Barco LC-42, LC-47 User Manual

User's manual

LC series

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

________________________________________________________________________________________

i

Title: LC SERIES
Date: March 2006
ProdID: R5976934

Revision: 05

This manual is divided into 11 chapters:

main
issue

update

Warranty
statement

Rev. 05

chapter 1

chapter 2 Rev. 03: new dimensions LC-47

chapter 3

chapter 4

chapter 5 OSD update

chapter 6

chapter 7

chapter 8 Rev. 03: new dimensions LC-47

chapter 9 Revised timing

chapter 10

chapter 11 Rev. 03, FCC statement

new: The corresponding chapters are new or completely revised.

corr.: Passages of the corresponding chapter were corrected; see modification bars.

add.: Passages of the corresponding chapter were added; see modification bars.

Document History

Modifications which result in a new version are indicated by a vertical bar.

ii

___________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

Trademarks

Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of
their respective holders. All brand and product names mentioned in this manual serve as comments or examples
and are not to be understood as advertising for the products or their manufacturers.

Copyright © 2005/2006 by Barco

Die Weitergabe sowie die Vervielfältigung aller Unterlagen, die von uns überlassen werden, deren Verwertung
und Mitteilung ihres Inhaltes an Dritte ist nicht gestattet, soweit dies nicht ausdrücklich zugestanden ist. Urheber­rechte, insbesondere auch solche an Software, werden nur insoweit übertragen, als es für die Erreichung des
speziellen Vertragszwecks erforderlich ist. Zuwiderhandlungen können zu Schadensersatz verpflichten. Alle Rech­te aus der Erteilung eines Patents oder der Eintragung eines Gebrauchsmusters verbleiben bei uns.

Copyright © 2005/2006 by Barco

All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

______________________________________________________________________________________

iii

WARRANTY STATEMENT

WARRANTY STATEMENTWARRANTY STATEMENT

WARRANTY STATEMENT

1 Warranty

(a) Hardware: Barco warrants that upon delivery hereunder the Products shall (i) conform to its specifi-

cations in effect at the date of delivery and (ii) be free from defects in material and workmanship
(the "Warranties").

(b) Software: Barco warrants that software written by Barco shall perform substantially in accordance

with the specifications in effect at the date of delivery. Software is inherently susceptible to bugs
and errors. Barco makes no warranties with respect to the software which is provided to Buyer on
an "as-is" basis and does no warrant uninterrupted or error-free operation of the Products.

2 The Warranty Period

(a) Hardware: 24 months commencing on the date of delivery.

(b) Software: 24 months commencing on the date of delivery.

3 Conditions precedent for Warranties to apply

The Warranties shall apply only to the extent the Products or any part thereof have

(i) been transported and stored at all times in the original packaging in the conditions as specified by

Barco (such as covered and secure location, minimum temperature, maximum humidity, …) or, in
absence thereof, at least in conditions consistent with generally accepted practice for this type of
products;

(ii) been handled at all times in accordance with Barco's instructions or, in absence thereof, at least

with the care and caution consistent with generally accepted practice for this type of products;

(iii) been installed strictly in accordance with the instructions and directions given by Barco (if and to

the extent the Products have not been installed by Barco or its authorized subcontractors);

(iv) not been subject to not any unauthorized access, alteration, modification or repair or attempts

thereto;

(v) been at all times "normally used" for the intended purpose and operated in strict accordance with

the operating instructions set forth in the operating manual of the Product in question and shall not
have been otherwise misused, abused, damaged. For the purpose hereof, "normally used" shall
mean a regular, ordinary and routine usage of the Product in question as intended and/or recom­mended by Barco;

(vi) been maintained at all times in accordance with Barco's instructions or, in absence thereof, at least

with intervals and in a manner consistent with generally accepted practice for this type of prod­ucts;

(vii) not been connected to or used in combination with other equipment, products or systems (hardware
and/or software), which are not compatible with the specifications of the Product in question.

4 In no event shall Barco be liable, whether during or after the expiration of the Warranty Period for any

defects, failures, loss of or damage to the Products or any part thereof which are caused by or resulting
from (i) wear and tear or (ii) any force majeure event, or (iii) Buyer’s use or operation of the Product prior
to the performance of Barco’s acceptance test(s) for the Product in question, or (iv) any action or negli­gence on the part of Buyer or any third party (including without limitation Buyer's employees, customers,
agents, carriers and contractors). In such case the repair or replacement of the Product or any part thereof
shall be at Buyer's sole option and cost. Any Product or any part thereof which is entirely manufactured by
third parties, is subject to the original manufacturer's warranty and no separate warranty is given in re­spect thereof by Barco.

In no event shall Barco be liable, whether during or after the expiration of the Warranty Period for any
image retention (shadows, dark lines and other image artifacts) phenomena on Products resulting from
prolonged continuous use of the Product as these phenomena are immanent to LCD technology and any
LCD display can show these image retention (shadows, dark lines and other image artifacts) phenomena.

5 Claims for repair or replacement under Warranties

iv

__________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

Any claim under the Warranties must be notified to Barco in writing within 8 days from the date the de­fect or failure has been discovered or noticed the first time.

6 Remedies under the Warranties

(a) Hardware: If during the Warranty Period a Product or any part thereof, fails to meet any of the

Warranties then, upon Buyer's request, Barco shall, at its sole option and cost, promptly and within
20 working days, either: (i) repair or correct the Product or part in question; or (ii) replace the
Product or supply part(s) or component(s). A replacement part shall be at least functionally
equivalent to the original part. The replaced Product, parts and/or components shall become the
property of Barco and shall, at Barco's request, be returned by Buyer to Barco at Barco's cost.

(b) Software: Barco's sole obligation shall be to rectify substantial malfunctions of the software (to the

extent technically reasonably possible) by amending the software or supplying an alternative
version of the software.

(c) The repair or replacement under the Warranties covers the cost of material and labor.

7 Return of defective Product or parts to Barco and back to Buyer

In no event shall Buyer return a defective Product or part thereof to Barco without Barco's prior written
approval.

Prior to returning any defective Product or part thereof to Barco, Barco shall, in common consent with
Buyer, determine whether the repair or replacement of the defective Product shall be carried out at either
the location where the Product is installed or at Barco's facility.

In the event the return to Barco of the defective Product is authorized by Barco, Barco shall issue to Buyer
a RAN (Return Authorization Number).

The one-way cost of packing, transport and insurance related to shipping the alleged defective Product or
part to Barco for repair or replacement shall be borne by Buyer. The one-way cost of packing, transport
and insurance related to shipping of the repaired or replacement Product or part to Buyer shall be borne
by Barco.

The travel time and the travel and living expenses of a service engineer of Barco to the location where the
alleged defective Product is installed, shall be charged to and paid by Buyer in accordance with Barco's
current rates and procedures.

8 The remedies specified herein shall constitute Buyer's sole and exclusive remedy and Barco's sole and

exclusive liability for Barco’s breach of the Warranties hereunder.

9 BARCO MAKES NOR INTENDS TO MAKE ANY OTHER WARRANTIES OR REPRESENTATIONS, EXPRESS OR IMPLIED,

AND IT EXPRESSLY EXCLUDES AND DISCLAIMS ANY AND ALL WARRANTIES WHICH MAY BE IMPLIED OR OTHER­WISE CREATED BY OPERATION OF LAW INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF UNIN­TERRUPTED OR ERROR-FREE USE OR OPERATION, AND MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.

10 After expiration of the Warranty Period, Barco and Buyer shall, at Buyer's request, negotiate in good faith

the scope and mutually acceptable terms and conditions of after sales services to be provided by Supplier.

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_______________________________________________________________________________________

v

Revision sheet

To:

• Barco Control Room GmbH

Barco Control Room GmbHBarco Control Room GmbH

Barco Control Room GmbH
An der Rossweid 5, D-76229 Karlsruhe
Phone: [phone], Fax: [phone]
E-mail: [e-mail], Web: www.barcocontrolrooms.de

From:

Date:

Please correct the following points in this documentation:

page wrong correct

vi

__________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

Contents

1 Preliminary Remarks .........................................................................................................................1-1

1.1 How this manual is organized ....................................................................................................................1-2

1.2 Styles and symbols......................................................................................................................................1-3

1.3 Safety information.......................................................................................................................................1-4

1.3.1 Safety on installation..........................................................................................................................1-4

1.3.2 Safety on servicing .............................................................................................................................1-7

1.3.3 Safety on shipping..............................................................................................................................1-8

1.3.4 Precautions .........................................................................................................................................1-8

1.3.5 Malfunction or Trouble .......................................................................................................................1-8

1.3.6 Unpacking of devices..........................................................................................................................1-9

1.3.7 Modification of devices ......................................................................................................................1-9

1.3.8 Disposal or handing over to a new owner........................................................................................1-9

1.3.9 Exemptions..........................................................................................................................................1-9

2 Unpacking and installation................................................................................................................ 2-1

2.1 Unpacking ....................................................................................................................................................2-2

2.2 Installation ...................................................................................................................................................2-3

2.2.1 Mounting of the table stand (optional).............................................................................................2-3

2.2.2 Dimensions of the 42" monitor:.........................................................................................................2-4

2.2.3 Dimensions of the 47" monitor:.........................................................................................................2-5

2.3 Examining the monitor................................................................................................................................2-6

2.3.1 Front view...........................................................................................................................................2-6

2.3.2 Side view.............................................................................................................................................2-6

2.3.3 Rear view............................................................................................................................................2-7

2.4 Cabling .........................................................................................................................................................2-8

2.5 Switching on and off ...................................................................................................................................2-8

2.6 Inserting batteries into the Infrared remote control unit..........................................................................2-9

3 Design and function........................................................................................................................... 3-1

3.1 Display of choice..........................................................................................................................................3-2

3.2 Technology...................................................................................................................................................3-3

3.2.1 Principle of LCD technology................................................................................................................3-3

4 Controlling.......................................................................................................................................... 4-1

4.1 General.........................................................................................................................................................4-2

4.1.1 The push buttons ................................................................................................................................4-2

4.1.2 The IR remote control unit .................................................................................................................4-3

4.2 Terminology of the RCU controls ................................................................................................................4-4

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

______________________________________________________________________________________

vii

4.3 Monitor address...........................................................................................................................................4-5

4.3.1 Displaying a monitor address ............................................................................................................4-5

4.3.2 The function keys................................................................................................................................4-6

4.3.3 Picture controls with direct access.....................................................................................................4-6

4.3.4 Audio controls with direct access.......................................................................................................4-6

5 The On Screen Display (OSD) ............................................................................................................. 5-1

5.1 General.........................................................................................................................................................5-2

5.1.1 Navigation and adjustment................................................................................................................5-3

5.2 Activating the OSD.......................................................................................................................................5-4

5.3 The signal menu (first and second input)..................................................................................................5-6

5.3.1 Display.................................................................................................................................................5-7

5.3.2 Position............................................................................................................................................. 5-11

5.3.3 PIP control........................................................................................................................................ 5-14

5.3.4 Image ............................................................................................................................................... 5-18

5.3.5 Color ................................................................................................................................................. 5-26

5.4 OSD setting menu..................................................................................................................................... 5-29

5.4.1 Vertical ............................................................................................................................................. 5-30

5.4.2 Horizontal......................................................................................................................................... 5-30

5.4.3 Blend ................................................................................................................................................ 5-30

5.4.4 Time out ........................................................................................................................................... 5-31

5.4.5 OSD Zoom......................................................................................................................................... 5-31

5.5 Audio setting menu.................................................................................................................................. 5-32

5.5.1 Volume............................................................................................................................................. 5-33

5.5.2 Balance............................................................................................................................................. 5-33

5.5.3 Balance............................................................................................................................................. 5-33

5.5.4 Treble ............................................................................................................................................... 5-34

5.6 Language setting menu........................................................................................................................... 5-35

5.7 Reset menu............................................................................................................................................... 5-37

5.7.1 Factory Reset ................................................................................................................................... 5-38

5.7.2 Set display address.......................................................................................................................... 5-39

5.7.3 Light Sensor ..................................................................................................................................... 5-39

5.7.4 Light Sensor Value ........................................................................................................................... 5-39

5.7.5 Light Sensor Threshold .................................................................................................................... 5-40

5.8 Input Signal Selection............................................................................................................................... 5-41

5.8.1 Input selection with the function key F1........................................................................................ 5-44

6 Maintenance and servicing ............................................................................................................... 6-1

6.1 Cleaning .......................................................................................................................................................6-2

7 Technical data LC-42 .......................................................................................................................... 7-1

7.1 General data ................................................................................................................................................7-1

7.2 LCD panel .....................................................................................................................................................7-1

7.3 Electrical data ..............................................................................................................................................7-1

viii

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

7.4 Operating conditions ...................................................................................................................................7-2

7.5 CCFL (Cold Cathode Fluorescent Lamp) characteristics (ambient temperature (25 ±2)°C)......................7-2

7.6 Interfaces .....................................................................................................................................................7-2

7.6.1 Video IN (Composite Video)...............................................................................................................7-2

7.6.2 S-Video ................................................................................................................................................7-3

7.6.3 Component Video (mini DIN 8 pin) ...................................................................................................7-3

7.6.4 DVI .......................................................................................................................................................7-5

7.6.5 RGB IN (D-Sub 15 pin)........................................................................................................................7-6

7.6.6 RS232 IN..............................................................................................................................................7-6

7.6.7 RS232 OUT...........................................................................................................................................7-7

7.7 Factory settings ...........................................................................................................................................7-7

8 Technical data LC-47 .......................................................................................................................... 8-1

8.1 General data ................................................................................................................................................8-1

8.2 LCD panel .....................................................................................................................................................8-1

8.3 Electrical data ..............................................................................................................................................8-1

8.4 Operating conditions ...................................................................................................................................8-2

8.5 CCFL (Cold Cathode Fluorescent Lamp) characteristics (ambient temperature (25 ±2)°C)......................8-2

8.6 Interfaces .....................................................................................................................................................8-2

8.6.1 Video IN (Composite Video)...............................................................................................................8-2

8.6.2 S-Video ................................................................................................................................................8-3

8.6.3 Component Video ...............................................................................................................................8-3

8.6.4 DVI .......................................................................................................................................................8-5

8.6.5 RGB IN (D-Sub 15 pin)........................................................................................................................8-5

8.6.6 RS232 IN..............................................................................................................................................8-6

8.6.7 RS232 OUT...........................................................................................................................................8-6

8.7 8.4 Factory setting.......................................................................................................................................8-7

9 Compliant timing ............................................................................................................................... 9-1

10 Troubleshooting ............................................................................................................................. 10-1

10.1 Faults....................................................................................................................................................... 10-2

10.2 Contact.................................................................................................................................................... 10-3

11 Compliance statement................................................................................................................... 11-1

11.1 FCC Compliance statement .................................................................................................................... 11-1

1. Preliminary Remarks

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

1-1

1 Preliminary Remarks

This manual describes unpacking, installation, cabling and controlling of the monitors of Barco's LC series.

The monitors of Barco's LC series are based on Super MVA TFT LCD technology and feature bright and wide im­ages with clear contrast.

The LCD panels have 1920x1080 pixels (HD resolution) to allow extreme fine pictures at 16.7 millions colors.

The monitors provide a set of interfaces to connect any analog video and analog and digital RGB data .

All settings can easily be accessed and modified by means of the Infrared remote control unit and the OnScre­enDisplay.

RS232 remote control is also possible.

The monitors are available with a screen diagonal of 42" and 47".

LC-47

Monitor with a screen diagonal of 47inch, Super MVA TFT LCD technology, HD
resolution (1920x1080 pixels), aspect ratio 16:9

LC-42

Monitor with a screen diagonal of 42inch, Super MVA TFT LCD technology, HD
resolution (1920x1080 pixels), aspect ratio 16:9

1. Preliminary Remarks

1-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

1.1 How this manual is organized

This manual is divided into 10 chapters:

• Preliminary remarks

explains the structure of the manual itself and the used typographic styles and symbols. Safety information is
provided concerning the monitors of Barco's LC series.

• Summary

provides a summary of the system components and characteristics.

• Design and function

provides a technical description of the equipment listing the fundamental characteristics and functional prin­ciples. Knowledge of this section is not absolutely essential for operation.

• Controlling

explains how the monitors are controlled

• The On Screen Display

explains the commands of the menus

• Maintenance and servicing

explains how the equipment can be serviced.

• Technical data of LC-42

provides tabular overviews about the technical details of the monitor LC-42.

• Technical data of LC-47

provides tabular overviews about the technical details of the monitor LC-47

• Compliant timing

lists the compliant timing of the monitor

• Trouble shooting

gives hints in case the monitor does not work

Chapters, pages, and tables are numbered separately. Chapters are indicated by a »point syntax«, e. g. 4.2.3,
pages and tables by a »dash syntax«, e. g. 2-1.

1. Preliminary Remarks

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

1-3

1.2 Styles and symbols

The typographic styles and the symbols used in this document have the following meaning:

Bold Labels, menus and buttons are printed in Bold font.

Condensed

Links to both other chapters of this manual and to sites in the Internet are printed

condensed. In the on-line version of this manual all hyperlinks appear teal.

Courier Names of files and parts from programs are printed in the Courier font.

Courier bold Inputs you are supposed to do from the keyboard are printed in Courier bold font.

If you do not heed instructions indicated by this symbol there is a risk of damage to the
equipment!

If you do not heed instructions indicated by this symbol there is a risk of electrical shock
and danger to personal health!

If you do not heed instructions indicated by this symbol there is a risk of damage to parts,
which are sensitive towared electrostatic charge!

If you do not heed instructions indicated by this symbol there is a risk to get harmed by
sharp objects!

If you do not heed instructions indicated by this symbol there is a risk that parts may
explode!

If you do not heed instructions indicated by this symbol there is a risk that hot parts impact
persons or objects!

The sheet icon indicates additional notes.

Next to this icon you find further information.

This arrow marks tips.

Next to this icon you find important notes.

1. Preliminary Remarks

1-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

1.3 Safety information

This section describes safety precautions which must be observed when installing a product from Barco.

Safety standards

The safety standards of information technology equipment impose important requirements on the use of safety
critical components, materials and isolation, in order to protect the user or operator against the risk of electric
shock and energy hazard, and having access to live parts.

Safety standards also impose limits to the internal and external temperature rises, radiation levels, mechanical
stability and strength, enclosure construction and protection against risk of fire.

Simulated single fault condition testing ensures the safety of the equipment to the use even when the equip­ment’s normal operation fails.

General safety instructions

• All the safety and operating instructions should be read before using this unit.

• The operating instructions manual should be retained for future reference.

• All warnings on the device and in the documentation manuals should be adhered to.

• All instructions for operating and use of this equipment must be followed precisely.

• All local installation codes should be adhered to.

Installation and preliminary adjustments should be performed by qualified Barco
personnel or authorized Barco service dealers.

1.3.1 Safety on installation

Check the power rating on your outlet before connecting the devices to the wall outlet or
to a power strip. Contact your facilities manager or a qualified electrician if you are not
sure what type of power is supplied to your building.

The devices are designed to operate with single-phase power systems having a
grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any
other type of power system.

A. Mains lead (AC Power cord) with CEE 7 plug:

The colors of the mains lead are colored in accordance with the following code:

Green-and-yellow: Earth (safety earth)

Blue: Neutral

Brown: Line (live)

1. Preliminary Remarks

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

1-5

B. Power cord with NEMA 15-5 plug:

The wires of the power cord are colored in accordance with the following code:

Green or green/yellow: Ground

White or blue: Neutral

Blackor brown: Line (live)

• Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the

cord.

• To disconnect the cord, pull it out by the plug. Never pull the cord itself.

• If an extension cord is used with this product, make sure that the total of the ampere ratings on the products

plugged into the extension cord does not exceed the extension cord ampere rating. Also make sure that the
total of all products plugged into the wall outlet does not exceed 15 amperes.

• Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage

points or short out parts that could result in a risk of fire or electrical shock.

• Never spill liquid of any kind on the product. Should any liquid or solid object fall into the cabinet, unplug the

set and have it checked by qualified service personnel before resuming operations.

• Lightning - For added protection for this video product during a lightning storm, or when it is left unattended

and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the monitor
due to lightning and AC power-line surges.

Warning: Do not place flammable or combustible materials near the monitor!

Transportation

• Any transportation of the unopened unit in its packaging should be done by two persons.

• In transportation or storage of products in original packing, NEVER stack more than the number stated on the

carton box. This warning is also indicated on the side of the card box.

• For transportation or storage, observe the warnings and instructions on the side of the card box.

Nearby equipment

If air conditioning ducts or lamps, etc. are located near the installation site, the attendant dust, extreme tem­peratures, humidity, and condensation may become sources of trouble. Please take sufficient steps to avoid this.

Safety locations

Do not install the unit where it may be easily touched or leaned against. Avoid locations subject to high vibra­tions or severe impacts. Do not install the unit where it is exposed to humidity, oil, smoke or excessive dust.

Mechanical stress.

Please be careful not to apply strong mechanical stress (shock, drop) to the LCD module. Such stress may cause
break of screen glass and lamp or may be the cause for failure.

Pressure to screen surface.

Please be careful not to apply strong pressure to the screen surface. Such pressure may cause scratches at the
surface or may be the cause of failure.

1. Preliminary Remarks

1-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

Protection against scratch.

Please be careful not to hit, press or rub the screen surface with hard material like tools. In addition, please do
not put heavy or hard material on the screen surface, and do not stack monitors. Polarizer at the front surface
can be easily scratched.

Temperature dependence of the display.

Response speed (optical response) of the LCD display is dependent on temperature. Under low temperature,
response speed is slower. Also brightness and chromaticity change slightly depend on temperature.

Image retention

Displaying the same pattern for a long time may cause image sticking, vertical dark lines or other forms of image
artifacts. This is a common phenomenon of all LCD displays. It disappears after some time if the pattern is
changed, or the monitor is switched off. However, image retention is not subject of warranty.
For more information contact Barco for a white paper on this topic.

Lightning conditions

Consider existing lightning and sunlight angles when creating the installation layout. Extremely bright lightning
can reduce the visibility and the quality of the displayed image.

In extremely bright surroundings, adjusting screen intensity may not result in perceptibly brighter images. Keep
in mind that extreme intensity settings can reduce system service life.

Barco products are designed and manufactured to meet the most stringent safety regulations. Exposing flamma­ble or combustible materials into close proximity of this device could result in the spontaneous ignition of that
material, resulting in a fire. For this reason, it is absolutely necessary to leave an "exclusion zone" around all
external surfaces of the monitor whereby no flammable or combustible materials are present. The exclusion zone
must be not less than 10 cm (4"). Do not cover the monitor with any material while it is in operation.

Keep flammable and combustible materials away from the monitor at all times. Mount the monitor in a well
ventilated area away from sources of ignition and out of direct sun light. Never expose this product to rain or
excessive moisture. In the event of fire, use sand, CO

2

, or dry powder fire extinguishers; never use water on an

electrical fire.

Always have service performed on this product by authorized Barco service personnel. Always insist on genuine
Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this device.

Use only the power cord supplied with your device. While appearing to be similar, other power cords have not
been safety tested at the factory and may not be used to power the display. For a replacement power cord, con­tact your dealer.

Slots and openings in the cabinet and the sides are provided for ventilation; to ensure reliable operation of the
device and to protect it from overheating, these openings must not be blocked or covered. This product should
never be placed near or over a radiator or heat register. This product should not be placed in a built-in installa­tion or enclosure unless proper ventilation is provided.

1. Preliminary Remarks

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

1-7

1.3.2 Safety on servicing

Do not attempt to service this device yourself, as opening or removing covers may expose you to dangerous
voltage potential and risk of electric shock! Refer all monitor service to a qualified Barco service center.

Adjust only those controls that are covered by the operating instructions since improper adjustment of the other
controls may result in damage and will often require extensive work by a qualified technician to restore the
product to normal operation.

Call for service in the following conditions:

• When the power cord or plug is damaged or frayed.

• If liquid has been spilled into the device.

• If the product has been exposed to rain or water.

• If the product does not operate normally when the operating instructions are followed.

• If the product has been dropped or the cabinet has been damaged;

• If the product exhibits a distinct change in performance, indicating a need for service.

Replacement parts

When replacement parts are required, be sure the service technician has used original Barco replacement parts
or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized
substitutions may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthor­ized substitutions may void warranty.

Safety check

Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.

Protection

Please do not disassemble or modify the LCD module to avoid the possibility of electric shock, damage of elec­tronic components, scratch at display surface and invasion of foreign particles. In addition, such activity may
result in fire accident due to burning of electronic component.

The LCD module disassembled or modified by customer is out of warranty.

Please be careful in handling of display with broken glass. When the display glass breaks, please pay attention
not to injure your fingers. The display surface has the plastic film attached, which prevents dispersion of glass
pieces; however touching broken edge will injure your fingers. Also the lamp (Cold Cathode Fluorescent Lamp) is
made of glass, therefore please pay attention in the same way.

Please do not touch the fluid flown out of broken display glass. If the fluid should stick to hand or clothes, wipe
off with soap or alcohol immediately and then wash it with water.

If the fluid should get in your eyes, wash your eyes immediately with pure water for more
than 15 minutes and then consult the doctor.

The lamp contains mercury inside. Please follow the regulations or rules established by
local authorities at its disposal..

1. Preliminary Remarks

1-8

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

1.3.3 Safety on shipping

Original shipping package

Save the original shipping packing material; they will come in handy if you ever have to ship one of your in­stalled modules. For maximum protection, repack your set as it was originally packed at the factory.

1.3.4 Precautions

For your own protection, observe the following safety precautions!

• Observe all warnings and instructions printed on the devices!

• Check that the voltage and frequency of your power supply match those printed on the device label with the

rated electrical values!

• Servicing not explicitly mentioned in this manual should never be carried out by unauthorized personnel!

• Some parts of the body are hot during operation. Please be careful.

• In case of moving long-distance, wrap the unit with blanket to avoid damages. Be careful not to bump the

unit.

• Do not spray

Unused for long periods of time

For added protection for this video product during a lightning storm, or when it is left unattended an unused for
long periods of time, unplug it from the wall outlet. This will prevent damage to the LCD module due to lightning
and AC power-line surges

1.3.5 Malfunction or Trouble

Trouble take the following steps risk of

Smoke or peculiar smells comes from
the unit

Remove the power plug from the out­let immediately!

Make sure that the smoke or smell has
stopped, then contact your dealer for
inspection

fire or an electric shock

No picture or sound

Remove the power plug from the out­let immediately!

Contact your dealer for inspection

fire or an electric shock

Water is spilled or objects are
dropped inside the unit

Remove the power plug from the out­let immediately!

Contact your dealer for inspection

fire or an electric shock

The unit is dropped or the cabinet is
damaged

Remove the power plug from the out­let immediately!

Contact your dealer for inspection

fire or an electric shock

The power cord or plug is damaged
or becomes hot

Power off the unit with the power
switch on the rear side.

When the power plug has cooled
down, remove the power plug from
the wall outlet!

Contact your dealer for inspection

fire or an electric shock

1. Preliminary Remarks

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

1-9

1.3.6 Unpacking of devices

Note advises on the packaging for unpacking!

Please refer to chapter 2 Unpacking and installation

1.3.7 Modification of devices

Mechanical or electrical modifications others than described in this manual must not be made to the devices.
Barco is not liable for damages resulting from modified devices.

Only authorized personnel should carry out other maintenance work not explicitly men­tioned in this user's manual!

Never open the case of the monitor without first disconnecting the power supply cord!
Measurements and tests with an opened device may be carried out only in the factory or
by specially trained personnel, due to the dangers of electrical shock.

1.3.8 Disposal or handing over to a new owner

• It is recommended to initialize the unit by resetting it to factory's default, cf. 5.7.1 Factory Reset.

• Do not mix with other general waste.

• Do not dispose the LCD monitor in waste treated by a waste treatment center.

The lamp contains mercury inside. Please follow the regulations or rules established by
local autorithies at its disposal..

1.3.9 Exemptions

• This monitor is not liable for any damage caused by natural disaster (such as earthquake, thunder, etc.),

fires, acts by third parties, accidents, owner’s intentional misuse and fault, or uses in other improper condi­tions.

• This monitor is not liable for incidental damages (such as profit loss or interruption in business, modification

or erasure of record data, etc.) caused by use or inability to use of this product.

• This monitor is not liable for any damage caused by neglect of the instructions described in the owner’s

manual.

• This monitor is not liable for any damage caused by misuse or malfunction through simultaneous use of this

product and the connected equipment or software.

• This monitor is not liable for any damage caused by neglect of the instructions described about the installa-

tion stand in the owner’s manual.

• This monitor is not liable for any damage caused by improper installation.

2. Unpacking and installation

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

2-1

2 Unpacking and installation

2. Unpacking and installation

2-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

2.1 Unpacking

The monitor is surrounded with foam for transportation protection and packed into a card box. Banding and fas­tening clips secure the package.

To unpack the monitor,

• Release the fastening clips

• Remove the banding

• Take the monitor out

• Remove the foam.

For later shipment, it is recommended to store the original packaging and to re-use it.

The following components are included in the delivery:

• The monitor itself

• 1 pc power cord (European, with CEE7 power plug)

• 1 pc power cord (American, with NEMA 15-5 (ANSI 73.11) power plug)

• 1 pc user's manual

• 1 pc Infra red remote control unit

• 1 pc RCA jack

• 1 pc DVI-D 24 pin cable

• 1 pc D-Sub 15 pin cable

• 1 pc S-Video Mini Din 4 pin cable

• 1 pc cable adapter Mini Din 8 pin to 3xRCA jack (for component video)

2. Unpacking and installation

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

2-3

2.2 Installation

Installation and preliminary adjustments should be performed by qualified Barco
personnel or authorized Barco service dealers.

Installation of the monitor shall comply with the safety instructions as listed in chapter 1.3.1 Safety on installation

• Make sure that the installation place has sufficient stability!

• Do not place the monitor near heat sources!

• Use maximum 15mm/0.59 inch long screws. Longer screws may damage the monitor!

• Ensure that the display is operating within the specified operating range +5°C – +40°C | 41°F – 104°F, at max.

90% RH, non-condensing.

• Never restrict airflow into the display by blocking any vents or air intakes.

• Leave a clearance on all vented sides of the display to permit the required airflow. Clearance should me

minimum 15 cm but may be larger depending on the ambient environment.

Do not install the unit where it may be easily touched or leaned against. Avoid locations
subject to high vibrations or severe impacts. Do not install the unit where it is exposed to
humidity, oil, smoke or excessive dust.

2.2.1 Mounting of the table stand (optional)

The table stand is an optional component.

To mount the table stand, proceed as follows:

• Lay the monitor upside down on a clean(!) surface.

Soil or particles laying on the surface may irretrievably

damage the screen of the monitor!

• Unpack the table stand

In the package of the table stand the required screws are included.

• Use the screws to mount the table stand.

• When the screws are fastened tightly, put up the monitor.

2. Unpacking and installation

2-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

2.2.2 Dimensions of the 42" monitor:

2.2.2.1 Front view

2.2.2.2 Side view and rear view:

103

2. Unpacking and installation

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

2-5

2.2.3 Dimensions of the 47" monitor:

2.2.3.1 Front view

1139

6

8

4

2.2.3.2 Side view and rear view:

1

26

7

7

4

2. Unpacking and installation

2-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

2.3 Examining the monitor

2.3.1 Front view

An LED on the bottom right edge indicates the operating status of the monitor.

LED indicator Mode

Orange Standby

Green In operation

Next the to LED indicator the sensor to receive the commands from the IR control unit is located as well as the

light sensor to determine the surrounding light intensity.

Take care that the sensors are not blocked by any objects placed in front of the monitor!

The preset for dim adjustment and bright adjustment can be set and controlled via the OSD, cf. 5.7.4 Light Sensor

Value.

2.3.2 Side view

>

<

+

-

SELECT

EXIT

The control elements of monitors are located on the right (seen from front). The 7 push buttons allow switching
the monitor from and to standby, to adjust volume and to activate and operate the OSD.

Item Refers to Function

1

Standby / switch into operation

2

S

ELECT

Activate selection

3

+

Scroll right for menu items / volume increase

4

-

Scroll left for menu items / volume decrease

5

<

Scroll down for menu items

6

>

Scroll up for menu items

7

EXIT

OSD control menu button / Access Main /

Sub-menu / Quick Menu Selection

2. Unpacking and installation

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

2-7

2.3.3 Rear view

On the rear, all interfaces as well as the power connector and the main power switch are located.

The standardized power socket is conform to IEC-320-13 and allows connecting local power cables. The internal
power supply is auto ranging from 100VAC to 240VAC.

The monitor allows connecting the following sources:

Input Interface signals

Video system input VIDEO IN RCA NTSC/PAL

S-VIDEO S-Video Mini Din 4pin NTSC/PAL

YUV (Y Pb/Cb Pr/Cr) Component Mini Din 7 pin NTSC/PAL

RGB input RGB Analog D-Sub 15 pin RGB analog

RGB Digital DVI-D 24 pin RGB digital

Signal receive&transmit RS232 IN D-Sub 9 pin

RS232 OUT D-Sub 9 pin

Audio

RCA
(red: right (R),
white:left (L))

Audio in (L+R)
Audio out(L+R) (2x) and
Subwoofer

The pin assignments of the interfaces are listed in chapter 7.6 Interfaces and chapter 8.6 Interfaces, respectively.

SW

R/INR/OUT2R/OUT1

L/INL/OUT2L/OUT1

RS232/INRS232/OUT

RGB IN

DVI

Pr/Cr

Pb/Cb

Y

S-VIDEO

IN

VIDEO

AC IN

OFF

ON

MAIN POWER

Two sources can be viewed simultaneously in either PIP mode (Picture-in-Picture) or PAP mode (Picture-and­Picture). In case more than one source is connected, the active sources and the display mode (one source or two
sources) are selected via the OSD.

2. Unpacking and installation

2-8

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

2.4 Cabling

All interfaces are located on the rear of the system!

Check the power rating on your outlet before connecting the monitor to the wall outlet
or to a power strip. Contact your facilities manager or a qualified electrician if you are
not sure what type of power is supplied to your building.

The devices are designed to operate with single-phase power systems having a
grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any
other type of power system.

• Use the power cord delivered with your system:

• Plug in the female power connector into the male connector AC IN on the rear of the monitor.

• Plug in the CEE7-plug (or ANSI 73.11 plug) into the wall outlet.

The power input is auto-ranging from 100VAC to 240 VAC.

• Connect the video and RGB sources with the respective interface using the included cables.

2.5 Switching on and off

Use the main power switch on the rear of the system to power the system on and off.

When the monitor is powered on, it can be switched into operation or switched to standby, respectively, using
eater the top most push button on the rear right side of the monitor or using the IR remote control unit (RCU).

If the system is not operated for longer periods, it is recommended to switch it off using
the main power switch on the rear side and to disconnect it from the wall outlet.

When the monitor is powered off by switching off the main power switch, the front LED indicating the operating
mode is off! Also you cannot switch the unit into operation by using the remote control unit or the top most push
button.

To power on the unit, switch on the main power switch on the rear of the system. The LED indicator will be
turned on, and you can switch the monitor into operation either by using the RCU or the top most push button
the rear of the system.

2. Unpacking and installation

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

2-9

2.6 Inserting batteries into the Infrared remote control unit

The batteries are not yet inserted in the remote control to avoid remote control operation in its package, result­ing in a shorter battery lifetime.

How to install the batteries:

• Push the cover tab with the fingernail a little backwards (as indicated by the arrow) and pull upwards the

cover top.

• Slide the cover forwards to remove-

• Insert two AA size batteries, making sure the polarities match the + and – marks inside the battery com-

partment.

• Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover

until it clicks in place

Note that there may be laws concerning disposal and recycling of used batteries in your
country! Please contact your local authorities to get further information!

Avoid keeping used, old batteries inside the remote control, causing leakage of internal
liquid resulting metal rust or fatal damage to the remote control unit.

3. Design and function

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

3-1

3 Design and function

This chapter introduces the systems and explains some of their characteristics.

3. Design and function

3-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

3.1 Display of choice

The state-of-the-art monitors deliver crisp, clear images detailed to perfection. Compatible with a wide variety of
signal sources, they are capable of showing analog video as well as data content.

Sources and interfaces

The monitor provides interfaces to connect composite video, S-Video, component video as well as analog or digi­tal RGB.

Picture-in-Picture

Two of the connected sources can be displayed simultaneously, either next to each other (PAP: picture-and­picture), or one source embedded in the other (PIP: picture in picture).

The sources can be controlled individually (brightness, contrast, color)

Automatic brightness adjustment

A light sensor determines the surrounding light intensity. According the measurement, the panel will adjust to
one of the two preset brightness levels: bright mode or dim mode.

User friendliness

The monitors can intuitively be operated and controlled via the OSD and the Infra Red Remote Control Unit (IR
RCU).

The language of the OSD can be selected as well as its position on the screen, size, etc.

RS232 remote control is also possible.

In case you want to operate the monitor via RSC232 Remote Control, contact Barco about
the protocol!

3. Design and function

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

3-3

3.2 Technology

The monitors are based on LCD Super MVA technology. The benefits of this technology are wide viewing angles,
fast video response and high contrast ratio.

MVA stands for Multidomain Vertical Alignment.

3.2.1 Principle of LCD technology

These are the basics used in LCD technology:

• Light can be polarized

• Liquid crystals can transmit polarized light.

• Liquid crystals align themselves when a voltage is applied.

• Liquid crystals change the light's plane of vibration to match their own angle.

There are multiple operating principles of LCD's; one of them is the Multidomain Vertical Alignment which – not
surprising – is based on the Vertical Alignment (VA) technology.

With this operating principle, the LC molecules are completely perpendicular when no voltage is applied, and
thus they don't change the polarization of light. Light simply passes the LC, and is blocked by the front end polar­izer (since this polarizer is rotated 90° against the back end polarizer which allowed the incident light to pass).

Because the blockage is complete, the quality of black produced this way is excellent!

When voltage is applied, the molecules shift to a horizontal position, producing a white image: the polarization
of the light is changed, and light can pass the front end polarizer.

Since the LC molecules are simply switched between vertical and horizontal alignment, response speeds are very
fast.

As a further development of the VA technology, with MVA technology the LC cell is divided in sub domains where
the molecules are oriented in opposite direction. This widens the viewing angles and enhances the performance.

The following picture shows the basic principle of VA technology:

backlight

V=0

full black

V=V

max

full white

back

p

olarizer

front

p

olarizer

substrate

substrate

liquid crystal

4. Controlling

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

4-1

4 Controlling

4. Controlling

4-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

4.1 General

The monitors can be controlled via the 7 push buttons at the right or conveniently remote-controlled by the infra­red remote control unit (RCU).

In case you want to use RS232 Remote Control, contact Barco!

The push buttons as well as the IR RCU make use of the OSD: the menu is displayed, a menu item is selected
and/or changed. Subsequently the OSD is closed again.

4.1.1 The push buttons

The push buttons are located on the right rear side of the monitor. The seven buttons are arranged in a vertical
row and have the following functions:

Push button Refers to Function

1 (top most)

Standby / switch into operation

2

S

ELECT

Activate selection

3

+

Scroll right for menu items / volume increase

4

-

Scroll left for menu items / volume decrease

5

<

Scroll down for menu items

6

>

Scroll up for menu items

7

EXIT

OSD control menu button / Access Main /

Sub-menu / Quick Menu Selection

4. Controlling

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

4-3

4.1.2 The IR remote control unit

The remote control is used for control, adaptation and source selection. It is also used to switch between standby
and operational mode.

The remote control unit (RCU) includes a battery powered infrared (IR) transmitter that allows the user to control
the monitor remotely.

4. Controlling

4-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

4.2 Terminology of the RCU controls

1 Function keys
F1 Source selection
F2 PIP control setting
F3 Switch between master source and PIP source
F4 In VGA mode: White balance
F5 Shows the RS232 address of the monitor
2 ADJ ADJUST key, to enter or exit the OSD
3 Address key has no function for this monitor
4 Selection key Switch the light sensor on/off
5 PAUSE has no function for this monitor
6 Standby stand by button, to start the monitor when the power switch is switched on and to

switch off the monitor without switching off the power switch.
7 Mute Switch off and on the sound (audio)
8 Help Indicates the resolution of the input video signal
9 Digit buttons Have no function for this monitor
10 Audio controls To control volume, balance, bass and treble of the audio signal
11 Picture controls Except for brightness and contrast, these keys have no function for this monitor
12 PHASE Adjust the phase of the signal
13 Freeze Auto adjust
14 TEXT has no function for this monitor
15 ENTER to start up the OSD or to confirm an adjustment or selection
16 Cursor Keys to make menu selections in the OSD.

RCU

cursor key up

cursor key down

cursor key right

cursor key left

Use the cursor keys up or right for increasing a value.

Use the cursor keys down or left for decreasing a value.
17 EXIT to leave a menu or the OSD
18 RC operating

indication

lights up when a button on the remote control is pressed. (This is a visual indicator

to check the operation of the remote control)

How to use the RCU?

Point the front of the RCU directly at the screen.

When using the IR remote control, make sure you are within the effective operating distance
(30m, 100ft in a straight line). The remote control unit will not function properly if strong light
strikes the sensor window or if there are obstacles between the remote control unit and the IR
sensor.

4. Controlling

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

4-5

4.3 Monitor address

The default (factory) address of a monitor is 1.

Via the OSD, every monitor can be assigned a unique address in the range of 1 and 255, cf. 5.7.2 Set display

address

With the IR remote control unit, all monitors with any address can be controlled.

With RS232 remote control, the monitors can be controlled individually if they had received a unique display
address. (This address can be displayed by means of the function key F5 on the IR remote control unit).

To send a command via RS232 remote control simultaneously to all monitors (broadcast), use the address 1
(common address of all monitors).

4.3.1 Displaying a monitor address

Press F5 on the IR remote control unit to display the address the monitor has received.

4. Controlling

4-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

4.3.2 The function keys

Using the function keys, the respective OSD command will immediately be executed.

For information about the commands, please refer to the respective section in the OSD description.

Function key Description refers to

F1 Source selection 5.8.1 Input selection with the function key F1,

F2 PIP control setting 5.3.3 PIP control

F3 Switch between master source and PIP source,

the source assigned to input 1 will be assigned
to input 2 and vice versa

F4 In VGA mode: White balance This command has no equivalent in the

OSD: when e.g. a signal looks greenish,
pressing the function key F4 will correct
and adjust the color impression.

F5 Display the monitor address 5.7.2 Set display address

4.3.3 Picture controls with direct access.

Brightness and contrast can be controlled directly via IR RCU. When Brightness or Contrast is pressed, the re­spective OSD dialog pops up to allow the adjustment.

Please refer to respective section of the OSD description, cf. 5.3.1.1 Brightness, 5.3.1.2 Contrast.

4.3.4 Audio controls with direct access.

Volume, balance, bass and treble can be controlled directly via IR RCU. When the respective keys on the IR re­mote control unit are pressed,, the respective OSD dialog pops up to allow the adjustment.

Please refer to respective section of the OSD description, cf. 5.5 Audio setting menu

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

5-1

5 The On Screen Display (OSD)

5. The On Screen Display (OSD)

5-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.1 General

The monitors feature an OSD which allows selecting the input, to adjust the sources, to modify OSD settings, etc.

When activating the OSD, the main menu is displayed.

Except for the function keys and the direct access keys, it is always the main menu which
is the entry level for any modification.

The main menu is activated by pressing ADJ on the RCU or by pressing push button 7 (the bottom most push
button the right rear side).

A selected menu item shows a blue background, an unselected menu item a gray background.

A selected menu entry looks like a button and it is indicated with a blue dot.

The current status of the menu entry shows a blue background.

If a value has been modified, it will definitely be applied when quitting the dialog (even
when pressing EXIT!)

Therefore it is recommended to write down the values: there is no UNDO to a single
operation, only the global factory reset.

Grayed out menus or items are not available with the current configuration.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

5-3

5.1.1 Navigation and adjustment

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to a menu

• Press 3 and 4 to navigate to a

menu

Except for signal 1 and signal 2, the menus do not have a submenu.

Menus without a submenu display their settings dialog as soon as they are activated!

• Press Enter to select a menu with a sub

menu: the menu icon will turn blue

• Press 2 to select a menu with a sub

menu: the menu item will turn blue

• Use the left and right cursor keys to

navigate to a submenu

• Press 3 and 4 to navigate to a sub

menu

• Press Enter to select: the item will turn

blue – or –

• Press the down cursor key:

• Press 2 to select: the item will turn

blue – or –

• Press 5

• Use the up and down cursor keys to navi-

gate to the entries of a dialog.
The entry will get a "button look" and a
blue dot.

• Press 5 and 6 to navigate to the

entries of a dialog
The entry will get a "button look"
and a blue dot.

• In case an option is linked to a button:

use the left and right cursor keys to se­lect one of the options

• In case an option is linked to a

button: use the push buttons 3 / 4
to select one of the options

• In case increase/decrease is linked to a

"slider": use the left and right cursor keys
to decrease/increase a value – or –

• In case increase/decrease is linked to a

button: use the Enter key to de-
crease/increase a value

• In case increase/decrease is linked

to a "slider": use the push buttons 3
/ 4 to decrease increase a value –
or –

• In case increase/decrease is linked

to a button: use the push button 2
to increase/decrease a value

As soon as a menu entry loses the focus, i.e. another entry is selected, the respective selection will be applied
without any further action: even when quitting the dialog with Exit, the modification will be applied!

• Press Exit to deactivate the dialog

• Press 7 to deactivate the dialog

• Press Exit to leave a sub menu

• Use the left and the right cursor key to

navigate to another menu

• Press 7 to leave a sub menu

• Use 3 and 4 to navigate to another

menu

• Press Exit to close the OSD

• Press 7 to close the OSD

Closing a first level dialog (i.e. a dialog linked to a menu, not to a sub menu) by means of the Exit key / the
push button 7 will close the OSD!

5. The On Screen Display (OSD)

5-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.2 Activating the OSD

The OSD can be activated and operated by means of the IR remote control unit (RCU) or the push buttons at the
right rear side of the monitor.

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

-

• Press 7 to activate the OSD

Then the main menu is displayed (default: on the upper left corner of the monitor).

The OSD will be displayed at the position and size as defined in the OSD setting menu. If no
modifications have been made via this menu, the OSD will pop up in the upper left corner
of the monitor in normal mode (not Zoomed In, background opaque)

Icon description

signal menu for the first input,
to select and control the settings of a source

The currently assigned signal is indicated in the label beneath

Signal menu for the second input,
to select and control the settings of a source

The currently assigned signal is indicated in the label beneath

OSD setting menu, to control the position, transparency and time out of the OSD

Audio setting menu, to adjust volume, balance, bass and treble

Language setting menu, to select the language of the OSD

Reset menu, to reset to factory defaults, to set the monitor address, and to control the light
sensor

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

5-5

To activate a menu, proceed as follows:

RCU Icon Push button (1: top most)

• Use the left and right cursor key to select a

menu

• Use the push buttons 3, 4 to select a

menu

• Menus without a submenu will turn blue

and display their settings dialog

• Menus with a sub menu will turn blue and

require an additional key stroke to open the
settings dialog:
Use Enter to open the signal setting sub­menu
Use the down cursor key to open the signal
selection dialog

-

• Press 7 to select

• Menus with a sub menu will turn

blue and require an additional key
stroke to open the settings dialog:
Use 2 to open the signal setting sub­menu
Use 5 to open the signal selection
dialog

5. The On Screen Display (OSD)

5-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3 The signal menu (first and second input)

The signal menu allows to control and adjust the settings of the source

The commands can be applied for the first input and for the second input, respectively.

Please note: the Image setting and Position setting is only available for the first (active)
input!

In case more than one source is connected, the signal for input1 and input2 has to be
assigned, cf.. 5.8 Input Signal SelectionThe signal for input1 can also be selected via the
function key F1, 5.8.1 Input selection with the function key F1

RCU Icon Push button (1: top most)

• Press the ADJ key

input1 input2

• Press 7

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left ad right cursor keys to navi-

gate to Display

• Press 3 and 4 to navigate to Display

• Press Enter to select

• Press 2 to select

The following sections will use the signal menu of the first input. For the second input, the
same dialogs are displayed, however some items are deactivated (Image, Position)

Nevertheless the dialogs may look different: some commands depend on the type of the
source. But this is independent from being input1 or input2!

The source menu button will turn blue. Subsequently the source sub menu opens with the items Display,
Position, PIP Control, Image, and Color

Image is only enabled for the source which is assigned to the first input!

The commands of Position are only enabled for the first input!

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

5-7

5.3.1 Display

On the Display dialog, brightness and contrast as well as hue, saturation, flesh tone can be adjusted (for VGA
sources only: also black level adjustment)

To activate the Display dialog, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left and right cursor keys to navi-

gate to Display

• Press 3 and 4 to navigate to Display

• Press Enter to select – or –

• Press the down key to activate the dialog

• Press 2 to select – or –

• Press 5 to activate the dialog

5. The On Screen Display (OSD)

5-8

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.1.1 Brightness

Brightness can be adjusted in the range between 0 and 100.

LCD panel screens are lit with built-in fluorescent tubes above, beside and sometimes behind the LCD (Cold Cath­ode Fluorescent Lamp, CCFL). This light is adjusted using the Brightness setting.

How brightness is perceived depends on the environment and on the content being viewed, which means that
switching a source and/or the ambient light could require re-adjustment of brightness.

H

ow bright a pixel is perceived depends on both, brightness setting and contrast setting: bright-

ness setting affects all levels from white to black at once. Contrast setting affects all but black.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Brightness

• Press 5 and 6 to navigate to Brightness

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.3.1.2 Contrast

Contrast can be adjusted in the range between 0 and 100.

The information content of a picture is related to contrast, not to brightness. The ratio between the brightest
white and the darkest black that a display can produce in a completely dark room is called the full field contrast
ratio.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Contrast

• Press 5 and 6 to navigate to Contrast

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

5-9

5.3.1.3 Hue

Hue can be adjusted in the range between -45 and +45.

The color = hue is most noticeable in areas of white.
There are multiple color models, one of them is the HSV model describing color as hue (color), saturation (the

amount of white light in the color), and V (value, the amount of black/lightness/brightness).

With PAL, part of the color information on the video signal is reversed in phase with each line,
which automatically corrects phase errors in the transmission of the signal.

With NTSC, the Hue control allows to perform the correction manually and to adjust the color

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Hue

• Press 5 and 6 to navigate to Hue

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.3.1.4 Saturation

Saturation can be adjusted in the range between 0 and 100.

Saturation adjusts the amount of white light in the color.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Saturation

• Press 5 and 6 to navigate to Saturation

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.3.1.5 Flesh tone

Flesh tone can be switched off, or turned on weak, soft, or strong.

When in bright areas of the pictures the skin-tones show chalky white, the normal skin tone color can be re­stored.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Flesh tone

• Press 5 and 6 to navigate to Flesh tone

• Use the left and right cursor keys to select one

of the options Off, Weak, Soft, Strong
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off,

Weak, Soft, Strong
The selection value is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

5-10

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.1.6 Black level (only available for analog RGB)

Black level can be adjusted in the range between 0 and 100.

The black level is the deepest black of the monitor.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Black Level

• Press 5 and 6 to navigate to Black Level

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-11

5.3.2 Position

On the Position dialog, the vertical and horizontal position of the image can be set as well as an area for zoom-
ing defined.

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left and right cursor keys to navi-

gate to Position

• Press 3 and 4 to navigate to

Position

• Press Enter to select – or –

• Press the down key to activate the dialog

• Press 2 to select – or –

• Press 5 to activate the dialog

The entries of Position are only enabled for the signal assigned to input 1.

5. The On Screen Display (OSD)

5-12

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.2.1 Zoom

Zoom can be selected to In and Out.

Zoom In

means to magnify the displayed picture. The magnification factor is related to the number of times the

In

button is activated. (The reverse operation is

Zoom Out

which reduces the picture back to the previous size).

The center of the original picture content will be "fixed" in the center of the monitor.

Due to the magnification, no longer the entire frame of the picture is displayed. To select the part of the frame to
be viewed, use the commands Zoom Horizontal Pan and Zoom Vertical Pan. Activating the Left/Right button
and the Down/Up button respectively resembles using the horizontal and vertical scrollbar to move the desired
portion of the picture content into the active window.

Each activation of the button means moving the picture 5 pixels in the selected direction.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Zoom

• Press 5 and 6 to navigate to Zoom

• Use the left and right cursor keys to select one

of the options In, Out.
The current value is visualized by a white cap­tion.

• Use 3 and 4 to select one of the options In, Out.

The current value is visualized by a white caption.

• Use the Enter to increase/decrease the zoom

factor.

• Use 2 to increase/decrease the zoom factor

Zoom Horizontal Pan and Zoom Vertical Pan is only available if the picture has been
Zoomed In, i.e. has been magnified and the display can no longer show the entire content
of the picture frame.

5.3.2.2 Zoom Horizontal Pan

Zoom Horizontal Pan can be set to left and right.

Zoom Horizontal Pan can be selected to Left and Right

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Zoom Horizontal Pan

• Press 5 and 6 to navigate to Zoom Horizontal

Pan

• Use the left and right cursor keys to select one

of the options Left, Right.
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Left,

Right
The current selection is visualized by a white cap­tion.

• Use the Enter to move the picture content in the

desired direction.

• Use 2 to move the picture content in the desired

direction.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-13

5.3.2.3 Zoom Vertical Pan

Zoom Vertical Pan can be set to Up and Down

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Zoom Vertical Pan

• Press 5 and 6 to navigate to Zoom Vertical Pan

• Use the left and right cursor keys to select one

of the options Left, Right.
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Left,

Right
The current selection is visualized by a white cap­tion.

• Use the Enter to move the picture content in the

desired direction.

• Use 2 to move the picture content in the desired

direction.

5.3.2.4 Vertical

Vertical can be adjusted in the range from 0 and 255.

Vertical and Horizontal moves the screen content within the allocated position ("centered
window") of the monitor. It is not possible to move e.g. a PAL Video (720x540) with
display mode 1:1 to the upper left corner of the monitor: the allocated position is in the
range 600pixel to 1320pixel (horizontal, counting started on the top left corner) and in the
range 270pixel to 810pixel (vertical, counting started on the top left corner).

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Vertical.

• Press 5 and 6 to navigate to Vertical.

• Use the left and right cursor keys to move the

picture content in steps of 1
The current value is indicated.

• Use 3 and 4 to move the picture content in steps

of 1
The current value is indicated.

The value is applied without any further action, e.g. the picture content is shifted in the desired direction.

5.3.2.5 Horizontal

Horizontal can be adjusted in the range from 0 and 255.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Horizontal.

• Press 5 and 6 to navigate to Horizontal.

• Use the left and right cursor keys to move the

picture content in steps of 1
The current value is indicated.

• Use 3 and 4 to move the picture content in steps

of 1
The current value is indicated.

The value is applied without any further action, e.g. the picture content is shifted in the desired direction.

5. The On Screen Display (OSD)

5-14

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.3 PIP control

On the PIP CONTROL dialog, the vertical and horizontal position of the image can be set as well as an area for
the embedded picture be defined.

PIP means picture-in-picture and displays dual moving images from two separate sources (e.g., PC and video) at
the same time.

There are two different ways: one source is displayed in full size, and the other one is displayed in a small size
overlaying the full screen picture. The full screen picture is called master source, and the other one PIP source.

Besides this display mode, the two sources can be displayed "side to side", which is called PAP mode (picture
and picture).

The source selected on input 1 is always the master source, the source selected on input 2 is always the PIP
source.

The master source and the PIP source can be switched by means of the function key F3 on the RCU (which in fact
is changing sources at the inputs).

PIP settings made with input 2 are only applied when input 2 becomes the PIP master!

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-15

To activate the PIP CONTROL dialog, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left and right cursor keys to navi-

gate to Display

• Press 3 and 4 to navigate to Display

• Press Enter to select – or –

• Press the down key to activate the dialog

• Press 2 to select – or –

• Press 5 to activate the dialog

5. The On Screen Display (OSD)

5-16

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.3.1 PIP Mode

PIP Mode can be set to off, single, PAP.

When PIP mode is Off, only one source is displayed.

When PIP mode is Single, the source connected to input 1 is the master source and displayed according its set­tings, whereas the source connected to input 2 is the PIP source and displayed either in Small, Medium or Large
size according the PIP Size selections.

The position of the PIP source is set using the Vertical and Horizontal adjustment.

PIP Size, Vertical and Horizontal are only enabled if PIP Mode is selected Single.

In case no source is connected to input 2,
Single will result in an empty window with blue borders,
PAP will result in displaying source1 at the left half of the monitor (right half remains
black).

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the PIP Mode

• Press 5 and 6 to navigate to PIP Mode

• Use the left and right cursor keys to select one

of the options Off, Single, PAP
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off,

Single, PAP

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

Using the direct access key F2, the selected PIP mode can be toggled between On and Off.

Using the direct access key F3, the PIP master and the PIP source can be toggled.

5.3.3.2 PIP Size

PIP size can be set to small, medium, and large.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the PIP Size

• Press 5 and 6 to navigate to PIP Size

• Use the left and right cursor keys to select one

of the options Small, Medium, Large.
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Small,

Medium, Large. The current selection is visualized
by a white caption.

The selection is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-17

5.3.3.3 Vertical

Vertical can be adjusted in the range from 0 to 255.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Vertical

• Press 5 and 6 to navigate to Vertical

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.
(increase: move down/decrease: move up)

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.
(increase: move down/decrease: move up)

The value is applied without any further action.

5.3.3.4 Horizontal

Horizontal can be adjusted in the range from 0 to 255.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Horizontal

• Press 5 and 6 to navigate to Horizontal

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.
(increase: move right/decrease: move left)

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.
(increase: move right/decrease: move left)

The value is applied without any further action.

5. The On Screen Display (OSD)

5-18

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.4 Image

On the Image dialog, the settings of the signal can be optimized.

For best image results, use short cables between the source and the monitor!

The image dialog depends on the source:

In case of analog RGB, the image settings comprises Scaling, Auto adjust, Phase, and Clock.

In case of S-Video/Video, the image settings comprise Scaling, Noise Reduction, Angle Filter, Film Mode Detect,
Sharpness.

In case of a DVI, due to the digital interface, no adjustment is required. Therefore the dialog only comprises Scal­ing-

Image is only enabled for the source assigned to input 1!

To do the image adjustment for the source of input 2, this source has to be assigned to
input 1.

To activate the Image dialog, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left and right cursor keys to navi-

gate to Display

• Press 3 and 4 to navigate to Display

• Press Enter to select – or –

• Press the down key to activate the dialog

• Press 2 to select – or –

• Press 5 to activate the dialog

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-19

5.3.4.1 Analog RGB

Scaling

Scaling can be set to 1:1, Fill, and Aspect.

Scaling means changing the resolution of an image.

1:1 is only enabled when the detected resolution of the source is lower than the resolution of the monitor.

'The monitor has a resolution of 1920x1080 pixel. In case the resolution of the source is lower (e.g. a PAL Video
with 720x540 pixels), when displayed 1:1, there will be a black border around the content.

In case Fill is selected, the content is displayed on the entire screen which, in case the ratio of the source is dif­ferent from the ratio of the screen (e.g. a PAL Video, 4:3), results in a distortion of the content: with PAL, in hori­zontal direction, the pixels would be multiplied by a factor of 2.6, whereas in vertical direction the factor would
be 2.0.

With Aspect, the aspect ratio of the source is maintained: in the above mentioned example, the pixels both in
horizontal and in vertical direction would be multiplied by a factor of two, thus the content would have a black
border of 240 pixels both, on the left side and on the right side.

5. The On Screen Display (OSD)

5-20

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Scaling

• Press 5 and 6 to navigate to Scaling

• Use the left and right cursor keys to select one

of the options 1:1, Fill, Aspect, Panor.
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options 1:1, Fill,

Aspect, Panor.
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

Auto Adjust

When Auto Adjust is selected, the monitor adjusts itself to the timing of the source which matches best one of
the internal preset timings.

Use the key FREEZE on the remote control unit to immediately start Auto Adjust.

During the Auto Adjust process, the monitor displays an information "Auto Configuration".

In case Auto Adjust is not selected, or the results are not perfect, the timing of the source
has to be manually adjusted to the timing of the monitor using the controls Phase and
Clock.

Both controls are to minimize the interferences (noise). Clock is course adjustment
whereas Phase is fine tuning of the setting.

To do the adjustment, use a test pattern (e.g. vertical stripes) of the connected source!

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Auto Adjust

• Press 5 and 6 to navigate to Auto Adjust

• Use the left and right cursor keys to select

Select

The current selection is visualized by a white
caption.

• Use 3 and 4 to select Select

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-21

Phase

Phase can be adjusted in the range from 0 to 255.

It is recommended to have the monitor warmed up for about 5 minutes before adjusting phase.

Use the Phase adjustment to eliminate shimmering horizontal streaking.

If there are not only horizontal streaking but also vertical banding, start with Clock
adjustment!

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Phase

• Press 5 and 6 to navigate to Phase

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action. Check the test pattern!

Clock

Clock can be adjusted in the range from 0 to 255.

It is recommended to have the monitor warmed up for about 5 minutes before adjusting clock.
Use the Clock adjustment to eliminate broad vertical banding.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Clock

• Press 5 and 6 to navigate to Clock

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action. Check the test pattern!

5. The On Screen Display (OSD)

5-22

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.4.2 S-Video

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-23

Scaling

Scaling can be set to 1:1, Fill, and Aspect.

Scaling means changing the resolution of an image.

1:1 is only enabled when the detected resolution of the source is lower than the resolution of the monitor.

'The monitor has a resolution of 1920x1080 pixel. In case the resolution of the source is lower (e.g. a PAL Video
with 720x540 pixels), when displayed 1:1, there will be a black border around the content.

In case Fill is selected, the content is displayed on the entire screen which, in case the ratio of the source is dif­ferent from the ratio of the screen (e.g. a PAL Video, 4:3), results in a distortion of the content: with PAL, in hori­zontal direction, the pixels would be multiplied by a factor of 2.6, whereas in vertical direction the factor would
be 2.0.

With Aspect, the aspect ratio of the source is maintained: in the above mentioned example, the pixels both in
horizontal and in vertical direction would be multiplied by a factor of two, thus the content would have a black
border of 240 pixels both, on the left side and on the right side.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Scaling

• Press 5 and 6 to navigate to Scaling

• Use the left and right cursor keys to select one

of the options 1:1, Fill, Aspect, Panor.
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options 1:1, Fill,

Aspect, Panor.
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

Adaptive Deinterlacing

Adaptive deinterlacing can be selected to off, level 1, level 2, level 3.

Select the appropriate level of adaptive deinterlacing to optimize the quality of the video.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Adaptive Deinterlacing

• Press 5 and 6 to navigate to Adaptive

Deinterlacing

• Use the left and right cursor keys to select one

of the options Off, Level 1, Level 2, Level 3
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off,

Level 1, Level 2, Level 3
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

5-24

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

Noise Reduction

Noise reduction can be selected to off, low, medium, or high.

Noise is generally visible as "snow", or small dots that make the picture look fuzzy, With

Noise Reduction

the

amount of noise attenuation can be specified.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Noise Reduction

• Press 5 and 6 to navigate to Noise Reduction

• Use the left and right cursor keys to select one

of the options Off, Low, Medium, High
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off, Low,

Medium, High
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

Angle Filtering

Angle filtering can be selected to on or off.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Angle Filtering

• Press 5 and 6 to navigate to Angle Filtering

• Use the left and right cursor keys to select one

of the options Off, On
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off, On

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-25

Film Mode Detect

Film Mode Detect can be selected to be on or off.

Film is usually recorded at 24 frames per second. When converting film to NTSC video (59.94 Hz field rate), 2 film
frames generate 5 video fields (3:2 pull down). Film scenes with high-speed motion objects thus may show mo­tion artifacts.

With Film Mode Detect on, the conversion to NTSC is detected and the original film frames are recreated by
blending the fields back together.

(3:2 pull down is only one of the pull down techniques and used as an example)

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Film Mode Detect

• Press 5 and 6 to navigate to Film Mode Detect

• Use the left and right cursor keys to select one

of the options Off, On
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Off, On

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

This function may cause undesired effects on standard sources, therefore it can be disabled
(OFF) at any time.

Sharpness

Sharpness can be set in the range from -15 to +29

The edges are localized and the contrast between neighboring pixels enhanced.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Sharpness

• Press 5 and 6 to navigate to Sharpness

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

5-26

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.3.5 Color

On the Color dialog, the gamma correction factor can be selected as well as the color temperature.

To activate the Color dialog, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the left and right cursor keys to navi-

gate to Display

• Press 3 and 4 to navigate to Display

• Press Enter to select – or –

• Press the down key to activate the dialog

• Press 2 to select – or –

• Press 5 to activate the dialog

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-27

5.3.5.1 Gamma Correction

The Gamma correction factor can be set to 2.2, 1.9, and 2.5.

Gamma is the relationship between the color values of the data and the color values displayed e.g. on a screen.
The Gamma coefficient makes it possible to adjust the brightness of the midtones only without affecting the very
bright and very dark areas..

If gamma is set too high, middle tones appear too dark. If it's set too low, middle tones appear too light

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Gamma Correction

• Press 5 and 6 to navigate to Gamma Correction

• Use the left and right cursor keys to select one

of the options 2.2, 1.9, 2.5. The current selec­tion is visualized by a white caption.

• Use 3 and 4 to select one of the options 2.2, 1.9,

2.5.
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5.3.5.2 Color Temperature

Color temperature can be selected to be 3200K, 5400K, 6500K, 9300K or custom (User, requires to adjust the
values for red, green, and blue).

Color temperature stands for the spectral properties of a light source.
Low color temperature implies warmer (more yellow/red) light while high color temperature implies a colder
(more blue) light.
The pictures of a monitor set to 9300K will look more bluish than if set to 3200K.
The following color temperature pre-sets can be selected:

Color temperature name / application

3200K Broadcast
5400K Film
6500K Video
9300K Computer
User custom

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Color Temperature

• Press 5 and 6 to navigate to Color Temperature

• Use the left and right cursor keys to select one

of the options 3200K, 5400K, User, 6500K,
9300K.

The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options 3200K,

5400K, User, 6500K, 9300K.
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

5-28

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

When User is selected, the values for red, green, blue can be individually be adjusted:

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Color Temperature

• Press 5 and 6 to navigate to Color Temperature

• Use the left and right cursor keys to select User • Use the left and right cursor keys to select User

• Use the down and up cursor keys to select Red,

Green, Blue

• Use the 5 and 6 to select Red, Green, Blue

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The selection is applied without any further action.

Manual modification of R, G, B requires some experience!

In case a VGA signal looks e.g. greenish, pressing the function key F4 (White balance) will
probably correct this. Thus no sophisticated color adjustment will be required.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-29

5.4 OSD setting menu

On the OSD dialog, the position of the OSD can be defined as well as zoom, blend and time out of the OSD.

To activate the OSD menu, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the cursor keys to navigate to the OSD

setting menu

• Press 3 and 4 to navigate to the

OSD setting menu

• The icon will turn blue, and the setting

dialog will pop up

• The icon will turn blue, and the set-

ting dialog will pop up

Each time the OSD opens, its position and behavior will be as set on this dialog.

5. The On Screen Display (OSD)

5-30

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.4.1 Vertical

The value can be set in the range form 0 to 255 (zero: top of OSD is level with top of monitor, 255: bottom of
OSD is level with bottom of monitor).

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Vertical

• Press 5 and 6 to navigate to Vertical

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.
(increase: move down)

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.
(increase: move down)

The value is applied without any further action.

Vertical and Horizontal define the position of the OSD. Whenever the OSD is activated, it
will be displayed at the position defined by the vertical and horizontal setting.

5.4.2 Horizontal

The value can be set in the range form 0 to 255 (zero: left of OSD is level with left of monitor, 255: right of OSD
is level with right of monitor).

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Horizontal

• Press 5 and 6 to navigate to Horizontal

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.
(increase: move right)

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.
(increase: move right)

The value is applied without any further action.

5.4.3 Blend

The value can be set in the range form 0 to 15 (zero: opaque, 15: transparent)

Use Blend to set the transparency of the OSD: when it Blend is set to zero, the background of the OSD will be
opaque thus entirely hiding the screen content at this position. To make the screen content visible in spite of the
overlaying OSD, increase the Blend parameter!

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Blend

• Press 5 and 6 to navigate to Blend

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-31

5.4.4 Time out

The value can be set between 0 and 60 seconds in steps of 5 seconds.

The OSD will close (disappear) automatically when no selections are made during a certain time. This period can
be set by means of the Time out parameter.

The OSD stays active as long as it is in use.

Independent from the Time out setting, you can close the OSD at any time by using the Exit
button the RCU or the push button 7 on the right rear side of the monitor.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Time out

• Press 5 and 6 to navigate to Time out

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 5
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 5
The current value is indicated.

The value is applied without any further action.

5.4.5 OSD Zoom

Zoom can be selected in or out.

This command will magnify the OSD window and the icons by approx. the factor of 2.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the OSD Zoom

• Press 5 and 6 to navigate to OSD Zoom

• Use the left and right cursor keys to select one

of the options In, Out
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options In, OUt

The current selection is visualized by a white cap­tion.

• Apply the selection with Enter. • Apply the selection with 2

This selection has to be confirmed to be applied.

5. The On Screen Display (OSD)

5-32

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.5 Audio setting menu

On the Audio setting menu, the volume and the balance of the left/right speaker can be adjusted as well as
bass and treble (low frequencies and high frequencies).

To activate the Audio setting menu, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the cursor keys to navigate to the

Audio setting menu

• Press 3 and 4 to navigate to the

Audio setting menu

• The icon will turn blue, and the setting

dialog will pop up

• The icon will turn blue, and the set-

ting dialog will pop up

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-33

5.5.1 Volume

Volume can be adjusted in the range from 0 to 79.

Use the push button 3 on the right rear side of the monitor to directly decrease the
volume, use the push button 4 to directly increase the volume.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Volume

• Press 5 and 6 to navigate to Volume

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.5.2 Balance

Balance can be adjusted in the range from -15 to +15.

The zero position is in the center of the slider. In case the left and the right speaker are not balanced, i.e. one
side is predominant, adjust the setting in negative direction to bring out the left speaker, in positive direction to
bring out the right speaker.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Balance

• Press 5 and 6 to navigate to Balance

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.5.3 Balance

Bass can be adjusted in the range from -7 to +7.

The zero position is in the center of the slider. In case the low frequencies are predominant, adjust the slider to
the left. In case they are rather faint or missing, adjust the slider to the right,

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Balance

• Press 5 and 6 to navigate to Balance

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

5-34

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.5.4 Treble

Treble can be adjusted in the range from -7 to +7.

The zero position is in the center of the slider. In case the high frequencies are predominant, adjust the slider to
the left. In case they are rather faint or missing, adjust the slider to the right.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Treble

• Press 5 and 6 to navigate to Treble

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-35

5.6 Language setting menu

On the Language setting menu, the language of the OSD can be selected

To activate the Language setting menu, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the cursor keys to navigate to the

Language setting menu

• Press 3 and 4 to navigate to the

Language setting menu

• The icon will turn blue, and the setting

dialog will pop up

• The icon will turn blue, and the set-

ting dialog will pop up

5. The On Screen Display (OSD)

5-36

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

To select a language for the OSD; proceed as follows:

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the desired language

• Press 5 and 6 to navigate to the desired language

• Use the left and right cursor keys to activate

the language.
The current selection is visualized by a white
caption.

• Use 3 and 4 to activate the language

'
The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

The OSD entries will now be displayed in the selected language.

This setting only affects the OSD, not the screen content!

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-37

5.7 Reset menu

On the Reset menu, the factory settings can be restored and the light sensor adjusted and activated, respec­tively. Also the light sensor threshold can be set.

To activate the Reset menu, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the cursor keys to navigate to the OSD

setting menu

• Press 3 and 4 to navigate to the

OSD setting menu

• The icon will turn blue, and the setting

dialog will pop up

• The icon will turn blue, and the set-

ting dialog will pop up

5. The On Screen Display (OSD)

5-38

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.7.1 Factory Reset

Clicking the button Yes on the option Factory Reset will inevitable reset the monitor to its
factory settings.

All former adjustment and modifications will be lost!

These are the factory settings which are applied after selecting Yes with Factory Reset:

Item default adjust range

Power switch Off On/Off

Brightness 80 0~100

Contrast 50 0~100

Color temp. User User, 3200K,5400K,6500K, 9300K

Red 255 0~255

Green 255 0~255

Blue 255 0~255

Language English English

Auto
configuration

On On/Off

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Factory Reset

• Press 5 and 6 to navigate to Factory Reset

• Use the left and right cursor keys to select one

of the options Yes, No
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Yes, No

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-39

5.7.2 Set display address

The value can be set in the range from 1 to 255.

If more than one monitor is installed, the monitors can independently be RS232 remote-controlled by means of
their display address.

Default monitor address is "1". Allowed addresses are in the range from 1 to 255.

"

1

" is the common address.

A monitor will listen to the commands explicitly sent to his specific address and to commands sent to the com­mon address.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Set display address

• Press 5 and 6 to navigate to Set display address

• Use the left and right cursor keys to in-

crease/decrease the address in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the address in

steps of 1
The current value is indicated.

The value is applied without any further action.

5.7.3 Light Sensor

The light sensor can be set on or off.

When a room is dark, the picture content can be viewed at lower brightness (power saving, avoiding eye fa­tigue). If enabled, the light sensor measures the ambient light, and if the room gets dark enough, the monitor
will be switched to the "dark mode" with a brightness set via the Light Sensor Value.

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Light Sensor

• Press 5 and 6 to navigate to Light Sensor

• Use the left and right cursor keys to select one

of the options Off, On
The current selection is visualized by a white
caption.

• Use 3 and 4 to select one of the options Yes, No

The current selection is visualized by a white cap­tion.

The selection is applied without any further action.

5.7.4 Light Sensor Value

The light sensor value can be set in the from 0 to 100.

This parameter defines the brightness the monitor is automatically switched to when the ambient light is below
the threshold of the light sensor (dark mode, requires that the light sensor is set On!)

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Light Sensor Value

• Press 5 and 6 to navigate to Light Sensor Value

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

5-40

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

5.7.5 Light Sensor Threshold

The light sensor value can be set in the from 0 to 100.

This parameter defines the ambient light level below which the monitor will switch to a low backlight mode.
(dark mode, requires that the light sensor is set On!)

RCU Push button (1: top most)

• Use the up and down cursor keys to navigate to

the Light Sensor Threshold

• Press 5 and 6 to navigate to Light Sensor

Threshold

• Use the left and right cursor keys to in-

crease/decrease the value in steps of 1
The current value is indicated.

• Use 3 and 4 to increase/decrease the value in

steps of 1
The current value is indicated.

The value is applied without any further action.

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-41

5.8 Input Signal Selection

In case multiple sources are connected, the signal for the first input and the second input have to be defined.

To select the signal for the respective input, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu (for the first input)

• Press 3 and 4 to navigate to the

signal (for the first menu input)

• Press Enter to select

• Press 2 to select

• Use the down cursor keys to open the

input signal selection dialog

• Press 3 to open the input signal

selection dialog

After the source has been selected, its timing is displayed.

In case the timing of the source is not included in the presets of the monitor, the timing of
the monitor which matches best the timing of the source is displayed!

5. The On Screen Display (OSD)

5-42

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

The following sources can be connected to the monitor:

Input Interface signals

Video system input VIDEO IN RCA NTSC/PAL

S-VIDEO S-Video Mini Din 4pin NTSC/PAL

YUV (Y Pb/Cb Pr/Cr) Component Mini Din 8 pin NTSC/PAL

RGB input RGB Analog D-Sub 15 pin RGB analog

RGB Digital DVI-D 24 pin RGB digital

Signal receive&transmit RS232 IN D-Sub 9 pin

RS232 OUT D-Sub 9 pin

Audio

RCA
(red: right (R),
white:left (L))

Audio in (L+R)
Audio out(L+R) (2x) and
Subwoofer

To select a signal, proceed as follows:

RCU Icon Push button (1: top most)

• Press the ADJ key to activate the OSD

• Press 7 to activate the OSD

• Use the left and right cursor keys to navi-

gate to the signal menu

• Press 3 and 4 to navigate to the

signal menu

• Press Enter to select

• Press 2 to select

• Use the down cursor keys to open the

input signal selection dialog

• Press 3 to open the input signal

selection dialog

• Use the left and right cursor keys to select

the desired signal

• Press 3 and 4 to select the desired

signal

In case the signal is assigned to input 1, it cannot be assigned to input 2!

To change the signal of input 1 and input 2, input 1 has to be assigned to the signal which
up to then has been assigned to input 2.

In case of two valid signals, input 2 then will automatically be assigned to the signal which
up to then has been assigned to input 1.

In case of more signals, input 2 has to be explicitely assigned to a signal (all but the one
assigned to input 1).

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

___________________________________________________________________________________

5-43

In case no signal is applied, the monitor displays a "no sync" message.

In case no cable is connected, the monitor displays a "no cable" message.

In case the timing of the connected source is not compliant to the monitor, the monitor displays a "invalid mode"
message.

For a list of compliant timings, cf. chapter 9 Compliant timing

The monitor features autodetect. In case e.g. DVI is selected, but the only connected source
is VGA, the monitor will display the no sync message, and after a while automatically
switch to VGA.

5. The On Screen Display (OSD)

5-44

________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

If no source is connected (neither no sync, no cable, no valid signal), the monitor switches to standby and dis­plays the respective information:

Whenever one of these messages pop up, check the respective item and fix it!

5.8.1 Input selection with the function key F1

For input 1, the input can be selected using the function key F1. Pressing F1 "scrolls" through the inputs and
displays one after the other the respective icon.

Press Enter to directly select the desired input.

6. Maintenance and servicing

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

6-1

6 Maintenance and servicing

Only authorized personnel should carry out other maintenance work not explicitly
mentioned in this manual!

Never open the case of the monitor without first disconnecting the power supply cord!
Measurements and tests with the opened device may be carried out only in the factory
or by specially trained personnel, due to the dangers of electrical shock.

6. Maintenance and servicing

6-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

6.1 Cleaning

Consult your dealer for internal cleaning once a year.

If you allow dust to accumulate on the unit, it may cause fire or malfunction when you operate it.

Refer to your dealer about the internal cleaning.

Power plug

If dust has collected on the power plug connectors, remove the plug from the outlet and clean off the dust. This
dust may cause a fire due to reduced insulation of the plug.

Cabinet

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning. To keep the cabinet looking brand-new, periodically clean it with a soft cloth. Stubborn
stains may be removed with a cloth lightly dampened with mild detergent solution. Never use strong solvents,
such as thinner or benzene, or abrasive cleaners, since these will damage the cabinet.

Contamination of screen surface.

When the screen surface of the monitor is contaminated, please wipe the surface softly with cotton swab or
clean cloth. If it is not enough, please take it away with cellophane tape or wipe the surface with cotton swab or
clean cloth containing solvent of 50% alcohol. In this case, please be careful so that the solvent does not get in
inside of the LCD module, because it may be damaged.

Water drop on LCD surface

Please do not leave LCD module with water drop. When the display surface gets water drop, please wipe it off
with cotton swab or soft cloth immediately, otherwise display surface will be deteriorated. If water gets in inside
the LCD module, the electric circuits may be damaged.

7. Technical data LC-42

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

7-1

7 Technical data LC-42

7.1 General data

characteristic specification

Screen size

Aspect ratio

active area (HxW)

width x height x depth
(without stand!)

42” diagonal

16:9

934mm x 527mm | 36.77in. x 20.75in.

1026mm x 619mm x103mm | 40.39in. x 24.37in. x 4.05in.

weight

29.5kg | 65.1lbs

Table 7-1

7.2 LCD panel

characteristic specification

Driver element a-Si TFT active matrix

Pixel number (1920 x R.G.B. x 1080) pixel (HDTV)

Display colors 16.7 millions of colors

Viewing angle 176 degree vertical / 176 degree horizontal

Brightness 500 cd/m²

Contrast ratio 800:1

Response time (Gray to Gray) Typ. 8 msec, max. 12msec

Interfaces

D-Sub 15 pins, DVI-D 24 pins, RCA, S-Video, Component video, RS232
IN/OUT

Dead pixel rate

Max. 8 bright pixels out of which max. 2 clusters of two bright pixels.
Max.10 dark pixels out of which max. 5 clusters of two dark pixels

Table 7-2

7.3 Electrical data

Characteristic specification

Power supply 100VAC-240 VAC, 50/60 Hz

Power consumption operating mode 234W

Power consumption Standby mode 14.8W

Table 7-3

7. Technical data LC-42

7-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

7.4 Operating conditions

Characteristic specification

Storage temperature -20°C - +60°C | -4°F – 140°F, at max. 90% RH, non-condensing

Operating ambient temperature +5°C – +40°C | 41°F – 104°F, at max. 90% RH, non-condensing

Table 7-4

7.5 CCFL (Cold Cathode Fluorescent Lamp) characteristics (ambient temperature (25 ±2)°C)

Characteristic Typ. value

Lamp voltage 1390 VRMS

Lamp current 5.0 mARMS

Lamp starting voltage 2055 VRMS (0°C), 1740 VRMS (25°C)

Lamp life time 50,000hrs *)

Operating frequency 40-70 KHz

Table 7-5

The life time of a lamp is defined as when the brightness is larger than 50% of its original value and the effec­tive discharge length is longer than 80% of its original length.

7.6 Interfaces

7.6.1 Video IN (Composite Video)

Item specification

Signal level 1.0Vpp

Connector type RCA Jack

Termination 75Ω

Table 7-6

7. Technical data LC-42

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

7-3

7.6.2 S-Video

4

2

3

1

Item specification

1,2 Ground

3 Y

4 C

Luminance level 1.0 Vpp

Color level 0.286 Vpp

Connector type Mini Din 4pin

Termination 75Ω

Table 7-7

7.6.3 Component Video (mini DIN 8 pin)

1

2

3

4

5

6

7

8

Item specification Item specification

1 GND 5 GND

2 CB 6 CR

3 GND 7 not connected

4 Y 8 not connected

Connector type Mini Din 8pin

Termination 75Ω

Table 7-8

7. Technical data LC-42

7-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

White Yellow Cyan Green Magenta Red Blue Black

IRE 75 69.5 59.1 53.6 21.4 15.9 5.4 0

Y

mV 525 487 413 375 150 112 38 0

IRE 0 -37.5 8.6 -28.9 28.9 -8.6 37.5 0

Pb

mV 0 -263 60 -202 202 -60 263 0

IRE 0 3.4 -37.5 -34.1 34.1 37.5 -3.4 0

Pr

mV 0 24 -263 -238 238 263 -24 0

Table 7-9

HDTV YPbPr 75% color bars. Values are relative to the blanking level.

White Yellow Cyan Green Magenta Red Blue Black

IRE 100 92.8 78.7 71.5 28.5 21.3 7.2 0

Y

mV 700 649 551 501 199 149 51 0

IRE 0 -50 11.5 -38.5 38.5 -11.5 50 0

Pb

mV 0 -350 80 -270 270 -80 350 0

IRE 0 4.6 -50 -45.4 45.4 50 -4.6 0

Pr

mV 0 32 -350 -318 318 350 -32 0

Table 7-10

HDTV YPbPr 100% color bars. Values are relative to the blanking level.

White Yellow Cyan Green Magenta Red Blue Black

IRE 75 66.5 52.6 44.0 31.0 22.4 8.6 0

Y

mV 525 465 368 308 217 157 60 0

IRE 0 -37.5 12.7 -24.8 24.8 -12.7 37.5 0

Cb

mV 0 -263 89 -174 174 -89 263 0

IRE 0 6.1 -37.5 -31.4 31.4 37.5 -6.1 0

Cr

mV 0 43 -263 -220 220 263 -43 0

Table 7-11

SDTV YCbCr 75% color bars. Values are relative to the blanking level.

7. Technical data LC-42

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

7-5

White Yellow Cyan Green Magenta Red Blue Black

IRE 100 88.6 70.1 58.7 41.3 29.9 11.4 0

Y

mV 700 620 491 411 289 209 80 0

IRE 0 -50 16.9 -33.1 33.1 -16.9 50 0

Cb

mV 0 -350 118 -232 232 -118 350 0

IRE 0 8.1 -50 -41.9 41.9 50 -8.1 0

Cr

mV 0 57 -350 -293 293 350 -57 0

Table 7-12

SDTV YCbCr 100% color bars. Values are relative to the blanking level.

7.6.4 DVI

9

16

17

24

1

8

Pin signal assignment pin signal assignment

1 TMDS Data 2- 13 NC

2 TMDS Data 2+ 14 NC

3 TMDS Data 2 Ground 15 Ground (+5, Analog /V Sync)

4 NC 16 Hot Plug Detect (HPD)

5 NC 17 TMDS Data 0-

6 DDC Clock 18 TMDS Data 0+

7 DDC Data 19 TMDS Data 0 Ground

8 NC 20 NC

9 TMDS Data 1- 21 NC

10 TMDS Data 1+ 22 TMDS Clock Ground

11 TMDS Data 1 Ground 23 TMDS Clock +

12 NC 24 TMDS Clock -

Table 7-13

7. Technical data LC-42

7-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

7.6.5 RGB IN (D-Sub 15 pin)

1

5

10

15

6

11

Pin signal assignment pin signal assignment

1 Red video input 9 NC

2 Green video input 10 Ground

3 Blue video input 11 NC

4 NC 12 (SDA)

5 Ground 13 Horizontal sync (Composite sync)

6 Red video ground 14 Vertical sync

7 Green video ground 15 (SCL)

8 Blue video ground

Table 7-14

7.6.6 RS232 IN

1

5

6

9

Pin signal assignment

1 NC

2 Signal receive

3 Signal transmit

4 NC

5 Ground

6 NC

7 NC

8 NC

Table 7-15

7. Technical data LC-42

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

7-7

7.6.7 RS232 OUT

1

5

6

9

Pin signal assignment

1 NC

2 Signal transmit

3 Signal receive

4 NC

5 Ground

6 NC

7 NC

8 NC

Table 7-16

7.7 Factory settings

Item default adjust range

Power switch Off On/Off

Brightness 80 0~100

Contrast 50 0~100

Color temp. User User, 3200K,5400K,6500K, 9300K

Red 255 0~255

Green 255 0~255

Blue 255 0~255

Language English English

Auto
configuration

On On/Off

Table 7-17

8. Technical data LC-47

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

8-1

8 Technical data LC-47

8.1 General data

characteristic specification

Screen size

Aspect ratio

active area (HxW)

width x height x depth
(without stand, with handle!)

47” diagonal

16:9

1044mm x 590mm | 41.1in. x 23.22in.

1139mm x 684mm x126mm | 44.84in. 26.93in. x 4.96in.

weight

40.2kg | 88.7lbs

Table 8-1

8.2 LCD panel

characteristic specification

Driver element a-Si TFT active matrix

Pixel number (1920 x R.G.B. x 1080) pixel (HDTV)

Display colors 16.7 millions of colors

Viewing angle 176 degree vertical / 176 degree horizontal

Brightness 500 cd/m²

Contrast ratio 800:1

Response time (Gray to Gray) Typ. 8 msec

Interfaces

D-Sub 15 pins, DVI-D 24 pins, RCA, S-Video, Component video, RS232
IN/OUT

Dead pixel rate

Max. 8 bright pixels out of which max. 2 clusters of two bright pixels.
Max. 10 dark pixels out of which max. 5 clusters of two dark pixels

Table 8-2

8.3 Electrical data

Characteristic specification

Power supply 100VAC-240 VAC, 50/60 Hz

Power consumption operating mode 303W

Power consumption Standby mode 19.9W

Table 8-3

8. Technical data LC-47

8-2

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

8.4 Operating conditions

Characteristic specification

Storage temperature -20°C - +60°C | -4°F – 140°F, at max. 90% RH, non-condensing

Operating ambient temperature +5°C – +40°C | 41°F – 104°F, at max. 90% RH, non-condensing

Table 8-4

8.5 CCFL (Cold Cathode Fluorescent Lamp) characteristics (ambient temperature (25 ±2)°C)

Characteristic Typ. value

Lamp voltage 1590 VRMS

Lamp current 4.5 mARMS

Lamp starting voltage 2650 VRMS (0°C), 2100 VRMS (25°C)

Lamp life time 50,000hrs *)

Operating frequency 40-70 KHz

Table 8-5

The life time of a lamp is defined as when the brightness is larger than 50% of its original value and the effec­tive discharge length is longer than 80% of its original length.

8.6 Interfaces

8.6.1 Video IN (Composite Video)

Item specification

Signal level 1.0Vpp

Connector type RCA Jack

Termination 75Ω

Table 8-6

8. Technical data LC-47

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

8-3

8.6.2 S-Video

4

2

3

1

Item specification

1,2 Ground

3 Y

4 C

Luminance level 1.0 Vpp

Color level 0.286 Vpp

Connector type Mini Din 4pin

Termination 75Ω

Table 8-7

8.6.3 Component Video

1

2

3

4

5

6

7

8

Item specification Item specification

1 GND 5 GND

2 CB 6 CR

3 GND 7 not connected

4 Y 8 not connected

Connector type Mini Din 8pin

Termination 75Ω

Table 8-8

White Yellow Cyan Green Magenta Red Blue Black

IRE 75 69.5 59.1 53.6 21.4 15.9 5.4 0

Y

mV 525 487 413 375 150 112 38 0

IRE 0 -37.5 8.6 -28.9 28.9 -8.6 37.5 0

Pb

mV 0 -263 60 -202 202 -60 263 0

IRE 0 3.4 -37.5 -34.1 34.1 37.5 -3.4 0

Pr

mV 0 24 -263 -238 238 263 -24 0

Table 8-9

HDTV YPbPr 75% color bars. Values are relative to the blanking level.

8. Technical data LC-47

8-4

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

White Yellow Cyan Green Magenta Red Blue Black

IRE 100 92.8 78.7 71.5 28.5 21.3 7.2 0

Y

mV 700 649 551 501 199 149 51 0

IRE 0 -50 11.5 -38.5 38.5 -11.5 50 0

Pb

mV 0 -350 80 -270 270 -80 350 0

IRE 0 4.6 -50 -45.4 45.4 50 -4.6 0

Pr

mV 0 32 -350 -318 318 350 -32 0

Table 8-10

HDTV YPbPr 100% color bars. Values are relative to the blanking level.

White Yellow Cyan Green Magenta Red Blue Black

IRE 75 66.5 52.6 44.0 31.0 22.4 8.6 0

Y

mV 525 465 368 308 217 157 60 0

IRE 0 -37.5 12.7 -24.8 24.8 -12.7 37.5 0

Cb

mV 0 -263 89 -174 174 -89 263 0

IRE 0 6.1 -37.5 -31.4 31.4 37.5 -6.1 0

Cr

mV 0 43 -263 -220 220 263 -43 0

Table 8-11

SDTV YCbCr 75% color bars. Values are relative to the blanking level.

White Yellow Cyan Green Magenta Red Blue Black

IRE 100 88.6 70.1 58.7 41.3 29.9 11.4 0

Y

mV 700 620 491 411 289 209 80 0

IRE 0 -50 16.9 -33.1 33.1 -16.9 50 0

Cb

mV 0 -350 118 -232 232 -118 350 0

IRE 0 8.1 -50 -41.9 41.9 50 -8.1 0

Cr

mV 0 57 -350 -293 293 350 -57 0

Table 8-12

SDTV YCbCr 100% color bars. Values are relative to the blanking level.

8. Technical data LC-47

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

_____________________________________________________________________________________

8-5

8.6.4 DVI

9

16

17

24

1

8

Pin signal assignment pin signal assignment

1 TMDS Data 2- 13 NC

2 TMDS Data 2+ 14 NC

3 TMDS Data 2 Ground 15 Ground (+5, Analog /V Sync)

4 NC 16 Hot Plug Detect (HPD)

5 NC 17 TMDS Data 0-

6 DDC Clock 18 TMDS Data 0+

7 DDC Data 19 TMDS Data 0 Ground

8 NC 20 NC

9 TMDS Data 1- 21 NC

10 TMDS Data 1+ 22 TMDS Clock Ground

11 TMDS Data 1 Ground 23 TMDS Clock +

12 NC 24 TMDS Clock -

Table 8-13

8.6.5 RGB IN (D-Sub 15 pin)

1

5

10

15

6

11

Pin signal assignment pin signal assignment

1 Red video input 9 NC

2 Green video input 10 Ground

3 Blue video input 11 NC

4 NC 12 (SDA)

5 Ground 13 Horizontal sync (Composite sync)

6 Red video ground 14 Vertical sync

7 Green video ground 15 (SCL)

8 Blue video ground

Table 8-14

8. Technical data LC-47

8-6

_________________________________________________________

Barco - LC series - R5976934 - user's manual - Revision 05 - March 2006

8.6.6 RS232 IN

1

5

6

9

Pin signal assignment

1 NC

2 Signal receive

3 Signal transmit

4 NC

5 Ground

6 NC

7 NC

8 NC

Table 8-15

8.6.7 RS232 OUT

1

5

6

9

Pin signal assignment

1 NC

2 Signal transmit

3 Signal receive

4 NC

5 Ground

6 NC

7 NC

8 NC

Table 8-16
