Barco IP-2003 user guide

ImagePRO, ImagePRO-SDI, ImagePRO-HD

Installation Manual

Model IP-2003

Folsom

www.barco.com
www.folsom.com

Barco Events USA

11101 Trade Center Drive

Rancho Cordova , CA 95670

Manual# 26-0302000-00 / Rev E

RECORD OF CHANGES

REV #

A 11/14/03 1171 Released A. Yerocostas
B 12/15/03 1188 Updated Save system State description to

C 4/1/04 1255 Added Serial Commands.

D

DATE

9/04 1318 Moved In Auto Acquire to the top menu

ECO #

DESCRIPTION

include saving input channel (s/w rev 1.01).
Miscellaneous spelling corrections.
Added Ethernet functionality.
Added Save messages when exiting input,
output and system menus.
Released SDI/HD functionality (s/w rev 1.02).

Added Logo operation

Added Hsync & Vsync adjustments to the
output timing adjustments menu.
Added Remote commands for Hsync & Vsync
adjustments.
Added Remote command for loading logo.
Added Remote command for edge
adjustments in oversample mode.
Updated limits on various remote commands.

Approved By

A. Yerocostas

Ching Ho

A. Yerocostas

E

3/05 1406 Added EDID submenu to System menus

Updated Input timing adjustment serial
commands

A. Yerocostas

Manual # 26-0302000-00/Rev E

Operators Safety Summary

Do Not Remove Covers or Panels

There are no user-serviceable parts within the unit. Removal of the top
cover will expose dangerous voltages. To avoid personal injury, do not
remove the top cover. Do not operate the unit without the cover installed

Power Source

This product is intended to operate from a power source that will not
apply more than 230 volts rms between the supply conductors or
between both supply conductor and ground. A protective ground
connection by way of grounding conductor in the power cord is essential
for safe operation.

Grounding the Product

This product is grounded through the grounding conductor of the power
cord. To avoid electrical shock, plug the power cord into a properly wired
receptacle before connecting to the product input or output terminals.

The general safety information in this summary is for operating personnel.

A protective-ground connection by way of the grounding conductor in the
power cord is essential for safe operation.

Use the Proper Power Cord

.

Use only the power cord and connector specified for your product. Use
only a power cord that is in good condition. Refer cord and connector
changes to qualified service personnel.

Use the Proper Fuse

To avoid fire hazard, use only the fuse having identical type, voltage
rating, and current rating characteristics. Refer fuse replacement to
qualified service personnel.

Do Not Operate in Explosive Atmospheres

To avoid explosion, do not operate this product in an explosive
atmosphere.

Terms In This Manual and Equipment Marking

WARNING

NOTE Highlights an essential operating procedure,

CAUTION

AVERTISSEMENT!

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

Le point d´exclamation dans un triangle equilatéral signale
à alerter l´utilisateur qu´il y a des instructions d´operation
et d´entretien tres importantes dans la litérature qui
accompagne l´appareil

Highlights an operating procedure, practice,
condition, statement, etc., which, if not strictly
observed, could result in injury to or death of
personnel.

condition or statement.

VORSICHT ein Ausrufungszeichen innerhalb eines gleichwinkeligen
den Benutzer auf wichtige Bedienungs-und
Great beiliegenden Literatur aufmerksam zu machen.

Dreiecks dient dazu,
Wartungsanweisungen in der Dem

ImagePRO™ Quick Start Guide

Step 1: Connect Input Sources to ImagePRO™

1. Connect analog video source to the ImagePRO™ using the three universal video inputs.

2. Connect any SDI video source to the SDI video input (ImagePRO-SDI™ and ImagePRO-HD™ only).

3. Connect DVI video source to the DVI video input (ImagePRO-HD™ only).

Step 2: Connect ImagePRO™ to Output Devices

1. Connect Hi-res video output devices to the ImagePRO™ using the 5 BNC or HD-15 output connectors.

2. Connect NTSC or PAL monitor using the Composite or S-Video Output connectors

3. Connect SDI video devices to the SDI video output (ImagePRO-SDI™ and ImagePRO-HD™ only).

4. Connect DVI Digital Flat panel display to the DVI video output (ImagePRO-HD™ only).

Step 3: Power Up

Connect ImagePRO™ to AC power using the power cord supplied with the unit. Locate the power s witch on the power entry module
at the rear of the unit and turn the power on. When initializatio n is complete, the front panel display will indicate that the unit has
powered up successfully. The Status screen is displayed when the initialization process is complete.

Step 4: Select and Save the desired Output Format

Press the SETUP button and then using the ADJUST knob, scroll do wn to “Output” and press the SE L key to e nter the Output Setup
menu. Press SEL key to select the Output Format field and then use the ADJUST knob to locate the desired output format. Press
the SEL key again to select this output format. Now scroll down to Save Config an d press the SEL key to save this format as the
default.

Press the ESC key to leave the Output Setup menu.

Step 5: Configure Input Sources

ImagePRO™ will automatically lock to video applied to the inputs and will make a attempt to match the Video format in the following

search order: Last configuration saved for the selected input channel, One of 64 stored configurations, a ny custom formats stored by the
user, library formats and finally using a “best guess” a lgorithm matching to the closest library format. While this approach ge nerally lea ds
to an acceptable output image, it is strongly recommended that the user sets up a configuration file to precisely define the video
parameters associated with each input. The use of configuration files provides consistent, repeatable operation and allows the user to
adjust video parameters for each source to optimize image qual ity. Each time a source is selected with the Source Selection keys, the
configuration file associated with that source is automatically reloaded.

Setting up input configuration files is simple. Proceed as follows for each input.

1. Select the source you wish to work by pressing the INPUT select key.

2. Enter the INPUT SETUP menu by pressing the SETUP button and then pressing SEL to select the “Input” menu.
Examine the image on the display device and adjust the input parameters as desired. The Input Setup menu is
described in detail in chapter 3 of the ImagePRO™ manual. Many of the parameters may require no adjustment,
however, be sure that the “Input Format” and “Input Type” menu items are selected to match the incoming source video.

3. When the input setup parameters have been set as desired, scroll down to “Save Config” using the A DJUST knob and
press the SEL button to save the current setup. The setup information is automatically as signed to the source used for
the input setup process. The input configuration file will automatically be recalled for use each time the source is
selected.

Whenever a modification is made to a configuration, you must resave the changes following the procedure above.

NOTE:

This is a quick reference guide. For detailed information on the ImagePRO

Installation and Operating Manual supplied with your unit.

Folsom Research, Inc. • 11101-A Trade Center Drive, Rancho Cordova CA 95670 • [phone] • www.folsom.com

™, please refer to the

Table of Contents

IMAGEPRO™ QUICK START GUIDE ____________________________________________________________________I

TABLE OF CONTENTS _________________________________________________________________________________I

CHAPTER ONE _______________________________________________________________________________________ 1

IMAGEPRO

DESCRIPTION __________________________________________________________________________________________ 3
IMAGEPRO™ FEATURES _________________________________________________________________________________ 3
ADDITIONAL IMAGEPRO-SDI™ FEATURES __________________________________________________________________ 4
ADDITIONAL IMAGEPRO-HD™ FEATURES___________________________________________________________________ 4

CHAPTER TWO ______________________________________________________________________________________ 5

INSTALLATION ______________________________________________________________________________________ 7

IMAGEPRO™ REAR PANEL CONNECTORS ___________________________________________________________________ 7
IMAGEPRO-SDI™ REAR PANEL CONNECTORS _______________________________________________________________ 8
IMAGEPRO-HD™ REAR PANEL CONNECTORS________________________________________________________________ 9
RACK-MOUNT INSTALLATION ____________________________________________________________________________ 10
VIDEO INPUT CONNECTIONS _____________________________________________________________________________ 11
VIDEO OUTPUT CONNECTIONS____________________________________________________________________________ 12
DVI-I VIDEO IN AND LOOP-THROUGH CONNECTORS (UNIVERSAL INPUT 1-IMAGEPRO-HD™)_________________________ 14
RS-232 REMOTE CONTROL CONNECTIONS__________________________________________________________________ 15
CONNECTION TO AC POWER _____________________________________________________________________________ 16

POWER CORD/LINE VOLTAGE SELECTION ____________________________________________________________________ 16

CHAPTER THREE ___________________________________________________________________________________ 19

TM

OVERVIEW ____________________________________________________________________________ 3

OPERATION ________________________________________________________________________________________ 21

IMAGEPRO™ FRONT PANEL CONTROLS____________________________________________________________________ 21
IMAGEPRO-SDI™ FRONT PANEL CONTROLS________________________________________________________________ 22
IMAGEPRO-HD™ FRONT PANEL CONTROLS ________________________________________________________________ 23
POWER UP INITIALIZATION ______________________________________________________________________________ 24
STATUS DISPLAY_______________________________________________________________________________________ 26
MENU CONTROL_______________________________________________________________________________________ 26
MENU OPERATION _____________________________________________________________________________________ 28
SETUP _______________________________________________________________________________________________ 28
INPUT SETUP SUBMENU _________________________________________________________________________________ 28

TYPE SELECTION _______________________________________________________________________________________ 29
YPBPR COLORSPACE SELECTION ___________________________________________________________________________ 29
SAMPLING ____________________________________________________________________________________________ 30

TIMING ADJUST SUBMENU _______________________________________________________________________________ 30

OVERSAMPLED TIMING EDGE SELECTIONS ____________________________________________________________________ 30
1:1 SAMPLING OVERVIEW ________________________________________________________________________________ 31
1:1 SAMPLING OPERATION ________________________________________________________________________________ 31
AUTO CONFIG _________________________________________________________________________________________ 31

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

i

AMPLE PHASE_________________________________________________________________________________________ 31

S
ACTIVE AREA__________________________________________________________________________________________ 31
CONTRAST AND BRIGHTNESS______________________________________________________________________________ 32

COLOR BALANCE SUBMENU______________________________________________________________________________ 32

GAMMA ______________________________________________________________________________________________ 32

ASPECT RATIO SUBMENU ________________________________________________________________________________ 32

LETTERBOX SELECTION __________________________________________________________________________________ 33

PROCESSING SUBMENU__________________________________________________________________________________ 33
DE-INTERLACING ______________________________________________________________________________________ 34
VIDEO PROCESSING DELAY ______________________________________________________________________________ 34

VIDEO PROCESSING DELAY FOR IMAGEPRO __________________________________________________________________ 34
VIDEO PROCESSING DELAY FOR IMAGEPRO-SDI AND IMAGEPRO-HD______________________________________________ 34
SAVE CONFIG__________________________________________________________________________________________ 34
RESET CONFIG _________________________________________________________________________________________ 35
RECALL CONFIG________________________________________________________________________________________ 36
DELETE CONFIG ________________________________________________________________________________________ 36

OUTPUT SETUP SUBMENU________________________________________________________________________________ 37
[OUTPUT FORMAT]_____________________________________________________________________________________ 37
TIMING ADJUST SUBMENU _______________________________________________________________________________ 37
COMP/S-VID ADJUSTMENTS SUBMENU _____________________________________________________________________ 38
SYNC SETTINGS SUBMENU _______________________________________________________________________________ 39

UNDERSCAN___________________________________________________________________________________________ 39
COLORSPACE __________________________________________________________________________________________ 39
GAMMA ______________________________________________________________________________________________ 39
SHARPNESS ___________________________________________________________________________________________ 39
FLICKER REDUCE _______________________________________________________________________________________ 40

GENLOCK SUBMENU____________________________________________________________________________________ 40

SOURCE ______________________________________________________________________________________________ 40
GENLOCK TYPE SUBMENU ________________________________________________________________________________ 40
H PHASE _____________________________________________________________________________________________ 41
SC PHASE ____________________________________________________________________________________________ 41
SAVE CONFIG__________________________________________________________________________________________ 41
RESET CONFIG _________________________________________________________________________________________ 41
IN AUTO ACQUIRE ______________________________________________________________________________________ 41

FORMATS SUBMENU ____________________________________________________________________________________ 43
SAVE AS SUBMENU _____________________________________________________________________________________ 43
DELETE SUBMENU _____________________________________________________________________________________ 45

H,V Parameters________________________________________________________________________________________ 46
V Rate _______________________________________________________________________________________________ 46
Computed_H_Rate _____________________________________________________________________________________ 46
Interlaced_____________________________________________________________________________________________ 46

VIEWS SUBMENU_______________________________________________________________________________________ 47
RECALL VIEWS SUBMENU _______________________________________________________________________________ 47
SAVE VIEWS SUBMENU__________________________________________________________________________________ 47
DELETE VIEWS SUBMENU________________________________________________________________________________ 47
EFFECTS SUBMENU _____________________________________________________________________________________ 49
TECH SUPPORT SUBMENU _______________________________________________________________________________ 50
SYSTEM SUBMENU _____________________________________________________________________________________ 51

VFD BRIGHTNESS ______________________________________________________________________________________ 51

RS232 SUBMENU_______________________________________________________________________________________ 51
ETHERNET SUBMENU ___________________________________________________________________________________ 52
SET STATIC IP SUBMENU ________________________________________________________________________________ 52
EDID DVI INPUT FORMAT SUBMENU ______________________________________________________________________ 54

PROGRAM EDID _______________________________________________________________________________________ 54
SAVE SYSTEM STATE ____________________________________________________________________________________ 56
FACTORY RESET________________________________________________________________________________________ 56

TEST PATTERN MENU___________________________________________________________________________________ 57
ZOOM MENU__________________________________________________________________________________________ 58
PAN MENU ___________________________________________________________________________________________ 58

PAN AND ZOOM RESET___________________________________________________________________________________ 58

ii ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

CHAPTER FOUR_____________________________________________________________________________________ 61

SERIAL COMMAND SYNTAX_________________________________________________________________________ 63

SERIAL PARAMETERS ___________________________________________________________________________________ 63
RS232 MODE _________________________________________________________________________________________ 63

IMAGEPRO

IMAGEPRO

TM

REMOTE COMMANDS _________________________________________________________________ 64

TM

COMMAND LIST/DESCRIPTION ________________________________________________________ 68

CHAPTER FIVE _____________________________________________________________________________________ 95

SOFTWARE UPGRADE INSTRUCTIONS _______________________________________________________________ 97

OVERVIEW ___________________________________________________________________________________________ 97
HARDWARE REQUIREMENTS _____________________________________________________________________________ 97
SOFTWARE REQUIREMENTS ______________________________________________________________________________ 97
CONNECTING TO FOLSOM RESEARCH ______________________________________________________________________ 97
DOWNLOADING NECESSARY FILES ________________________________________________________________________ 97
INSTALLING IMAGEPRO’S SOFTWARE FILES AND FLASH FILE LOADER ___________________________________________ 97

STARTING THE IMAGEPRO FLASH FILE LOADER UTILITY ________________________________________________________ 97
PREPARING TO UPGRADE THE IMAGEPRO UNIT________________________________________________________________ 98
UPLOADING FILES TO THE IMAGEPRO UNIT __________________________________________________________________ 98

CHAPTER SIX _______________________________________________________________________________________ 99

BARCO FOLSOM INFORMATION____________________________________________________________________ 101

BARCO FOLSOM WARRANTY ____________________________________________________________________________ 101
RETURN MATERIAL AUTHORIZATION (RMA) ______________________________________________________________ 101
BARCO FOLSOM CONTACT INFORMATION__________________________________________________________________ 101

APPENDIX _________________________________________________________________________________________ 103

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

iii

iv ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

CHAPTER ONE

Introduction
What you will find in this chapter…

 About ImagePRO
 Features

TM

1

Model IP-2003

ImagePRO – Multi Format Image Processor

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

1

2 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

ImagePRO

Overview

Description

TM

The Folsom ImagePRO™
and processes them into a number of different output signal formats to meet the video requirements of virtually any
application. The ImagePRO™ line allows you to scale visual sources, mix and match them in any way while still
maintaining a high quality picture.

The unit is a high performance digital video scaler, scan converter, standards converter, switcher and transco der in
one. The ImagePRO™ line is the ideal solution for converting RGB, HDTV, component, S-video, composite (NTSC,
PAL and SECAM), SDI, DVI, and HDSDI into a user-selectable format. ImagePRO™ output formats include a wide
variety that support popular computer video, standard video, plasma, DVI, and HDTV rates.

is a powerful all-in-one signal processor that accepts a wide range of video input signals

The ImagePRO™ has an advanced feature set that includes:
universal inputs, aspect ratio conversion, memory presets, test patterns, Genlock, picture adjustments, motion
adaptive de-interlacing, and 3:2 and 2:2 pull-down detection.

ImagePRO™ Features

• Three universal inputs accept RGBHV/RGBCs/RGsB computer video, component video (STD or HDTV), S-

Video, or composite video with loop-through

• Input Video detection and Auto-acquisition. ImagePRO will auto detect and match input video to stored
formats or user configurations.

• Four video outputs; (2) RGB or component video, (1) composite video, and (1) S-video

• Aspect ratio conversion and adjustments

• Pan and zoom

• Freeze

• 10-Bit processing

• De-interlacing modes: Motion Adaptive and Field to Frame

• 3:2 pulldown detection for NTSC and 2:2 film detection for PAL video sources

• Decodes NTSC, PAL, and SECAM

• Ethernet connector for real-time control

• Encodes NTSC and PAL

• Vertical lock (Genlock) eliminates image tears and other artifacts in scaled motion video by eliminatin g frame

rate conversion

• Executive mode: protects system configuration settings during use

• 64 independent input configuration memory presets

• Backed by three-year warranty

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

3

Additional ImagePRO-SDI™ Features

• One SD SDI input and output

• Can be later upgraded to ImagePRO-HD

• Motion adaptive de-interlacing for HDTV inputs

• Low Video Delay

• Logo image capture and recall feature

• Dissolve to/from stored logo

Additional ImagePRO-HD™ Features

• SD SDI/HD SDI input and output

• DVI-I connectors support both universal analog and DVI input with loop-through

• DVI output

4 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

CHAPTER TWO

INSTALLATION
What you will find in this chapter…

 Rear Panel Connectors
 Rack-Mount Installation
 Video Input & Output Connections
 Remote Control Connections
 Power Cord/Line Voltage Selection

2

Model IP-2003

ImagePRO – Multi Format Image Processor

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

5

6 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

Installation

ImagePRO™ Rear Panel Connectors

UNIVERSAL INPUT 1

IN

IN

UNIVERSAL INPUT 2

LOOP

LOOP

R/R-Y/C

UNIVERSAL INPUT 3

G/Y/COMPOSITER/R-Y/C

G/Y/COMPOSITE

B/B-Y

B/B-Y

UNIVERSAL INPUT 3

IN IN IN

LOOP LOOP LOOP

H/C

H/C

IN IN

LOOP

V

LOOP

V

S-VIDEO
OUTPUT OUTPUT 1

Figure 2-1: ImagePRO™ Rear Panel

Video Input BNC connectors with loop-through (Universal Input 3)
Video Input HD-15 connectors with loop-through (Universal Inputs 1 & 2)

Video Output BNC connectors (Output 2)
Video Output HD-15 connectors (Output 1)
S-video on 4-pin mini-DIN connector
Composite Output BNC
Genlock BNCs

Remote Control RJ-45 Ethernet Connector

Remote Control RS-232 DB-9 Connector

AC Power connector

COMPOSITE

OUTPUT

R/R-Y

H/C V

G/Y/COMPOSITE B/B-Y

GENLOCK INOUTPUT 2

H/C/BURST

REMOTE CONTROL

V

ETHERNET

RS-232

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

7

ImagePRO-SDI™ Rear Panel Connectors

UNIVERSAL INPUT 1

IN

IN

UNIVERSAL INPUT 2

LOOP

LOOP

R/R-Y/C

IN IN

LOOP

G/Y/COMPOSITER/R-Y/C

UNIVERSAL INPUT 3

H/CG/Y/COMPOSITE

B/B-Y

IN IN

LOOP LOOP LOOP

B/B-Y

UNIVERSAL INPUT 3

H/C

V

V

IN

LOOP

S-VIDEO
OUTPUT

SDI INPUT SD I OUTPUT

OUTPUT 1

Figure 2-2: ImagePRO-SDI™ Rear Panel

Video Input BNC connectors with loop-through (Universal input 3)
Video Input HD-15 connectors with loop-through (Universal inputs 1 & 2)
Standard Definition SDI Digital Video Input BNC

Video Output BNC connectors (Output 2)
Video Output HD-15 connectors (Output 1)
S-video on 4-pin mini-DIN connector
Composite Output BNC
Genlock BNCs

Standard Definition SDI Digital Video Output BNC
Remote Control RJ-45 Ethernet Connector

Remote Control RS-232 DB-9 Connector

AC Power connector

OUTPUT

R/R-Y G/Y/COMPOSITE

OUTPUT 2COMPOSITE

H/C V

B/B-Y

GENLOCK IN

H/C/BURST

REMOTE CONTROL

V

RS-232ETHERNET

8 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

ImagePRO-HD™ Rear Panel Connectors

UNIVERSAL INPUT 1

IN

IN

UNIVERSAL INPUT 2

LOOP

LOOP

R/R-Y/C

R/R-Y/C

G/Y/COMPOSITE

G/Y/COMPOSITE

UNIVERSAL INPUT 3

ININ

LOOPLOOP

UNIVERSAL INPUT 3

H/C

B/B-Y

H/C

B/B-Y

SDI INPUT

V

INININ

LOOPLOOPLOOP

V

S-VIDEO
OUTPUT

OUTPUT 1

OUTPUT

H/C

G/Y/COMPOSITE

R/R-Y

COMPOSITE

SDI OUTPUT

Figure 2-3: ImagePRO-HD™ Rear Panel

Video Input BNC connectors with loop-through (Universal input 3)

Video Input HD-15 connectors with loop-through (Universal input 2)
Digital / Analog Video Input on DVI-I Connector with loop-through (Universal input 1)
Standard Definition/High Definition SDI Digital Video Input BNC

Video Output BNC connectors (Output 2)
Video Output HD-15 connectors (Output 1)
DVI Digital Video Output on DVI-D Connector
S-video on 4-pin mini-DIN connector
Composite Output BNC
Genlock BNCs

Standard Definition/High Definition SDI Digital Video Output BNC
Remote Control RJ-45 Ethernet Connector

Remote Control RS-232 DB-9 Connector

AC Power connector

OUTPUT 2

GENLOCK IN

H/C/BURST

V

V

B/B-Y

ETHERNET

DVI-D OUTPUT

REMOTE CONTROL

RS-232

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

9

Rack-Mount Installation

ImagePROTM units are designed to be rack mounted and are supplied with front rack-mount hardware. Rear rack­mount brackets are available as a kit and are recommended for use when units are mounted in transit cases. When
rack mounting the unit, remember that the maximum ambient operating temperature for the unit is 40 degrees C.
Leave at least one inch of space front and rear to make sure that the airflow through the fan and vent holes is not
restricted. When installing equipment into a rack, distribute the units evenly to prevent hazardous conditions that may
be created by uneven weight distribution. Connect the unit only to a properly rated supply circuit. Reliable grounding
(earthing) of rack-mounted equipment should be maintained.

10 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

Video Input Connections

Universal Input Connectors

The video input section on the ImagePRO
YUV, S-Video (Y/C), or composite (NTSC, PAL or SECAM) video signals. On ImagePRO™ and ImagePRO-SDI™
Universal Inputs 1 & 2 are provided with HD-15 female connectors. On ImagePRO-HD™ Universal input 2 is provided
with an HD-15 connector. Universal input 1 is provided with a DVI-I connector, which can be converted to an HD-15
via the DVI-I to HD-15 adaptor provided with the unit. Universal Input 3 is provided with BNC connectors on all
models. All inputs are provided with a corresponding buffered loop-through. Connection pins for each video signal are
specified below.

TM

rear panel provides three universal inputs. Each input can accept RGB,

Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8

Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15

RGBHV

RED

GREEN

BLUE

RED return

GREEN return

BLUE return

GND

Hsync or Csync

Vsync

15

6

1115

HD-15 Input Connector Pinout

(as viewed from rear of unit)

Format – RGB

(Typical Devices: Computers)

Format – YUV or Y Pr Pb (Betacam)

(Typical Devices: DVD Player or Betacam Deck)

Source to ImagePROTM Source to ImagePROTM
R R/R-Y/C Y G/Y/COMPOSITE
G G/Y/COMPOSITE Pr R/R-Y
B B/B-Y Pb B/B-Y
H H/C or
V V Y G/Y/COMPOSITE

Format – S-Video (Y/C)

(Typical Devices: S-Video DVD or VCR)

Source to ImagePROTM

Format – Composite (Typical Devices: NTSC/PAL DVD or VCR)

U R/R-Y
V B/B-Y

Y G/Y/COMPOSITE Source to ImagePROTM
C B/B-Y NTSC/PAL/SECAM G/Y/COMPOSITE

*NOTE: Composite sync or separate Hsync and Vsync signals are accepted. Sync on Green is also supported.

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

11

Video Output Connections

Four independently buffered outputs (one five wire BNC connection, one HD-15, one S-Video, and one Composite
video BNC) are provided. Both 5-wire and HD-15 outputs provide the same Video in RG B or YPbPr format. Outputs
are available depending on the resolution selected. For example, RGB vid eo at 1024x768@60Hz
both on the 5-wire BNC and HD-15 outputs. Likewise, NTSC Video will be available on th e Composite, S-Video and
SDI output connectors.

The operator can select the type of output sync to match application requirements. Separate C (Composite) or
separate H/V (Horizontal/Vertical) as well as sync on Green Video sync modes are supported.

HD-15 Output Connector Pinout

Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8

Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15

RGB Output

RED

GREEN

BLUE

RED return

GREEN return

BLUE return

GND

Hsync or Csync

Vsync

15

will be available

6

1115

HD-15 Output Connector Pinout

(as viewed from rear of unit)

(Typical Devices: Monitor/Plasma/Projector)

Format – RGB

Format – YUV or Y Pr Pb (Betacam)

(Typical Devices: Betacam Deck)

Sourced from ImagePROTM Sourced from ImagePROTM
R R/R-Y/C Y G/Y/COMPOSITE
G G/Y/COMPOSITE Pr R/R-Y
B B/B-Y Pb B/B-Y
H H/C or
V V Y G/Y/COMPOSITE

Format – S-Video (Y/C)

(Typical Devices: S-Video VCR,Monitor)

Sourced from ImagePROTM

Format – Composite (Typical Devices: NTSC/PAL VCR,Monitor)

U R/R-Y
V B/B-Y

Y G/Y/COMPOSITE Sourced from ImagePROTM
C B/B-Y NTSC/PAL/SECAM G/Y/COMPOSITE

*NOTE: Composite sync or separate Hsync and Vsync signals as well as Sync on Green are supported.

12 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

RGB/YPbPr Video Output
Connect the output device to the set of BNC connectors marked R/R-Y, G/Y and B/B-Y on the output section of the

ImagePRO™ rear panel

S-Video (Y/C) Video Output

The Y/C video output connector is a 4-Pin Mini DIN located on the rear panel of the ImagePRO™. Using a
commercial S-VHS cable, connect the Y/C video output to the input of the S-VHS device (monitor, video recorder,
etc.).

Composite Video Output

Connect the composite input of the monitor to the composite output BNC of the ImagePRO™ using a 75-ohm coaxial
cable.

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

13

DVI-I Video In and Loop-Through Connectors (Universal Input 1-ImagePro-HD™)

Two DVI-I female connectors are located on the rear panel of the ImagePRO-HD™. One is used for Video input and
the other one is used for the buffered DVI-I Loop-Through. This Connector can be used with Analog inputs using the
DVI-I to HD-15 adaptor provided with ImagePRO-HD™.

Pin Function Pin Function

1 T.M.D.S. Data2- 13
2 T.M.D.S. Data2+ 14
3 T.M.D.S. Data2/4 Shield 15
4 T.M.D.S. Data4- 16
5 T.M.D.S. Data4+ 17
6 DDC Clock 18
7 DDC Data 19 T.M.D.S. Data0/5 Shield
8 Analog Vertical Sync 20

9 T.M.D.S. Data1- 21
10 T.M.D.S. Data1+ 22 T.M.D.S. Clock Shield
11 T.M.D.S Data1/3 Shield 23 T.M.D.S. Clock+
12 T.M.D.S. Data3- 24

MicroCross Pins
Pin Function
C1 Analog Red Video
C2 Analog Green Video
C3 Analog Blue Video
C4 Analog Horizontal Sync
C5 Analog Common Ground Return

Legend

T.M.D.S. Data3+

+5V Power

ground (for +5V)

Hot Plug Detect

T.M.D.S. Data0-

T.M.D.S. Data0+

T.M.D.S. Data5-

T.M.D.S. Data5+

T.M.D.S. Clock-

DDC = Display Data Channel

T.M.D.S. = Transition Minimized Differential Signal

14 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E

RS-232 Remote Control Connections

The Remote serial port can be connected to a PC or other Remote Controller to support remote control of the
ImagePROTM unit. Pinouts for the remote port are shown below.

1 2 3 4 5

6 7 8 9

DB-9 RS-232 Signal Description

1 CD Carrier Detect

2 RXD Received Data

3 TXD Transmitted Data

4 DTR Data Terminal Ready

5 GND Signal Ground

6 DSR Data Set Ready

7 RTS Request To Send

8 CTS Clear To Send

Refer to Section 3, SYSTEM: RS-232 Menu, for configuring the hardware handshake.

9 RI Unused

Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor

15

Connection to AC Power

Power Cord/Line Voltage Selection

ImagePROTM is rated to operate with the following supplies:
Input Power: 100-240 VAC, 47-63 Hz
Power Consumption : 150 watts maximum

The ImagePRO
required for line voltage selection.

TM

Wide Screen Image Processor performs line voltage selection automatically. No user controls are

WARNING

When the ImagePRO
250 volts at 15 amps must be used. This cord will be fitted with a tandem prong-type
plug.

TM

is used with 230-volt supplies, a UL listed line cord rated for

Tandem Plug

La choix de la ligne de voltage se realize automatiquement par I’ImagePROTM

Transformateur Graphique On n’apas besoin du controller usager pour la choix de la ligne

AVERTISSEMENT

AVERTISSEMENT

de voltage.

Das ImagePROTM -Gerät mu beim Anschlu an 240V ~ mit einer vom VDE auf

250V/10A geprüften Netzleitung mit einem Schukostecker ausgestattet sein.

16 ImagePRO – Multi Format Image Processor Manual # 26-0302000-00 / Revision E
