Baldor VHM2531T Product Information Sheet

Download
Product Information Packet
VHM2531T
25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Part Detail
Revision: S Status: INA/A Change #: Proprietary: No Type: AC Elec. Spec: 10WGX260 CD Diagram: CD0005 Mfg Plant: Mech. Spec: 10F886 Layout: 10LYF886 Poles: 04 Created Date: Base: N Eff. Date: 03-08-2016 Leads: 9#10
Specs
Catalog Number: VHM2531T Enclosure: OPEN Frame: 284HP Frame Material: Iron Output @ Frequency: 25.000 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ XP Class and Group: None XP Division: Not Applicable Agency Approvals: UR
CSA Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: No Mounting Bearing Grease Type: Polyrex EM (-20F +300F) Current @ Voltage: 30.000 A @ 460.0 V
Insulation Class: F Inverter Code: Not Inverter KVA Code: G Lifting Lugs: Standard Lifting Lugs Locked Bearing Indicator: Locked Bearing Motor Lead Quantity/Wire Size: 9 @ 10 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 1040M Mounting Arrangement: F1 Power Factor: 84 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: P-Base Pulley Shaft Indicator: P-Base Groove & Key Rodent Screen: None Shaft Extension Location: Pulley End
60.000 A @ 230.0 V
Shaft Ground Indicator: No Shaft Grounding
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
65.000 A @ 208.0 V Design Code: B Drip Cover: Drip Cover Duty Rating: CONT Front Face Code: Drip Cover Mounting Front Shaft Indicator: None
Shaft Rotation: Reversible Shaft Slinger Indicator: Shaft Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Vibration Sensor Indicator: No Vibration Sensor
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Nameplate NP1256L
CAT.NO. VHM2531T
SPEC. 10F886X260
HP 25
VOLTS 230/460
AMP 60/30 RPM 1770
FRAME 284HP HZ 60 PH 3
SER.F. 1.15 CODE G DES B CLASS F
NEMA-NOM-EFF 92.4 PF 84
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 65 DE 6312 ODE 6309
ENCL OPEN SN
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Parts List
Part Number Description Quantity SA124439 SA 10F886X260 1.000 EA RA114860 RA 10F886X260 1.000 EA 10CB3003A04 KO BOX, MACH W/2.00 NPT LD HL & #26 DRAI 1.000 EA 10XN3118K16 5/16-18 X 1' GRADE #5, STL, ZINC PLATE 4.000 EA HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 4.000 EA WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA 51XF2520A08 SCREW, HEX SER SLT HD, ZN 1/4-20 X .50 L 1.000 EA 10EP1201A01 FREP, MACH W/309 BRG 1.000 EA 10AD2002 AIR DEFLECTOR, 310 OPEN P-BASE 1.000 EA 12XN1032A08 10-32X1/2 HEX HD SLTD 3.000 EA HW1001A10 WASHER, #10 SPLT LK, ZN X 3.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA 10XN3816K52 3/8-16 X 3-1/4 HEX HEAD CAP SCREW GRD 5 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA HW4600B41 V-RING SLINGER 2.125 X 2.880 X 0.280 1.000 EA HW5100A11 W3917-042 WVY WSHR (WB) 1.000 EA 10XN3118K80 .31-18 X 5.0 HEX HD CAP SCREW, GRADE 5 4.000 EA HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 4.000 EA 10EP1507A02 ENDPLATE, MACH W/312 BRG W/SLINGER RECES 1.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA 10XN3816K44 3/8-16 X 2.75 HEX HD CAP SCREW, GRADE 5 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA 10FH1500A01 DRIP COVER, MACH 1.000 EA HW3201A12 .50-13 EYEBOLT W/2.25 SHANK 2.000 EA
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Parts List (continued)
Part Number Description Quantity HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 2.000 EA HW1000A50 1/2 SAE FLAT WASHERS 2.000 EA 10CB3501 CONDUIT BOX LID FOR 10CB3003, 10CB3004 & 1.000 EA 14GS1001 GASKET, CONDUIT BOX LID 314 FRAME 1.000 EA 10XN2520K16 1/4-20 X 1" HX HD SCRW GRADE 5, ZINC P 4.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA HW2501E11 KEY, 1/4 SQ X 1.125 1.000 EA 12GS1000 GASKET 1.000 EA HW4500A03 GREASE FITTING, .125 NPT 1610(ALEMITE) 8 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.130 LB HW4500A03 GREASE FITTING, .125 NPT 1610(ALEMITE) 8 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.200 GA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA LB1119N WARNING LABEL 1.000 EA LB1182 WARNING LABEL FOR MOTORS WITH EYENUTS 2.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA LC0005 CONN.DIA.,TY M,9-LD,DUAL VOLT,REVERSING 1.000 EA NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA 12PA1030 PACKAGING GROUP PRINT PK1024A06 1.000 EA PK6538 2X4 X 11 SPACER 2.000 EA
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
AC Induction Motor Performance Data
Record # 2577 - Typical performance - not guaranteed values
Winding: 10WGX260-R001 Type: 1040M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection Rated Output (HP) 25 Full Load Torque 74.2 LB-FT Volts 230/460 Start Configuration direct on line Full Load Amps 60/30 Breakdown Torque 216 LB-FT R.P.M. 1770 Pull-up Torque 91.2 LB-FT Hz 60 Phase 3 Locked-rotor Torque 114 LB-FT NEMA Design Code B KVA Code G Starting Current 176 A Service Factor (S.F.) 1.15 No-load Current 12.18 A NEMA Nom. Eff. 92.4 Power Factor 84 LinelineRes.@25ºC 0.324Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 65°C S.F. Amps Temp. Rise @ S.F. Load 87°C
Locked-rotor Power Factor 33
Rotor inertia 3.18 LB-FT2
Load Characteristics 460 V, 60 Hz, 25 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 48 70 79 84 85 85 85 Efficiency 86.6 91.3 92.4 92.4 91.9 91 92.1 Speed 1792 1785 1778 1770 1761 1751 1765 Line amperes 14.1 18.34 24.02 30.35 37.3 45.2 34.5
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Performance Graph at 460V, 60Hz, 25.0HP Typical performance - Not guaranteed values
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Product Information Packet: VHM2531T - 25HP,1770RPM,3PH,60HZ,284HP,1040M,OPEN
Page 10 of 10
