Product Information Packet
M7032
1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Part Detail
Revision: G Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGN025 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35E352 Layout: 35LYE352 Poles: 06 Created Date: 06-02-2011
Base: RG Eff. Date: 03-08-2016 Leads: 9#18
Specs
Catalog Number: M7032
Enclosure: TEFC
Frame: 56
Frame Material: Steel
Output @ Frequency: 1.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: CLI GP D
XP Division: Division I
Agency Approvals: UL
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: RG
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Inverter Code: Not Inverter
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3520M
Mounting Arrangement: F1
Power Factor: 63
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Current @ Voltage: 1.900 A @ 460.0 V
Shaft Rotation: Reversible
Page 2 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
3.800 A @ 230.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
XP Temp Code: T2C
Page 3 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Nameplate NP0015XPSL
NO. CC
SPEC 35E352N025G1
CAT.NO. M7032 T. CODE T2C
VOLTS 230/460
AMPS 3.8/1.9
HZ 60 PH 3
SER.F. 1.00 DES B CODE K
RATING 40C AMB-CONT
FRAME 56
USABLE AT 208V PF 63
BLANK
Page 4 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Parts List
Part Number Description Quantity
SA224453 SA 35E352N025G1 1.000 EA
RA211564 RA 35E352N025G1 1.000 EA
35FN3002A05SP EXFN, PLASTIC, 6.376 OD, .638 ID 1.000 EA
35CB3001A01SP EXPL CONDUIT BOX, MACH, 1/2" PIPE TAP LE 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
35EP3700A01SP FR ENDPLATE, XPFC 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3701A01 PU ENDPLATE, XPFC - 205 BRG 1.000 EA
XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4005A01SP IEC FH NO GREASER W/PRIMED 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
35CB3500A01SP CONDUIT BOX LID, MACH 1.000 EA
51XN2520A16 SCREW, HEX WS SLT, ZN, 1/4-20 X 1.00 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 6.000 EA
NP0018F ALUM UL XP CONDUIT BOX NAMEPLATE 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1025G29 WILKOFAST, 789.229, DARK CHARCOAL GRAY 0.017 GA
HA3104A06 THRUBOLT 5/16-18 X 8.50 OHIO ROD 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
Page 5 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Parts List (continued)
Part Number Description Quantity
NP0015XPSL SS XP UL CSA CC CL-I GP-D 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
AC Induction Motor Performance Data
Record # 36535 - Typical performance - not guaranteed values
Winding: 35WGN025-R004 Type: 3520M Enclosure: XPFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 1 Full Load Torque 4.52 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 3.8/1.9 Breakdown Torque 14.1 LB-FT
R.P.M. 1155 Pull-up Torque 8.43 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 9.76 LB-FT
NEMA Design Code B KVA Code K Starting Current 10.3 A
Service Factor (S.F.) 1 No-load Current 1.41 A
NEMA Nom. Eff. 78.5 Power Factor 63 LinelineRes.@25ºC 19.8Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 67°C
S.F. Amps Temp. Rise @ S.F. Load 78°C
Locked-rotor Power Factor 49
Rotor inertia 0.119 LB-FT2
Load Characteristics 460 V, 60 Hz, 1 HP
% of Rated Load 25 50 75 100 125 150
Power Factor 27 42 54 63 70 74
Efficiency 61.5 73.7 77.7 78.6 77.9 75.9
Speed 1191 1180 1169 1157 1141 1123
Line amperes 1.42 1.52 1.67 1.88 2.15 2.49
Page 7 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Performance Graph at 460V, 60Hz, 1.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Page 9 of 10
Product Information Packet: M7032 - 1HP,1155RPM,3PH,60HZ,56,3520M,XPFC,F1,N
Page 10 of 10
