Barco PGWU-61B, PGWX-61B User Manual

PGXG-61B / PGWX-61B / PGWU-61B

User manual

Doc. Revision: 03

Barco nv Projection Division

Noordlaan 5, B-8520 Kuurne

Phone: +32 56.36.89.70

Fax: +32 56.36.88.24

Support: www.barco.com/esupport

Visit us at the web: www.barco.com

Changes

Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or merchantability and tness for a particular purpose. Barco may make improvements and/or

changes to the product(s) and/or the program(s) described in this publication at any time without notice.

This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this publication; these changes are incorporated in new editions of this publication.

The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the secured Barco web site https://my.barco.com.

All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.

EN55022/CISPR22 Class A ITE (Information Technology Equipment)

Class A ITE is a category of all other ITE which satises the class A ITE limits but not the class B ITE limits. Such equipment should not be restricted in its sale but the following warning shall be included in the instructions for use:

Warning : This is a class A product. In a domestic environment this product may cause radio interference in which case

the user may be required to take adequate measures.

Federal Communications Commission (FCC Statement)

This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the

FCC rules.

These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may cause harmful interference, in which case the user will be responsible for correcting any interference at his own expense.

Guarantee and Compensation

Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of any complaints.

The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date

of commissioning, at latest 30 days after the transfer of risks. In the event of justied notice of complaint, Barco can

repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the intent or gross negligence or part of Barco.

If the purchaser or a third party carries out modications or repairs on goods delivered by Barco, or if the goods are

handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the

goods are subject to inuences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered

invalid. Not included in the guarantee coverage are system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee provided by Barco either.

The environmental conditions as well as the servicing and maintenance regulations specied in the this manual must be

complied with by the customer.

Trademarks

Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.

All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products or their manufacturers.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

Table of Contents

TABLE OF CONTENTS

1. SAFETY .................................................................................................................................................................................. 6

1.1 General considerations .................................................................................................................................................... 6

1.2 Important safety instructions ............................................................................................................................................ 7

2. INTRODUCTION ...................................................................................................................................................................12

2.1 Installation requirements ................................................................................................................................................12

2.2 Projector package overview ...........................................................................................................................................13

2.3 Product Overview ..........................................................................................................................................................14

2.3.1 Main Unit .............................................................................................................................................................14

2.3.2 Input/Output (I/O) Panel ......................................................................................................................................15

2.3.3 Remote Control ...................................................................................................................................................16

3. INSTALLATION .................................................................................................................................................................... 17

3.1 RCU Battery Installation ................................................................................................................................................17

3.2 Installing the Lens .......................................................................................................................................................... 18

3.3 Connecting the Projector ............................................................................................................................................... 19

3.3.1 Removing the rear cover ..................................................................................................................................... 19

3.3.2 Connecting to a Computer or Laptop ..................................................................................................................20

3.3.3 Connecting to Video Sources .............................................................................................................................. 21

3.4 Powering On/Off the Projector ....................................................................................................................................... 22

3.4.1 Powering On the Projector ..................................................................................................................................22

3.4.2 Powering Off the Projector ..................................................................................................................................22

3.5 Adjusting the Projected Image ....................................................................................................................................... 23

3.6 Ceiling Mount Installation ...............................................................................................................................................25

4. USER CONTROLS ............................................................................................................................................................... 26

4.1 On-Screen Display Menus ............................................................................................................................................. 26

4.1.1 Using the OSD Lite Menus .................................................................................................................................. 26

4.1.2 Using the Advanced OSD Menus ........................................................................................................................ 28

4.1.2.1 Input Menu ........................................................................................................................................................29

4.1.2.2 Image Menu ......................................................................................................................................................30

4.1.2.3 Layout Menu ..................................................................................................................................................... 32

4.1.2.4 Lamps Menu ..................................................................................................................................................... 33

4.1.2.5 Alignment Menu ................................................................................................................................................34

4.1.2.6 Control Menu .................................................................................................................................................... 36

4.1.2.7 Service Menu ....................................................................................................................................................37

5. TROUBLESHOOTING ..........................................................................................................................................................39

5.1 Image Problems .............................................................................................................................................................39

5.2 LED Indication Chart ......................................................................................................................................................40

5.3 Warning Message .......................................................................................................................................................... 41

6. MAINTENANCE & SERVICE ............................................................................................................................................... 42

6.1 Replacing the Lamp ....................................................................................................................................................... 42

6.2 Replacing the Air Filter ................................................................................................................................................... 43

6.3 Replacing the Lens ........................................................................................................................................................ 44

7. SPECIFICATIONS ................................................................................................................................................................ 45

7.1 PGXG-61B ..................................................................................................................................................................... 45

7.2 PGWX-61B .................................................................................................................................................................... 47

7.3 PGWU-61B .................................................................................................................................................................... 49

7.4 Dimensions .................................................................................................................................................................... 51

7.5 Compatibility Modes ......................................................................................................................................................52

8. ENVIRONMENTAL INFORMATION ..................................................................................................................................... 54

8.1 Disposal information ...................................................................................................................................................... 54

8.2 RoHS compliance .......................................................................................................................................................... 54

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

“Lamp(s) contain Mercury, Dispose Properly.”

1. SAFETY

About this chapter

Read this chapter attentively. It contains important information to prevent personal injury while installing and using your PRESENT series projector. Furthermore, it includes several cautions to prevent damage to your PRESENT series projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing and using the PRESENT series projector. After this chapter, additional “warnings” and “cautions” are given depending on the procedure. Read and follow these “warnings” and “cautions” as well.

Clarication of the term “PRESENT series” used in this document

When referring in this document to the term “PRESENT series” means that the content is applicable for following Barco products:

PGXG-61B y

PGWX-61B y

PGWU-61B y

Overview

General considerations y

Important safety instructions y

1.1 General considerations

Caution: Do not touch a lamp during operation and right after is turned off as it is extremely hot. Lamp contains mercury. it’s brokeage might cause mercury or broken glass to follow out of lamp housing. To avoid exposure the risk of mercury poisoning. Don’t drop, hit, force or scratch while handing a lamp.

CAUTION: Don’t turn on the projector immediately after entering Standby mode.

General safety instructions

Before operating this equipment please read this manual thoroughly and retain it for future reference. y

Installation and preliminary adjustments should be performed by qualied Barco personnel or by authorized y

Barco service dealers.

All warnings on the projector and in the documentation manuals should be adhered to. y

All instructions for operating and use of this equipment must be followed precisely. y

All local installation codes should be adhered to. y

The lightning ash with arrowhead symbol within an equilateral triangle

is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufcient magni-

tude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The hot surface symbol within an equilateral triangle is intended to

alert the user the presence of “hot surface” on lamp module, so when the user replace the lamp, please allow the unit to cool down.

The lamp in the projector contains mercury,which must be recycled or disposed of in accordance with local, state, or country laws.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

Do not look into the projector’s lens when the lamp is on. The bright light may hurt and

damage your eyes.

Notice on safety

This equipment is built in accordance with the requirements of the international safety standards IEC60950-1, EN60950-1, UL60950-1 and CAN/CSA C22.2 No.60950-1, which are the safety standards of information technology equipment including electrical business equipment. These safety standards impose important requirements

on the use of safety critical components, materials and insulation, in order to protect the user or operator against

risk of electric shock and energy hazard and having access to live parts. Safety standards also impose limits to the

internal and external temperature rises, radiation levels, mechanical stability and strength, enclosure construction

and protection against the risk of re. Simulated single fault condition testing ensures the safety of the equipment to the user even when the equipment’s normal operation fails.

Users denition

Throughout this manual, the term SERVICE PERSONNEL refers to persons having appropriate technical training

and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons. The term USER and OPERATOR refers to any person other than SERVICE PER-SONNEL, AUTHORIZED to operate professional

projection systems.

A PRESENT series projector is intended “FOR PROFESSIONAL USE ONLY” by AUTHORIZED PERSONNEL familiar with potential hazards associated with high voltage, high intensity light beams, ultraviolet exposure and high temperatures generated by the lamp and associated circuits. Only qualied SERVICE PERSONNEL, knowledge-

able of such risks, are allowed to perform service functions inside the product enclosure.

Owners record

The part number and serial number are printed on a label which is stuck on the respective part. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Barco dealer regarding this product.

Product article number

Product serial number

Dealer

1.2 Important safety instructions

To prevent the risk of electrical shock

This product should be operated from a mono phase AC power source. y

This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If none of the sup- y plied power cables are the correct one, consult your dealer. If you are unable to insert the plug into the outlet,

contact your electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding-type plug.

Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. y

To disconnect the cord, pull it out by the plug. Never pull the cord itself.

Use only the power cord supplied with your device. While appearing to be similar, other power cords have not y been safety tested at the factory and may not be used to power the device. For a replacement power cord, contact your dealer.

Do not operate the projector with a damaged cord. Replace the cord. Do not operate the projector if the projec- y tor has been dropped or damaged until it has been examined and approved for operation by a qualied service

technician.

Position the cord so that it will not be tripped over, pulled, or contact hot surfaces. y

If an extension cord is necessary, a cord with a current rating at least equal to that of the projector should be y used. A cord rated for less amperage than the projector may overheat.

Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage y

points or short out parts that could result in a risk of re or electrical shock.

Do not expose this projector to rain or moisture. y

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

Do not immerse or expose this projector in water or other liquids. y

Do not spill liquid of any kind on this projector. y

Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualied service y

personnel before resuming operations.

Do not disassemble this projector, always take it to an authorized trained service person when service or repair y work is required.

Do not use an accessory attachment which is not recommended by the manufacturer. y

Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and y unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the device due to lightning and AC power-line surges.

To prevent personal injury

Isolate electrically before replacing the lamp or lamp house. Caution: Hot lamp (house). y

Caution: High pressure lamp may explode if improperly handled. Refer servicing to qualied service personnel. y

To prevent injury and physical damage, always read this manual and all labels on the system before inserting y the lamp casing, connecting to the wall outlet or adjusting the projector.

To prevent injury, take note of the weight of the projector. y

To prevent injury, ensure that the lens and all covers are correctly installed. See installation procedures. y

Warning: high intensity light beam. NEVER look into the lens ! High luminance could result in damage to the y eye.

Warning: extremely high brightness lamps: This projector uses extremely high brightness lamps. Never attempt y to look directly into the lens or at the lamp. If the projection distance is less than 6 meter, any person needs to

be at least 4 meters away from the projected image. Avoid close range reection of the projected image on any reecting surface (such as glass, metal, …) . When operating the projector, we strongly recommend wearing

suitable safety glasses.

Before attempting to remove any of the projector’s covers, you must turn off the projector and disconnect from y the wall outlet.

When required to switch off the projector, to access parts inside, always disconnect the power cord from the y power net.

The power input at the projector side is considered as the disconnect device. When required to switch off the y projector, to access parts inside, always disconnect the power cord at the projector side. In case the power input at the projector side is not accessible (e.g. ceiling mount), the socket outlet supplying the projector shall be installed nearby the projector and be easily accessible, or a readily accessible general disconnect device shall

be incorporated in the xed wiring.

Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious damage y

to it and possible injury to the user.

It is hazardous to operate without lens or shield. Lenses, shields or ultra violet screens shall be changed if they y have become visibly damaged to such an extent that their effectiveness is impaired. For example by cracks or deep scratches.

Warning: Protection from ultraviolet radiation: Do not look directly in the light beam. The lamp contained in this y product is an intense source of light and heat. One component of the light emitted from this lamp is ultraviolet

light. Potential eye and skin hazards are present when the lamp is energized due to ultraviolet radiation. Avoid unnecessary exposure. Protect yourself and your employees by making them aware of the hazards and how

to protect themselves. Protecting the skin can be accomplished by wearing tightly woven garments and gloves.

Protecting the eyes from UV can be accomplished by wearing safety glasses that are designed to provide UV protection. In addition to the UV, the visible light from the lamp is intense and should also be considered when

choosing protective eye wear.

Exposure to UV radiation: Some medications are known to make individuals extra sensitive to UV radiation. The y American Conference of Governmental Industrial Hygienists (ACGIH) recommends occupational UV exposure for an-8 hour day to be less than 0,1 micro-watts per square centimeters of effective UV radiation. An evaluation

of the workplace is advised to assure employees are not exposed to cumulative radiation levels exceeding these

government guidelines. The exposer of this UV radiation is allowed for only 1 hour per day for maintenance and

service persons.

Mercury Vapor Warnings: Keep the following warnings in mind when using the projector. The lamp used in the y projector contains mercury. In case of a lamp rupture, explosion there will be a mercury vapor emission. In order

to minimize the potential risk of inhaling mercury vapors: - Ensure the projector is installed only in ventilated

rooms. - Replace the lamp module before the end of its operational life. - Promptly ventilate the room after a lamp rupture, explosion has occurred, evacuate the room (particularly in case of a pregnant woman). - Seek

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

medical attention if unusual health conditions occur after a lamp rupture, explosion, such as headache, fatigue, shortness of breath, chest-tightening coughing or nausea.

To prevent re hazard

Do not place ammable or combustible materials near the projector! y

Barco large screen projection products are designed and manufactured to meet the most stringent safety regu- y lations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation,

which is both normal and safe. Exposing ammable or combustible materials into close proximity of this projector could result in the spontaneous ignition of that material, resulting in a re. For this reason, it is absolutely necessary to leave an “exclusion zone” around all external surfaces of the projector whereby no ammable or combustible materials are present. The exclusion zone must be not less than 50 cm (20”) for all DLP projectors. The exclusion zone on the lens side must be at least 5 m. Do not cover the projector or the lens with any material while the projector is in operation. Keep ammable and combustible materials away from the projector at all times. Mount the projector in a well-ventilated area away from sources of ignition and out of direct sun light. Never expose the projector to rain or moisture. In the event of re, use sand, CO2 or dry powder re extinguishers. Never use water on an electrical re. Always have service performed on this projector by authorized Barco

service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.

Slots and openings in this equipment are provided for ventilation. To ensure reliable operation of the projector y and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the projector too close to walls, or other similar surface. This projector should never be placed near or over a radiator or heat register. This projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.

Projection rooms must be well ventilated or cooled in order to avoid build up of heat. y

Let the projector cool down completely before storing. Remove cord from the projector when storing. y

Heat sensitive materials should not be placed in the path of the exhausted air or on the lamp house. y

To prevent projector damage

This projector has been designed for use with a specic lamp (house) type. See installation instructions for its y correct type.

The air lters of the projector must be cleaned or replaced on regular base (a “clean” booth would be monthly- y minimum). Neglecting this could result in disrupting the air ow inside the projector, causing overheating. Over-

heating may lead to the projector shutting down during operation.

The projector must always be installed in a manner which ensures free ow of air into its air inlets and unim- y peded evacuation of the hot air from its cooling system.

In order to ensure that correct airow is maintained, and that the projector complies with Electromagnetic Com- y patibility (EMC) requirements, it should always be operated with all of its covers in place.

Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and y to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. The device should not be placed in a built-in installation or enclosure unless proper ventilation is provided.

Ensure that nothing can be spilled on, or dropped inside the projector. If this does happen, switch off and unplug y

the mains supply immediately. Do not operate the projector again until it has been checked by qualied service

personnel.

Do not block the projector cooling fans or free air movement around the projector. Loose papers or other objects y may not be nearer to the projector than 30 cm (12”) on any side.

Do not use this equipment near water. y

Special care for Laser Beams: Special care should be used when DLP projectors are used in the same room as y high power laser equipment. Direct or indirect hitting of a laser beam on to the lens can severely damage the Digital Mirror Devices™ in which case there is a loss of warranty.

Never place the projector in direct sun light. Sun light on the lens can severely damage the Digital Mirror De- y vices™ in which case there is a loss of warranty.

Save the original shipping carton and packing material. They will come in handy if you ever have to ship your y

equipment. For maximum protection, repack your set as it was originally packed at the factory.

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use y a damp cloth for cleaning. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since

these will damage the cabinet. Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

20°

To ensure the highest optical performance and resolution, the projection lenses are specially treated with an y

anti-reective coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do

not use a damp cloth, detergent solution, or thinner.

Rated maximum ambient temperature, ta= 40 °C (104 °F). y

The lamp house shall be replaced if it has become damaged or thermally deformed. y

Horizontal and vertical projector tilt ranges: The projector is designed to work in a table or ceiling mounted posi- y tion, but tilting is allowed. Side to side tilt, however, must not exceed +/- 20°. This limit ensures that the lamp in the projector operates properly and safely.

A: Tilting allowed without problems -

B: No tilting allowed in this area -

Front View Side View

On servicing

Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous y voltage potentials and risk of electric shock.

Refer all servicing to qualied service personnel. y

Attempts to alter the factory-set internal controls or to change other control settings not specially discussed in y this manual can lead to permanent damage to the projector and cancellation of the warranty.

Unplug this product from the wall outlet and refer servicing to qualied service technicians under the following y conditions:

When the power cord or plug is damaged or frayed. -

If liquid has been spilled into the equipment. -

If the product has been exposed to rain or water. -

If the product does not operate normally when the operating instructions are followed. Adjust only those controls that are covered by the operating instructions since improper adjustment of the other controls may

result in damage and will often require extensive work by a qualied technician to restore the product to

normal operation.

If the product has been dropped or the cabinet has been damaged. -

If the product exhibits a distinct change in performance, indicating a need for service. -

Replacement parts: When replacement parts are required, be sure the service technician has used original y Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, re, electric shock or other hazards. Unauthorized substitutions may void warranty.

Safety check: Upon completion of any service or repairs to this projector, ask the service technician to perform y

safety checks to determine that the product is in proper operating condition.

Possible explosion hazard: Always keep in mind the caution below: y

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

1. Safety

To prevent battery explosion

Danger of explosion if battery is incorrectly installed. y

Replace only with the same or equivalent type recommended by the manufacturer. (AAA LR03,1.5V) y

For disposal of used batteries, always consult federal, state, local and provincial hazardous waste disposal rules y

and regulations to ensure proper disposal.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

2. Introduction

2. INTRODUCTION

About this chapter

Read this chapter before installing PRESENT series projector. It contains important information concerning instal-

lation requirements for the PRESENT series projector, such as minimum and maximum allowed ambient temperature, humidity conditions, required safety area around the installed projector, required power net, etc.

Furthermore, careful consideration of things such as image size, ambient light level, projector placement and type

of screen to use are critical to the optimum use of the projection system.

Overview

Installation requirements y

Projector package overview y

Note: Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. Observing the specication mentioned in this chapter is critical for projector performance. Neglecting this can result in loss of warranty.

2.1 Installation requirements

Environment conditions

Table below summarizes the physical environment in which the PGXG-61B/PGWX-61B/PGWU-61B projector may

be safely operated or stored.

Environment Operating Non-Operating

Ambient Temperature 5 °C (41 °F) to 40 °C (104 °F) -10°C (14°F) to 60°C (140°F)

Humidity 10% to 85% RH Non-Condensed 5% to 90% RH Non-Condensed

Altitude 0 (0Ft) to 3000m (9843Ft)

Cooling requirements

The projector is fan cooled and must be installed with sufcient space around the projector head, minimum 30 cm (12 inch) to ensure sufcient air ow. It should be used in an area where the ambient temperature, as measured at the projector air inlet , does not exceed +40°C (+104°F).

Clean air environment

A projector must always be mounted in a manner which ensures the free ow of clean air into the projectors ventilation inlets. For installations in environments where the projector is subject to airborne contaminants such as that produced by smoke machines or similar (these deposit a thin layer of greasy residue upon the projectors internal optics and imaging electronic surfaces, degrading performance), then it is highly advisable and desirable to have

this contamination removed prior to it reaching the projectors clean air supply. Devices or structures to extract or shield contaminated air well away from the projector are a prerequisite, if this is not a feasible solution then mea-

sures to relocate the projector to a clean air environment should be considered.

Only ever use the manufacturer’s recommended cleaning kit which has been specically designed for cleaning

optical parts, never use industrial strength cleaners on the projector’s optics as these will degrade optical coatings and damage sensitive optoelectronics components. Failure to take suitable precautions to protect the projector from the effects of persistent and prolonged air contaminants will culminate in extensive and irreversible ingrained

optical damage. At this stage cleaning of the internal optical units will be noneffective and impracticable. Damage of

this nature is under no circumstances covered under the manufacturer’s warranty and may deem the warranty null and void. In such a case the client shall be held solely responsible for all costs incurred during any repair. It is the clients responsibility to ensure at all times that the projector is protected from the harmful effects of hostile airborne particles in the environment of the projector. The manufacturer reserves the right to refuse repair if a projector has been subject to knowingly neglect, abandon or improper use.

Main Power requirements

The PRESENT series projector operates from a nominal mono phase power net with a separate earth ground PE.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

2. Introduction

Projector Power requirements

PGXG-61B AC INPUT 100-240V, 6.5A, 50/60Hz

PGWX-61B AC INPUT 100-240V, 6.5A, 50/60Hz

PGWU-61B AC INPUT 100-240V, 6.5A, 50/60Hz

The power cord required to connect the projector with the power net is delivered with the projector.

Projector weight

Do not underestimate the weight of the projector. The projector weights about 17±0.5 kg without lens. Be sure that the pedestal or ceiling mount on which the projector has to be installed is capable of handling ve (5) times the

complete load of the system.

2.2 Projector package overview

Box content

This projector comes with all the items shown below. Check to make sure your package is complete. Contact your dealer immediately if anything is missing.

Projector

Power Cord (China) Power Cord (EU) Power Cord (US)

Remote Control with two AAA size

batteries

User Guide, Quick Start

Guide, Safety Manual

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

2. Introduction

2.3 Product Overview

2.3.1 Main Unit

Component Location

Projection Lens

Lamp Cover

Tilt-Adjustment Feet

Input/Output (I/O) Panel

Power Switch

Power Socket (AC Input: AC100-240V~, 50-60Hz)

Note: The Projection Lens is optional item not a standard accessary in the package.

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

2. Introduction

2.3.2 Input/Output (I/O) Panel

Component Location

Networking Connector RJ45

DVI-D Input ConnectorVideo Input Connector

BNC Input Connector (YPbPr/RGBHV)

+12V Relay Connector

6 7

431

8 9

Video Input Connector

HDMI Connector

VGA Connector (PC Analog Signal/Component Video Input)

Monitor Connector (Loop from VGA)

RS232 Connector

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

2. Introduction

2.3.3 Remote Control

Button Location

On/Off

Home

Arrow Right

Arrow Up

Arrow Left

Arrow Down

LED Indication

Battery Compart-

ment

IR LED’S

Use the remote control to control these functions.

Basic Remote Command

(Result)

Start the projector Press “On/off”

Turn off the projector Press “On/off”

Remote Lite

(Action)

> 1

Show main menu on screen Press “Home”

Move through menu Press “Arrow keys”

Select button Press “OK”

Select and return to previous menu Press “OK”

Return to previous menu without selecting Press “Home”

Clear OSD Lite of screen Press “Home”

Activate picture mute function Press 2x “Arrow Up” Press any key to deactivate

Activate picture freeze function Press 2x “Arrow Left”

6 4

Press 2x “Arrow Left” again to deactivate

PGXG-61B/PGWX-61B/PGWU-61B - - 2015/04/01

3. INSTALLATION

Overview

RCU Battery Installation y

Installing the Lens y

Connecting the Projector y

Powering On/Off the Projector y

Adjusting the Projected Image y

Ceiling Mount Installation y

3.1 RCU Battery Installation

Procedure:

Remove the cover by sliding it in the direction indicated by the arrow. 1. Insert two new AAA batteries (observe the polarity). 2. Replace the cover. 3.

3. Installation

Notes for the Remote Control Unit

Be sure to insert the batteries in the corresponding orientations to match the polarities. y Do not mix new batteries with used batteries as it would shorten the life of new batteries or cause leak- y

age. Only used AAA batteries as instructed; do not attempt to insert different types of batteries into the y

remote control. If the remote is going to be unused for long periods of time, be sure to remove the batteries to prevent y

leakage, which could damage the remote control. The liquid contents in the batteries is harmful to the skin; do not touch the leakage with your bare y

hands directly. When installing fresh batteries, be sure to clean up the leakage thoroughly.

Under most circumstances, you only need to point the remote control towards the screen and the IR y signal would be reected off the screen and picked up by the IR sensor on the projector. But under specic circumstances, the projector may fail to receive signals from the remote control due to environ-

mental factors. When this happens, orient the remote control at the projector and try again. If the range of effective remote control signal reception decreases or if the remote control stops work- y

ing, replace the batteries. If the infrared receiver is exposed to uorescent lamp or strong sunlight, the remote control may not y

operate normally. Refer to the regulations enforced by your local government on the disposal of used batteries; improper y

disposal could damage the environment.
