Product Information Packet
M7073T
7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Part Detail
Revision: M Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGY869 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 36N002 Layout: 36LYN002 Poles: 02 Created Date:
Base: RG Eff. Date: 03-01-2010 Leads: 9#16
Specs
Catalog Number: M7073T
Enclosure: TEFC
Frame: 184T
Output @ Frequency: 7.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UL
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 16.600 A @ 230.0 V
8.300 A @ 460.0 V
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3640M
Mounting Arrangement: F1
Power Factor: 96
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Design Code: A
Shaft Slinger Indicator: No Slinger
Page 2 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Inverter Code: Not Inverter
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
XP Temp Code: T2C
Page 3 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Nameplate NP0015XP
NO. CC 010A
SER.
SPEC. 36N002Y869H1
CAT.NO. M7073T
HP 7.5 T. CODE T2C
VOLTS 230/460
AMPS 16.6/8.3
RPM 3450
HZ 60 PH 3 CL B
SER.F. 1.00 DES A CODE K
RATING 40C AMB-CONT
FRAME 184T NEMA-NOM-EFF 88.5 PF 96
USABLE AT 208V
Page 4 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Parts List
Part Number Description Quantity
SA052939 SA 36N002Y869H1 1.000 EA
RA047703 RA 36N002Y869H1 1.000 EA
35CB3001A02SP EXPL PROOF CONDUIT BOX, 3/4"PIPE TAP LEA 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
36EP3700A01 FR ENDPLATE, MACH 1.000 EA
HW4500A19 1/4-28X1/4 SLOTTED PLUG F/S 2.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36EP3701A01 PU ENDPLATE, MACH 1.000 EA
HW4500A19 1/4-28X1/4 SLOTTED PLUG F/S 2.000 EA
XY3816A12 3/8-16 FINISHED NUT 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
36FH4009A02 FAN COVER FOR VM7042T,PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
35CB3500A01SP CONDUIT BOX LID, MACH 1.000 EA
10XN2520A16 1/4-20 X 1 HEX HEAD CAP SCR, ZINC PLATED 4.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA
HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 6.000 EA
NP0018F ALUM UL XP CONDUIT BOX NAMEPLATE 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1025G29 WILKOFAST, 789.229, DARK CHARCOAL GRAY 0.022 GA
HA3105A09 THRUBOLT 3/8-16 X 12.000 4.000 EA
Page 5 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Parts List (continued)
Part Number Description Quantity
35FN3002A04SP EXFN, PLASTIC, 6.376 OD, .906 ID W/KEY 1.000 EA
LB1119N WARNING LABEL 1.000 EA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 1.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
NP0015XP UL/CSA, CLI GP-D,CC 1.000 EA
36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
AC Induction Motor Performance Data
Record # 11522 - Typical performance - not guaranteed values
Winding: 36WGY869-R001 Type: 3640M Enclosure: XPFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 7.5 Full Load Torque 11.5 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 16.6/8.3 Breakdown Torque 51.8 LB-FT
R.P.M. 3450 Pull-up Torque 35.5 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 40.2 LB-FT
NEMA Design Code A KVA Code K Starting Current 80.9 A
Service Factor (S.F.) 1 No-load Current 2.03 A
NEMA Nom. Eff. 88.5 Power Factor 96 LinelineRes.@25ºC 1.61Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 74°C
Locked-rotor Power Factor 45
Rotor inertia 0.178 LB-FT2
Load Characteristics 460 V, 60 Hz, 7.5 HP
% of Rated Load 25 50 75 100 125 150
Power Factor 75 92 95 97 97 97
Efficiency 85.9 89.6 89.6 88.4 86.7 84.5
Speed 3559 3524 3484 3441 3394 3338
Line amperes 2.88 4.39 6.28 8.31 10.6 13
Page 7 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Performance Graph at 460V, 60Hz, 7.5HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Page 9 of 10
Product Information Packet: M7073T - 7.5HP,3450RPM,3PH,60HZ,184T,X3640M,XPFC
Page 10 of 10
