Product Information Packet
M7002A
.33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Part Detail
Revision: AF Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 34WG5723 CD Diagram: CD0007 Mfg Plant: Mech. Spec: 34-5323 Layout: 34LY5323 Poles: 04 Created Date: Base: RG Eff. Date: 01-03-2020 Leads: 12#18
Specs
Catalog Number: M7002A Enclosure: XPFC Frame: 56 Frame Material: Steel Output @ Frequency: .330 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 208.0 V @ 60 HZ
230.0 V @ 60 HZ
460.0 V @ 60 HZ XP Class and Group: CLI GP D; CLII GP F,G XP Division: Division I Agency Approvals: UR
UL
CSA Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid
Insulation Class: B Inverter Code: Not Inverter KVA Code: L Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 12 @ 18 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: X3413M Mounting Arrangement: F1 Power Factor: 57 Product Family: Hazardous Location Motor Pulley End Bearing Type: Ball Pulley Face Code: Standard Pulley Shaft Indicator: Standard Rodent Screen: None RoHS Status: ROHS COMPLIANT
Bearing Grease Type: Polyrex EM (-20F +300F)
Shaft Extension Location: Pulley End
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Blower: None Current @ Voltage: .800 A @ 460.0 V
1.600 A @ 230.0 V
1.800 A @ 208.0 V Design Code: B Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding Shaft Rotation: Reversible Shaft Slinger Indicator: No Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: Automatic Thermal Overload Winding Thermal 1 Location: EP Winding Thermal 2: None XP Temp Code: T3C
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Nameplate NP0016XPSL
NO. CC
SER. #
SPEC 34-5323-5723
CAT.NO. M7002A
H.P. .33 T. CODE T3C
VOLTS 208-230/460
AMPS 1.8-1.6/.8
R.P.M. 1725
HZ 60 PH 3 CLASS B
SER.F. 1.00 DES B CODE L
RATING 40C AMB-CONT
FRAME 56 NEMA NOM. EFF 67
USABLE AT 208V 1.8 PF 57
BLANK
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Parts List
Part Number Description Quantity SA008949 SA 34-5323-5723 1.000 EA RA005396 RA 34-5323-5723 1.000 EA TPMYJ72KL THERMAL 3PH 0.75 AUT 105C 1.000 EA MJ5000A09 EFI KIT #1578 (400 ML CARTRIDGE OF EFI 0.050 EA 35CB3001A01SP EXPL CONDUIT BOX, MACH, 1/2" PIPE TAP LE 1.000 EA 11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA 34EP3703A01 FR ENDPLATE, MACH XP 1.000 EA HW4002A02 1-11.5X2LG PIPE NIPPLE (F/S) 1.000 EA HA1025A13 WSHR,FELT,.38" THICK F-26 CLASS 1.000 EA HW3021E06 1/8 DIA X 5/8 ROLLPIN (F/S) 1.000 EA HW5100A03 WAVY WASHER (W1543-017) 1.000 EA 34EP3704A01 PU ENDPLATE, MACH XP 1.000 EA XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA 34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA 34FH4002A01SP IEC FH NO GREASER PRIMED 1.000 EA 51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA 35CB3500A01SP CONDUIT BOX LID, MACH 1.000 EA 51XN2520A16 SCREW, HEX WS SLT, ZN, 1/4-20 X 1.00 4.000 EA HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA NP0018W ALUM UL XP CONDUIT BOX NAMEPLATE 1.000 EA HA6001A01 THERMAL RETAINER (PLATED) 1.000 EA
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Parts List (continued)
Part Number Description Quantity NS2500A05 INSULATOR, AUTO THER PROT 1.000 EA 12XF0632A06 6-32X3/8 TY F HEX HD SLT 2.000 EA WD1000A16 2-520128-2 AMP FLAG TERMINAL(4M/RL) 12.000 EA MG1025G29 WILKOFAST, 789.229, DARK CHARCOAL GRAY 0.014 GA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 6.000 EA SP5037A01 TERMINAL PLATE ASS'Y MODEL 34 - 3 PHASE 1.000 EA WD1000A16 2-520128-2 AMP FLAG TERMINAL(4M/RL) 12.000 EA HA3104A05 THRUBOLT, 5/16-18 X 8.375 4.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA LB1118 LABEL,WARNING (ROLL LABEL) 1.000 EA LC0007 CONNECTION LABEL 1.000 EA NP0016XPSL SS XP UL CSA CC CL-I GP-D CL-II GP-F&G 1.000 EA 35PA1000 PKG GRP, PRINT PK1008A06 1.000 EA
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
AC Induction Motor Performance Data
Record # 6820 - Typical performance - not guaranteed values
Winding: 34WG5723-R001 Type: 3413M Enclosure: XPFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection Rated Output (HP) .33 Full Load Torque 1 LB-FT Volts 208-230/460 Start Configuration direct on line Full Load Amps 1.8-1.6/.8 Breakdown Torque 4.7 LB-FT R.P.M. 1725 Pull-up Torque 3.35 LB-FT Hz 60 Phase 3 Locked-rotor Torque 3.75 LB-FT NEMA Design Code B KVA Code L Starting Current 4.4 A Service Factor (S.F.) 1 No-load Current 0.7 A NEMA Nom. Eff. 67 Power Factor 57 LinelineRes.@25ºC 49.1Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
Load Characteristics 460 V, 60 Hz, 0.33 HP
% of Rated Load 25 50 75 100 125 150 Power Factor 28 40 50 57 64 69 Efficiency 44 59 65 68 68 67 Speed 1788 1770 1760 1745 1730 1710 Line amperes 0.7 0.73 0.77 0.8 0.85 1
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Performance Graph at 460V, 60Hz, 0.33HP Typical performance - Not guaranteed values
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
AC Induction Motor Performance Data
Record # 65177 - Typical performance - not guaranteed values
Winding: 34WG5723-R001 Type: 3413M Enclosure: XPFC
Nameplate Data
230 V, 60 Hz:
Low Voltage Connection Rated Output (HP) .33 Full Load Torque 1 LB-FT Volts 208-230/460 Start Configuration direct on line Full Load Amps 1.8-1.6/.8 Breakdown Torque 4.7 LB-FT R.P.M. 1725 Pull-up Torque 3.35 LB-FT Hz 60 Phase 3 Locked-rotor Torque 3.75 LB-FT NEMA Design Code B KVA Code L Starting Current 8.8 A Service Factor (S.F.) 1 No-load Current 1.4 A NEMA Nom. Eff. 67 Power Factor 57 LinelineRes.@25ºC 12.2Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
Locked-rotor Power Factor 69.4
Rotor inertia 0.031 LB-FT2
Load Characteristics 230 V, 60 Hz, 0.33 HP
% of Rated Load 25 50 75 100 125 150 Power Factor 26 37 47 57 67 68 Efficiency 44.1 59 65.1 67.9 67.9 66.9 Speed 1788 1770 1760 1745 1730 1710 Line amperes 1.4 1.46 1.54 1.6 1.7 2
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Performance Graph at 230V, 60Hz, 0.33HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Page 11 of 12
Product Information Packet: M7002A - .33HP,1725RPM,3PH,60HZ,56,X3413M,XPFC,F1
Page 12 of 12
