTER SIZE
FLF/FLR085 16 x 20 x1
FLF/FLR110 20 x 20 x1

FLR140 20 x 25 x 1

STEP 3:

SLIDE FILTER OUT

TOWARDS BLOWER

DOOR

LOWBOY FILTER

REPLACEMENT

STEP 2:

REMOVE BLOWER DOOR

BY PULLING OUT ON

SWELL LATCHES AND

TILTING OUTWARDS

Manual 2100-422
Page 28

STEP 1:

UNFASTEN SWELL

LATCHES BY PULLING

HANDLES OUTWARD

MIS-1835

MAINTENANCE

LUBRICATION

No lubrication is required for either the burner or the
blower motor. Both are permanently lubricated.

INSPECT AIR FILTER

Replace filters before each heating season begins. It is
recommended that filters also be replaced at least twice
during the heating season.

Be sure the new filters are set securely in the filter rack
so there can be minimal leakage around them.

FINAL INSPECTION AND TEST

Final inspection and test of an installation shall be
made to determine that the work has been done in full
accordance with regulations and according to the
highest standards for safety, performance and
appearance. Such an inspection and test should
indicate the following as a minimum:

1. Determine that all parts of the oil storage and
circulating system, including tank, piping and
burner, are free from oil leaks. Be sure that no oil
discharges from the nozzle when burner is not
operating.

2. Be sure that the suction line and pump have been
entirely vented of air so that the burner has
instantaneous oil shutoff at the nozzle and so that
the pump operates without an air noise.

3. Check the flame adjustment to determine that the
flame is clear, quiet, free of odor and oil nozzle is
of proper size for the furnace.

4. Test operation of burner by operating the
thermostat. First, set the thermostat above room
temperature. Burner should start. Second, set
thermostat below room temperature. Burner will
stop.

5. Check operation of burner primary control in
accordance with manufacturer’s instructions
included with the control. Following is the method
we recommend in checking the safety switch in
this primary control.

A. Flame Failure – Simulate by shutting off oil

supply manual valve while burner is on.
Within 9 seconds the control will shut the
burner down and flash a diagnostic code of
1/2 second on / 1/2 second off. Ignition and
motor stop and oil valve closes

B. Ignition Failure – Test by closing oil supply

while burner is off. Run through starting
procedure. The primary control will attempt
three trials for ignition. After three attempts,
the control will lockout.

C. Power Failure – Turn off power supply

while burner is on. When burner goes out,
restore power and burner will restart.

D. If operation is not as described, check wiring

and installation first. If trouble appears to be
in the control circuit, replace the flame
detector. If trouble still persists, refer to
“Common Causes of Trouble” section on
page 28.

SERVICE HINTS

Preventive maintenance is the best way to avoid
unnecessary expense, inconvenience, and retain
operating efficiency of your furnace. It is advisable to
have your heating system and burner inspected at
periodic intervals by a qualified serviceman. If trouble
develops, follow these simple checks before calling the
serviceman.

1. Make sure there is oil in tank and valve is open.

2. Make sure thermostat is set above room
temperature.

3. Make sure electrical supply to furnace is on and
fuses are not blown or circuit breakers tripped.

4. Reset safety switch of burner primary control.

CAUTION

Reset three (3) times only. More than three
resets can cause excessive oil to be pumped
into combustion chamber which could result in
explosion upon ignition.

5. Press thermal protector button of burner motor.

6. Make sure air filters are in place and are clean.

7. Make sure all air openings in furnace, all
ventilation and combustion air openings, all return
air grilles, and all warm air registers are
unobstructed and open.

Manual 2100-422
Page 29

COMBINATION COMBUSTION
CHAMBER/BURNER MOUNTING
SYSTEM

The furnace has been designed with a combustion
chamber mounting system that enables service
personnel to remove the combustion chamber, its
mounting system, and burner assembly as one unit for
inspection and/or service on the bench. It has also been
designed to remove the burner assembly independently
from the mounting system to perform basic annual
service and inspection. The mounting system is
completely adjustable so exact alignment between the
burner tube and combustion chamber may be assured
prior to installation into the furnace. See Figure 19
and 20.

REMOVAL OF BURNER ONLY

DANGER

!

*ELECTRICAL SHOCK HAZARD
*DISCONNECT POWER BEFORE
SERVICING.

WARNING

The procedures described in Figures 19 and
20 should be conducted only by a qualified
service technician.

Improper servicing could cause electric shock
hazard, fires or explosion resulting in damage,
injury or death.

FIGURE 19

BURNER REMOVAL

INSTRUCTIONS

STEP 2:

LOOSEN (3) BOLTS

ENOUGH TO ROTATE

BURNER ASSEMBLY.

STEP 4:
PULL BURNER STRAIGHT
OUT TO PREVENT DAMAGE
TO CHAMBER DURING
REMOVAL.

Manual 2100-422
Page 30

STEP 3:
ROTATE BURNER
COUNTER-CLOCKWISE

STEP 1:
DISCONNECT "T-T" WIRES,
POWER CONNECTIONS, AIR
BOOT (OPTIONAL) AND OIL
LINES TO BURNER.

MIS-1834

TO REMOVE BURNER ONLY

Disconnect fuel line, power cord and wires from T, T
on primary control. Loosen (3) 1/4 inch bolts securing
burner mounting flange. Twist burner counterclockwise
and pull straight back away from the furnace. (See
Figure 19.)

REMOVAL OF ENTIRE COMBUSTION CHAMBER MOUNTING SYSTEM

TO REMOVE THE ENTIRE COMBUSTION
CHAMBER MOUNTING SYSTEM

Disconnect fuel line, power cord and wires from T, T
on primary control. Remove (6) 5/16 inch bolts from
around front plate. Next remove (2) 5/16 inch nuts
from upper right and left hand corners of the front plate.
Pull entire assembly straight back away from furnace.

BE CAREFUL NOT TO TIP ASSEMBLY UP OR
DOWN AS IT MAY DAMAGE THE COMBUSTION
CHAMBER. (See Figure 20.)

FIGURE 20

DANGER

!

*ELECTRICAL SHOCK HAZARD
*DISCONNECT POWER BEFORE
SERVICING.

STEP 3:

REMOVE (2) NUTS

IN THE TOP LEFT

AND RIGHT CORNERS

OF BURNER PLATE.

BURNER REMOVAL

INSTRUCTIONS

CHAMBER

BURNER
PLATE

STEP 4:
PULL BURNER ASSEMBLY
STRAIGHT OUT TO PREVENT
DAMAGE TO CHAMBER
DURING REMOVAL.

STEP 2:
REMOVE (6) BOLTS
AROUND PERIMETER
OF BURNER PLATE

STEP 1:
DISCONNECT "T-T" WIRES,
POWER CONNECTIONS, AIR
BOOT (OPTIONAL) AND OIL
LINES TO BURNER.

MIS-1837

Manual 2100-422
Page 31

COMMON CAUSES OF TROUBLE

CAUTION

PUMP SQUEALS OR CHATTERS

This may be caused by air in pipes. Check all joints in
the oil supply pipe for leaks. Check strainer in pump; if
dirty, clean.

To avoid accidents, always open main switch
(OFF position) when servicing the burner.

BURNER WILL NOT PRODUCE FLAME

Check oil level gauge to see that there is sufficient oil in
tank or tanks. Check the burner mounted relay control.
Do not adjust this control.

Check position of electrodes – incorrect position will
cause slow or delayed ignition. Clean electrodes and
nozzle. Check and clean strainer in pump. If oil line
filter is used, check filter condition.

If burner runs but there is no flame the fuel pump may
be air bound. Follow instructions for bleeding fuel
pump.

Check and make sure the solenoid valve on the oil
pump is being energized and opening.

BURNER STARTS OR STOPS TOO OFTEN

Check heat anticipator setting on thermostat.

NOZZLE PRODUCES A STRINGY FLAME

Worn tangential grooves in nozzle. Replace nozzle.

BASEMENT TANK HUM

Occasionally with a two-pipe installation there may be
a low return line hum. Eliminate hum by installing a
special anti-hum valve in the return line near pump.

HEAVY FIRE OR PULSATING FLAME.

These may occur after burner starts. It may be caused
by a slight oil leak in the fuel pump and cannot be
corrected except by replacing the pump. This happens
only when the burner is started.

CHATTERING SOUND OR HIGH PITCH NOISE

This noise from motor can usually be traced to where a
conduit or BX cable is fixed rigidly or attached to some
part of the building. Relieving this strain may eliminate
noise.

INSUFFICIENT HEAT

Check limit control setting. It may be that flame is not
allowed to stay on long enough to generate sufficient
heat in furnace to heat the house properly. If the proper
size furnace has been selected according to house
requirements and satisfactory heat is not obtained,
recheck the heating plant for size and capacity in
relation to house. Check for clogged filters.

Check and make sure the heat anticipator on the
thermostat is set correctly.

CARE OF FINISH

This furnace cabinet is made with a very durable and
corrosion resistant finish. With normal cleaning it will
last for many years.

WARNING

Under no circumstance should a soot
deterioration device be used in the
combustion chamber. These products known
as “soot busters” or “soot sticks” are
comprised of chemicals that burn at very high
temperatures which may exceed the
temperature rating of the combustion chamber
material.

Use of these products are detrimental to the
life expectancy of the combustion chamber
and will destroy the chamber. Refer to the
“Cleaning of Furnace” section for proper
cleaning methods.

CLEANING OF THE HEAT EXCHANGER

All of these units have four clean out plugs for easy
cleaning of the heat exchanger. They are accessible
from the front and back of these units by removing the
clean out access cover in the burner compartment and at
the back of unit. The furnace should be checked
annually by a qualified service technician.

Manual 2100-422
Page 32

BLOWER SYSTEM RESIST ANCE CHARTS

deepSrewolBcitatSrewolB

woL

50.90.51.02.

woLmuideM

90.61.32.13.

hgiHmuideM

51.42.43.24.

hgiH

02.03.04.05.

CHART 1

FH085D36E DATA

deepSrewolBcitatSrewolB

woL

muideM

hgiH

CHART 2

FH110D48E DATA

deepSrewolBcitatSrewolB

woL

woLmuideM

hgiHmuideM

01.51.32.03.

61.42.43.34.

02.03.04.05.

30.80.31.81.

90.61.32.23.

61.52.43.44.

CHART 4

FLF/FLR085D36E DATA

deepSrewolBcitatSrewolB

woL

muideM

hgiH

70.31.91.52.

51.42.33.14.

02.03.04.05.

CHART 5

FLF/FLR110D48E DATA

hgiH

woL

hgiH

02.03.04.05.

CHART 3

FH110D60E DATA

deepSrewolBcitatSrewolB

60.21.71.12.

woLmuideM

hgiHmuideM

01.71.32.03.

41.12.13.83.

02.03.04.05.

CHART 6

FLF/FLR110D60E DATA

deepSrewolBcitatSrewolB

woL

woLmuideM

hgiHmuideM

hgiH

80.21.71.12.

01.61.22.82.

31.12.92.63.

02.03.04.05.

Manual 2100-422
Page 33

CHART 7

FLR140D60E DATA

CHART 8

FC085D36E DATA

deepSrewolBcitatSrewolB

woL

woLmuideM

hgiHmuideM

hgiH

50.41.71.42.

80.71.22.03.

11.02.72.53.

02.03.04.05.

deepSrewolBcitatSrewolB

woL

muideM

hgiH

80.41.02.62.

61.42.63.24.

02.03.04.05.

Manual 2100-422
Page 34

FH SERIES

BLOWER CAPACITOR RATING

BLOWER CAPACITOR RATING

WIRING DIAGRAM

T

PLUG
#1

PURPLE
PURPLE

BURNER ASS'Y

L1

T

L2

VALVE

OIL VALVE

BURNER
MOTOR

IGNITOR

CAD CELL

CAD CELL

3456789

PURPLE

PURPLE

BLACK

BLACK

BURNER
MOTOR

IGNITOR

WHITE

GREEN

UNIT

WHITE

BLACK

2112

BACKUP

LIMIT

BLACK

PLUG #2

BLACK

BLACK

1

BLACK
WHITE

GREEN

BLACK

PRIMARY

LIMIT

CONTROL

BLACK

DOOR
SWITCH

BLACK

NOTES

IF PRIMARY LIMIT WIRES
ARE TO BE REPLACED,

1

USE WIRE WITH INSUL.
TEMP. RATING OF 200°C.

HEATING SPEED

2

CONNECTION POINT.
COOLING SPEED

3

CONNECTION POINT.
ONLY ONE HEATING

AND COOLING SPEED
CAN BE CONNECTED.

4

ALL OTHER TAPS

HEAT EXCHANGER AREA

CONNECT TO "SPARE"
TERMINALS.

DASHED LINES

5

REPRESENT FIELD WIRING.

DANGER

!

*ELECTRICAL SHOCK HAZARD
*DISCONNECT POWER BEFORE
SERVICING.

HOT
NEUTRAL
GROUND

WARNING

!

IF ANY OF THE ORIGINAL WIRE AS
SUPPLIED WITH THIS APPLIANCE
MUST BE REPLACED, IT MUST BE
REPLACED WITH WIRING MATERIAL
HAVING A TEMP. RATING OF AT
LEAST 105°C EXCEPT PRIMARY
LIMIT WIRES. SEE NOTE "1".

5

150

180
210
240

HUM

2

LOW

VOLTAGE

HIGH

VOLTAGE

FIELD

WIRING

RWGYC

BLOWER CONTROL

3

HEAT

COOL

EACL2COM

WHITE

PLUG #3

BLOWER
CAPACITOR

BROWN

SEC1

SEC2

T
T

L1

SPR2

SPR1

SPR3

4

WHITE

WHITE

345

12

RED

ORANGE

BLUE

BLACK

BROWN

BLOWER ASSEMBLY

BLUE

BLACK

SEE CHART FOR
HEATING AND COOLING
WIRE COLORS

WHITE

RETURN AREA

GREEN

24V

TRANSFORMER

120V COM

UNIT

UNIT

FH085D36E

FH085D36E

FH110D48E

FH110D48E

FH110D60E

FH110D60E

UNIT MOTOR CAPACITOR

UNIT MOTOR CAPACITOR

FH085D36E 1/3 5/370

FH085D36E 1/3 5/370
FH110D48E 1/2 7.5/370

FH110D48E 1/2 7.5/370
FH110D60E 3/4 15/370

FH110D60E 3/4 15/370

C

Rc

Y

WRh

G

Y

COND.

UNIT

24V.

CONN.

UNIT

UNIT

FH085D36E

FH085D36E

CONTROL PANEL

FH110D48E

FH110D48E

FH110D60E

FH110D60E

FACTORY SETTINGS

INPUT

INPUT

RATE

RATE

FACTORY SETTINGS

HEATING BLOWER

HEATING BLOWER

SPEED (COLOR)

SPEED (COLOR)

GPH

GPH

0.55 LOW (RED) 70°-100°

0.55 LOW (RED) 70°-100°

0.65 LOW (RED) 70°-100°

0.65 LOW (RED) 70°-100°

0.75 MED (BLUE) 60°-90°

0.75 MED (BLUE) 60°-90°

0.85 LOW (RED) 70°-100°

0.85 LOW (RED) 70°-100°
1 MED-LOW (ORANGE) 60°-90°

1 MED-LOW (ORANGE) 60°-90°

0.85 LOW (RED) 60°-90°

0.85 LOW (RED) 60°-90°
1 MED-LOW (ORANGE) 60°-90°

1 MED-LOW (ORANGE) 60°-90°

THERMOSTAT

T87F/Q539A1220
OR EQUIVELANT

OPTIONAL AIR COND. SETTINGS

OPTIONAL AIR COND. SETTINGS

NOM.

NOM.

COOLING BLOWE R

COOLING BLOWE R

A/C

A/C

SPEED (COLOR)

SPEED (COLOR)

TONS

TONS

2 LOW (RED) 730

2 LOW (RED) 730

2 1/2 MED (BLUE) 900

2 1/2 MED (BLUE) 900

3 HIGH (BLACK) 1160

3 HIGH (BLACK) 1160

2 1/2 LOW (RED) 1020

2 1/2 LOW (RED) 1020

3 MED-LOW (ORANGE) 1280

3 MED-LOW (ORANGE) 1280

3 1/2 MED-HIGH (BLUE) 1495

3 1/2 MED-HIGH (BLUE) 1495

4 HIGH (BLACK) 1640

4 HIGH (BLACK) 1640
3 LOW ( RED) 1300

3 LOW ( RED) 1300

3 1/2 MED-LOW (ORANGE) 1460

3 1/2 MED-LOW (ORANGE) 1460

4 MID-HIGH (BLUE) 1660

4 MID-HIGH (BLUE) 1660
5 HIGH (BLACK) 1970

5 HIGH (BLACK) 1970

COOLING BLOWER

COOLING BLOWER

SPEED (COLOR)

SPEED (COLOR)

HIGH (BLACK)

HIGH (BLACK)

CFM @

CFM @
.50 WC

.50 WC

TEMP.

TEMP.

RISE

RISE

RANGE

RANGE

4047-118 B

Manual 2100-422
Page 35

Manual 2100-422

Page 36

FLF/R SERIES

WIRING DIAGRAM

RETURN AREA

BLOWER CAPACITOR

BROWN

BROWN

BLOWER ASSEMBLY

5

4

3

2

1

BLACK
BLUE
ORANGE
RED
WHITE

BLACK

TRANSFORMER

COM

120V

24V

VALVE

BURNER
MOTOR

CAD CELL

L1
L2

IGNITOR

CAD CELL

IGNITOR

BURNER
MOTOR

OIL VALVE

BURNER ASS'Y

TT

1
2

24V.

CONN.

COND.

UNIT

Y

C

WRh

Y

G

Rc

THERMOSTAT

T87F/Q539A1220
OR EQUIVELANT

BLACK

BLACK

GREEN

WHITE

BLACK

GROUND

NEUTRAL

HOT

BLUE

BLACK

BLACK

BLACK

4047-119 C

HEAT EX. AREA

CONTROL PANEL

PURPLE

PURPLE

1

5

BACKUP LIMIT

PRIMARY LIMIT

BLACK

SEE CHART FOR

"HEAT" AND "COOL"

WIRE COLORS.

2

BLACK

GREEN

COOL

EAC

L2

COM

SPR1

SPR2

SPR3

3

4

240

210

180

150

RWGYC

BLOWER CONTROL

T
T

L1

SEC2

SEC1

HEAT

HUM

WHITE

WHITE

WHITE

*ELECTRICAL SHOCK HAZARD
*DISCONNECT POWER BEFORE
SERVICING.

DANGER

!

DASHED LINES
REPRESENT FIELD WIRING.

ONLY ONE HEATING
AND COOLING SPEED
CAN BE CONNECTED.
ALL OTHER TAPS
CONNECT TO "SPARE"
TERMINALS.

COOLING SPEED
CONNECTION POINT.

HEATING SPEED
CONNECTION POINT.

IF PRIMARY LIMIT WIRES
ARE TO BE REPLACED,
USE WIRE WITH INSUL.
TEMP. RATING OF 200°C.

5

4

3

2

NOTES

1

UNIT MOTOR CAPACITOR
FLF/R085D36E 1/3 5/370
FLF/R110D48E 1/2 7.5/370

FLF/R110D60E

FLR140D60E

3/4 15/370

BLOWER CAPACITOR RATING

0.55 LOW (RED) 60°-90° HIGH (BLACK)

0.65 LOW (RED) 60°-90° HIGH (BLACK)

0.75 MED (BLUE) 60°-90° HIGH (BLACK)

0.85 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1.1 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1.25 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

FLR140D60E

UNIT GPH INPUT

HTG. BLWR SPD.

(COLOR)

FACTORY SETTINGS

COLING BLWR.

SPEED

FLF/R085D36E

FLF/R110D48E
FLF/R110D60E

TEMP.

RISE

2 LOW (RED) 775

2.5 MED (BLUE) 1070
3 HIGH (BLACK) 1275

2.5 LOW (RED) 1065
3 MED LOW (ORANGE) 1235

3.5 MED HIGH (BLUE) 1415
4 HIGH (BLACK) 1525
3 LOW (RED) 1190

3.5 MED LOW (ORANGE) 1400
4 MED HIGH (BLUE) 1640
5 HIGH (BLACK) 2250

COOLING BLOWER SPEEDS

FLF/R085D36E

FLF/R110D48E

CFM@

.50" WC

UNIT

NOM. A/C

(TONS)

SPEED (COLOR)

FLF/R110D60E

FLR140D60E

UNIT MOTOR CAPACITOR
FLF/R085D36E 1/3 5/370
FLF/R110D48E 1/2 7.5/370

FLF/R110D60E

FLR140D60E

3/4 15/370

BLOWER CAPACITOR RATING

0.55 LOW (RED) 60°-90° HIGH (BLACK)

0.65 LOW (RED) 60°-90° HIGH (BLACK)

0.75 MED (BLUE) 60°-90° HIGH (BLACK)

0.85 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1.1 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

1.25 MED. HIGH (BLUE

)

60°-90° HIGH (BLACK)

FLR140D60E

UNIT GPH INPUT

HTG. BLWR SPD.

(COLOR)

FACTORY SETTINGS

COLING BLWR.

SPEED

FLF/R085D36E

FLF/R110D48E
FLF/R110D60E

TEMP.

RISE

2 LOW (RED) 775

2.5 MED (BLUE) 1070
3 HIGH (BLACK) 1275

2.5 LOW (RED) 1065
3 MED LOW (ORANGE) 1235

3.5 MED HIGH (BLUE) 1415
4 HIGH (BLACK) 1525
3 LOW (RED) 1190

3.5 MED LOW (ORANGE) 1400
4 MED HIGH (BLUE) 1640
5 HIGH (BLACK) 2250

COOLING BLOWER SPEEDS

FLF/R085D36E

FLF/R110D48E

CFM@

.50" WC

UNIT

NOM. A/C

(TONS)

SPEED (COLOR)

FLF/R110D60E

FLR140D60E

Manual 2100-422

Page 37

FC SERIES

WIRING DIAGRAM

RETURN AREA

BLOWER CAPACITOR

(5/370)

BROWN

BROWN

BLOWER ASSEMBLY (1/3 HP)

5

4

3

2

1

BLACK
BLUE

RED
WHITE

2

VALVE

BURNER
MOTOR

CAD CELL

L1
L2

IGNITOR

CAD CELL

IGNITOR

BURNER
MOTOR

OIL VALVE

BURNER ASS'Y

TT

1
2

24V.

CONN.

COND.

UNIT

Y

C

WRh

Y

G

Rc

THERMOSTAT

T87F/Q539A1220
OR EQUIVELANT

BLACK

BLACK

GREEN

WHITE
BLACK

GROUND

NEUTRAL

HOT

BLACK

BLACK

4047-120 B

HEAT EX. AREA

CONTROL PANEL

PURPLE

PURPLE

1

5

PRIMARY LIMIT

BACKUP LIMIT

BLACK

BLACK

1
2

3
4

DOOR
SWITCH

24V

120V

COM

TRANSFORMER

BLACK

BLACK

SEE CHART FOR

"HEAT" AND "COOL"

WIRE COLORS.

WHITE

WHITE

WHITE

COOL

EAC

L2

COM

SPR1

SPR2

SPR3

3

4

240

210

180

150

RWGYC

BLOWER CONTROL

T
T

L1

SEC2

SEC1

HEAT

HUM

WHITE

*ELECTRICAL SHOCK HAZARD
*DISCONNECT POWER BEFORE
SERVICING.

DANGER

!

DASHED LINES
REPRESENT FIELD WIRING.

ONLY ONE HEATING
AND COOLING SPEED
CAN BE CONNECTED.
ALL OTHER TAPS
CONNECT TO "SPARE"
TERMINALS.

COOLING SPEED
CONNECTION POINT.

HEATING SPEED
CONNECTION POINT.

IF PRIMARY LIMIT WIRES
ARE TO BE REPLACED,
USE WIRE WITH INSUL.
TEMP. RATING OF 200°C.

5

4

3

2

NOTES

1

0.55 LOW (RED) 60°-90° HIGH (BLACK)

0.65 LOW (RED) 70°-100° HIGH (BLACK)

0.75 MED (BLUE) 60°-90° HIGH (BLACK)

UNIT GPH INPUT

HTG. BLWR SPD.

(COLOR)

FACTORY SETTINGS

COLING BLWR.

SPEED

FC085D36E

TEMP.

RISE

2 LOW ( RED) 775

2.5 MED (BLUE) 1070
3 HIGH (BLACK) 1230

COOLING BLOWER SPEEDS

FC085D36E

CFM@

.50" WC

UNIT

NOM. A/C

(TONS)

SPEED (COLOR)

0.55 LOW (RED) 60°-90° HIGH (BLACK)

0.65 LOW (RED) 70°-100° HIGH (BLACK)

0.75 MED (BLUE) 60°-90° HIGH (BLACK)

UNIT GPH INPUT

HTG. BLWR SPD.

(COLOR)

FACTORY SETTINGS

COLING BLWR.

SPEED

FC085D36E

TEMP.

RISE

2 LOW ( RED) 775

2.5 MED (BLUE) 1070
3 HIGH (BLACK) 1230

COOLING BLOWER SPEEDS

FC085D36E

CFM@

.50" WC

UNIT

NOM. A/C

(TONS)

SPEED (COLOR)
