Product Information Packet
R40-A000-0162
450HP,1200,480V,RL4046,DPFV,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Part Detail
Revision: - Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: L8279A CD Diagram: 422927-001 Mfg Plant:
Mech. Spec: Layout: 619657-341 Poles: 04 Created Date: 04-09-2019
Base: Eff. Date: 04-15-2019 Leads:
Specs
Enclosure: DPFV
Frame: RL4046Z
Frame Material: Exposed Laminations
Output @ Frequency: 450.000 HP @ 407 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 407 HZ
Voltage @ Frequency: 330.0 V @ 407 HZ
Auxillary Box: No Auxillary Box
Base Indicator: Rigid
Bearing Grease Type: Kluberquiet BQ 72-72
Current @ Voltage: 710.000 A @ 330.0 V
Duty Rating: CONT
Feedback Device: ENCODER
Frame Prefix: RL
Heater Indicator: No Heater
Insulation Class: H
IP Rating: NONE
Mounting Arrangement: F1
Product Family: General Industrial
Page 2 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Motor Standards: NEMA
Starting Method: Full Voltage
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Page 3 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Nameplate 000613006MY
DUTY HP RPM AMPS VOLTS HZ
CONT 450 1200 710 330 40.7
CONT 450 1765 503 480 59.3
CONT 450 4400 494 480 148
CAT.NO. SPEC. NO. R40-A000-0162
SER.NO FR RL4046Z INSUL H
PH. 3 MAX SAFE SPEED 4550 AMB. 40 MIN. AMB. -25
DESIGN NO. L8279A TYPE ENCL. DPG-FV
S.F. 1.00 D.E. BRG. 95BC02T35X
ENCL MOD O.D.E. BRG. 80BC03T35X
Page 4 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Nameplate 000692000CW
LUBRICATE WITH KLUBERQUIET BQ 72-72
Page 5 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Parts List
Part Number Description Quantity
WS361566 WS R40-A000-0162 1.000 EA
RA357855 RA R40-A000-0162 1.000 EA
000692000FP NP, WARNING LIFT INSTRUCTIONS 1.000 EA
000692000VD LABEL WARNING 1.000 EA
418057747A METAL FASTENER 8.000 EA
000613006MY NP-RPMAC INVERTER DUTY 1.000 EA
000692000CW "LUBRICATE MOTOR WITH" 1.000 EA
422927001 C/D LABEL 1.000 EA
807532004AA BRKT,RL400 1.000 EA
807532003AA BRKT,RL400 1.000 EA
HA4054 SHORT T-DRAIN FITTING, .125" N.P.T. 1.000 EA
HA4054 SHORT T-DRAIN FITTING, .125" N.P.T. 1.000 EA
004824015CP GREASE BQ72-72 0.900 LB
048977006B GRFTG - XP 1.000 EA
048977006B GRFTG - XP 1.000 EA
419912001B W WASHER 1.000 EA
418150003A GREASE FITTING CAP 2.000 EA
035000001A ALFTG 1/8" 1610-BL 1.000 EA
035000001A ALFTG 1/8" 1610-BL 1.000 EA
036100090KA HSHCS SHAFT BLOCK 4.000 EA
036100090KA HSHCS SHAFT BLOCK 4.000 EA
036140001F M30-3.5 X 45MM EYEBOLT 2.000 EA
034690002AL 1/4 SQ.HD.PIPE PLUG 1.000 EA
034690002AL 1/4 SQ.HD.PIPE PLUG 1.000 EA
Page 6 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Parts List (continued)
Part Number Description Quantity
036500013AB HX NUT,ODE BRKT 4.000 EA
036500013AB HX NUT,ODE BRKT 4.000 EA
708532016A AIR BAFFLE 1.000 EA
609830005ACY STUD,FRAME,FL4046 2.000 EA
609830005ABA TBOLT METRIC 2.000 EA
610490001BW 3//2.5HP,3450//2850RPM,3PH,60//50,145TCZ 1.000 EA
415000103E T/LUG #4AWG-1/0AWG W/HOLE FOR .375 BOLT 1.000 EA
036000012JB M8-1.25 X 12MM HXHDC 3.000 EA
422962052DY STUB SHAFT 1.000 EA
607980071B ENCODER 210 1.000 EA
611965001E BLOWER WHEEL 1.000 EA
403969029A COUPLING 1.000 EA
417733004G GASKT 2.000 EA
611917002P GASKT C400 1.000 EA
036000020JB HHCS M8-1.25X20L PLTD-250 6.000 EA
036000012GB HHCS M5X12MM LONG PLATED 4.000 EA
032018006CK HHCS 3/8-16X3/4L PLATED 4.000 EA
000613006NT NAME PLATE IEC 1.000 EA
417733036C GASKT,C/BOX BACKPLATE,REF 706310063B 1.000 EA
418057256C HHCS M10 25MM 440 IEC 1.000 EA
032018004DK HHCS,DRIP COVER 4.000 EA
706310389B ENTRY PLATE 706310389AB 1.000 EA
417733014C GASKT (REK P/N 187215) 1.000 EA
036000020JD HHCS M8X20MM LONG 304S.S 5.000 EA
Page 7 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
418018074A GROUND LABEL G100 METRIC 160 D.C. 1.000 EA
706313062B BLHSG FE MTG C400 1.000 EA
410978010F FLANGE, INLET BLOWER HSG 1.000 EA
410978015A GRILL, INLET FLANGE 1.000 EA
036000055KB M10-1.5 X 55MM HHCS 4.000 EA
036620010AB M10 EXT. TOOTH LK WASHER 1.000 EA
034017014AB LCKW 3/8 STD. PLATED 4.000 EA
418014014T ADAPT,C/BOX 1.000 EA
613439048A C/BOX,ADAPT,BACKPLATE 1.000 EA
417077-102 FILTER KIT 1.000 EA
422919137 HHCVR KIT,C400,DE,SOLID,X/T 1.000 EA
422919136 HHCVR KIT,C400,DE,LOUVERED,S/P 1.000 EA
422919136 HHCVR KIT,C400,DE,LOUVERED,S/P 1.000 EA
422919418 HHCVR KIT,RL400,ODE/DE,C/BOX MTG 1.000 EA
422919137 HHCVR KIT,C400,DE,SOLID,X/T 1.000 EA
036600008AD FLTWSHR,T BLK SPT 8.000 EA
706310063B CBOX (REK) 1.000 EA
706310058B CBCVR(REK P/N 187296) 1.000 EA
417733013B GASKT (REK P/N 189486) 1.000 EA
036000020HD HHCS M6X20MM LONG 304S.S 8.000 EA
036000025JB HHCS M8X25MM LONG PLATED 4.000 EA
706352034A ADAPTER 706352034X 1.000 EA
034180046KA KEY 7/8X7/8X5-3/4L 1.000 EA
000640000P TAG WINDING THERMOST 1.000 EA
004824007K SPECIAL PAINT 0.300 EA
418018116 WARNING PLATE 1.000 EA
Page 8 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
L8279A
ISSUE DATE 04-04-19
AC MOTOR
PERFORMANCE
DATA
DATE:
APPROVED BY:
CHECKED BY:
DRAWN BY:
C. ETIENNE
B. GRANT
J. MARTIN
04-04-19
INVERTER SETUP DATA POINT: 659 HP AT 1757 RPM, 710 AMPS, 480 VOLTS AT 59.3 HZ
CORRELATED DATA
REMARKS:
780
40.7
330
2167
494
1197
0/L
710
40.7
330
1970
450
1200
FULL LOAD
544
40.7
330
1470
337
1206
3/4
392
40.7
330
976
225
1211
1/2
265
40.7
330
488
113
1216
1/4
201
40.7
330
0
0
1221
NO LOAD
AMPS
FREQ-HZ
FUND
VOLTS
TORQUE
LB-FT
HP
RPM
LOAD PERFORMANCE AT BASE SPEED
710
.708
9.19
1970
0
0
MIN SPEED
494
148
480
538
450
4400
MAX SPEED
710
40.7
330
1970
450
1200
BASE SPEED
AMPS
FREQ-HZ
FUND
VOLTS
TORQUE
LB-FT
HP
RPM
RATED FULL LOAD DATA
.956
XM
85
WK² (Lb-Ft²)
40/H
AMB.°C / INSUL
3/40.7
PHASE/HZ
.0300
X2
.00323
R2
.035/.893
P.F. @NL / FL
1.0
S.F.
1200
BASE SPEED
.0287
X1
.00431
R1
205
IM (AMPS)
CONT
DUTY
450
HP
4550
MAX SAFE SPEED
710
AMPS
RL4046
FRAME
DPFV
ENCLOSURE
330/480
VOLTS
-
S/O
Printed on 04/04/2019 3:37 PM
USBAGRA
WYE CONN EQ CKT PER PHASE (AT
BASE RATING, 25°C)
Page 9 of 14
.956
XM
85
WK² (Lb-Ft²)
40/H
AMB.°C / INSUL
3/40.7
PHASE/HZ
.0300
X2
.00323
R2
.035/.893
P.F. @NL / FL
1.0
S.F.
1200
BASE SPEED
.0287
X1
.00431
R1
205
IM (AMPS)
CONT
DUTY
450
HP
4550
MAX SAFE SPEED
710
AMPS
RL4046
FRAME
DPFV
ENCLOSURE
330/480
VOLTS
-
S/O
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000
MOTOR SHAFT SPEED IN RPM
0 40 80 120 160 200 240 280 320 360 400 440 480 520 560
FUNDAMENTAL VOLTS AT RATED LOAD (1)
0 200 400 600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800
RATED (2) & 1 MIN (3) TORQUE IN LB-FT
0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400
RATED (4) & 1 MIN (5) CURRENT IN AMPS
1
2
3
4
5
RATED SPEED AT 40.7 HZ
CORRELATED DATA
VARIABLE SPEED AC MOTOR CURVES
L8279A
ISSUE DATE: 04-04-19
AC MOTOR
PERFORMANCE
DATA
C. ETIENNE
B. GRANT
04-04-19
J. MARTIN
DATE:
APPROVED BY:
CHECKED BY:
DRAWN BY:
INVERTER SETUP DATA POINT: 659 HP AT 1757 RPM, 710 AMPS, 480 VOLTS AT 59.3 HZ
DATA VALID FOR NAMEPLATE SPEED RANGE ONLY
Printed on 04/04/2019 3:37 PM
USBAGRA
WYE CONN EQ CKT PER PHASE
(AT BASE RATING, 25°C)
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Page 10 of 14
.956
XM
85
WK² (Lb-Ft²)
40/H
AMB.°C / INSUL
3/40.7
PHASE/HZ
.0300
X2
.00323
R2
.035/.893
P.F. @NL / FL
1.0
S.F.
1200
BASE SPEED
.0287
X1
.00431
R1
205
IM (AMPS)
CONT
DUTY
450
HP
4550
MAX SAFE SPEED
710
AMPS
RL4046
FRAME
DPFV
ENCLOSURE
330/480
VOLTS
-
S/O
0 400 800 1200 1600 2000 2400 2800 3200 3600 4000 4400 4800
SHAFT TORQUE IN LB-FT
0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400
LINE AMPS (1)
0 4 8 12 16 20 24 28 32 36 40 44 48 52 56
SLIP RPM (2)
1
2
RATED
CORRELATED DATA
LOAD PERFORMANCE (CONSTANT V/HZ RANGE)
L8279A
ISSUE DATE: 04-04-19
AC MOTOR
PERFORMANCE
DATA
C. ETIENNE
B. GRANT
04-04-19
J. MARTIN
DATE:
APPROVED BY:
CHECKED BY:
DRAWN BY:
INVERTER SETUP DATA POINT: 659 HP AT 1757 RPM, 710 AMPS, 480 VOLTS AT 59.3 HZ
DATA VALID FOR NAMEPLATE SPEED RANGE ONLY
Printed on 04/04/2019 3:37 PM
USBAGRA
WYE CONN EQ CKT PER PHASE
(AT BASE RATING, 25°C)
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Page 11 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
7.00
33.50
36.50
10.18
10.18
3.625
3.624
6.62
6.12
43.62
14.77
55.46
4.66
KEY .875 SQ.
X 5.75
ROTATABLE IN 90
INCREMENTS.
FILTER KIT SUPPLIED
ONLY WHEN SPECIFIED
33.63
16.00
19.81
4.12
1.12
8.00
10.00
NOTE 2
9.82
3.98
20.00
15.37
21.40
19.43
3.13
1.06
6 HOLES
NOTE 3
DIMENSIONS ARE IN INCHES
MOTOR WEIGHT: 2800 LBS. (
MAY VARY 15%
FOR NON-STANDARD RATINGS AND / OR
ACCESSORIES.)
NOTE S
O.D.E. C-FACE & TACHOMETER MOUNTING. 1/2-13 TAP
.75 1.
ON A
7.25 B.C. FACE RUNOUT AND ECCENTRICITY 0.004
MAX. T.I.R.
SHAFT HEIGHT WILL NOT BE EXCEEDED. SHIMS UP TO 0.06
2.
INCHES IN THICKNESS ARE USUALLY REQUIRED FOR COUPLED
OR GEARED MACHINES.
REMOVABLE COVER PLATE FOR CUSTOMER DRILLING.
3.
ENCLOSURE:
MOUNTING:
DRIP PROOF
H20 ENCODER
FORCE VENTILATED
COOLING:
ACCESSORIES:
RPM-AC VARIABLE SPEED ALTERNATING CURRENT MOTOR
RL4046Z
FOOT
TERMINAL BOX MAY BE LOCATED F1, F2 OR F3, IF SPECIFIED.
•
REFER TO 616779-55 FOR SPECIFIED TACHOMETER DIMENSIONS.
•
BLOWER ASSEMBLY CAN BE LOCATED F1, F2, OR F3, IF SPEC'D.
•
BLOWER ASSEMBLY AND TERMINAL BOX CANNOT BE LOCATED AT
•
THE SAME POSITION.
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
619657-341
B
DIM SHT,RL4046Z,FOOTED,RPMAC,FV,6219/6316 BRG,H20
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
619657-341
INITIAL RELEASE
RGGWT
-
08:11:57 04/09/2019
-
000001104281
00
619657-341
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 12 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Page 13 of 14
Product Information Packet: R40-A000-0162 - 450HP,1200,480V,RL4046,DPFV,F1
Marketing maintained PDF of MN406:
http://www.baldor.com/support/Literature/Load.ashx/MN406?ManNumber=MN406
Page 14 of 14
Loading...
