Product Information Packet
M3586T
2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Part Detail
Revision: V Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 05WGW501 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 05C001 Layout: 05LYC001 Poles: 02 Created Date: 07-17-2008
Base: RG Eff. Date: 10-02-2009 Leads: 9#18
Specs
Catalog Number: M3586T
Enclosure: TEFC
Frame: 145T
Frame Material: Iron
Output @ Frequency: 2.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
208.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0526M
Mounting Arrangement: F1
Power Factor: 88
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Current @ Voltage: 2.600 A @ 460.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
5.200 A @ 230.0 V
5.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Nameplate NP1256L
CAT.NO. M3586T
SPEC. 05C001W501H1
HP 2
VOLTS 208-230/460
AMP 5.6-5.2/2.6
RPM 3450
FRAME 145T HZ 60 PH 3
SER.F. 1.15 CODE L DES B CLASS F
NEMA-NOM-EFF 84 PF 88
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 5.6
DE 6205 ODE 6203
ENCL TEFC SN
Page 4 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Parts List
Part Number Description Quantity
SA019164 SA 05C001W501H1 1.000 EA
RA015217 RA 05C001W501H1 1.000 EA
S/P101-000-000 EPACT PROCEDURES-FS PLANT-POLYREX EM, NO 1.000 EA
06CB3000 BALDOR CONDUIT BOX CAST 1.000 EA
06GS1000 GASKET,CONDUIT BOX 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B02 BRASS CUP WASHER W/GROUND SYMBOL TAB, 1.000 EA
35EP1100A02 FR ENDPLATE, TEFC W/GREASER 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP1102A02 PU ENDPLATE, MACH 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HA3100A37 THRUBOLT 10-32 X 8.500 4.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4005A02 IEC FH W/GREASER - W/PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
06CB3500 BALDOR CONDUIT BOX LID 1.000 EA
06GS1001 BALDOR CONDUIT BOX GASKET 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
Page 5 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.022 GA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Accessories
Part Number Description Multiplier
35-1300 C FACE KIT A8
Page 7 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
AC Induction Motor Performance Data
Record # 178 - Typical performance - not guaranteed values
Winding: 05WGW501-R001 Type: 0526M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 3 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 5.6-5.2/2.6 Breakdown Torque 12.4 LB-FT
R.P.M. 3450 Pull-up Torque 7.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 11 LB-FT
NEMA Design Code B KVA Code L Starting Current 24.3 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 84 Power Factor 88 LinelineRes.@25ºC 7.86Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
S.F. Amps Temp. Rise @ S.F. Load 55°C
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 50 73 80 85 89 89 0
Efficiency 72.7 81.2 83.8 84.2 83.7 82.6 0
Speed 3563 3537 3507 3475 3440 3402 0
Line amperes 1.3 1.6 2.1 2.6 3.1 3.7 2.9
Page 8 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 9 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
AC Induction Motor Performance Data
Record # 20640 - Typical performance - not guaranteed values
Winding: 05WGW501-R002 Type: 0526M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 3 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 5.6-5.2/2.6 Breakdown Torque 12.4 LB-FT
R.P.M. 3450 Pull-up Torque 7.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 11 LB-FT
NEMA Design Code B KVA Code L Starting Current 24.3 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 84 Power Factor 88 LinelineRes.@25ºC 7.86Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
S.F. Amps Temp. Rise @ S.F. Load 55°C
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 50 73 80 85 89 89 0
Efficiency 72.7 81.2 83.8 84.2 83.7 82.6 0
Speed 3563 3537 3507 3475 3440 3402 0
Line amperes 1.3 1.6 2.1 2.6 3.1 3.7 2.9
Page 10 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 11 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
10.37
7.49
6.65
5.19
6.37
3.50
+-.00
.06
2.75
2.75
2.04
LEAD HOLE
1.09 DIA.
5.88
2.25
2.50
2.25
(513-535) =
12.54
.8750
.8745
5.00
4.00
4.00
7.19
GREASE FITTING
(EA. END)
8 HOLES
.38 DIA.
.19 KEY
1.38 LONG
AUX NAMEPLATE
(WHEN REQ'D)
GRD LUG
(THIS SIDE
ONLY)
A
B
C
D
5
6
7
8
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
05LYC001
B
HORZ 143-5T TEFC 305M
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
05LYC001
05SF1100A11 WAS A01, PAM PART CONSOLIDATION
ENBILT0
K
02:11:52 04/22/2019
000001106342
03
05LYC001
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT BALDOR'S PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
Page 12 of 13
Product Information Packet: M3586T - 2HP,3450RPM,3PH,60HZ,145T,0526M,TEFC,F1
Page 13 of 13
