Page 1
Product Information Packet
VEBM3710T
7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Page 2
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Part Detail
Revision: D Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 37WGR872 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 37F721 Layout: 37LYF721 Poles: 04 Created Date: 12-07-2015
Base: N Eff. Date: 03-05-2020 Leads: 9#14
Specs
Catalog Number: VEBM3710T
Enclosure: TEFC
Frame: 213TC
Frame Material: Steel
Output @ Frequency: 7.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
CSA EEV
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: No Mounting
Bearing Grease Type: Polyrex EM (-20F +300F)
Inverter Code: Inverter Ready
IP Rating: NONE
KVA Code: J
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3738M
Mounting Arrangement: F1
Power Factor: 80
Product Family: General Purpose
Product Type: BRAKE MOTOR
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
RoHS Status: ROHS COMPLIANT
Page 2 of 10
Page 3
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Current @ Voltage: 19.000 A @ 230.0 V
20.000 A @ 208.0 V
9.500 A @ 460.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Brake Mounting
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Page 4
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Nameplate NP1259L
CAT.NO. VEBM3710T
SPEC. 37F721R872G1
HP 7.5
VOLTS 230/460
AMP 19/9.5
RPM 1770
FRAME 213TC HZ 60 PH 3
SER.F. 1.15 CODE J DES A CL F
NEMA-NOM-EFF 91.7 PF 80
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 20
DE 6307 ODE 6306
ENCL TEFC SN
Page 4 of 10
Page 5
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Parts List
Part Number Description Quantity
SA311426 SA 37F721R872G1 1.000 EA
RA298851 RA 37F721R872G1 1.000 EA
HW3200A01 3/8-16X3/4 I-BLT WELDED F/S 1.000 EA
37CB3000SP CONDUIT BOX, CAST, W/1.089/1.100 CAST LE 1.000 EA
37GS1000SP GASKET, CONDUIT BOX STD., .06 THICK LEXI 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
37EP1301A97 STD FACE MTD ENDPLATE, BRAKE MTG 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A07 W2816-030 WVY WASHER (WB) 1.000 EA
37PE3300A01 PUEP ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
10XN2520A30 HEX HD CAP SCREW-STD THD-.25 X 20 THD PE 4.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA
XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA
84XN5013L12 .50-13 X .75 NYLOK TYPE HEX.SOC.HD.CAP S 4.000 EA
HW2501E10 KEY, 1/4 SQ X 1.000 1.000 EA
37FN5001A01SP EXFN ASSY, BALTRIC, 8.50 OD, .986 ID 1.000 EA
80XN2520A06 1/4-20 X 3/8 SET SCREW 1.000 EA
37FH5007 W/FINGER GUARDS 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
36CB4516 36 LIPPED CB LID - GALVANNEAL 1.000 EA
37GS1001SP GASKET, CONDUIT BOX LID, .06 THICK LEXID 1.000 EA
Page 5 of 10
Page 6
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Parts List (continued)
Part Number Description Quantity
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501F21 KEY, 5/16 SQ X 2.375 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.028 GA
HA3104A17 5/16-18X13.250 T-BLT/OHIO 4.000 EA
87BK4120EQF 35LB-FT 230/460V STD BK W/SIDE RELEASE L 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
LB1404 BRAKE CONNECTION LABEL 1.000 EA
NP1259L ALUM SUPER-E UL CSA-EEV CC NEMA PREMIUM 1.000 EA
37PA1039 PALLET PACK GROUP, BLANK PK1148 1.000 EA
PK3082 STYROFOAM CRADLE 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Page 7
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
AC Induction Motor Performance Data
Record # 54275 - Typical performance - not guaranteed values
Winding: 37WGR872-R001 Type: 3738M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 7.5 Full Load Torque 22.2 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 19/9.5 Breakdown Torque 70.9 LB-FT
R.P.M. 1770 Pull-up Torque 32.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 43 LB-FT
NEMA Design Code A KVA Code J Starting Current 70.9 A
Service Factor (S.F.) 1.15 No-load Current 4.31 A
NEMA Nom. Eff. 91.7 Power Factor 80 LinelineRes.@25ºC 1.41Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 63°C
S.F. Amps Temp. Rise @ S.F. Load 77°C
Locked-rotor Power Factor 37.2
Rotor inertia 0.934 LB-FT2
Load Characteristics 460 V, 60 Hz, 7.5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 42 64 75 80 83 84 82
Efficiency 87.1 91.6 92 92 91.1 89.8 91.5
Speed 1793 1786 1778 1770 1760 1750 1764
Line amperes 4.83 6.02 7.6 9.5 11.6 13.9 10.8
Page 7 of 10
Page 8
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Performance Graph at 460V, 60Hz, 7.5HP Typical performance - Not guaranteed values
Page 8 of 10
Page 9
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Page 9 of 10
Page 10
Product Information Packet: VEBM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Page 10 of 10
