Baldor VHECP4109T Product Information Sheet

Download
Product Information Packet
VHECP4109T
40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Part Detail
Revision: T Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 12WGX906 CD Diagram: CD0180 Mfg Plant: Mech. Spec: 12S033 Layout: 12LYS033 Poles: 02 Created Date: 10-03-2008 Base: N Eff. Date: 10-22-2019 Leads: 9#8
Specs
Catalog Number: VHECP4109T Enclosure: TEFC Frame: 324HP Frame Material: Iron Output @ Frequency: 40.000 HP @ 60 HZ Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ XP Class and Group: None XP Division: Not Applicable Agency Approvals: CSA
CSA EEV
UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: No Mounting Bearing Grease Type: Polyrex EM (-20F +300F)
Insulation Class: F Inverter Code: Inverter Ready KVA Code: H Lifting Lugs: Vertical Lifting Lugs Locked Bearing Indicator: Locked Bearing Motor Lead Quantity/Wire Size: 9 @ 8 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 1240M Mounting Arrangement: F1 Power Factor: 90 Product Family: Super-E Chemical Processing Pulley End Bearing Type: Ball Pulley Face Code: P-Base Pulley Shaft Indicator: P-Base Groove & Key Rodent Screen: None Shaft Extension Location: Pulley End
Blower: None
Shaft Ground Indicator: No Shaft Grounding
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Current @ Voltage: 45.000 A @ 460.0 V
90.000 A @ 230.0 V Design Code: A Drip Cover: Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Rotation: Reversible Shaft Slinger Indicator: No Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Nameplate NP1260E
CAT.NO. VHECP4109T
SPEC. 12S033X906G1
HP 40
VOLTS 230/460
AMP 90/45 RPM 3540
FRAME 324HP HZ 60 PH 3
SER.F. 1.15 CODE H DES A CL F
NEMA-NOM-EFF 93 PF 90
RATING 40C AMB-CONT
CC 010A USABLE AT 208V DE 6312 ODE 6311
ENCL TEFC SN
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Parts List
Part Number Description Quantity SA176155 SA 12S033X906G1 1.000 EA RA164236 RA 12S033X906G1 1.000 EA 37FN3002C04 EXFN, PLASTIC, 6.00 OD, 2.003 ID 1.000 EA 10CB1000A16P KOBX, MACH 2.00 NPT W/#26 DRAIN W/PRIMER 1.000 EA 09GS1010 GASKET, DWG, LEADWIRE SEPERATOR 1.000 EA 10XN3118K16 5/16-18 X 1' GRADE #5, STL, ZINC PLATE 4.000 EA HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 4.000 EA WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA 10XN2520K08 1/4-20 X .50 GRADE #5, STL, ZINC PLATE 1.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 1.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA HA3400A18 STUD .50-13 X 7.50L W/4.19L HEX WELKER 4.000 EA HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 4.000 EA HW4600B41 V-RING SLINGER 2.125 X 2.880 X 0.280 1.000 EA 12FH1002A08P FAN COVER, MACH W/EPOXY PRIMER 1.000 EA HW4600B41 V-RING SLINGER 2.125 X 2.880 X 0.280 1.000 EA HW5100A13 W4627-047 WVY WSHER 1.000 EA 10XN3118K36 5/16-18 X 2.25" HEX HD, GRADE 5 2.000 EA 10XN3118K72 5/16-18 X 4.50" HEX HD, GRADE 5 4.000 EA 12EP1502A02P ENDPLATE, MACH W/EPOXY PRIMER 1.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA 10XN5013K36 1/2-13 X 2.25" HEX HD GRADE 5 4.000 EA HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 4.000 EA HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 4.000 EA
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Parts List (continued)
Part Number Description Quantity XY5013A12 NUT,1/2-13,HEX,STEEL,ZINCPLATED 4.000 EA HW3203A02 1/2-13 HVY FORGED EYE-NUT 2.000 EA 12FH1500A01P MACH DRIP COVER 310-312 MTRS 1.000 EA 10XN3816K36 3/8-16 X 2.25 HEX HD CAP SCREW, GRADE 5 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA 10CB1503A01P CONDUIT BOX LIPPED LID, MACH W/EPXY PRMR 1.000 EA 14GS1003 GASKET CONDUIT BOX LID, NEOP 1.000 EA 10XN2520K16 1/4-20 X 1" HX HD SCRW GRADE 5, ZINC P 4.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA HW2501G32 KEY, 3/8 SQ X 3.750 1.000 EA MJ5001A27 32220KN GRAY SEALER *MIN BUY 4 QTS=1GAL 0.031 QT MJ5001A14 DYNAPRO SEALANT, CP MTR VC#2508050 (603 0.029 EA LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA LB1182 WARNING LABEL FOR MOTORS WITH EYENUTS 2.000 EA HW4500A21 1618BALEMITE FITTING 825 UNIVERSAL 1.000 EA HA4017A01 1/8 X 4 GREASE EXT (F/S) 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.200 LB HW4500A03 GREASE FITTING, .125 NPT 1610(ALEMITE) 8 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA HW2500A25 WOODRUFF KEY USA #1008 #BLOW CARBON STEE 1.000 EA 51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA MG1025N19 WILKOFAST, 778.50, RELIANCE BLUE-GREEN 0.125 GA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
LB1002N LABEL,MARINE DUTY (ON ROLLS) 1.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA PK6014 STEEL STRAP FOR 309-312 BASELESS MOTORS 3.000 EA 10XN5013K10 1/2-13 X .625 HEX HD, GRADE 5 3.000 EA 12EP1107A13GP6 FREP, MACH W/EPOXY PRIMER & MG1025N19 1.000 EA LB1119N WARNING LABEL 1.000 EA LC0181 CONNECTION LABEL 1.000 EA NP1260E SS CP SUPER-E UL CSA CC 1.000 EA 10PA1052 PACKAGING GROUP, PRINT PK1151A06 1.000 EA
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
AC Induction Motor Performance Data
Record # 27714 - Typical performance - not guaranteed values
Winding: 12WGX906-R002 Type: 1240M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection Rated Output (HP) 40 Full Load Torque 59.5 LB-FT Volts 230/460 Start Configuration direct on line Full Load Amps 90/45 Breakdown Torque 236 LB-FT R.P.M. 3540 Pull-up Torque 62.9 LB-FT Hz 60 Phase 3 Locked-rotor Torque 80.2 LB-FT NEMA Design Code A KVA Code H Starting Current 326 A Service Factor (S.F.) 1.15 No-load Current 13.6 A NEMA Nom. Eff. 93 Power Factor 90 LinelineRes.@25ºC 0.148Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 81°C S.F. Amps Temp. Rise @ S.F. Load 96°C
Locked-rotor Power Factor 21.5
Rotor inertia 3.13 LB-FT2
Load Characteristics 460 V, 60 Hz, 40 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 61 80 87 90 90 90 90 Efficiency 87.7 92.3 93.4 93.5 93.2 92.6 93.3 Speed 3587 3573 3560 3547 3533 3515 3539 Line amperes 17.7 25.7 35 44.9 55.7 67.7 51.4
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Performance Graph at 460V, 60Hz, 40.0HP Typical performance - Not guaranteed values
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Page 10 of 12
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Page 11 of 12
Product Information Packet: VHECP4109T - 40HP,3540RPM,3PH,60HZ,324HP,1240M,TEFC,F
Marketing maintained PDF of MN416:
http://www.baldor.com/support/Literature/Load.ashx/MN416?ManNumber=MN416
Page 12 of 12
