Product Information Packet
PCL1327M
5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Part Detail
Revision: AP Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGS322 CD Diagram: CD0002A02 Mfg Plant:
Mech. Spec: 35L263 Layout: 35LYL263 Poles: 02 Created Date: 06-22-2007
Base: RG Eff. Date: 06-01-2018 Leads: 2#12 A PH,3#18 B&J
Specs
Catalog Number: PCL1327M
Enclosure: ODTF
Frame: 56HCY
Frame Material: Steel
Output @ Frequency: 5.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 23.000 A @ 230.0 V
Inverter Code: Not Inverter
KVA Code: F
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 2 @ 12 AWG, A PH
Motor Lead Exit: Cap Box
Motor Lead Termination: Flying Leads
Motor Type: 3535LC
Mounting Arrangement: F1
Power Factor: 95
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
24.000 A @ 208.0 V
Shaft Rotation: Reversible
Page 2 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Design Code: Drip Cover: Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Drip Cover Mounting
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Do Not Use
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: Manual Thermal Overload
Winding Thermal 1 Location: KO
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Nameplate NP1257L
CAT.NO. PCL1327M
SPEC. 35L263S322
HP 5
VOLTS 230
AMP 23
RPM 3450
FRAME 56HCY HZ 60 PH 1
SER.F. 1.00 CODE F DES - CL F
NEMA-NOM-EFF 74.2 PF 95
RATING 40C AMB-CONT
CC USABLE AT 208V 24
DE 6205 ODE 6203
ENCL ODTF SN
Page 4 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Parts List
Part Number Description Quantity
SA026879 SA 35L263S322 1.000 EA
RA022928 RA 35L263S322 1.000 EA
OC3050F09SP CAPACITOR 50 MFD 370 VAC 1.000 EA
TPBRT34DA THERMAL 1PH 1.25 MAN 105C 1.000 EA
EC1161C06SP ELEC CAP, 161-193 MFD, 250V, 2.06D X 4. 2.000 EA
WD3006A01 RSS-2-103JT 2W 10K RES. METAL OXIDE 5% 1.000 EA
TP5059A02 GENERIC THERMAL KIT - 12 GAUGE 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
36CB3802B01 CPBX 36 W/1.09 DIA LEAD @ 6 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 3.000 EA
HA6003A28 CAPAC. CLAMP MODEL 36 MOTORS PLATED 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 1.000 EA
HA6015A08 THERMAL RETAINER (PLATED) 1.000 EA
51XB1214A10 12-14 X 5/8HX WS SL SR TYBX 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
35EP3209D00 MASTER ODE,203 BRG,.683SH,DRIP CVR 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA
35CB4802A02SP CAPACITOR COVER, STAMPED X 1.000 EA
51XB1016A05 10-16X5/16HX WA SL SR TYB (F/S) 2.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3402C00 MASTER DE,205 BRG,OPEN 1.000 EA
35AD2000 AIR BAFFLE - GALVANNEAL 1.000 EA
60XW0632A06 6-32 X 3/8 TORX HEAD SCREW TAPTITE II 4.000 EA
Page 5 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Parts List (continued)
Part Number Description Quantity
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
35FN3002A05SP EXFN, PLASTIC, 6.376 OD, .638 ID 1.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4006A01SP DRIP COVER,STAMPED,W/ PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
36CB4505 CONDUIT BOX LID, STAMPED 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1087 LABEL,MANUAL RESET (ROLL LABEL) 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.017 GA
WD1000A16 2-520128-2 AMP FLAG TERMINAL(4M/RL) 6.000 EA
SP5181A27 MODEL 35 LC TORQ STAT SWITCH LEAD ASSY 1.000 EA
HA3100A18 THRUBOLT 10-32 X 9.250 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0002 CONNECTION LABEL 1.000 EA
NP1257L ALUM UL CSA CC THERMAL REV MTG 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
Page 6 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
AC Induction Motor Performance Data
Record # 8979 - Typical performance - not guaranteed values
Winding: 35WGS322-R001 Type: 3535LC Enclosure: ODTF
Nameplate Data
230 V, 60 Hz:
Single Voltage Motor
Rated Output (HP) 5 Full Load Torque 7.7 LB-FT
Volts 230 Start Configuration direct on line
Full Load Amps 23 Breakdown Torque 18.8 LB-FT
R.P.M. 3450 Pull-up Torque 12.8 LB-FT
Hz 60 Phase 1 Locked-rotor Torque 14.7 LB-FT
NEMA Design Code - KVA Code F Starting Current 122 A
Service Factor (S.F.) 1 No-load Current 8.9 A
NEMA Nom. Eff. 74.2 Power Factor 95 LinelineRes.@25ºC
0.535ΩAPh
1.1ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 89°C
Load Characteristics 230 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150
Power Factor 78 89 94 95 96 95
Efficiency 56.5 69.5 74.5 74.2 72.5 66
Speed 3570 3535 3500 3450 3390 3275
Line amperes 10.4 13.7 17.8 23 28.6 36.2
Page 7 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Performance Graph at 230V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
6250
6245
4 500
4 497
6 49
2 06
13
1 88
521-528 = 13 23
529-535 = 14 10
536-546 = 15 48
7 19
3 06 NON-NEMA
3 00
5 00
6 50
1 00
NAMEPLATE
19 KEY
1 38 LONG
MANUAL
THERMAL
6 SLOTS
Ø 34
2 44 2 44
3 25
6 50
45° 45°
3 50
3 44
6 78
6 06
1 43
6 61
4 HOLES
38-16 TAP
ON Ø5 88 B C
LEAD HOLE
Ø1 09
FRONT END DETAIL
INSTALL EXTERNAL FAN WITH BLADES
TOWARDS FRONT ENDPLATE
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYL263
B
HORX 56HCY ODTF 35LC W/1.25 MTO
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYL263
LOAD INOPC CREATED SWD DRG INTO BUS - PACKAGE 15
USBUFRA
J
03 29 06 01/22/2019
-
000001096905
03
35LYL263
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
SH 1 OF 1
Page 9 of 10
Product Information Packet: PCL1327M - 5HP,3450RPM,1PH,60HZ,56HCY,3535LC,ODTF
Page 10 of 10
