Baltech 10117501A01A Users Manual

Operation Manual
RFID Reader IDE-ZM-L2M-U2
Covered Variants:
M/N: 10117-501
1y1z1
REVISION 1.0, 2018-07-08
BALTECH AG
Lilienthalstraße 27
85399 Hallbergmoos
Germany
Phone: +49 (811) 99 88 1- 0
FAX: +49 (811) 99 88 1- 11
e-mail: info@baltech.de
http://www.baltech.de/
1
“x“, “y” and “z” shall represent any alphanumerical number or can be left blank.
- 1 -
Introduction
The “IDE-ZM-L2M-U2” Reader/Writer is a desktop contactless smart card USB/RS232 reader and writer with 13.56 MHz card technology. It supports Legic Advant ISO 14443A/B, ISO 15693 and Legic Prime standards.
Based on BALTECH’s core technology it provides support of the latest smartcard technologies,
encryption and security features.
Mounting and Connection
The reader generates a magnetic field at 13.56MHz which could be influenced by any electrically conductive material close to the device. To ensure good performances and functionalities in terms of read range and reliability a minimum distance of 10cm from such materials is required. Mounting the unit directly to metal would result in a severe reduction of read range down to zero functionality. Care should be taken when testing the device after mounting at a problematic environment: Read ranges and performance vary from card to card and very much from card to tag or key-fob.
When mounting multiple readers, the distance between readers should be minimum 0.5 m in order to avoid degradation of performance due to interference.
To connect the device to a host system (a printer or a PC), please make sure that the system provides an USB socket intended for connection of the reader.
Operation
Whenever the device is connected to a proper power supply, it will switch on the internal antenna and periodically scan for a card. Once a card has been detected, the card number is read, the data converted and sent to the host system through the USB Interface. To enable the device to read cards, tags and key-fobs successfully, they should be placed centred above the reader.
