Product Information Packet
VHECP4316T
75HP,1780RPM,3PH,60HZ,365HP,1482M,TEFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: VHECP4316T - 75HP,1780RPM,3PH,60HZ,365HP,1482M,TEFC
Part Detail
Revision: |
J |
Status: |
PRD/A |
Change #: |
|
Proprietary: |
No |
|
|
|
|
|
|
|
|
Type: |
AC |
Elec. Spec: |
A36WG0766 |
CD Diagram: |
416820-002 |
Mfg Plant: |
|
|
|
|
|
|
|
|
|
Mech. Spec: |
|
Layout: |
617428-035 |
Poles: |
04 |
Created Date: |
10-19-2010 |
|
|
|
|
|
|
|
|
Base: |
|
Eff. Date: |
05-05-2017 |
Leads: |
3#4,6#6 |
|
|
|
|
|
|
|
|
|
|
Specs
Catalog Number: |
VHECP4316T |
|
|
Enclosure: |
TEFC |
|
|
Frame: |
365HP |
|
|
Frame Material: |
Iron |
|
|
Output @ Frequency: |
75.000 HP @ 60 HZ |
|
|
Synchronous Speed @ Frequency: |
1800 RPM @ 60 HZ |
|
|
Voltage @ Frequency: |
460.0 V @ 60 HZ |
|
|
|
230.0 V @ 60 HZ |
|
|
XP Class and Group: |
None |
|
|
XP Division: |
Not Applicable |
|
|
Agency Approvals: |
CSA EEV |
|
|
Auxillary Box: |
No Auxillary Box |
|
|
Base Indicator: |
Bracket Mounted |
|
|
Bearing Grease Type: |
Polyrex EM (-20F +300F) |
|
|
Current @ Voltage: |
171.000 A @ 230.0 V |
|
|
|
85.900 A @ 460.0 V |
|
|
Design Code: |
B |
|
|
Drip Cover: |
Drip Cover |
|
|
Feedback Device: |
NO FEEDBACK |
|
|
Heater Indicator: |
No Heater |
|
|
Insulation Class: |
F |
|
|
Inverter Code: |
Inverter Ready |
|
|
KVA Code: |
G |
|
|
Lifting Lugs: |
Standard Lifting Lugs |
|
|
Motor Lead Quantity/Wire Size: |
3 @ 4 AWG |
|
|
Motor Type: |
A36070M |
|
|
Mounting Arrangement: |
F1 |
|
|
Power Factor: |
86 |
|
|
Pulley End Bearing Type: |
Ball |
|
|
Pulley Face Code: |
P-Base |
|
|
Shaft Ground Indicator: |
No Shaft Grounding |
|
|
Shaft Rotation: |
Reversible |
|
|
Shaft Slinger Indicator: |
Shaft Slinger |
|
|
Speed Code: |
Single Speed |
|
|
Motor Standards: |
NEMA |
|
|
Starting Method: |
Direct on line |
|
|
of 15 2
Page
Product Information Packet: VHECP4316T - 75HP,1780RPM,3PH,60HZ,365HP,1482M,TEFC
Duty Rating: |
CONT |
|
Thermal Device - Bearing: |
None |
|
|
|
|
|
|
|
|
Thermal Device - Winding: |
None |
|
|
|
|
|
of 15 3
Page
Product Information Packet: VHECP4316T - 75HP,1780RPM,3PH,60HZ,365HP,1482M,TEFC
Nameplate 000613007EW
CAT.NO. |
VHECP4316T |
|
|
|
|
|
|
|
|
|
SPEC NO. |
P36G3429 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HP |
75 |
|
AMPS |
171/85.9 |
|
|
|
|
|
|
VOLTS |
230/460 |
|
|
|
|
|
|
|
DESIGN |
B |
|
|
|
|
|||||||||
FRAME |
365HP |
|
RPM |
1780 |
|
|
|
|
|
HZ |
60 |
|
|
|
AMB |
40 |
|
|
SF |
1.15 |
|
|
|
|
|
|
||||||||
DRIVE END BEARING |
65BC03J30X |
|
|
|
PH |
3 |
|
|
|
DUTY |
CONT |
|
|
|
INSUL.CLASS |
F |
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
OPP D.E. BEARING |
65BC03J30X |
|
|
|
TYPE |
P |
|
|
|
ENCL |
TEFC |
|
|
CODE |
G |
|
|
|
|
|
|
|
|
|
|
|||||||||
D.E.BRG.DATA |
6313 |
|
|
|
|
|
|
|
POWER FACTOR |
86 |
|
|
|
|
|
|
|
NEMA NOM EFFICIENCY |
95.4 |
|
|
|||||||||||||
O.D.E.BRG.DATA |
6313 |
|
|
|
|
|
|
|
|
MAX CORR KVAR |
16.0 |
|
|
|
|
|
|
GUARANTEED EFFICIENCY |
95.0 |
|
||||||||||||||
3/4 LOAD EFF. |
95.8 |
|
|
|
|
|
|
|
NEMA NOM/CSA QUOTED EFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
SER.NO. |
|
|
|
|
|
|
|
|
|
|
|
|
MOTOR WEIGHT |
1008 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
of 15 4
Page
Product Information Packet: VHECP4316T - 75HP,1780RPM,3PH,60HZ,365HP,1482M,TEFC
Nameplate 000901002AAA
SUIT FOR 208 V @ 187 AMPS
