Product Information Packet
M3661T
3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Part Detail
Revision: N Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 06WGW385 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 06C101 Layout: 06LYC101 Poles: 04 Created Date:
Base: RG Eff. Date: 05-27-2011 Leads: 9#16
Specs
Catalog Number: M3661T
Enclosure: TEFC
Frame: 182T
Frame Material: Iron
Output @ Frequency: 3.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 208.0 V @ 60 HZ
230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: K
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0628M
Mounting Arrangement: F1
Power Factor: 78
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Current @ Voltage: 4.100 A @ 460.0 V
8.200 A @ 230.0 V
8.500 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Nameplate NP1256L
CAT.NO.
SPEC. 06C101W385H1
HP 3
VOLTS 208-230/460
AMP 8.5-8.2/4.1
RPM 1750
FRAME 182T HZ 60 PH 3
SER.F. 1.15 CODE K DES B CLASS F
NEMA-NOM-EFF 87.5 PF 78
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 8.5
DE 6206 ODE 6205
ENCL TEFC SN
Page 4 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Parts List
Part Number Description Quantity
SA019769 SA 06C101W385H1 1.000 EA
RA015822 RA 06C101W385H1 1.000 EA
S/P101-000-000 EPACT PROCEDURES-FS PLANT-POLYREX EM, NO 1.000 EA
HW3201A05 3/8-16 EYEBOLT 1.000 EA
06CB3000 BALDOR CONDUIT BOX CAST 1.000 EA
06GS1000 GASKET,CONDUIT BOX 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
36FE1101B47 FREP ASSEMBLY FOR ROUTING PURPOSES 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36PE1100A01 PUEP ASSEMBLY FOR ROUTING PURPOSES 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HA3101A34 THRUBOLT- 1/4-20 X 10.375 4.000 EA
XY2520A12 1/4-20 HEX NUT, DIRECTIONAL SERRATIONS 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
36FH4009A03SP IEC FH , W/ PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
06CB3500 BALDOR CONDUIT BOX LID 1.000 EA
06GS1001 BALDOR CONDUIT BOX GASKET 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
Page 5 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
36FN3000C01SP EXFN, PLASTIC, 5.25 OD, .912 ID 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.028 GA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
LB1417 LABEL CARTON 6X4 PERFORATED BLANK ROLLS 1.000 EA
Page 6 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Accessories
Part Number Description Multiplier
36-1749 C FACE KIT A8
Page 7 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
AC Induction Motor Performance Data
Record # 438 - Typical performance - not guaranteed values
Winding: 06WGW385-R005 Type: 0628M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 3 Full Load Torque 8.9 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 8.5-8.2/4.1 Breakdown Torque 33 LB-FT
R.P.M. 1750 Pull-up Torque 17.8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 22 LB-FT
NEMA Design Code B KVA Code K Starting Current 32.4 A
Service Factor (S.F.) 1.15 No-load Current 2.2 A
NEMA Nom. Eff. 87.5 Power Factor 78 LinelineRes.@25ºC 4.28Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 36°C
S.F. Amps Temp. Rise @ S.F. Load 42°C
Locked-rotor Power Factor 44
Rotor inertia 0.263 LB-FT2
Load Characteristics 460 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 38 59 71 78 80 81 79
Efficiency 78.4 86.1 87.8 88.1 87.4 86.1 87.7
Speed 1793 1783 1774 1764 1752 1738 1757
Line amperes 2.4 2.8 3.4 4.1 5 5.9 4.6
Page 8 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Performance Graph at 460V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 9 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
AC Induction Motor Performance Data
Record # 20664 - Typical performance - not guaranteed values
Winding: 06WGW385-R005 Type: 0628M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 3 Full Load Torque 8.9 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 8.5-8.2/4.1 Breakdown Torque 33 LB-FT
R.P.M. 1750 Pull-up Torque 17.8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 22 LB-FT
NEMA Design Code B KVA Code K Starting Current 32.4 A
Service Factor (S.F.) 1.15 No-load Current 2.2 A
NEMA Nom. Eff. 87.5 Power Factor 78 LinelineRes.@25ºC 4.28Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 36°C
S.F. Amps Temp. Rise @ S.F. Load 42°C
Locked-rotor Power Factor 44
Rotor inertia 0.263 LB-FT2
Load Characteristics 460 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 38 59 71 78 80 81 79
Efficiency 78.4 86.1 87.8 88.1 87.4 86.1 87.7
Speed 1793 1783 1774 1764 1752 1738 1757
Line amperes 2.4 2.8 3.4 4.1 5 5.9 4.6
Page 10 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
Performance Graph at 460V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 11 of 13
Product Information Packet: M3661T - 3HP,1750RPM,3PH,60HZ,182T,0628M,TEFC,F1
4.50
5.50
6.50
2.75
.50
1.1250
1.1245
2.75
2.81 6.98
614-643 = 15.23
8.60
8 HOLES
Ø.41
.25 KEY
1.75 LONG
GREASE FITTING
(EACH END)
AUX NAMEPLATE
(WHEN REQ'D)
3.75 3.75
8.62
5.94 4.31
4.50
4.44
7.12 4.73
11.86
9.23
2.04
LEAD HOLE
Ø1.09
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
06LYC101
B
STD HORZ 182-4T TEFC 306M
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
06LYC101
LOADING OF INOPC SWD MODEL & DRAWING FOR PKG 37
ENALEM0
H
09:25:17 09/19/2019
-
000001120280
03
06LYC101
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 12 of 13
