Product Information Packet
M7065T
7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Part Detail
Revision: K Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 09WGX829 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 09E270 Layout: 09LYE270 Poles: 06 Created Date:
Base: RG Eff. Date: 03-15-2010 Leads: 9#12
Specs
Catalog Number: M7065T
Enclosure: TEFC
Frame: 256T
Frame Material: Iron
Output @ Frequency: 10.000 HP @ 60 HZ
7.500 HP @ 50 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
1000 RPM @ 50 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
190.0 V @ 50 HZ
460.0 V @ 60 HZ
380.0 V @ 50 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UL
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: H
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 12 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0946M
Mounting Arrangement: F1
Power Factor: 73
Product Family: Hazardous Location Motor
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Base Indicator: Rigid
Pulley Shaft Indicator: None
Page 2 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 30.400 A @ 208.0 V
28.800 A @ 230.0 V
26.800 A @ 190.0 V
14.400 A @ 460.0 V
13.400 A @ 380.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
XP Temp Code: T3C
Page 3 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Nameplate NP1426XP
NO. CC 010A
SER.
SPEC. 09E270X829H1
CAT.NO. M7065T
HP 10//7.5 T. CODE T3C
VOLTS 230/460//190/380
AMPS 28.8/14.4//26.8/13.4
RPM 1175//975
HZ 60//50 PH 3 CL B
SER.F. 1.00 DES B CODE H
RATING 40C AMB-CONT
FRAME 256T NEMA-NOM-EFF 89.5 PF 73
USABLE AT 208V 30.4
Page 4 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Parts List
Part Number Description Quantity
SA070036 SA 09E270X829H1 1.000 EA
RA063951 RA 09E270X829H1 1.000 EA
MJ5000A09 SEALANT, CHICO A COMPOUND 0.031 LB
09CB1000A01SP KOBX, MACH XP W/1.25 NPT 1.000 EA
10XN3118K16 5/16-18 X 1' GRADE #5, STL, ZINC PLATE 4.000 EA
HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 4.000 EA
WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA
10XN2520K06 1/4-20 X 3/8" HX HD SCREWGRADE 5, ZINC P 1.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 1.000 EA
09EP1700A01 FR ENDPLATE, MACH 1.000 EA
10XN3816K28 3/8-16 X 1.75 HEX HD CAP SCREW, GRADE 5 4.000 EA
HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA
HW5100A08 W3118-035 WVY WSHR (WB) 1.000 EA
10XN2520K36 1/4-20 X 2.25" HX HD SCRWGRADE 5, ZINC P 4.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA
09EP1707A01 PU ENDPLATE, MACH 1.000 EA
10XN3816K28 3/8-16 X 1.75 HEX HD CAP SCREW, GRADE 5 4.000 EA
HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA
09FH1004A01 FAN COVER, MACH 1.000 EA
10XN2520K16 1/4-20 X 1" HX HD SCRW GRADE 5, ZINC P 3.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 6.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 3.000 EA
09CB1500A01SP CONDUIT BOX LID, MACH 1.000 EA
10XN2520K16 1/4-20 X 1" HX HD SCRW GRADE 5, ZINC P 6.000 EA
Page 5 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Parts List (continued)
Part Number Description Quantity
HW2501G25 KEY, 3/8 SQ X 2.875 1.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
HW4500A20 1/8NPT SL PIPE PLUG 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.080 LB
HW4500A20 1/8NPT SL PIPE PLUG 2.000 EA
MG1025G05 WILKOFAST, 789.227, MED. GRAY CHAR. MET. 0.050 GA
85XU0407A04 #4-7 X 1/4 DRIVE PIN 6.000 EA
LB1073 ALUM XP CAUTION LABEL 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
09FN3001A01SP EXTERNAL FAN, PLASTIC 1.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
HW2500A25 WOODRUFF KEY USA #1008 #BLOW CARBON STEE 1.000 EA
LB1119N WARNING LABEL 1.000 EA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 4.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
NP1426XP SS UL CSA CLI GP-D CLII GP-F&G CC 1.000 EA
40PA1005 PACKAGING GROUP, 09 STD 1.000 EA
Page 6 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
AC Induction Motor Performance Data
Record # 20708 - Typical performance - not guaranteed values
Winding: 09WGX829-R003 Type: 0946M Enclosure: XPFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 10//7.5 Full Load Torque 44.6 LB-FT
Volts 230/460//190/380 Start Configuration direct on line
Full Load Amps 28.8/14.4//26.8/13.4 Breakdown Torque 139 LB-FT
R.P.M. 1175//975 Pull-up Torque 53.5 LB-FT
Hz 60//50 Phase 3 Locked-rotor Torque 76.4 LB-FT
NEMA Design Code B KVA Code H Starting Current 86.1 A
Service Factor (S.F.) 1 No-load Current 7.04 A
NEMA Nom. Eff. 89.5 Power Factor 73 LinelineRes.@25ºC 0.83Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 50°C
Locked-rotor Power Factor 26
Rotor inertia 3.7 LB-FT2
Load Characteristics 460 V, 60 Hz, 10 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 36 56 67 72 75 75 74
Efficiency 82.9 88.6 89.9 89.9 89.2 87.1 89.5
Speed 1195 1190 1184 1178 1171 1163 1174
Line amperes 7.82 9.42 11.61 14.38 17.56 21.2 16.29
Page 7 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Performance Graph at 460V, 60Hz, 10.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Page 9 of 10
Product Information Packet: M7065T - 7.5/10HP,975/1175RPM,3PH,50/60HZ,256T
Page 10 of 10
