Product Information Packet
M3546T-8
1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Part Detail
Revision: L Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGM635 CD Diagram: CD0006 Mfg Plant:
Mech. Spec: 35A001 Layout: 35LYA001 Poles: 04 Created Date: 05-10-2010
Base: RG Eff. Date: 03-08-2016 Leads: 3#18
Specs
Catalog Number: M3546T-8
Enclosure: TEFC
Frame: 143T
Frame Material: Steel
Output @ Frequency: 1.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 200.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: RG
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 3.600 A @ 200.0 V
Design Code: B
KVA Code: M
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 3 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3516M
Mounting Arrangement: F1
Power Factor: 73
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Drip Cover: No Drip Cover
Shaft Slinger Indicator: No Slinger
Page 2 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Not Inverter
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Nameplate NP1256L
CAT.NO. M3546T-8
SPEC. 35A001M635H1
HP 1
VOLTS 200
AMP 3.6
RPM 1750
FRAME 143T HZ 60 PH 3
SER.F. 1.15 CODE M DES B CLASS F
NEMA-NOM-EFF 82.5 PF 73
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6205 ODE 6203
ENCL TEFC SN
Page 4 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Parts List
Part Number Description Quantity
SA194642 SA 35A001M635H1 1.000 EA
RA182228 RA 35A001M635H1 1.000 EA
34FN3002B01 EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007 35 CB CASTING W/.88 DIA. LEAD HOLE 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3122A00 FREP TEFC ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3123F00 PUEP ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4005A84SP IEC FH W/GRSR, NO DIMPLES PRIMED 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
35CB4521GX CONDUIT BOX LID KIT **ORDER INDIV PARTS 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.017 GA
Page 5 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
HA3100A15 THRUBOLT 10-32 X 8.375 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0006 CONNECTION LABEL 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
35PA1066 PKG GRP, PRINT PK1008A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Accessories
Part Number Description Multiplier
35-8762 C FACE KIT A8
35EP1506A01SP D-FLANGE KIT A8
Page 7 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
AC Induction Motor Performance Data
Record # 36530 - Typical performance - not guaranteed values
Winding: 35WGM635-R002 Type: 3516M Enclosure: TEFC
Nameplate Data
200 V, 60 Hz:
Single Voltage Motor
Rated Output (HP) 1 Full Load Torque 2.99 LB-FT
Volts 200 Start Configuration direct on line
Full Load Amps 3.6 Breakdown Torque 17.5 LB-FT
R.P.M. 1750 Pull-up Torque 8.15 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 10.2 LB-FT
NEMA Design Code B KVA Code M Starting Current 29.9 A
Service Factor (S.F.) 1.15 No-load Current 2.35 A
NEMA Nom. Eff. 82.5 Power Factor 73 LinelineRes.@25ºC 3.16Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 25°C
S.F. Amps Temp. Rise @ S.F. Load 29°C
Locked-rotor Power Factor 63
Rotor inertia 0.0946 LB-FT2
Load Characteristics 200 V, 60 Hz, 1 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 32 50 64 72 79 83 76
Efficiency 66.2 77.9 81.4 82.7 83 82.2 82.9
Speed 1789 1777 1765 1749 1737 1718 1742
Line amperes 2.51 2.74 3.09 3.58 4.07 4.74 3.87
Page 8 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Performance Graph at 200V, 60Hz, 1.0HP Typical performance - Not guaranteed values
Page 9 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
510-520 = 12 29
521-528 = 13 29
529-535 = 14 17
536-546 = 15 54
2 50
2 25
3 75
5 94
4 00
5 00 50
2 25
8750
8745
7 19
NAMEPLATE
19 KEY
1 38 LONG
6 HOLES
38
GREASE FITTINGS
EACH END
5 75
6 61
6 81
3 50
3 44
2 75 2 75
4 63 3 25
6 50
LEAD HOLE
88
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYA001
B
STD HORZ 143-5T TEFC 35M
SH 1 of 1
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYA001
LOADING OF SWD DWG FOR 2D TO 3D CONVERSION - PKG13
ENSTEK0
Y
02 58 56 12/19/2018
-
000001094435
07
35LYA001
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 10 of 11
Product Information Packet: M3546T-8 - 1HP,1750RPM,3PH,60HZ,143T,3516M,TEFC,F1
Page 11 of 11
