Baldor VL425A Product Information Sheet

Product Information Packet

VL425A

.75HP,3450RPM,1PH,60HZ,56C,1720L,OPEN,F1

Product Information Packet: VL425A - .75HP,3450RPM,1PH,60HZ,56C,1720L,OPEN,F1

Specs

Catalog Number: VL425A Frame: 56C Frame Material: Steel Output @ Frequency: .750 HP @ 60 HZ Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ Voltage @ Frequency: 115.0 V @ 60 HZ

230.0 V @ 60 HZ Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: No Mounting Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None Current @ Voltage: 9.200 A @ 115.0 V

5.000 A @ 208.0 V

4.600 A @ 230.0 V Design Code: N Drip Cover: Drip Cover

KVA Code: K Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 6 @ 18 AWG Motor Lead Exit: Terminal Panel Motor Lead Termination: None Motor Type: 1720L Mounting Arrangement: F1 Power Factor: 77 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: C-Face Pulley Shaft Indicator: Standard Rodent Screen: None RoHS Status: ROHS COMPLIANT Shaft Extension Location: Pulley End

Shaft Ground Indicator: No Shaft Grounding Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Drip Cover Mounting Front Shaft Indicator: None Heater Indicator: No Heater Insulation Class: B

Shaft Rotation: Reversible: Connected OPP STD

Shaft Slinger Indicator: No Slinger

Speed Code: Single Speed

Motor Standards: NEMA

Starting Method: Direct on line

Thermal Device - Bearing: None

Vibration Sensor Indicator: No Vibration Sensor
